Santana CD 2018 Ed. User Guide Read this manual. It contains important information regarding your safety, the correct use of the bike and how to avoid expensive repair fees in the future. Support is available Mon to Fri from 10am to 5pm on 01702 Sales: 01702 435566 —...
Page 3
The Santana 2018 Edition from Woosh The Santana 2018 Edition is a strong sturdy bike which can be used for commuting to and from work. Battery capacities of 13Ah, 15Ah and 17Ah are available for this model. If you rely heavily on the throttle and do not put much effort in yourself, then the battery will run down more quickly and the distance able to be travelled on a single charge will be reduced accordingly.
Page 4
See the maintenance manual for how to adjust and maintain the various components of the bike. Please note that failure to carry out these checks properly could result in serious injury for which Woosh Bikes Ltd will not be held liable.
Page 5
Unpacking: Two people are required to unpack the bike. Stand the carton upright. Remove the shipping straps, cut the tape seals and then remove any/all loose packaging materials. Keep the carton/bike in the upright position, and then lift the bike out of the carton and then engage the kick-stand.
Page 6
Handlebars: If you haven’t already, slide the handlebar stem into the frame at the desired height, remove the weather- proof cap and then tighten the Allen bolt indicated below to secure the stem in position, whilst ensuring that the handlebars line up correctly with the front wheel. Once the stem has been secured, you can now fine tune the positioning of the handlebars.
Page 7
The Santana 2018 now comes 95% built, and so the below is for reference only. You are now ready to fit the front wheel to the forks. First you will need to fit the skewer to the wheel, the skewer is the spindle which slides through the wheel. The skewer consists of the spindle (with clamp on one side), two springs and a tension nut.
Page 8
Seat-post/saddle: The seat-post simply slides into position and then the clamp is used to secure it. To adjust the height of the saddle, simply open the clamp and position the seat-post at the desired height and then close the clamp to lock it into position. It may be necessary to tighten the thumb screw a little to ensure that when the clamp is closed the seat-post is properly secured.
Page 9
Once unlocked remove the key and then slide the battery from the bike using the grip at the rear underside of the battery. Remember to separate your keys, Woosh Bikes is not able to supply replacements if you lose them both.
Page 10
Obviously the bike shop will you charge for this service. Woosh Bikes will not reimburse you for these costs.
Page 11
Riding the bike To begin using the bike, press (and hold) the top ‘Mode’ button to switch on the display. The bike is now effectively on, and if you ride it in this state, the motor will provide assistance when pedalling and you will also be able to use the thumb-throttle if you wish—see notes on this below.
Page 12
Riding the bike cont. Your bike features 9 speed gears, the shifter is located on the right side of the handlebars. To change gear, simply press (with your thumb) the lever shown in the photo below—this will select the lower gears. To select the higher gears, press the lever that rests under your trigger finger.
Page 13
Operating the lights: The rear light is already fitted, to operate the rear light, simply press the button on the top of the light as shown below. To change the batteries in this unit, simply reach under the bottom edge and then pull the lower edge of the light rearwards towards you.
Page 14
Control Module—Advanced The display has many advanced features and modes, these include a back-lit display (for night riding), in- dicator options for max speed, average speed and current speed and a battery –level indicator. It also fea- tures a walking/start-assist mode which is used when you want to wheel/push the bike or if you need help starting off, this is basically a very low speed mode which can be activated by pressing and holding the minus (-) button.
Woosh Sant Ana Woosh Sant Ana CD/CDL Manufacturer, address Made in China for Woosh Bikes Ltd 42-46 Queens Road, Southend-on-Sea, Essex, SS1 1NL, UK The product (system) identified above is in conformity with the listed European Directive(s). The following table identifies the applied standards and the conformity assessment procedure.
