LI-ION HIGH POWER CORDLESS IMPACT WRENCH
18 V 1/2" 1490 Nm
LI-ION 60 MIN. FAST CHARGER 18 V
Art. 32102
WARNING:
DO NOT attempt to operate the tool until you have read and understood all
instructions and safety rules contained in this manual. Failure to comply
may result in accidents involving fire, electric shock, or serious personal
injury. Save this owner's manual for future reference and review it
frequently for safe operation.
www.KRAFTWERK.eu
www.KRAFTWERK.eu
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for KRAFTWERK 32102
Summary of Contents for KRAFTWERK 32102
- Page 1 LI-ION HIGH POWER CORDLESS IMPACT WRENCH 18 V 1/2” 1490 Nm LI-ION 60 MIN. FAST CHARGER 18 V Art. 32102 WARNING: DO NOT attempt to operate the tool until you have read and understood all instructions and safety rules contained in this manual. Failure to comply may result in accidents involving fire, electric shock, or serious personal...
-
Page 2: Work Area
GENERAL SAFETY RULES WARNING! READ AND UNDERSTAND ALL INSTRUCTIONS. Read all instructions Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. The term "power tool" in all of the warnings listed below refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. -
Page 3: Specific Safety Rules And Symbols
15. Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. 16. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. -
Page 4: Functional Description
11. The label on your tool may include the following symbols. The symbols and their definitions are as follows: volts kilograms direct current ... /min revolutions or reciprocation per minute FUNCTIONAL DESCRIPTION SPECIFICATION Model Number 32102 Voltage 18 V Drive 1/2” Square Overall length 240 mm (9-7/16") Max. Torque 680 Nm (500 pi-lb) -
Page 5: Variable Speed Switch
1. 1/2” Anvil 2. Aluminum Gearbox Housing 3. Built-in LED light 4. Forward / Reverse Control Button 5. Variable Speed Switch 6. Anti-slip Soft Grip 7. Battery Indicator 8. Battery Pack Release Button 9. Battery Pack VARIABLE SPEED SWITCH The variable speed switch provides safety feature to the user for screw driving. To turn the tool on, squeeze the trigger switch. - Page 6 Fig. 1 BUILT-IN LED LIGHT A built-in LED light can illuminate the work area and improve vision when drilling/driving in areas with insufficient light. ELECTRIC BRAKE The variable speed switch is equipped with a circuit design electric of brake function. The tool will consistently operate to quickly stop rotating after the switch release.
-
Page 7: Operation
NOTE: Before disposing of damaged, check with your state Environmental Protection Agency to find out about special restrictions on the disposal of tool or return them to a KRAFTWERK certified service center for recycling. -
Page 8: Declaration Of Conformity
DECLARATION OF CONFORMITY 32102 Model: LI-ION HIGH POWER CORDLESS IMPACT WRENCH 18 V 1/2” 1490 Nm KRAFTWERK Sàrl, 25 rue due Stade, F-67870 Bischoffsheim Declares under sole responsibility that the product to which this declaration relates is in conformity with the following... -
Page 9: General Safety Rules
GENERAL SAFETY RULES WARNING! Read and Understand All Instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious personal injury. SAVE THESE SAFETY INSTRUCTIONS NOTE: This instruction manual contains important safety and operation procedures for the designated battery packs and charger. -
Page 10: Battery Care
18. Children should be supervised to ensure that they do not play with the appliance. 19. If the supply cord is damaged, it must be replaced by the manufacturer or it’s service agent or similar qualified person in order to avoid a hazard. BATTERY CARE WARNING! When batteries are not in tool or charger, keep them away from metal objects. -
Page 11: Specifications
FUNCTIONAL DESCRIPTION SYMBOLS Volts Alternating Current Amperes Direct Current Hertz Class II Construction SPECIFICATIONS Charger Output Model Number Type Input Power Output (DC) Input (AC) Amps 32101AL Li-ion 220-240 V 50 Hz 100 W 20.6 V Battery Pack Model Number Volts (DC) 32101AK 18 V... -
Page 12: Important Charging Notes
Charger Light Indicator LED Indicator Situation Yellow Blinking Light Battery pack is inserted Green Standing by (when no battery pack is inserted) Steady Light No Light Charging No Light Blinking Light Charging is complete No Light Steady Light Battery pack is too hot or too cold (charging will begin automatically when battery reaches correct charging Blinking Light Blinking Light... -
Page 13: Cleaning Instructions
4. Under certain conditions, with the charger plugged into the power source, the exposed charging contacts inside the charger can be shorted by foreign material. Foreign materials of a conductive nature such as, but not limited to, steel wool, aluminum foil, or any buildup of metallic particles should be kept away from charger cavities. Always unplug the charger from the power source when there is no battery pack in the battery compartment. - Page 14 32101AL Model: LI-ION 60 MIN. FAST CHARGER 18 V KRAFTWERK Sàrl, 25 rue due Stade, F-67870 Bischoffsheim Declares under sole responsibility that the product to which this declaration relates is in conformity with the following standard(s) or other normative document(s):...
- Page 16 KRAFTWERK Europe AG KRAFTWERK Sàrl. Mettlenbachstrasse 23 25, rue du Stade CH-8617 Mönchaltorf/Switzerland F – 67870 Bischoffsheim Tel. +41-44 949 40 50 Tel. +33-388 46 64 50 www.KRAFTWERK.eu...
