ST50 PLUS RADAR Operation and Installation Handbook
The compact design of the display unit is made possible by the use of
custom LSI (Large Scale Integrated circuit) components. An LSI type
of "chip" contains, in one package, the equivalent of up to 30
integrated circuits. Thus compact size, power efficiency, and full
radar navigation features at an economical price are all "standard" in
the ST50 radar system.

1.2.2 Radome Antenna Unit Main Features

The antenna and transceiver are contained within the 18 inch radome
assembly, the radome is made of AES plastic and has a single-flange
mounting. The radome protects the electronic assemblies from the
environment, yet is transparent to the radar's RF energy, thereby
allowing full performance. A small, flexible interunit cable connects the
Radome Unit to the Display Unit.
The radome cover is secured to the pan base by four clamping bolts
and is provided with a heavyduty rubber
unit from the weather and salt spray.
Inside, the radome features a printed-circuitcard array. This technically
innovative antenna provides a narrow 6' beamwidth for excellent short
range resolution and high gain in a very compact antenna package.
The internal X-band transmitter operates at
a sensitive micro-integrated circuit (mic) front end receiver.
The construction of the antenna unit is modularized, so repairs, should
they be required, can be made quickly and cost-effectively.
to completely seal the
gasket
2 kW peak power, with
a
Section 1. Introduction

1.3 About This Manual

This manual contains important information to help you get the best
operation and performance from your new ST50 and its associated
optional equipment. Although the unit is actually pretty simple to
master, please take the necessary time to read through each section.
Section 2 containsveryimportantinformationon the proper installation
of your new ST50 Radar. Although the typical installation might seem
straight forward and simple, we highly recommend that this section be
read thoroughly and the guidelines for installation be closely followed
to obtain trouble-free and efficient operation of your new units.
Section 3 contains a brief discussion of the general principles of radar,
along with the operating instructions for the ST50 Radar which will
guide you through the unit? operating controls and display layouts. To
more easily recognize how to enable the various operations, the
names of the keys that must be pressed to complete the described
operation
displays to obtain the desired entry, are included next to each function.
The best way to learn about your ST50 is to dive right in. You can't
damage the unit by randomly pressing keys. So don't be afraid to
experiment. In Menu mode, if at any time the results appear confusing,
just push themhey twice in order to return to the Main menu, and
start again.
In the event that your ST50 should ever experience an operational
failure, it is recommended that all repair services be provided by an
authorized service dealer or by the Factory Service Center.
are enclosed i n boxes, such as
