WHEEL AND TIRE
GENERAL INFORMATION . . . . . . . .
SPECIAL TOOLS. . . . . . . . . . . . . . . .
DIAGNOSIS . . . . . . . . . . . . . . . . . . . . . . . .
WHEEL BALANCE ACCURACY . . . . . . . .
STRATEGY. . . . . . . . . . . . . . . . . . . . . . . . .
TPMS DIAGNOSTIC FUNCTION . . . . . . . .
PROCEDURES. . . . . . . . . . . . . . . . . . . . . .
TPMS SYMPTOM CHART . . . . . . . . . . . . .
GROUP 31
CONTENTS
31-2
CHECK AT ECU TERMINAL. . . . . . . . . . . .
31-5
ON-VEHICLE SERVICE . . . . . . . . . . .
31-6
TIRE WEAR CHECK . . . . . . . . . . . . . . . . . .
31-8
WHEEL RUNOUT CHECK . . . . . . . . . . . . .
31-8
TEMPORARY REPAIR AGENT . . . . . . . . .
31-9
TEMPORARY REPAIR AGENT . . . . . . . . .
31-12
REPLACE . . . . . . . . . . . . . . . . . . . . . . . . . .
31-12
TPMS SPECIAL FUNCTION . . . . . . . . . . . .
31-12
WHEEL AND TIRE . . . . . . . . . . . . . . .
31-13
31-15
31-18
SYSTEM (TPMS) . . . . . . . . . . . . . . . .
31-19
TPMS RECEIVER . . . . . . . . . . . . . . . . . . . .
31-34
TPMS TRANSMITTER . . . . . . . . . . . . . . . .
31-34
31-1
31-38
31-40
31-41
31-41
31-41
31-41
31-41
31-41
31-42
31-42
31-45
31-45
31-46
31-46
31-47

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mirage 2015 and is the answer not in the manual?

Questions and answers

Related Manuals for Mitsubishi Mirage 2015

Summary of Contents for Mitsubishi Mirage 2015

  • Page 1: Table Of Contents

    31-1 GROUP 31 WHEEL AND TIRE CONTENTS GENERAL INFORMATION ..31-2 DATA LIST REFERENCE TABLE ..31-38 CHECK AT ECU TERMINAL... . 31-40 SERVICE SPECIFICATIONS.

  • Page 2: General Information

    WHEEL AND TIRE 31-2 GENERAL INFORMATION GENERAL INFORMATION M1311000101870 The wheels and tires of the following specifications have been established. SPECIFICATIONS ROAD WHEEL AND TIRE ITEM SPECIFICATIONS Wheel Type Steel type or Aluminum type* 14  4.5 J Size Amount of wheel offset mm 46 PCD mm Tire Size...

  • Page 3: Tire Pressure Monitoring System

    WHEEL AND TIRE 31-3 GENERAL INFORMATION SPECIFICATIONS Items Specifications Flat tire Repair agent volume mL (fl. oz.) 320 (10.8) temporary Repairable area Nail puncture hole of 4 mm (0.2 in) or less at tire repair agent tread Shelf life Shelf life is indicated on the repair agent bottle. Disposal method Waste oil disposal Relief valve operating pressure kPa...
  • Page 4 WHEEL AND TIRE 31-4 GENERAL INFORMATION OPERATION  The signals from the TPMS transmitter are  For 3 seconds after the ignition switch (engine received by the ETACS-ECU <vehicles without starting switch) is turned to the "ON" position, Keyless Operation System> or KOS&OSS-ECU ETACS-ECU <vehicles without Keyless Opera- <vehicles with Keyless Operation System>.

  • Page 5: Service Specifications

    WHEEL AND TIRE 31-5 SERVICE SPECIFICATIONS WARNING DISPLAY PATTERN OF TPMS WARNING LIGHT AND TPMS INFORMATION DISPLAY Circumstance Warning light Information display For 3 seconds after Illuminates No indication the engine switch is turned to the "ON" position (warning light circuit self-check) TPMS problems Symbol is...

  • Page 6: Special Tools

    WHEEL AND TIRE 31-6 SPECIAL TOOLS SPECIAL TOOLS M1311000600173 Tool Tool number Supersession Application and name  DTC, service data and actuator test a. MB992744 check. b. MB992745 c. MB992746 d. MB992747 e. MB992748 MB992744 a. Vehicle communicatio interface-Lite (V.C.I.-Lite) b.
  • Page 7 WHEEL AND TIRE 31-7 SPECIAL TOOLS Tool Tool number Supersession Application and name MB991958 MB991824-KIT CAUTION a. MB991824 NOTE: G: M.U.T.-III main harness A b. MB991827 MB991826 M.U.T.-III (MB991910) should be used. Trigger Harness is c. MB991910 M.U.T.-III main harness B and C not necessary when should not be used for this vehicle.

  • Page 8: Wheel And Tire Diagnosis

    WHEEL AND TIRE 31-8 WHEEL AND TIRE DIAGNOSIS WHEEL AND TIRE DIAGNOSIS DIAGNOSIS M1311000701021 Symptom Probable cause Remedy Reference page Rapid wear Under-inflation Adjust the tire For tire inflation at shoulders or lack of pressure. pressure, refer to rotation the label on the driver's side center pillar.

  • Page 9: Wheel Balance Accuracy

    WHEEL AND TIRE 31-9 WHEEL AND TIRE DIAGNOSIS Symptom Probable cause Remedy Reference page Scalloped Lack of rotation of tires or worn Rotate the tires, and Refer to GROUP wear or out-of-alignment suspension check the front 33, On-vehicle Service  Front suspension alignment.
  • Page 10 WHEEL AND TIRE 31-10 WHEEL AND TIRE DIAGNOSIS <Confirming Proper Balance> 2. Turn the wheel again 180 degree angle against the balancer's hub. If the wheel becomes 1. After balancing the wheel, loosen the wing nut out-of-balance each time it is turned against the and turn the wheel 180 degree angle against the balancer's hub, the wheel balancer may require balancer's hub.
  • Page 11 WHEEL AND TIRE 31-11 WHEEL AND TIRE DIAGNOSIS WHEEL BALANCER CALIBRATION CHECKING FLOW CHART Balance wheel. ZERO CALIBRATION CHECK Rotate wheel 1/2 turn. Imbalance = 5 g (0.18 oz) or less Imbalance = more than 5 g (0.18 oz) Rebalance wheel. Rotate wheel 1/4 turn.

  • Page 12: Tire Pressure Monitoring System (Tpms) Diagnosis

     The TPMS transmitter’s battery is discharged. AFTER REPLACING TPMS  Wheels other than Mitsubishi genuine wheels are COMPONENTS being used.  Whenever the TPMS transmitter and/or  Wheels that are not fitted with TPMS transmitters ETACS-ECU <vehicles without Keyless Opera-...

  • Page 13: Tpms Diagnostic Function

    WHEEL AND TIRE 31-13 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS TPMS DIAGNOSTIC FUNCTION M1311002600102 HOW TO CONNECT THE SCAN TOOL (M.U.T.-III) CAUTION To prevent damage to scan tool MB991958, always turn the ignition switch (engine starting switch) to the LOCK (OFF) position before connecting or disconnecting scan tool MB991958.
  • Page 14 3. Select "Interactive Diagnosis" from the start-up screen. 4. Select "System select." 5. Choose "TPMS" from the "CHASSIS" tab. MB992745, MB991910 6. Select "MITSUBISHI." 7. Select "Diagnostic Trouble Code." 8. If a DTC is set, it is shown. MB992744, MB991824 9.

  • Page 15: Tpms Warning Light Check

    WHEEL AND TIRE 31-15 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS TPMS WARNING LIGHT CHECK M1311002500086 1. Check that the TPMS warning light illuminates for TPMS warning light approximately three seconds when the ignition switch (engine starting switch) is turned to the "ON" position. TPMS information display 2.
  • Page 16 WHEEL AND TIRE 31-16 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS Item Display State Warning operation Warning content cancellation TPMS TPMS condition information warning light (when any of display the condition met) TPMS ID not The TPMS Symbol is ID is registered Flashes failure stored...
  • Page 17 WHEEL AND TIRE 31-17 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS Item Display State Warning operation Warning content cancellation TPMS TPMS condition information warning light (when any of display the condition met) TPMS ID not The TPMS Symbol is ID is registered Flashes failure stored...

  • Page 18: Diagnostic Trouble Code Chart

    WHEEL AND TIRE 31-18 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS DIAGNOSTIC TROUBLE CODE CHART M1311002700132 CAUTION  During diagnosis, a DTC associated with another system may be set when the ignition switch (engine starting switch) is turned to the "ON" position with connector(s) disconnected. When diagnosis is finished, check all systems for DTC(s).

  • Page 19: Tpms Diagnostic Trouble Code Procedures

    WHEEL AND TIRE 31-19 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS TPMS DIAGNOSTIC TROUBLE CODE PROCEDURES DTC C1564: Vehicle speed data invalid JUDGMENT CRITERIA CAUTION When the ETACS-ECU <Vehicles without Keyless If there is any problem in the CAN bus lines, an Operation System>...
  • Page 20 WHEEL AND TIRE 31-20 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS STEP 4. Check whether the DTC is set again. Recheck if the DTC is set. (1) Turn the ignition switch (engine starting switch) from the "LOCK" (OFF) to "ON" position. (2) Check if the DTC is set.
  • Page 21 WHEEL AND TIRE 31-21 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS STEP 2. Check whether the DTC is set again. Recheck if the DTC is set. (1) Turn the ignition switch (engine starting switch) from the "LOCK" (OFF) to "ON" position. (2) Check if the DTC is set.
  • Page 22 WHEEL AND TIRE 31-22 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS DTC C1901: Vehicle speed signal Operation System> or KOS&OSS-ECU <Vehicles CAUTION with Keyless Operation System> receives the infor- If there is any problem in the CAN bus lines, an mation that the wheel is not currently rotated from incorrect DTC may be set.
  • Page 23 WHEEL AND TIRE 31-23 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS STEP 4. Check the TPMS transmitter acceleration. Check the acceleration value sent by each TPMS transmitter by performing the transmitter check using the scan tool (Refer to P.31-38), when the vehicle is stationary. ...
  • Page 24 WHEEL AND TIRE 31-24 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS DIAGNOSIS STEP 1. Using scan tool MB991958, diagnose the CAN bus lines. Use scan tool to diagnose the CAN bus lines. Q: Is the check result normal? YES : Go to Step 2. NO : Repair the CAN bus lines (Refer to GROUP 54C ...
  • Page 25 WHEEL AND TIRE 31-25 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS STEP 5. Check the tire IDs for the TPMS transmitters. Could any of the tire IDs for the TPMS transmitters be con- firmed? Q: Is the check result normal? YES : Register the applicable IDs to the ECU as the active tire ID set (Refer to P.31-42).Then go to Step 8.
  • Page 26 WHEEL AND TIRE 31-26 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS DTC C1910: Transmitter BATT voltage, Tire1 DTC C1920: Transmitter BATT voltage, Tire2 DTC C1930: Transmitter BATT voltage, Tire3 DTC C1940: Transmitter BATT voltage, Tire4 DTC C1911: Tire ID reception fail, Tire1 DTC C1921: Tire ID reception fail, Tire2...
  • Page 27 WHEEL AND TIRE 31-27 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS STEP 3. Check the tire IDs for the TPMS transmitters. Could all the tire IDs for the TPMS transmitters be confirmed? Q: Is the check result normal? YES : Adjust the tire inflation pressure to the recommended value.
  • Page 28 WHEEL AND TIRE 31-28 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS DTC C1912: Tire air pressure low, Tire1 DTC C1922: Tire air pressure low, Tire2 DTC C1932: Tire air pressure low, Tire3 DTC C1942: Tire air pressure low, Tire4 CAUTION TROUBLESHOOTING HINTS If there is any problem in the CAN bus lines, an The most likely causes for this DTC to be set is: incorrect DTC may be set.
  • Page 29 WHEEL AND TIRE 31-29 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS STEP 4. Check whether the DTC is set again. Recheck if the DTC is set. (1) Turn the ignition switch (engine starting switch) to the" LOCK" (OFF) to "ON" position, and adjust the pressure to the recommended tire pressure.
  • Page 30 WHEEL AND TIRE 31-30 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS STEP 7. Check whether the DTC is set again. Recheck if the DTC is set. (1) Turn the ignition switch (engine starting switch) from the "LOCK" (OFF) to "ON" position. (2) Check if the DTC is set.
  • Page 31 WHEEL AND TIRE 31-31 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS Operation System> or KOS&OSS-ECU <Vehi- transmitter judges that the tire temperature sen- cles with Keyless Operation System>, and sor is failed, the failure signal is sent to ETACS-ECU <Vehicles without Keyless Opera- ETACS-ECU <Vehicles without Keyless Opera- tion System>...
  • Page 32 WHEEL AND TIRE 31-32 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS STEP 3. Check for TPMS transmitter. Identify the TPMS transmitter which the DTC is set by TPMS transmitter check (Refer to P.31-44). NOTE: The TPMS transmitter which cannot be checked may be faulty or the ID code may not be registered, thus do not replace it, but register the ID code.
  • Page 33 WHEEL AND TIRE 31-33 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS DIAGNOSIS STEP 1. Using scan tool MB991958, diagnose the CAN bus lines. Use scan tool to diagnose the CAN bus lines. Q: Is the check result normal? YES : Go to Step 2. NO : Repair the CAN bus lines (Refer to GROUP 54C ...

  • Page 34: Tpms Symptom Chart

    WHEEL AND TIRE 31-34 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS TPMS SYMPTOM CHART M1311003100111 CAUTION During diagnosis, a DTC associated with another system may be set when the ignition switch (engine starting switch) is turned to the ON position with connector(s) disconnected. when diagnosis is fin- ished, check all systems for DTC.
  • Page 35 WHEEL AND TIRE 31-35 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS STEP 2. After the tire inflation pressure is adjusted and the TPMS transmitter sends inflation pressure information on it, check the TPMS warning light. (1) Wait until the tires cool down, and adjust road tire inflation pressures to the value specified on the tire pressure label.
  • Page 36 WHEEL AND TIRE 31-36 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS STEP 6. Check the TPMS warning light. Q: Does the TPMS warning light turn OFF after three seconds of initial lamp check? YES : Go to Step 7. NO : Replace the combination meter assembly (Refer to GROUP 54A - Combination Meter Assembly).
  • Page 37 WHEEL AND TIRE 31-37 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS STEP 2. Using scan tool MB991958, read the diagnostic trouble code. (1) Turn the ignition switch (engine starting switch) to the ON position. (2) Check whether any TPMS DTC is set. Q: Is any TPMS DTC set? YES : Carry out the relevant TPMS troubleshooting (Refer to P.31-18).

  • Page 38: Data List Reference Table

    WHEEL AND TIRE 31-38 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS DATA LIST REFERENCE TABLE M1311003300171  NOTE: KOS&OSS-ECU input data refer to GROUP 42B Data List Reference Table P.42B-75. <Vehicles with Keyless Operation System> The following items can be read by the scan tool from the ETACS-ECU <Vehicles without Keyless Operation System>...
  • Page 39 WHEEL AND TIRE 31-39 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS Item No. Scan tool MB991958 Check condition Normal condition display   Air pressure, Tire1(not adjusted) Air pressure, Tire2(not adjusted) Air pressure, Tire3(not adjusted) Air pressure, Tire4(not adjusted)   Temperature, Tire1 Temperature, Tire2 Temperature, Tire3...

  • Page 40: Check At Ecu Terminal

    WHEEL AND TIRE 31-40 TIRE PRESSURE MONITORING SYSTEM (TPMS) DIAGNOSIS Item No. Scan tool MB991958 Check condition Normal condition display   Latest R PRS, Tire1 (not adjusted) Latest R PRS, Tire2 (not adjusted) Latest R PRS, Tire3 (not adjusted) Latest R PRS, Tire4 (not adjusted) ...

  • Page 41: On-Vehicle Service

    WHEEL AND TIRE 31-41 ON-VEHICLE SERVICE ON-VEHICLE SERVICE TIRE INFLATION PRESSURE CHECK M1311000900776 NOTE: For the tire pressure, refer to the tire pressure label attached to the lower section of driver's side door striker. TIRE WEAR CHECK M1311001000839 Measure the tire tread depth. Limit value: Minimum 1.6 mm (0.06 inch) If the remaining tread depth is less than the minimum limit value, replace the tire.

  • Page 42: Tpms Transmitter Check Or Replace

    WHEEL AND TIRE 31-42 ON-VEHICLE SERVICE TPMS TRANSMITTER CHECK OR REPLACE M1311008500028 After removing the tire from the wheel, remove the TPMS trans- mitter(Refer to P.31-47). Then check it as follows and replace if necessary: 1. Wipe off the agent remained on the TPMS transmitter housing.
  • Page 43 WHEEL AND TIRE 31-43 ON-VEHICLE SERVICE "TIRE PRESSURE SENSOR ID REGISTRATION" METHOD 1. Select "4tires ID Reg. (Change tire PRS.)" and start the tire pressure sensor ID registration. CAUTION Register all tire pressure sensor IDs within twenty min- utes. 2. "4 SNSR ID Registration Do you want to start? Note Finish ID Registration within 20 minutes."...
  • Page 44 WHEEL AND TIRE 31-44 ON-VEHICLE SERVICE 4. "4 SNSR ID Registration Completed." is displayed. Then, select "OK." NOTE: The TPMS indicator illuminates for tire pressure alarm. 5. After one minute or more has passed, correct the tire pressure for all wheels with ignition switch (engine starting switch) "ON".

  • Page 45: Wheel And Tire

    WHEEL AND TIRE 31-45 WHEEL AND TIRE NOTE:  It may take approximately one minute that the data of tire pressure change is displayed on the scan tool MB991958 screen.  If the data of tire pressure change is not displayed on the scan tool MB991958 screen, the most possible cause is that the radio wave sent from the TPMS transmitter cannot be received.

  • Page 46: Tire Pressure Monitoring System (Tpms)

    WHEEL AND TIRE 31-46 TIRE PRESSURE MONITORING SYSTEM (TPMS) TIRE PRESSURE MONITORING SYSTEM (TPMS) TPMS RECEIVER REMOVAL AND INSTALLATION M1311003700180 Refer to GROUP 54A  ETACS-ECU P.54A-260 <vehicles without Keyless Operation System> or GROUP 42B  KOS&OSS-ECU P.42B-132 <vehi- cles with Keyless Operation System>. TSB Revision...

  • Page 47: Tpms Transmitter

    WHEEL AND TIRE 31-47 TIRE PRESSURE MONITORING SYSTEM (TPMS) TPMS TRANSMITTER REMOVAL AND INSTALLATION M1311003800154 WARNING Certain components of this vehicles, such as TPMS transmitters, may contain perchlorate materials. Special handling may apply. For additional information, see www.dtsc.ca.gov/haz- ardouswaste/perchlorate. CAUTION ...
  • Page 48 WHEEL AND TIRE 31-48 TIRE PRESSURE MONITORING SYSTEM (TPMS) ACC02899 Installation steps Removal steps >> << Valve <In case of installing the valve> Valve core >> << TPMS transmitter  Tire bead  >> << Tire bead mounting << >> TPMS transmitter Valve core Valve <In case of removing the...
  • Page 49 WHEEL AND TIRE 31-49 TIRE PRESSURE MONITORING SYSTEM (TPMS) REMOVAL SERVICE POINT <<A>> TPMS TRANSMITTER REMOVAL CAUTION Be careful not to damage the TPMS transmitter. 1. Fix the tire on a tire changing machine. Then apply a bead breaking shoe to the shown range to disengage the tire bead from the wheel rim.
  • Page 50 WHEEL AND TIRE 31-50 TIRE PRESSURE MONITORING SYSTEM (TPMS) CAUTION Do not allow any impact or shock to the TPMS transmitter with a tire lever or tire bead. 6. Use a tire lever to disengage the lower bead. TPMS transmitter ACC02924 AC 7.
  • Page 51 WHEEL AND TIRE 31-51 TIRE PRESSURE MONITORING SYSTEM (TPMS) INSTALLATION SERVICE POINTS >>A<< VALVE INSTALLATION 1. The projection shown by the arrow should face towards the outside of the wheel. >>B<< TPMS TRANSMITTER INSTALLATION CAUTION Valve Do not attempt to install the TPMS transmitter without depressing the portion indicated by the arrow.
  • Page 52 WHEEL AND TIRE 31-52 TIRE PRESSURE MONITORING SYSTEM (TPMS) 3. Engage the shoe and make sure that 20 cm (7.9 inch) is maintained between the cross point and the valve. The arrow shows the direction of rotation of the wheel. AC609534 4.
