Chronis RTS/RTS L has several functions, which can fulfil individual requirements at the touch of a button:
Weekly program
set different times for automatic opening and closing of your roller shutters every day of the week.
Holiday security
set random times to give the impression of an occupied house.
Cosmic
roller shutters are activated automatically according to the times the sun rises and sets.
OFF setting
The automatic control can be turned off at the touch of a button.
A detailed description of each mode of operation is given under point 4 "Programming".
All functions of the Chronis RTS also apply for the Chronis RTS L for light sensor. Please read the instructions included
with the light sensor.
1
Characteristics:
80 mm
We reserve the right to make changes due to technical improvements.
inteo
CHRONIS RTS / RTS "L"
Chronis RTS/RTS L is the programmable radio time switch in the new inteo-control range
from SOMFY, which controls your electrically operated roller shutters or external blinds.
Operating commands are transmitted by radio signal, significantly reducing the cost of instal-
lation.
The radio signal has a range of up to 300 metres in free field, or 20 metres through two con-
crete walls in buildings.
80 mm
27 mm
Supply:
Degree of protection:
Operating temperature:
Environmental conditions:
Chronis RTS/RTS L
guide
2 x 1,5 V DC (Type : AAA LR03)
IP 30
+5°C to +40°C
dry living areas.
Hereby, SOMFY, declares that this equipment is in
compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC.
A Declaration of Conformity is available at the web ad-
dress www.somfy.com Heading CE
1
Advertisement
Table of Contents
Related Manuals for SOMFY Chronis RTS
Summary of Contents for SOMFY Chronis RTS
- Page 1 The automatic control can be turned off at the touch of a button. A detailed description of each mode of operation is given under point 4 “Programming”. All functions of the Chronis RTS also apply for the Chronis RTS L for light sensor. Please read the instructions included with the light sensor.
- Page 2 In order not to affect quality of reception, a minimum distance of 30 cm between a Chronis RTS/RTS L unit and a radio receiver should be maintained. Chronis RTS/RTS L should not be installed in the immediate vicinity of metal surfaces. Powerful local transmitter equipment (e.g. cordless headphones) with a transmission frequency identical to the Chronis RTS/RTS L can affect its function.
- Page 3 DOWN button. Setting operation mode Setting operation mode The Chronis RTS/RTS L has 5 different operating modes: 4.2.1 Weekly programme ( Roller shutters are opened or closed automatically at individually set times.
- Page 4 Cosmic 2 always opens the roller shutters at the times set individually in the weekly programme and closes them at the ti- mes set for Cosmic 1. The cut-off and differential times set in Cosmic 1 are observed. No changes can be made in Cosmic 2. We reserve the right to make changes due to technical improvements. Chronis RTS/RTS L...
- Page 5 – Slide the Chronis RTS/RTS L unit upwards out of the mounting plate. – Change the dead batteries, which are located on the back of the Chronis RTS/RTS L unit. Observe the polarity specified on the unit! –...
- Page 6 Automatic commands are not carried out Increase transmission repeat rate. (see chapter 7 “Diagnosis menu: rts”). Change the position of the Chronis RTS/RTS L unit. Automatic commands are repeated unnecessarily Set transmission repeat rate to zero. Blinds are not always operated by automatic commands Change to blinds mode (see chapter 7 “Diagnosis menu: rts”).
