- Page 1 UniTire Pressure Gauge User Guide...
-
Page 2: Important Safety Instructions
Important safety instructions S a f e t y PLEASE READ THE SAFETY INSTRUCTIONS CAREFULLY • Read the instructions. • Keep these instructions. • Follow all instructions. • Do not use the UniTire in water. • Be careful not to drop it on the ground. • Do not leave it under heavy objects. -
Page 3: Table Of Contents
Contents C o n t e n t s IMPORTANT SAFETY INSTRUCTIONS STEALTH MODE SETUP CONTENTS STEALTH TARGET SETUP COPYRIGHT AND ACKNOWLEDGEMENTS IV LANGUAGE SETUP SALES AND SERVICE IN DENMARK CONTRAST SETUP INTERNATIONAL DEALERS OPERATION SETUP DESIGN AND PRODUCTION roubleshootInG COPYRIGHT ABOUT THIS USER GUIDE BATTERY CHANGE... -
Page 4: Copyright And Acknowledgements
Designed and manufactured in Denmark by Unipro ApS. The UniTire pressure gauge was designed by Palle Schultz, Denmark: www.Palleschultz.dk Unipro reserves the right to make changes and improvements to any of the products described in this document without prior notice. Part numbers: 17-01-001 UniTire (black) -
Page 5: Introduction
I n t r o d u c t i o n Introduction This User Guide contains all relevant information about your new UniTire digital tire pressure gauge. Get ready to use the UniTire in 2 minutes with the Quick Guide, and read all about the advanced features and functions in the Reference Guide. -
Page 6: Overview
Overview I n t r o d u c t i o n Please notice that the functions of the two This manual assumes that UniTire is set for buttons are depending on whether the UniTire right hand operation. is set for right or left hand operation. DURABLE CASING HIGH RESOLUTION DISPLAY UniTire is made of... -
Page 7: Specifications
Specifications I n t r o d u c t i o n Pressure range 0 - 5 bar (72.5 psi) Resolution < 0.0002 bar (0.0029 psi) Typical accuracy < ± 0.01 bar (0.145 psi)* Proof pressure 10 bar (145 psi) Wasted air 0.8 cm (0.05 inch... -
Page 8: Examples
Examples I n t r o d u c t i o n... -
Page 9: Quick Guide
Q u i c k G u i d e Quick Guide Read the Quick Guide and learn how to use the basic functions of the UniTire: Turn UniTire on and off, view current tire pressure, save the pres- sure values for all tires and recall them later. You will be ready to go in 2 minutes... -
Page 10: Save The Measured Pressure Values
Quick guide Q u i c k G u i d e SAVE THE MEASURED SETUP MODE PRESSURE VALUES To change settings, press and hold the left and the right button ( ) at the same If you start in “sequence mode”, the screen will time to go to setup mode - either when turning inform you about which tire you are supposed UniTire on or during normal operating. -
Page 11: Reference Guide
R e f e r e n c e G u i d e Reference Guide In the reference guide you can find detailed information about all features and functions of the UniTire. We recommend that you read this guide at least once, if you want to get the full value of your UniTire. -
Page 12: Ways To Press Buttons
R e f e r e n c e Operating UniTire G u i d e 3 WAYS TO PRESS BUTTONS serial number. To use UniTire, you need to know how to press TURN UNITIRE OFF the two buttons in 3 different ways: Press the right button ( ) and hold it down 1. -
Page 13: Pressure Mode
R e f e r e n c e Operating UniTire G u i d e PRESSURE MODE The history list will be saved even when UniTire is turned off. Here is your regular tire pressure gauge. It simply shows the current tire pressure and If you want to clear the history, press and hold continuously updates it when you let out air down the left button (... -
Page 14: Sequence Mode
R e f e r e n c e Operating UniTire G u i d e SEQUENCE MODE Analog gauge mode In sequence mode you measure and save the pressure on all tires in a predefined order (2 or 4 tires depending on which sport you have chosen in setup). -
Page 15: Stealth Mode
R e f e r e n c e Operating UniTire G u i d e STEALTH MODE Digital gauge view in Stealth mode Stealth mode is an alternative way of using the Sequence mode. The purpose with Stealth mode is to make it impossible for your competitors to see your tire pressure when you are measuring. - Page 16 R e f e r e n c e Operating UniTire G u i d e Digital gauge view in Stealth mode If you want to start over with the current sequence, press and hold the left button ( down until the circle shows the first tire again. When you save the measured values in Stealth mode, the actual values are stored in the memory, so you will be able...
-
Page 17: Recall Mode
R e f e r e n c e Operation UniTire G u i d e RECALL MODE brackets at the bottom of the screen. The recall mode is where you view the tire Navigating the pages is easy pressure values you have saved in Sequence To go to the next page just press the right mode / Stealth mode. -
Page 18: Enter Setup Mode
R e f e r e n c e Setup mode G u i d e ENTER SETUP MODE by pressing the right button ( ). You enter Setup mode by pressing both the When the sport is changed, the overwrite left and right buttons at the same time of values need to be confirmed on the next screen. -
Page 19: Max Range Setup
R e f e r e n c e Setup mode G u i d e choice between Digital and Analog view. Scroll between choices by pressing the left button ( ). Select and move to next setup screen by pressing the right button ( ). -
Page 20: Language Setup
R e f e r e n c e Setup mode G u i d e STEALTH OFFSET SETUP ton ( ). Select and move on to the next setup screen by pressing the right button ( ). When stealth mode is enabled, it is possible to offset the value shown in Pressure mode. -
Page 21: Operation Setup
R e f e r e n c e Setup mode G u i d e AUTO OFF TIME SETUP UniTire will automatically be turned off after some time when it is not used. Scroll through the choices by pressing the left button ( ). - Page 22 This page was intentionally left blank!
-
Page 23: Troubleshooting
If you have any problems, either with the setup or the daily use, please check the following pages for suggested solutions. If you don’t find the answer to the problem here, please contact your Unipro dealer for further assistance. Weak and hard to read text Pressure value is showing --- The contrast is set too low. -
Page 24: Battery Change
Maintenance M a i n t e n a n c e Battery change Cleaning To replace batteries To clean the case, display, and buttons When the batteries reaches 2.2 V the low The exterior surfaces of UniTire products are battery symbol will be shown at the bottom of made from solid anodized aluminum, plastic the display:... -
Page 25: Service
Service and guarantee s h o o t i n g Service Guarantee The Unipro UniTire pressure gauge has been The product is guaranteed against defects in carefully designed to give you many years of material and workmanship for two years from untroubled use. -
Page 26: Index
Index I n d e x Accuracy, typical 7 Gauge mode setup 18 Acknowledgements IV Guarantee 25 Alkaline batteries 24 Analog mode setup 18 Analog stealth mode 16 Handle 11 Help mode 10, 12 History list, clearing 13 Batteries 11 Battery change 24 Battery lifetime 7 Introduction 5... - Page 27 I n d e x Pressure range 7 Stealth mode setup 19 Pressure units 7 Stealth offset 16 Proof pressure 7 Stealth offset setup 20 Stealth target setup 19 Storing tires in sequence mode 14 Quick guide 9 Table of content III Troubleshooting 23 Rain II Turning UniTire off 10, 12...
- Page 28 Unipro ApS • Viborg Hovedvej 24 • DK-7100 Vejle • Denmark Tel: +45 7585 1182 • Fax: +45 7585 1782 www.uniprolaptimer.com...
- Page 29 UniTire Pressure Gauge IR Temperature addendum...
- Page 30 INTERNATIONAL DEALERS You can find our International dealers on the web site: www.uniprolaptimer.com DESIGN AND PRODUCTION Designed and manufactured in Denmark by Unipro ApS. Unipro reserves the right to make changes and improvements to any of the products described...
- Page 31 I n t r o d u c t i o n Introduction This User Guide addendum contains all relevant information about your new UniTire digital tire pressure gauge equipped with an infrared temperature sensor. Get ready to use the UniTire in 2 minutes with the Quick Guide in the main UniTire User Guide.
- Page 32 Specifications and overview I n t r o d u c t i o n Temperature range -40 .. +115 °C (-40 .. +239 °F) Resolution 0.02 °C (0.036 °F) Accuracy < ± 0.5 °C (0.9 °F) in the range 0 .. 60 °C (32 .. 140 °F) Accuracy <...
- Page 33 R e f e r e n c e G u i d e Reference Guide In the reference guide you can find detailed information about the additional features and functions of the IR temperature sensor in the UniTire. We recommend that you read this guide at least once, if you want to get the full value of your UniTire - IR.
- Page 34 R e f e r e n c e Operating UniTire G u i d e ton ( ) from either sequence mode or stealth mode. When you enter recall mode, it will always start with the tire pressures. To change to tire temperature press a little longer on the left button ( The first screen in the sequence is the...
- Page 35 R e f e r e n c e Operating UniTire G u i d e SETUP MODE press on the right button ( ) will bring you to the first page again. You enter Setup mode by pressing both the left and right buttons at the same time If you want to clear the memory, press and hold the left button (...
- Page 36 Unipro ApS • Viborg Hovedvej 24 • DK-7100 Vejle • Denmark Tel: +45 7585 1182 • Fax: +45 7585 1782 www.uniprolaptimer.com...
