24 LCD Color Monitor
Service
Service
Service
Description
Table of Contents......................................................1
Revision List.............................................................2
Important Safety Notice............................................3
1. Monitor Specifications............................................5
2. LCD Monitor Description........................................8
3. Operation Instructions............................................9
3.1General Instructions........................................9
3.2 Control Buttons..........................................9
3.3 OSD Menu.....................................................11
4. Input/output Specification..................................12
4.1 Input Signal Connector.......................................12
4.2 Resolution & Preset Modes.................................13
4.3 Pixel Defect Policy.......................................15
4.4 Failure Mode of Panel...................................17
5. Block Diagram...............................................18
5.1 Scaler Board.....................................................18
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE
CHASSIS AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN
SERVICING ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING
REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES
Copyright 2013 Philips Consumer Lifestyle
247E4QHSD/93
247E4QHAD/00
247E4QHAD/69
247E4QHKAD/94
Description
Page
6. Schematic Diagram.............................................. 19
6.1 Scaler Board..............................................19
6.2 Key Board..............................................33
7. PCB Layout................................................34
7.1 Scaler Board............................................34
7.2 Key Board.................................................35
8. Wiring Diagram.............................................36
9. Scaler Board Overview..................................38
10. Mechanical Instructions...............................39
11. Repair Flow Chart........................................41
12. ISP Instructions..................................................45
13. DDC Instructions................................................58
15. Monitor Exploded View.......................................80
17. General Product Specification.......................89
SAFETY NOTICE
Subject to modification
K
Mar.8, 2013
Chassis: Meridian 3
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 247E4QHSD/93 and is the answer not in the manual?

Questions and answers

Related Manuals for Philips 247E4QHSD/93

Summary of Contents for Philips 247E4QHSD/93

  • Page 1: Table Of Contents

    CHASSIS AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES. CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES Copyright 2013 Philips Consumer Lifestyle Subject to modification Mar.8, 2013...

  • Page 2: Revision List

    Meridian 3 Revision List Version Release Date Revision History Jan.18, 2013 Initial release, Draft Version Jan.25,2013 Add new model 247E4QHAD/00 Feb.1,2013 Add new model 247E4QHAD/69 Mar.8,2013 Add new model 247E4QHKAD/94...

  • Page 3: Important Safety Notice

    Meridian 3 Important Safety Notice This electronic user guide is intended for anyone who uses the Philips monitor. Take time to read this user manual before you use your monitor. It contains important information and notes regarding operating your monitor. The...
  • Page 4 Meridian 3 IMPORTANT: Always activate a moving screen saver program when you leave your monitor unattended. Always activate a periodic screen refresh application if your monitor will display unchanging static content. Uninterrupted display of still or static images over an extended period may cause “burn in”, also known as “after-imaging”...

  • Page 5: Monitor Specifications

    Meridian 3 1. Monitor Specifications Technical specifications...
  • Page 6 Meridian 3...
  • Page 7 Meridian 3 Note: 1. EPEAT Gold or Silver is valid only where Philips registers the product. Please visit www.epeat.net registration status in your country. 2. This data is subject to change without notice. Go to www.philips.com/support to download the latest...

  • Page 8: Lcd Monitor Description

    Meridian 3 2. LCD Monitor Description The LCD monitor will contain a scaler board and a key board. The scaler board houses the flat panel control logic, brightness control logic and DDC. Monitor Block Diagram LED Drive LED Panel Scaler Board Adapter board Key Board Video signal, DDC...

  • Page 9: Operation Instructions

    Meridian 3 3. Operating Instructions 3.1 General Instructions Press the power button to turn the monitor on or off. The other control knobs are located at front panel of the monitor. By changing these setting, the picture can be adjusted to your personal preference. The power cord should be connected.
  • Page 10 Meridian 3 Connect to PC Connecting to your PC 1. Connect the power cord to the back of the monitor firmly. 2. Turn off your computer and unplug its power cable. 3. Connect the monitor signal cable to the video connector on the back of your computer.

  • Page 11: Osd Menu

    Meridian 3 3.3 OSD Menu The OSD Menu On-screen Display (OSD) is feature in all Philips LCD Below is an overall view of the structure of the monitors. It allows an end user to adjust screen On-Screen Display. You can use this as a reference...

  • Page 12: Input/Output Specification

    Meridian 3 4. Input/ Output Specification 4.1 Input Signal Connector HDMI Connector D-sub Connector Pin No. Description Pin No. Signal Name TMDS Data2+ TMDS Data2 Shield Green/ SOG TMDS Data2– Blue TMDS Data1+ Sense (GND) TMDS Data1 Shield Cable Detect (GND) TMDS Data1–...

  • Page 13: Resolution & Preset Modes

    Meridian 3 4.2 Resolution & Preset Modes Maximum Resolution 1920 x 1080 at 60 Hz (analog input) 1920 x 1080 at 60 Hz (digital input) Recommended Resolution 1920 x 1080 at 60 Hz (digital input) Note: Please notice that your display works best at native resolution of 1920 x 1080@60Hz. For best display quality, please follow this resolution recommendation.
  • Page 14 Meridian 3 Power Management Definition If you have VESA DPM compliance display card or software installed in your PC, the monitor can automatically reduce its power consumption when not in use. If an input from a keyboard, mouse or other input device is detected, the monitor will 'wake up' automatically.

  • Page 15: Pixel Defect Policy

    Meridian 3 4.3 Pixel Defect Policy defects and several types of sub pixel defects within Philips strives to deliver the highest quality products. each category. We use some of the industry's most advanced manufacturing processes and practice stringent quality Bright Dot Defects Bright dot defects appear as pixels control.
  • Page 16 In order to qualify for repair or replacement due to pixel defects during the warranty period, a TFT LCD panel in a Philips flat panel monitor must have pixel or sub pixel defects exceeding the tolerances listed in the following tables.

  • Page 17: Failure Mode Of Panel

    Meridian 2 4.4 Failure Mode Of Panel Quick reference for failure mode of LCD panel this page presents problems that could be made by LCD panel. It is not necessary to repair circuit board. Simply follow the mechanical Polarizer has bubbles instruction on this manual to eliminate failure by replace LCD panel.
  • Page 21 D405 RLZ5.6B C428 NC/100N16V D404 RLZ5.6B C427 NC/100N16V D403 RLZ5.6B C426 NC/100N16V C425 NC/0.1UF 16V C424 NC/0.1UF 16V...
  • Page 23 NC/G691L400T73F NC/0R05 1/10W NC/0R05 1/10W NC/62K1/16W NC/30Kohm 1/16W +/-5%...
  • Page 28 D405 RLZ5.6B C428 NC/100N16V D404 RLZ5.6B C427 NC/100N16V D403 RLZ5.6B C426 NC/100N16V C425 NC/0.1UF 16V C424 NC/0.1UF 16V...
  • Page 30 G691L400T73F 0R05 1/10W 0R05 1/10W 62K1/16W 30Kohm 1/16W +/-5%...

  • Page 34: Pcb Layout

    Meridian 3 7. PCB Layout 7.1 Scaler Board (715G5616M01000004K) Remark: Parts position can be searched by using FIND function in PDF. SCREW1 SCREW2 CN408 SEN7 R720 C726 R719 C724 C722 C603 C608 C614 C721 U705 R717 R610 R605 R718 C607 C606 U702 CN409...

  • Page 35: Key Board

    Meridian 3 7.2 Key Board 715G5453K02000004S Remark: Parts position can be searched by using FIND function in PDF. U001 CN001 LED001...

  • Page 38: Scaler Board Overview

    Meridian 3 9. Scaler Board Overview FFC Cable DC-DC Flash ROM Scaler D-SUB EEPROM HDMI EEPROM HDMI EEPROM Audio IC...

  • Page 39: Mechanical Instructions

    Meridian 3 10. Mechanical Instructions Note: 247E4QHSD/93 have no speakers, so some steps are needless for it. 2. Disconnect the connector to remove the Rear cover. Needless for 247E4QHSD/93 Step 2: Remove the scaler board 1. Disconnect all the connectors and remove the screw to remove the scaler board.
  • Page 40 Meridian 3 2. The Bezel and Key Board. Step 4: Rear cover with speakers stand and HINGE ASSY. Note 247E4QHSD/93 have no Speakers. 2. The scaler board. Step 5: Remove the screw to remove the Base. Step 3: Panel and Bezel.

  • Page 41: Repair Flow Chart

    Meridian 3 11. Repair Flow Chart 1. No Power No power Check power cable is Re-plug the power cable tightened? Check Power “On/Off” Turn on the Power “On/Off” switch is “On”? Check the LED Check the AC power indicator is OK? Replace the power board and check connections Replace main board and check connections Replace key board and check connections...
  • Page 42 Meridian 3 Video (Power LED White) No Video (Power LED White) Press the power Replace the main board button is OK? Replace the power The end board and connection Replace the main The end board and connection Check the FFC cable Replace the FFC cable or panel or panel...
  • Page 43 Meridian 3 3. DIM DIM (image overlap, focus or flicker) Reset in factory mode The end Set to the optimal The end frequency, select the recommended frequency Readjust the phase and pixel The end clock in the user mode Pull out signal cable and Check the signal cable check “Self Test Feature and the PC...
  • Page 44 Meridian 3 4. Color is not optimal Color is not optimal Color shift Miss color Reset the factory mode Replace the signal cable In the user mode, set the “color settings” until customer satisfy The end Pull out the signal cable and check the screen color display is normal? Replace the signal cable or PC...

  • Page 45: Isp Instructions

    Meridian 3 12. ISP Instruction 12.1Materials list ISP JIG: 715GT089-B/C VGA cable TPV P/N: 089G728 GAA DB Monitor USB cable USB port driver TPV P/N: 089G1758 X MSTAR driver ISP tool: V4.5.1.0.5 New F/W...
  • Page 46 Meridian 3 12.2 Connection 12.3 Install driver 12.3.1 If you use this ISP board first time you need to install mstar driver .
  • Page 47 Meridian 3...
  • Page 48 Meridian 3...
  • Page 49 Meridian 3...
  • Page 50 Meridian 3 12.3.2 When insert the USB cable to PC USB port, will pop up a Hardware Wizard to help you install the USB driver if you use this ISP board first time. You can install it successfully as the below instruction step by step. Remark: The USB driver files path: D:\FTC100103(Mstar)\FTCUSB.INF...
  • Page 51 Meridian 3 Click “Finish” to complete the USB serial port driver installation. After installation the USB serial port driver, please to check the port. Look the properties of “my Computer”.
  • Page 52 Meridian 3 12.4 Install the ISP tool. 12.4.1 Copy the three files in one folder. 12.4.2 Double-click to run the ISP tool. 12.4.3 Set the parameters in “Device” window..
  • Page 53 Meridian 3 12.4.4 Connect to the monitor. Click “Connect”. If the tool communicate with monitor successfully, the tool will detect the flash type of monitor. 12.4.5 Load the F/W you want to upgrade.
  • Page 54 If the monitor has DVI or HDMI port, you need to set restore address for HDCP key to avoid re-program HDCP key. “0x07D000”, 12KB for philips 247E4QHSD. 12.4.7 Set parameter in “Auto” window. If you have set “Restore address”, please tick “Restore Data”.
  • Page 55 Meridian 3 12.4.8 Processing of upgrade. After clicking “Run”, the tool start to program. It is forbided to power off monitor or switch off connection during programming. 12.4.9 Successful upgrade. When upgrade successful, there will be green Pass letter appearing.
  • Page 56 Meridian 3 12.5 Check the FW version after upgrade. 12.5.1 The way to open factory menu. (1)Connect video source to monitor and AC on. (2)The way to factory menu: Press “MENU” and “+” keys synchronously (The rightmost and leftmost keys in the touch keyboard), and DC on.
  • Page 57 Meridian 3 12.6 Troubleshooting. 12.6.1 Can’t Entry ISP Mode!! (1) Check the cables and ISP JIG are connected fluently. (2) Click the “Dis Con” and click “Connect” again. (3) AC off the monitor for a while and retry it. (4) Change other vervion ISP program. (4)Change ISP JIG or cable.

  • Page 58: Ddc Instructions

    Meridian 3 13. DDC Instruction General DDC Data Re-programming In case the main EEPROM with Software DDC which store all factory settings were replaced because a defect repaired monitor’ the serial numbers have to be re-programmed. It is advised to re- soldered the main EEPROM with Software DDC from the old board onto the new board if circuit board have been replaced, in this case the DDC data does not need to be re-programmed.
  • Page 59 Anolog EDID WA.dat HDMI2 EDID WH2.dat MHL EDID WHM.dat 13.3.2 Copy these four files to one folder named as PHILIPS 247E4QHSD which must contains “config.ini” file. 13.3.3 Copy PHILIPS 247E4QHSD to DDC folder and put DDC and ISP tool together.
  • Page 60 Meridian 3 13.4 Run the ISP tool. 13.4.1 Double-click the icon to open the tool. 13.4.2 Select the EDID folder.
  • Page 61 Meridian 3 13.4.3 Load EDID successful. 13.4.4 Tick the “Only connect HDMI”and “write SN”, and type in the 14 digit S/N.

  • Page 62: Troubleshooting

    Meridian 3 13.4.5 Start to writing. Click “write EDID” to start writing. When The green “PASS” appear, the process is finished. 13.4.6 Check the S/N in monitor user menu. Press “MENU” and select “Information”—“SN”, you can check the SN. 12.5 Troubleshooting. 12.5.1 Can’t write! (1)AC on the monitor and turn on it.(Restart the monitor) (2)Although we write all EDID through by HDMI single port in this SOP, I can also write it one by one when can’t...
  • Page 63 Meridian 3 247E4QHSD/93 EDID Analog 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F ----------------------------------------------- 00| 00 FF FF FF FF FF FF 00 41 0C C0 C0 01 01 01 01 10| 1F 16 01 03 6E 34 1D 78 2A 2C C5 A4 56 50 A1 28...
  • Page 64 1440 x 900 @ 60Hz 1680 x 1050 @ 60Hz 1280 x 720 @ 60Hz <-Detailed Timing Descriptions:-> FC (Monitor Name) : Philips 247E4 FD (Monitor Limits): Min. V. rate: 56 Hz Max. V. rate: 76 Hz Min. H. rate: 30 KHz Max.
  • Page 65 Meridian 3 Digital 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F ----------------------------------------------- 00| 00 FF FF FF FF FF FF 00 41 0C C0 C0 01 01 01 01 10| 1F 16 01 03 80 34 1D 78 2A 2C C5 A4 56 50 A1 28 20| 0F 50 54 BD 4B 00 D1 C0 81 80 95 0F 95 00 B3 00 30| 81 C0 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C 40| 45 00 09 25 21 00 00 1E 00 00 00 FF 00 0A 20 20...
  • Page 66 1440 x 900 @ 60Hz 1680 x 1050 @ 60Hz 1280 x 720 @ 60Hz <-Detailed Timing Descriptions:-> FC (Monitor Name) : Philips 247E4 FD (Monitor Limits): Min. V. rate: 56 Hz Max. V. rate: 76 Hz Min. H. rate: 30 KHz Max.
  • Page 67 Meridian 3 HDMI 1 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F --------------------Block 0-------------------- 00| 00 FF FF FF FF FF FF 00 41 0C C0 C0 01 01 01 01 10| 1F 16 01 03 80 34 1D 78 2A 2C C5 A4 56 50 A1 28 20| 0F 50 54 BD 4B 00 D1 C0 81 80 95 0F 95 00 B3 00 30| 81 C0 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C 40| 45 00 09 25 21 00 00 1E 00 00 00 FF 00 0A 20 20...
  • Page 68 1280 x 720 @ 60Hz <-Detailed Timing Descriptions:-> Detailed Timing : 1920x1080 @ 60Hz FF (Monitor SN) : FC (Monitor Name) : Philips 247E4 FD (Monitor Limits): Min. V. rate: 56 Hz Max. V. rate: 76 Hz Min. H. rate: 30 KHz Max.
  • Page 69 Meridian 3 Extension Flag : 01 Block0 Checksum : 85 ------------------------------------------------------- Block 1: Extended Block Type: CEA 861B Detailed Timing Blocks start at Byte: 22 DTV Underscan YES DTV Basic Audio YES YCbCr (4:4:4) YES YCbCr (4:2:2) YES <-Video Short Block Description:-> 640 x 480 P 59.94/60Hz 4:3 720 x 480 P 59.94/60Hz 4:3 720 x 480 P 59.94/60Hz 16:9...
  • Page 70 Meridian 3 Detailed Timing Descriptions: 1920x1080 @ 60Hz H Image Size: 521 mm V Image Size: 293 mm Pixel Clock: 148 Hz Refreshed Mode: Non-Interlaced Detailed Timing Descriptions: 720x480 @ 60Hz H Image Size: 521 mm V Image Size: 293 mm Pixel Clock: 27 Hz Refreshed Mode: Non-Interlaced Detailed Timing Descriptions: 1280x720 @ 60Hz...
  • Page 71 Meridian 3 ------------------------------------------------------- Block 0: EDID Structure Version/Revision: 01 03 <-Vendor/Product Identification:-> ID Manufacturer Name: PHL ID Product Code: C0C0 ID Serial Number: No Use Week of Manufacture: Year of Manufacture: 2012 <-Basic Display Parameters/Features:-> Video i/p definition: Digital Max. H. Image Size : 52cm Max.
  • Page 72 1280 x 720 @ 60Hz <-Detailed Timing Descriptions:-> Detailed Timing : 1920x1080 @ 60Hz FF (Monitor SN) : FC (Monitor Name) : Philips 247E4 FD (Monitor Limits): Min. V. rate: 56 Hz Max. V. rate: 76 Hz Min. H. rate: 30 KHz Max.
  • Page 73 Meridian 3 1920 x 1080 P 59.94/60Hz 16:9 720 x 576 P 50Hz 4:3 720 x 576 P 50Hz 16:9 1280 x 720 P 50Hz 16:9 1920 x 1080 I 50Hz 16:9 720(1440) x 576 I 50Hz 4:3 720(1440) x 576 I 50Hz 16:9 1920 x 1080 P 50Hz 16:9 1280 x 720 P 59.94/60Hz 16:9 <-Audio Short Block Description:->...
  • Page 74 Meridian 3 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F --------------------Block 0-------------------- 00| 00 FF FF FF FF FF FF 00 41 0C C0 C0 01 01 01 01 10| 32 16 01 03 80 34 1D 78 2A 2C C5 A4 56 50 A1 28 20| 0F 50 54 BD 4B 00 D1 C0 81 80 95 0F 95 00 B3 00 30| 81 C0 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C 40| 45 00 09 25 21 00 00 1E 00 00 00 FF 00 0A 20 20...
  • Page 75 1280 x 720 @ 60Hz <-Detailed Timing Descriptions:-> Detailed Timing : 1920x1080 @ 60Hz FF (Monitor SN) : FC (Monitor Name) : Philips 247E4 FD (Monitor Limits): Min. V. rate: 56 Hz Max. V. rate: 76 Hz Min. H. rate: 30 KHz Max.
  • Page 76 Meridian 3 Block0 Checksum : 72 ------------------------------------------------------- Block 1: Extended Block Type: CEA 861B Detailed Timing Blocks start at Byte: 23 DTV Underscan YES DTV Basic Audio YES YCbCr (4:4:4) YES YCbCr (4:2:2) YES <-Video Short Block Description:-> 640 x 480 P 59.94/60Hz 4:3 720 x 480 P 59.94/60Hz 4:3 720 x 480 P 59.94/60Hz 16:9 1920 x 1080 I 59.94/60Hz 16:9...
  • Page 77 Meridian 3 <-Detailed Timing Descriptions: -> Detailed Timing Descriptions: 1920x1080 @ 60Hz H Image Size: 521 mm V Image Size: 293 mm Pixel Clock: 148 Hz Refreshed Mode: Non-Interlaced Detailed Timing Descriptions: 720x480 @ 60Hz H Image Size: 521 mm V Image Size: 293 mm Pixel Clock: 27 Hz Refreshed Mode: Non-Interlaced...

  • Page 78: White Balance, Luminance Adjustment

    Meridian 3 14. White Balance, Luminance Adjustment 1. Apparatuses and program: analyzer CA-210, PC, tool, FGA adjustment program (Philips LEDFGA.DDCI), Pattern generator. 2. Equipment installation: a. Connect analyzer CA-210 to PC by USB connector, install drive program CA-SDK Ver4.00 for CA-210 and restart PC after finish installing b.
  • Page 79 Meridian 3 5. Color Temp confirmation Connect the signal to the monitor, the monitor displays white-picture, use CA-210 to measure the Color Temp of the screen center and select the OSD to make sure whether the Color Temps accord with the SPEC. 11500K 9300K 8200K...

  • Page 82: Recommended & Spare Parts List

    Meridian 3 16. Recommended & Spare Parts List Note: Take the 247E4QHSD/93 BOM for example, the parts information listed below are for reference only, and are subject to change without notice. Please go to http://cs.tpv.com.cn/hello1.asp for the latest information Item...
  • Page 83 Meridian 3 C710 367G315M2213AB EC 220UF 20% 16V 6.3*7 3000 hr ERF1CM221 U702 056G 563127 IC G1117-25T63Uf SOT-223 U703 056G 563368 DC/DC G5725ADJT11U 1A Adj SOT-23-5 U504 056G 662 18 ESD PROTECT AZ1045-04F.R7G DFN2510P10E U503 056G 662 21 IC AOZ8804DI DFN-10 U506 056G 662 52 ESD PROTECT AZC398-04S.R7G SOT23-6...
  • Page 84 Meridian 3 R720 061G0402333 JY RST CHIPR 33KOHM £«-5£¥ 1/16W YAGEO R467 061G04023901FT RST 0402 3.9K 1% 1/16W TZAI YUAN R467 061G04023901FY RST CHIP 3.9KOHM 1% YAGEO R496 061G0402393 JF RST CHIP 39K 1/16W 5% FENGHUA R456 061G0402393 JT RST CHIP 39K 1/16W 5% TZAI YUAN R456 061G0402393 JY RST CHIP 39K 1/16W 5% YAGEO...
  • Page 85 Meridian 3 FB613 061G0805000 JF RST CHIPR 0 OHM +-5% 1/8W FENGHUA R851 061G0805000 JT RST 0805 0.05R MAX 1/8W R823 061G0805205 JF RST CHIPR 2M +-5% 1/8W FENGHUA R823 061G0805205 JT RST CHIPR 2M +-5% 1/8W TZAI YUAN R802 061G1206000 JF RST CHIPR MAX0R05 1/4W FENGHUA R802...
  • Page 86 Meridian 3 C812 065G060322422K CAP CHIP0603 220NF K 25V X7R C678 065G060322515K CAP 0603 2.2UF 10% 16V X5R C816 065G060322515K CAP 0603 2.2UF 10% 16V X5R C809 065G060339131J CAP CHIP 0603 390PF J 50V NPO C809 065G060339131J CAP CHIP 0603 390P 50V NP0 +/-5% C818 065G060347412K CAP 0603 470NF 10% 16V X7R...
  • Page 87 Meridian 3 C004 065G040210131J CAP 0402 100PF 5% 50V NP0 C004 065G040210131J CAP CHIP 0402 100P 50V NP0 +/-5% C001 065G040210412K CAP 0402 100NF 10% 16V X7R LED001 081G 15W 1 EL CHIP LED WHITE 99-113UNC/2223010/TR8 ZD001 093G 64 59 SU ESD MLVS0603M04 0603 247E4QHAD/00 Item...
  • Page 88 Meridian 3 U602 056G 643 13 G691L400T73UF SOT-23 GMT U504 056G 662 21 IC AOZ8804DI DFN-10 U506 056G 662 52 ESD PROTECT AZC398-04S.R7G SOT23-6 U513 056G 662902 ESD PROTECT RClamp0502B.TCT SC-75 3L U509 056G 667 3 Power Switch G5250H1T1U SOT-23-5 U801 056G 700 11 LED DRIVER OZ9998BGN-A1-0-TR SOP-16...

  • Page 89: General Product Specification

    . SOG SUPPORT . Windows 7compliant . HDCP support for DVI input . SMART Contrast 20M:1(max.) . True Vision (FACTORY GAMMA ALIGNMENT) (FGA) REQUIREMENT . POWER ON PHILIPS LOGO REQUIREMENT . WEEE REQUIREMENT . RoHS REQUIREMENT Quick Specification table: Model...
  • Page 90 All optical characteristics are determined according to panel specification after warming up longer than 30 minutes. PRODUCT PROFILE EDID header Data for EDID & .inf file Philips 247E4 (24inch Wide LCD MONITOR User visible strings on .inf file 247E4) Manufacturer ID ( EDID data) Product ID, "xxxx" 4 codes...
  • Page 91 Scaler should be capable of below items. 1) Scaler must support color engine for Image enhancement feature (SmartImage) 2) Scaler must have enough memory to support PerfecTune feature and Philips OSD 3) Scaler must support SmartContras, 20M:1 DCR preferred 4) VGA signal Auto adjustment: Monitor automatically adjusts and optimizes resolution and frequency based on input signal defined by “Source”...
  • Page 92 Meridian 3 Vsync Positive/Negative Composite sync TTL level, input impedance 2.2k ohm terminate (Positive/Negative) Sync on green video 0.3 Vp-p Negative (Video 0.7 Vp-p Positive) 2). DVI-D Digital Input signal: Single TMDS link (Three channels: RX0-/+, RX1-/+, RX2-/+) 3) HDMI ( option , refer to Quick specification table) Follow HDMI 1.4 specification 4).
  • Page 93 Meridian 3 Over Scan - 1. RGB signal : OFF (no this function) 2. YUV signal : (Video timming) ON (Be use and set ON/OFF) (But only 1080p define is OFF ) PC timing: to follow PC timing table TMDS/+5V/DDC/HPD/CEC Signals (TMDS Signal) Termination Supply Voltage AV 3.3V±5%...
  • Page 94 Meridian 3 Interface D-Sub Cable Length : Please refer to M3 cable bundle summary file Fix with monitor when packing, with transplant pin protective cover. Connector type : D-Sub male with DDC2B pin assignments. Blue connector thumb-operated jack screws Pin assignments: PIN No.
  • Page 95 Meridian 3 T.M.D.S. data0 shield No Connect No Connect T.M.D.S clock shield T.M.D.S. clock+ T.M.D.S. clock- HDMI Cable The input signals are applied to the display through HDMI cable. Length : Please refer to M4 cable bundle summary file Connector type : HDMI male with DDC-2B pin assignments White connector thumb-operated jackscrews With transplant pin protective cover.
  • Page 96 English, French, German, Spanish, Italian, Russian, Simplified Chinese, Portuguese, Turkish (9) Power On logo Power On Logo: Power Show up Philips logo 3 seconds Change to input signal. This picture is reference only. The official drawing will send out by PM.
  • Page 97 Meridian 3 PS : Item 3.4 and 3.5 , as far as possible to be display (another Horizontal and Vertical) Vertical scanning Sync polarity : Positive or Negative Scanning frequency : 56 - 76 Hz Power input connection Power cord length :please refer to M4 cable bundle summary file Power cord type : 3 leads power cord with protective earth plug.
  • Page 98 Meridian 3 24"(16:10) 1920x1200 36.8 24"(16:9) 1920x1080 EPA 5.1 VS EPA6.0 VGA Display identification In accordance with VESA Display Channel Standard Ver.1.0 and DDC 2B capability DVI Display identification In accordance with DVI requirement (DDWG digital Visual Interface revision 1.0) use DDC-2B, DDC/CI, and EDID V1.3 DDC /CI Support and Smart Manage/Control In accordance with VESA DDC/CI and MCCS ver.2.0, the monitor should be workable with ,...
  • Page 99 Meridian 3 audio 3.17.1 Frequency Response The amplifier and speaker combination shall provide a frequency response of 300 Hz to 20 kHz, with +/- 3 dB variation over the entire response range. 3.17.2 Total Harmonic Distortion Total harmonic distortion shall be limited to 5% THD at the maximum wattage speaker rating specified in section 1.3, at 1 kHz, when the input is 1.0Vrms.
  • Page 100 100 Meridian 3 VISUAL CHARACTERISTICS Test conditions Unless otherwise specified, this specification is defined under the following conditions. (1) Input signal : As defined in 3.3, 1920 x 1080 non-interlaced mode (1920 x 1080@60Hz), signal sources must have 75 ohm output impedance. (2) Luminance setting : controls to be set to nits with full screen 100 % duty cycle white signal (3) Warm up: more than 30 minutes after power on with signal supplied.
  • Page 101 Meridian 3 101 y = 0.306 ± 0.02 7500K x = 0.298 ± 0.02 PerfecTune II y = 0.314 ± 0.02 6500K/sRGB x = 0.313 ± 0.02 PerfecTune II y = 0.329 ± 0.02 sRGB x = 0.313 ± 0.02 PerfecTune II y = 0.329 ±...
  • Page 102 Base / Pedestal to be Flame Retardant UL 94-HB. All major plastic parts (bezel, back cover) need to be molded from same resin. Plastic resin type selection should be referred to “plastic-Philips Pool monitor”. Texture/Glossing of housing The texture area and texture no should follow Philips make-up sheet.
  • Page 103 MMD request metal plate in Kensington hole. Label Regulatory label / Carton label should follow Philips requirement. Detail document refer to Philips Engineering Reference Book. Product dimension / Weight ( Refer to Philips approved SHT 191/SHT560 ) Unit dimension Packed unit dimension: Net weight...
  • Page 104 3. Cold Drop test (for design reference) Un-package test 1. Sine vibration (operating) 2. Half sine shock test (non operation) Pallet / Container loading (Refer to Philips approved SHT 560) Transportation standards refer to TYE-M0002 ,UAN-D1534 and UAW-0309. Air shipment - Sea container 20'(pallet/slip sheet)
  • Page 105 Meridian 3 105 - Humidity : 95% max - Altitude : 0-12192m - Air pressure : 300-1100 mBAR Note: recommend at 5 to 35 C, Humidity less than 60 % 7.2Transportation tests Refer to 5.15.2 7.3Display disturbances from external environment According to IEC 801-2 for ESD disturbances 7.4 Display disturbances to external environment...
  • Page 106 4. When the HV circuitry is operating properly there is no possibility of an x- tube must be the same type as the original, including suffix letter, or a Philips radiation problem. High voltage should always be kept at the manufacturer's approved type.

This manual is also suitable for:
