Flow Table Values
View Instrument Values
The View Instrument Values button
requests the contents of the flow
calibration table stored in the AE51.
The flow calibration table shows the pump
drive values and internal flowmeter values
for the specified flow setpoints.
VERY IMPORTANT: As the flow setpoint
increases from 0 to 250 ml/min, the
pump drive and internal flowmeter
values should increase. If this is not the
case, please try again to calibrate the
AE51. If this issue persists, please contact
AethLabs for further assistance.
Save Instrument Values
The Save Instrument Values button will
prompt the user to select a location to save
the flow calibration table file.
The flow calibration table values will
be read from the AE51 and saved to a
selected location where it can be kept for
archival purposes and comparison, or can
be retrieved and uploaded to the AE51 at a
later time.
Write Values to Instrument
The Write Values to Instrument button
will prompt the user to select a previously
saved flow calibration table file for upload
to the AE51.
