INSTALLATION AND OPERATING
INSTRUCTIONS
COLD WATER START & COLD WATER RUN
For Hi Delta & MVB
Heaters & Boilers
This manual should be maintained in legible condition and kept adjacent to the heater or in another safe place
for future reference.
Catalog No: 1000.57A
Effective: 02-28-07
Replaces: 02-24-06
P/N 241275 Rev. 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 241275 and is the answer not in the manual?

Questions and answers

Summary of Contents for Raypak 241275

  • Page 1 For Hi Delta & MVB Heaters & Boilers This manual should be maintained in legible condition and kept adjacent to the heater or in another safe place for future reference. Catalog No: 1000.57A Effective: 02-28-07 Replaces: 02-24-06 P/N 241275 Rev. 2...
  • Page 3: General Safety

    GENERAL SAFETY To meet commercial hot water use needs, the high limit safety control on this water heater is adjustable up to 210°F. However, water temperatures over 125°F can cause instant severe burns or death from scalds. When supplying general purpose hot water, the rec- ommended initial setting for the temperature control is 125°F.
  • Page 4: Installation

    COLD WATER START Before arriving at the job site to begin the installation, it's important to first inspect the system and determine what materials you will need. Some parts are includ- ed with the controller while others you will need to provide.
  • Page 5: Operation

    1. CALL FOR HEAT LED on PCB illuminates GREEN. 2. START UP MODE LED on PCB illuminates YEL- LOW. Before 7 minutes it should go out if boiler inlet temperature is approaching the set point tem- perature.
  • Page 6 NOTE: The minimum return water temperature to the heater to prevent condensate is 105°F on stan- dard heaters and 120°F on 87% Efficiency heaters. Ensure that during operation the Set Point Pot is adjusted properly. Cold Start Sequence of Operation 1) 120VAC to heater sends 120VAC to Cold Start control on terminal block 1.
  • Page 7: Troubleshooting

    Fig. 8: Elodrive Actuator — Rotation Knob Setting Fig. 9: Elodrive Actuator — Actuator Shown in Full System Flow Position NOTE: Elodrive actuator is Nema 4 rated. TROUBLESHOOTING Check your power source using a Volt-Ohm meter; check the following voltages at TB1 terminal block: TB1-1 to TB1-2 = 108 VAC Minimum, 132 VAC Maximum TB1-1 to TB1-3 = 108 VAC Minimum, 132 VAC...
  • Page 8 Cold Water Start Troubleshooting Guide...
  • Page 9 Wiring Diagram...
  • Page 10: Installation Codes

    This approach allows the full capacity of the boiler to be utilized to meet the system load, while at the same time continuously maintaining the optimum inlet water temperature to prevent con- densation.
  • Page 11: Check The Power Source

    Injection & Heater Pump Comparison — Hi Delta Heater Pump Heater Flow Temp. Rise Press. Drop Model 1262 1532 1802 2002 2072 2342 Table B: Injection and heater pump specifications Check the Power Source WARNING: Using a multi-meter, check the follow- ing voltages at the circuit breaker panel prior to con- necting any equipment.
  • Page 12: Before Starting

    Injection Pump Cover Installation Before Starting 1) Turn off power to the unit at the circuit breaker. 2) Turn off gas supply. 3) Shut off the water supply to the heater and, if nec- essary, drain water from the system. 4) Allow heater to cool down before attempting work.
  • Page 13 Fig 15: Reposition the pump body so that the electrical box points downward 3. Insert and tighten all eight (8) wrench bolts, secur- ing the pump body in place. 4. You will now be able to install the pump cover. See Fig.
  • Page 14 Typical Boiler Piping (Hi Delta shown)
  • Page 15: Start-Up Procedure

    Initiate PID pump control to achieve target inlet temperature by slowing injector pump. • Boiler ΔT will not increase during bypass operation. • If target temperature is not achieved after seven minutes from “call for heat”, the system will shut down.
  • Page 16: Wiring Diagram

    Wiring Diagram...
  • Page 17 Cold Water Run Troubleshooting Guide Does TB1 of cold run controller have 120 VAC? Step 1 Is there a Call For Heat at the heater? Is the 220VAC inverter in the Step 2 cold run controller powered? Does the cold run inverter output Step 3 12VDC from PCS to pin FS? Is 24VAC present at Poolstat...
  • Page 18: Illustrated Parts Lists

    ILLUSTRATED PARTS LISTS Cold Water Start...
  • Page 19 CALL OUT POWER SUPPLY 120VAC/12VDC TEMP SENSOR 10K (NOT SHOWN) PUMP-WATER BR 2" FLANGE, 1/4 HP PUMP-WATER CI 2" FLANGE, 1/4 HP PUMP-WATER BR 2" FLANGE, 1/2 HP PUMP-WATER CI 2" FLANGE, 1/2 HP PUMP-WATER BR 2-1/2" FLANGE, 3/4 HP PUMP-WATER CI 2-1/2"...
  • Page 20 Cold Water Run...
  • Page 21 CALL TEMPERATURE SENSOR 10K (NOT SHOWN) " 2 " 2 PUMP-WATER BR 2-1/2" FLANGE, 3/4 HP PUMP-WATER CI 2-1/2" FLANGE, 3/4 HP " 2 INJECTOR PUMP, BR 302B-902B (NOT SHOWN) INJECTOR PUMP, CI 302B-902B (NOT SHOWN) INJECTOR PUMP, BR 992B-1802B (NOT SHOWN) INJECTOR PUMP, CI 992B-1802B (NOT SHOWN) INJECTOR PUMP, BR 2002B-2342B (NOT SHOWN) INJECTOR PUMP, CI 2002B-2342B (NOT SHOWN)
