QuickStartGuide
Congratulations on purchasing your new RCA Wi-Fi Internet Radio.
Please follow these instructions to set up and start using the radio.
Unpack the unit
1
You should fi nd the following items in the box:
Radio
Power adapter
Ethernet cable
Quick Start
Setup
Guide (this
Information
leafl et)
Card
Additional requirements
Broadband Internet service
Broadband (cable/DSL) modem, usually supplied by your Internet service provider
An 802.11 b or g (Wi-Fi) wireless home network or Ethernet router/switch/hub with available
LAN port
For Wi-Fi connections, you may also need:
Your wireless network's SSID
Your access password (for secure networks)
Setup your RCA Infi nite Radio accounts
2
To simplify setup and avoid manual confi guration on the radio please complete these steps:
1. Find the Setup Information Card that contains your radio's MAC address number (MAC:
00-00-00-00-00-00) and activation PIN # (PIN: 0000). (This number is also found in the Device
Info screen under the Settings menu in your radio.)
2. Using any Internet-connected computer, go to www.rcainfi niteradio.com/setup and follow
the online instructions.
You will need to input your radio's MAC address and PIN # to associate your radio with your
personal settings.
v1.0 (EN)
Insert AAA batteries in the base of the radio
3
RIR200
www.rcaaudiovideo.com
Optional: Connect the radio using an Ethernet cable
4
Use an Ethernet cable if you do not have a Wi-Fi access point.
AM loop antenna
LAN
Broadband modem or
Ethernet router/hub/switch
Plug in and turn on the radio
5
Electrical outlet
!
Set up the radio
6
1.
NOTE:
Follow the polarity markers in the battery
it will be in
compartment.
preset 1, then SLEEP/SNOOZE, then preset 6 on
top of the radio.
The batteries (not included) power the
clock and alarm whenever the radio loses
2. After exiting the DEMO
electricity.
mode, the radio displays
the Select Language
screen. Choose your
preferred language.
3. The Internet Setup screen
then displays:
Connecting via Ethernet
In the Internet Setup screen,
choose Wired. The radio
should then connect to the Internet.
Connecting via wireless
In the Internet Setup screen, choose Wireless.
To display a list of available networks, choose
Detect Networks, then choose your network.
To use a known network SSID, choose Enter SSID
and then input your SSID.
3. If the network is secure, enter your password in
the Network Security screen. The radio should then
connect to the Internet.
After connecting to the Internet
If you did not activate your Infi nite Radio accounts,
or if the radio cannot get your details from the
Infi nite Radio server, the radio may ask for your ZIP code. Input your code.
If your radio has successfully connected to the Internet you will hear a welcome message.
Learn more about your Internet Radio
Read the user manual (download from www.rcainfi niteradio.com) for more information on the
Deactivate the DEMO mode
player's features, safety and warranty information, and answers to Frequently Asked Questions (FAQ's).
after turning on
Need more help?
Press preset 1, then SLEEP/
SNOOZE, then preset 6.
Visit www.rcainfi niteradio.com to get the latest fi rmware updates and FAQ's.
When you turn on the radio for the fi rst time,
Use the navigation controls to make
"DEMO"
mode. To exit this mode, press
choices and input information:
− move highlight up
– move highlight down
– move selection/navigate left
– move selection/navigate right
SELECT - confi rm selected option or
character
When inputting characters, press
to choose among uppercase, lowercase,
numeric, or special characters.
To insert spaces or correct mistakes, press
to display the Commands list and then
press
or
to choose the desired
command.
About passphrase:
This radio supports secured access
points using the Wireless Equivalent
Privacy (WEP) keys or Wi-Fi Protected
Access (WPA and WPA2) standards.
WEP keys are either 10 or 26
Press
to show "DONE"
characters long (e.g. 6e78214a52).
and SELECT to confi rm.
Some access points for WEP
support passphrases (e.g. changing
entertainment again) which do not
conform to the industry standard and
Press
or
to highlight,
SELECT to confi rm.
are not supported in this radio.
If you are using a WEP secured access
point, enter the WEP key (HEX format)
instead of the passphrase.
Do not return this product to the store.
