Nuvo-2000+ Series User's Manual

Neousys Technology Inc.

Nuvo-2000+ Series

Intel® Atom™ D525 Fanless Controller

User's Manual

Rev. A1

Published September 18

, 2013

Page 1 of 78

Table of Contents

Need help?

Do you have a question about the Nuvo-2021+ and is the answer not in the manual?

Questions and answers

Summary of Contents for Neousys Technology Nuvo-2021+

Page 1 Nuvo-2000+ Series User’s Manual Neousys Technology Inc. Nuvo-2000+ Series Intel® Atom™ D525 Fanless Controller User’s Manual Rev. A1 Published September 18 , 2013 Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 1 of 78...
Page 2: Table Of Contents
2.3.6 DDR3 SODIMM Socket................24 2.3.7 SATA#1 Connector..................24 2.3.8 SATA#2 Connector..................25 2.3.9 PCI Slot....................25 2.3.10 x4 PCI Express Slot ................26 2.3.11 Optional Isolated DIO ................27 2.4 Mechanical Dimension..................29 2.4.1 Front View....................29 Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 2 of 78...
Page 3 4.2 Operating System Support..................67 4.3 Driver Installation ....................68 4.3.1 Install all drivers using “One-Click” driver installation ......68 4.3.2 Install drivers manually................69 Appendix A Using H/W Watchdog Timer ................70 Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 3 of 78...
Page 4 Appendix B Using Isolated DIO ..................74 B.1 Wiring for Isolated DIO ..................74 B.2 Install WDT and DIO Library.................75 B.3 Function Reference ....................77 InitDIO......................77 DIReadLine ......................77 DIReadPort ......................77 DOWriteLine ....................78 DOWritePort.....................78 Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 4 of 78...
Page 5: Declaimer
Company/product names mentioned herein are used for identification purposes only and are trademarks and/or registered trademarks of their respective companies. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 5 of 78...
Page 6: Chapter 1 Introduction
DIN-Rail mounting. Its compact size, PCI/PCIe slots and simple yet useful I/O functions fit most applications where a reliable platform is needed.. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 6 of 78...
Page 7: Product Specification
141 mm (W) x 156 mm (H) x 224 mm (D) Weight 2.9 kg (with one 2.5” HDD and DDR3 memory module) Mounting Wall-mount by mounting brackets Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 7 of 78...
Page 8 ** The CPU loading is applied using Intel® Thermal Analysis Tool. For detail testing criteria, please contact Neousys Technology *** For sub-zero operating temperature, a wide temperature HDD drive or Solid State Disk (SSD) is required. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 8 of 78...
Page 9: Specification Of Nuvo-2021
141 mm (W) x 156 mm (H) x 224 mm (D) Weight 2.9 kg (with one 2.5” HDD and DDR3 memory module) Mounting Wall-mount by mounting brackets Environmental Operating -20°C ~ 70°C, 100% CPU loading **/*** Temperature Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 9 of 78...
Page 10 ** The CPU loading is applied using Intel® Thermal Analysis Tool. For detail testing criteria, please contact Neousys Technology *** For sub-zero operating temperature, a wide temperature HDD drive or Solid State Disk (SSD) is required. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 10 of 78...
Page 11: Specification Of Optional Isolated Dio
No. of Channel Sink Current 100 mA (sustained loading) (per channel) 250 mA (peak loading) Isolated Voltage 2500 Vrms Output Type Power MOSFET + Analog Device iCoupler® Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 11 of 78...
Page 12: Chapter 2 Getting To Know Your Nuvo-2000
When you receive the package of Nuvo-2000+ series, please check immediately if the package contains all the items listed in the following table. If any item is missing or damaged, please contact your local dealer or Neousys Technology Inc. for further assistance.
Page 13: Front Panel I/O Functions
To avoid unexpected operation, the reset button is hidden behind the front panel. You need to use a pin-like object to push the reset button. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 13 of 78...
Page 14: Led Indicators
EHCI (Enhanced Host Control Interface) mode and are compatible to USB 2.0, USB 1.1 and USB 1.0 devices. Legacy USB support is also provided so you can use USB keyboard/mouse in DOS environment. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 14 of 78...
Page 15: Gigabit Ethernet Port
Windows, you need to install corresponding drivers for both Intel ICH8-M chipset and Realtek ALC262 ® codec. Please refer to section 4.3 for information regarding driver installation. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 15 of 78...
Page 16: Vga Connector
COM1 can be set in BIOS setup utility (refer to section 4.1.1 for detail). The following table describes the pin definition of COM ports. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 16 of 78...
Page 17: Dc Jack
The rated voltage of DC jack is 16V. Supplying a voltage over 16V may cause safety issue. You should use either 2-pin pluggable terminal block or DC jack for DC power input. DO NOT supply power to both connectors at the same time. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 17 of 78...
Page 18: Dc Input Terminal Block
Supplying a voltage over 25V will damage the system. You should use either 2-pin pluggable terminal block or DC jack for DC power input. DO NOT supply power to both connectors at the same time. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 18 of 78...
Page 19: Internal I/O Functions
Definition Description Power+ System power indicator, on if system is turned on, off if system is turned off. Power- HDD+ Hard drive indicator, flashing when SATA hard Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 19 of 78...
Page 20: Remote On/Off Control
The function is provided via a 3-pin, 2.0mm pitch wafer connector. Both AT-mode and ATX-mode on/off control are supported. For detail information of using remote on/off control function, please refer to section 3.8. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 20 of 78...
Page 21: Parallel Port
ITE8783 Super IO chip (-40 to 85°C) and has pin-out via a 2x13, 2.00mm pitch box header. For users who need to connect a printing device via a standard DSub-25 connector, Neousys Technology Inc. provides an optional panel/cable kit to expose one DSub-25 (parallel) and one DSub-9 (COM port).
Page 22: Com Ports (Com3 & Com4)
COM3 and COM4 support 9-wire RS-232 operation. For users who need to connect devices via standard DSub-9 connectors, Neousys Technology Inc. provides an optional panel/cable kit to expose two DSub-9 connectors. Copyright © 2013 Neousys Technology Inc. All Right Reserved.
Page 23: Cf Socket
When using a CF card as storage device, we highly recommend you to set the IDE Controller Mode as “IDE+SATA (Non-AHCI)” in BIOS setup for better compatibility. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 23 of 78...
Page 24: Ddr3 Sodimm Socket
Nuvo-2000+ provides two SATA ports to accommodate two 2.5” SATA hard drives in its chassis. The first SATA port is located on the SBC via a 22-pin SATA connector. With the Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 24 of 78...
Page 25: Sata#2 Connector
PCI card with a maximal dimension of 205mm x 105mm (PCB size, excluding connector). For information of installing PCI cards, please refer to section 3.5 for detail. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 25 of 78...
Page 26: X4 Pci Express Slot
The operating temperature of the whole system when cards installed is affected by the power consumption and operating temperature of add-on cards. Please consult your add-on card dealer or Neousys Technology for further information. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 26 of 78...
Page 27: Optional Isolated Dio
2x13 pins box header. Neousys also provides a flat cable and DSub 25-pin connector to allow front-panel access for the DIO function. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 27 of 78...
Page 28 Pin# Pin Definition ISO_5V DO_GND DO_0 DO_6 DO_1 DO_7 DO_GND DO_GND DO_2 DO_4 DO_3 DO_5 DO_GND DI_GND DI_0 DI_4 DI_1 DI_5 DI_GND DI_GND DI_2 DI_6 DI_3 DI_7 Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 28 of 78...
Page 35: Chapter 3 Getting Start
Place the chassis on a plat surface. Open the chassis by pushing its side cover toward left and then toward up. Gently remove the side cover and the SBC is exposed. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 35 of 78...
Page 37 HDD into the HDD bracket. Note that the HDD must be placed in a right direction. Fasten the HDD using four M3 flat-head screws. (Another two screws are on the opposite side) Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 37 of 78...
Page 38 SBC. Fasten the HDD bracket assembly with three M3, L16 P-head screws. Now you’ve done the installation of HDD for SATA#1 port. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 38 of 78...
Page 39: Install A Hdd On Sata#2 Port
Get four M3 flat-head screws from the accessory box. Place your HDD into the HDD bracket and fix it with M3 flat-head screws. Note that the HDD must be placed in a right direction. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 39 of 78...
Page 40 SATA signals and 4-pin power) on the backplane. Note that the polarity of power connector must be connected correctly. Connect the HDD assembly to the 22-pin connector of the SATA cable. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 40 of 78...
Page 41 Tilt the HDD assembly and insert the wedge of HDD bracket to the bottom cover. Once it’s firmly wedged, push it down and fix it using a M3 flat-head screw. Now you’ve done the installation of HDD for SATA#2 port. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 41 of 78...
Page 42: Install A Cf Card
Align your CF card with the guide of the CF socket. Note that you must have the obverse side toward the SBC. Push down your CF card until it’s firmly contacted with pins of the CF socket. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 42 of 78...
Page 43: Install The Ddr3 Sodimm Module
As the DDR3 SODIMM module is firmly contacted with socket connectors, press it down until the clamps of the socket snap into the latching position of SODIMM module. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 43 of 78...
Page 44: Install The Pci/Pcie Add-On Cards
Install your add-on card into the PCI/PCIe slot. Make sure the “golden finger” connector is firmly contacted with PCI/PCIe connector and the faceplate of the add-on card is well inserted to the groove underneath. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 44 of 78...
Page 45 Nuvo-2000+ Series User’s Manual Get the M3 PW-head screw from the accessory box. And use it to fix your PCI/PCIe add-on card. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 45 of 78...
Page 46: Mount Your Nuvo-2000
3.6.1 Mount your Nuvo-2000+ on the Wall Get one wall-mounting bracket and four M4 screws from the accessory box. Fix the mounting bracket to the back side of Nuvo-2000+ using M4 screws. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 46 of 78...
Page 47 Fix Nuvo-2000+ on the wall via the screw holes of the mounting bracket. You can also take advantage of the keyhole-shaped holes of the mounting bracket to suspend Nuvo-2000+ on the Wall. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 47 of 78...
Page 48: Mount Your Nuvo-2000+ On A Flat Surface
3.6.2 Mount your Nuvo-2000+ on a Flat Surface Get two wall-mounting brackets and four M4 screws from the accessory box. Fix the mounting brackets to the bottom side of Nuvo-2000+ using M4 screws. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 48 of 78...
Page 50: Mount Your Nuvo-3000 On The Din Rail
Nuvo-2000+ using four M4 flat-head screws before mount it to a DIN rail. This option can be useful if you want to deploy Nuvo-2000+ inside an equipment cabinet where DIN rail is available. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 50 of 78...
Page 51: Connect Dc Power To You Nuvo-2000
Insert the wires to correct contacts of pluggable terminal block and tighten clamping screws using a Philips screwdriver. Firmly plug the terminal block into a receptacle on the front panel, and tighten the captive screws using a Slotted screwdriver. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 51 of 78...
Page 52: Connect Dc Power Via The Dc Jack
Make sure the AC-DC adapter is off before you connect the DC plug to your Nuvo-2000+. Plug the AC-DC adapter into the DC jack and push it to the end. The DC plug shall stay firmly with the DC jack. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 52 of 78...
Page 53: Power On Your Nuvo-2000
DC power. When the switch is closed, the DC power is break-off. When it’s opened, the DC power is feed-in. To power on Nuvo-2000+ using an external latched switch (AT-mode), please follow the steps listed below. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 53 of 78...
Page 54: Power On Nuvo-2000+ Using An External Non-Latched Switch (Atx-Mode)
To power on Nuvo-2000+ using an external non-latched switch (ATX-mode), please follow the steps listed below. Prepare a non-latched switch with a 2-pin, 2.0mm pitch connector. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 54 of 78...
Page 55: Power On Nuvo-2000+ Using Wake-On-Lan Function
Wake-on-LAN function for Nuvo-2000+. Please refer to section 4.1.7 for the instruction of configuring this option. In Windows system, identify the Local Area Connection of Intel® 82574L Gigabit Controller and click the Configure button. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 55 of 78...
Page 56 Nuvo-2000+ can wake from S3 or S4 state when receiving a magic packet. The magic packet is a broadcast frame containing anywhere within its payload 6 bytes Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 56 of 78...
Page 57 Wake on Magic Packet from power off state When checking this option, Nuvo-2000+ can wake from S5 (system off with standby power) state when receiving a magic packet. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 57 of 78...
Page 58: Chapter 4 Bios And Driver
When Nuvo-2000+ boots up, press F2 to enter BIOS setup utility. Go to [Advanced] [Peripheral Configuration]. Set the [Set COM1 as] to a proper mode for COM1 of your Nuvo-2000+. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 58 of 78...
Page 59: Sata Controller Mode
When Nuvo-2000+ boots up, press F2 to enter BIOS setup utility. Go to [Advanced] [SATA Configuration]. Set the [HDC Configure as] to a proper mode for your Nuvo-2000+. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 59 of 78...
Page 60: Boot Display Device
Select “Int. Graphics Device” if using integrated Intel® GMA 3150 graphics engine Select “PCI Graphics Card” if using a PCI graphics card Select “PCI-E Graphics Card” if using a PCI Express graphics card Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 60 of 78...
Page 61: Pci Latency Timer
When Nuvo-2000+ boots up, press F2 to enter BIOS setup utility. Go to [Advanced] [Chipset Configuration]. Set the [PCI Latency Timer] to a proper value for your Nuvo-2000+. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 61 of 78...
Page 62: Trip Point For Cpu Thermal Throttling
When Nuvo-2000+ boots up, press F2 to enter BIOS setup utility. Go to [Power] [Advanced CPU Control] [Thermal Trip Points Setting]. Set the [Throttle On Temperature] to a proper value for your Nuvo-2000+. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 62 of 78...
Page 63: Power On After Power Failure Option
When Nuvo-2000+ boots up, press F2 to enter BIOS setup utility. Go to [Power]. Set the [Power On after Power Failure] to a proper value for your Nuvo-2000+. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 63 of 78...
Page 64: Wake-On-Lan Option
To enable/disable “Wake on LAN” option: When Nuvo-2000+ boots up, press F2 to enter BIOS setup utility. Go to [Power]. Enable/disable the [Wake on LAN] option according to your application. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 64 of 78...
Page 65: Watchdog Timer For Booting
Disable or select timeout value for [WDT for Booting] option. Once you give a timeout value, the [WDT Stop Option] option appears. You can select “Automatically after POST” or “Manually after Entering OS”. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 65 of 78...
Page 66: Select A Boot Device
The [Boot Menu] option decides whether to list all bootable devices connected to your Nuvo-1000 by device or by device category. You can use F5/F6 or +/- to change the boot order of devices or device categories. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 66 of 78...
Page 67: Operating System Support
Debian 6.0 64bit Neousys will keep this list updated as we continuously test other operating systems with Nuvo-2000+. Please contact us for the latest OS support list. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 67 of 78...
Page 68: Driver Installation
Nuvo-2000+ Series User’s Manual 4.3 Driver Installation Neousys Technology Inc. provides a very convenient utility in “Drivers & Utilities DVD” to allow the “One-Click” driver installation. This utility automatically detects your Windows operating system and installs all necessary drivers to your Nuvo-2000+ with just one mouse click.
Page 69: Install Drivers Manually
Windows 7 or Windows Vista 64-bit The recommended driver installation sequence is Chipset driver (x:\Driver_Pool\Chipset_ICH8M\ALL\infinst_autol.exe) Graphics driver (x:\Driver_Pool\Graphics_D525\Win7_64\Setup.exe) Audio driver (x:\Driver_Pool\Audio_ALC262\Win7_ALL\Setup.exe) LAN driver (x:\Driver_Pool\GbE_82574L\Win7_64\APPS\PROSETDX\Winx64\DxSetup.exe) WDT & DIO driver (x:\Driver_Pool\WDT_DIO\Win7_64\WDT_DIO_Setup_v2.0.1(x64).exe) Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 69 of 78...
Page 70: Appendix A Using H/W Watchdog Timer
WDT_DIO_Setup.exe. In prior to program WDT and DIO on Nuvo-2000+ series, you should execute the setup program and install the WDT and DIO library. Execute WDT_DIO_Setup.exe. The following dialog appears. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 70 of 78...
Page 71 C:\Neousys\WDT_DIO. Once the installation is finished, a dialog appears to prompt you to reboot the system. The WDT & DIO library will take effect after system rebooting. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 71 of 78...
Page 72: Function Reference
If value of unit is correct (0 or 1), this function returns TRUE, otherwise FALSE. Usage WORD tick=255; BYTE unit=1; //unit is second. BOOL bRet = SetWDT(tick, unit); //timeout value is 255 seconds Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 72 of 78...
Page 73: Startwdt
Stop the countdown of WDT. When WDT is stopped, the WDT LED indicator stops blinking. Parameter None Return Value Always returns TRUE; Usage BOOL bRet = StopWDT() Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 73 of 78...
Page 74: Appendix B Using Isolated Dio
GND return path is established. You should configure a sinking current connection for DO of Nuvo-2000+. The following diagrams are the suggested wiring for DO: Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 74 of 78...
Page 75: Install Wdt And Dio Library
WDT_DIO_Setup.exe. In prior to program WDT and DIO on Nuvo-1000 series, you should execute the setup program and install the WDT and DIO library. Execute WDT_DIO_Setup.exe. The following dialog appears. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 75 of 78...
Page 76 C:\Neousys\WDT_DIO. Once the installation is finished, a dialog appears to prompt you to reboot the system. The WDT & DIO library will take effect after system rebooting. Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 76 of 78...
Page 77: Function Reference
The status (TRUE or FALSE) of the specified DI channel. Usage BYTE ch=3; //DI channel #3 BOOL DIChValue = DIReadLine(ch); //read DI channel #3 DIReadPort Description Read the entire isolated digital input port (8 channels). Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 77 of 78...
Page 78: Dowriteline
WORD value specifies the status of the DO port. For Nuvo-2000+, value should be a value of 0~255. Return Value None Usage WORD DOPortValue=0x3F; //00111111b DOWritePort(DOPortValue); //write DO port as 00111111b Copyright © 2013 Neousys Technology Inc. All Right Reserved. Page 78 of 78...
