OWNER’S MANUAL DRYER Before beginning installation, read these instructions carefully. This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. TD-C80NPW TD-C90NPE MFL67653085 www.lg.com Rev.00_060116...
TABLE OF CONTENTS This manual may contain images or content different from the model you purchased. This manual is subject to revision by the manufacturer. SAFETY INSTRUCTIONS ............03 IMPORTANT SAFETY INSTRUCTIONS ..........03 INSTALLATION ................09 Specifications ................... 09 Accessories (Optional) ................09 Installation Place Requirements ...............
SAFETY INSTRUCTIONS The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. This symbol is displayed to the indicate matters and operations that can cause risk.
Page 4
Installation • Make sure the appliance is properly installed, grounded, and adjusted by qualified service personnel according to the installation instructions. • Never attempt to operate this appliance if it is damaged, malfunctioning, partially disassembled, or has missing or broken parts, including a damaged cord or plug.
Page 5
• Improper connection of the equipment-grounding conductor can result in risk of electric shock. Check with a qualified electrician or service person if you are in doubt as to whether the appliance is properly grounded. • Do not modify the plug provided with the appliance. If it does not fit the outlet, have a proper outlet installed by a qualified electrician.
Page 6
• In case of flood, disconnect the power plug and contact the LG Electronics customer information centre. • Do not push down on the door excessively, when the appliance door is open. • Use new hose or hose-set supplied with the appliance. Reusing old hoses can cause a water leak and subsequent property damage.
Page 7
• Never unplug the appliance by pulling on the power cable. Always grip the power plug firmly and pull straight out from the socket outlet. Technical Safety for Using the Appliance • Do not dry unwashed items in the appliance. •...
Page 8
• Remove clothes from the product immediately when drying is complete or the power is turned off during the drying process. Leaving clothes that has been dried in the appliance unattended could result in fire. Clothes removed from the appliance after drying could result in fire.
Max. capacity 8 kg • Appearance and specifications may vary without notice to improve the quality of the appliance. Accessories (Optional) Please contact the LG Electronics Customer Information Centre for purchase. Condensing Drain Hose Dry Rack Stacking Kit and Hose Holder...
Installation Place Requirements Positioning Location • Install the appliance on a flat hard floor. • Make sure that air circulation around the appliance is not impeded by carpets, rugs, etc. • Never try to correct any unevenness in the floor with pieces of wood, cardboard or similar materials under the appliance.
• Avoid installing the appliance around a heat source.The rear side of the appliance must Your dryer can be placed on top of an LG front be well ventilated. Failure to follow these loader washing machine and securely fixed with a instructions may result in problems.
Installation Procedure WARNING • Incorrect installation can cause serious Place the LG dryer on the LG washing accidents. machine. • The weight of the appliance and the height of installation make the stacking procedure too Remove the two screws from the bottom of risky for one person.
Page 13
Condensed Water Drain-out Leveling the Appliance Normally, condensed water is pumped up to the Leveling the appliance prevents unnecessary noise water container where water is collected until and vibration. Place the appliance on a solid, level manually emptied. Water can also be drained out floor.
OPERATION Using the Appliance CAUTION Before the first cycle, set the appliance to dry for • Be careful not to trap laundry between the door five minutes to warm up the drum. Open the door and rubber seal. between loads the first few times you use the appliance to allow any odours from the interior of Turn the power on.
Rubber and Plastics CAUTION • Be careful! The drum inside may still be hot. Do not dry any items made from or containing rubber or plastics such as: • The appliance must not be used for purposes other than those for which it was designed. –...
Control Panel Power button Display • Press the Power button to turn power on : This icon indicates that the lint filter • and off. should be cleaned or is clogged. • Press the Power button to cancel the – Cleaning notice: When you press the Time Delay function.
Programme Table Drying Programme Sensor Dry Programmes Programme Laundry Type Detail Drying Level Towels, dressing gowns and bed For thick and quilted fabrics Extra linen Terry towels, tea towels, towels For thick and quilted fabrics that Very and bed linen do not need to be ironed Bath towels, tea towels, For fabrics that do not need to be...
Page 18
Sensor Dry Programmes Programme Laundry Type Detail Drying Level For cotton fabrics which do not Cotton Soft T-shirts, pillowcase, and towels need to be ironed Sports Soccer kit and training wear For polyester material Wear Linen and towels (excluding For small loads of suitable fabrics Quick Dry delicate fabrics) sports wear, with short drying times...
Option Cycle Drum Light Whilst the appliance is running it is possible to Time Delay see inside the drum if you select the Drum Light function. You can use the Time Delay option to delay the • Light on : Door is opened. finishing time of the drying cycle.
Damp Dry Beep Child Lock ( With this option, the appliance will beep when the Select this function to lock the buttons on the load is ready for ironing. control panel to prevent tampering. This allows you to remove faster-drying lightweight items or items that you would like to iron or hang Locking the control panel while still slightly damp.
Rack Dry (Optional) Close the door. The dryer rack is placed inside the appliance, as in the picture below. Remove and discard packing Turn power on and select Rack Dry. material before use. The Rack Dry is designed for use with laundry that must be dried flat, without tumbling, including Press the Start/Pause button.
Installation of the application • The content found in this manual may differ depending on the version of LG Smart • Search LG Smart Laundry&DW Global on the Laundry&DW Global application, and it may be Google Play Store from your smart phone.
Use this function if you need an accurate diagnosis for analysis at the call to the LG Electronics by an LG Electronics Customer Information Centre Customer Information Centre.
MAINTENANCE Dry the lint filter completely, close and reinsert WARNING the lint filter. • Remove the power plug when you clean the appliance. Not removing the plug may result in electric shock. Cleaning the Lint Filter Clean the lint filter before each drying cycle. It should also be cleaned if the icon becomes illuminated and the buzzer sounds while the...
Emptying the Water Container Cleaning the Cool Air Inlet Grill Condensed water is collected in the water Vacuum the Cool Air Inlet grill 3 - 4 times a year container. to make sure there is no build up of lint or dirt that may cause improper air flow.
Cleaning the Condenser Clean the condenser thoroughly under a tap, letting the water flow through. The condenser is also a very important part for efficient drying performance result, so it needs special care from you. It is recommended that the condenser be cleaned three or four times a year or when the icon blinks.
TROUBLESHOOTING The appliance is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If the appliance does not function properly or does not function at all, check the following before you call for service: Diagnosing Problems Symptoms Reason...
Page 28
Symptoms Reason Solution • Reset circuit breaker or replace fuse. House fuse is blown, circuit Do not increase fuse capacity. If the breaker has tripped, or power problem is a circuit overload, have it outage has occurred. corrected by a qualified electrician. •...
Page 29
Symptoms Reason Solution • Over drying a load of laundry can Clothes have dried too long lead to wrinkled clothes. Try a shorter (overdried). drying time. Clothes are wrinkled Clothes have been left in the appliance for too long after •...
Page 30
If water leaks continuously, is caught in the door. contact the LG Electronics Customer Information Centre. • If items are too tightly packed or too sparse the sensor may have trouble reading the dryness level of the load.
Error Codes Symptoms Reason Solution The door has been opened while the appliance is in • Close the door completely. operation or the appliance is • If dE is not released, call for service. being operated without the door being closed properly. Temperature Sensor has •...
