AXIS T93F Housing Series

How to repaint the product

How to repaint the product
Disassembly

Disassemble the housing

1. Loosen the four screws to separate the top cover from the bottom chassis.
2. Remove the four screws from the bottom chassis.
1
Screw (4x)
2 Bottom chassis
3
Top cover

Disassemble the wall mount bracket

1. Remove the torx screw at the bottom of the arm.
2. Separate the socket and the suqare nut.
3. Remove the four screws from the ball joint.
