OPERATION,
PERFORMANCE,
SPECIFICATIONS and
PARTS MANUAL
12 Volt
Battery
Backup Sump
Pump System
• Thank you for purchasing this pump. Take the time to
read the instructions carefully before using this
product. We strongly recommend that you keep this
instruction manual in a safe place for future reference.
• Please refer to our website and the Products Center for
additional installation and operation instructions.
• Refer to the website for replacement parts information.
LIMITED WARRANTY
This pump is warranted to be free from defects in material and workmanship
and to perform within applicable specifications for a period of one year from
date of installation or 18 months from date of manufacture, which ever comes
first. Obligation under this warranty is limited to repairing or replacing any part
thereof, which shall within one year be returned to us with transportation charges
prepaid, and proved to be defective.
The above limited warranty takes the place of all other warranties, express or
implied and correction of such defects by replacement or repair shall constitute
a fulfillment of all obligations under the terms of the warranty, which specifically
EXCLUDES any incidental damages caused by or associated with this product or
its use. The warranty does not cover any unit which has been damaged either in
transit or by misuse, accident or negligence. No warranty or representative not
contained herein shall be binding.
PERFORMANCE
Model
HP
APBS
1/4
GPM at Total Feet of Head
0'
10'
45
29
MARKS AND MEANING:
"Danger" indicates an
DANGER
imminent hazardous situation
which, if not avoided, WILL result in death or
serious injury.
"Warning" indicates an
WARNING
imminent hazardous situation
which, if not avoided, MAY result in death or
serious injury.
"Caution" indicates a
CAUTION
potentially hazardous situation
which, if not avoided, MAY result in minor or
moderate injury.
15'
20
20'
21'
5
0
