Figure 9. Initial Setup
Setup
1. Plug in camera
2. Plug in LAN
3. Plug in power
4. Turn on
(wait for Home
screen, see Fig. 1)
5. Goto LAN IP Screen
(see Fig. 4)
6. Open web browser
7. Enter LAN IP on
address line
8. On web page, press
'Metadata' button*
9. Enter metadata
(see
Figs. 9 and 10)
*
Item #8 is not shown in this picture
Figure 10. Streambox Micro Access
Editing Metadata
(Step 1)
1. Find the LAN IP
(for initial setup – see Fig. 4)
2. Open web browser on same network
3. Enter LAN IP address on address line
you directly with the Micro/Drone)
4. Click Metadata button
5. Go to Fig. 11
Video
Camera
3
(this connects
2
1
3
4
8
