Block Diagram; 1001Rb Series Specifications; Amplifier Protection - Gallien-Krueger 1001RB Owner's Manual

Output Power:
540W Amplifier
50W Amplifier
Input Section:
Maximum Input Level
With -10dB pad
Input Impedance
Send output impedance
Return input impedance
Tuner Output Impedance
Direct Output Impedance
Equalizer:
Bass +10db @ 60Hz
Lo-Mid +6db/-10db @ 250Hz
Hi-Mid +6db/-10db @ 1kHz
Treble +14db @ 7kHz
Voicing Filters:
String Bass Button +11db@20Hz
Contour +2db@50Hz /
-10db@500Hz /
+3db@7kHz
Presence +9db@10kHz
Crossover Triple pole constant
voltage crossover at 5kHz
Noise -90db referenced to 540W,
"A" weighted
540W @ 8 Ohms
540W @ 4 Ohms
50W @ 8 Ohms
50W @ 4 Ohms
0.6V Rms
1.6V Rms
1M Ohm
220 Ohm
50k Ohm
10k Ohm
500 Ohms
Cooling Continuously Variable-
Speed Fan

Amplifier Protection:

Full short circuit, thermal,& RF protection.
Stable into reactive and mismatched loads.
Five second muted warm-up.
Dimensions (HxWxD):
3 1/2" x 17" x 8 ¼"
(2 Rack Spaces)
Weight:
18lbs
Power Requirements:
U.S.A./Canada 120V/60Hz
880W (full power)
165W (average power)
Europe 230V/50Hz
880W (full power)
165W (average power)
Japan 100V/50Hz
880W (full power)
165W (average power)
