Streambox Chroma User Manual

Hd/uhd/4k rackmount encoder and decoder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HD/UHD/4K Rackmount
Encoder and Decoder
User Manual
August 2019 v0.3 LN/DB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Chroma and is the answer not in the manual?

Questions and answers

Related Manuals for Streambox Chroma

Summary of Contents for Streambox Chroma

  • Page 1 HD/UHD/4K Rackmount Encoder and Decoder User Manual August 2019 v0.3 LN/DB...
  • Page 2 With optional hardware and software upgrades, Chroma can utilize such features as 4:4:4 12-bit Color depth, Rec.709, Rec.2020, DCI-P3, XYZ and RGB color spaces, and 2K/4K video, with support for HDR and HFR video, as well as up to 16 channels of PCM audio.

  • Page 3: Solution Features

    ✔ Workflow support from capture to playback with either a hardware Decoder or media player ✔ Integration with Streambox Enterprise Server and Cloud Service for video routing of live streams ✔ Supports file-based streaming from Streambox Enterprise Server or Cloud Services to Decoder or media player ✔...

  • Page 4: Specifications

    3 Specifications Hardware ● Size: 1 Rack Unit: W48.2cm x D28.2cm x H44.0cm (19in x 11in x 1.7in) ● Weight: 4.7kg (10.5lbs) ● Power: 100-240 VAC, 160 W ● 2x 1000Mbps RJ-45 Ethernet ports ● HDMI Monitor Output (for terminal access) ●...

  • Page 5: Input Resolutions

    Supported Encoder Video Inputs Input Resolutions Input Frame rates (fps) SD: 29.97 (NTSC); 25 (PAL) SD NTSC and PAL HD: 50, 59.94 (720p, 1080i), 23.98, 24, HD 720p, 1080i, 1080p, 25, 29.97, 30 (1080p); 23.98, 24 1080psf (1080psf) 2K DCI (2048x1080) 23.98, 24 (2K DCI) UHD (3840 x 2160) 23.98, 23.98psf, 24 (3D)

  • Page 6: Front Panel

    4 Hardware Streambox Chroma is available in 3 main models: HD, UHD, and 4K, with some additional upgraded versions such as the 12G-SDI version, available. Furthermore, each of the 3 models is available in an Encoder version and a Decoder-only version. The Encoder versions can be switched into Decoder mode, in a half-duplex fashion: the unit can be anEncoder or a Decoder, but not both at the same time.
  • Page 7 The title bar contains the Streambox logo, product information, and important information about the Streambox stream. 5.3 Info Page The Info page is the main interface for Streambox Chroma Encoder and provides an instant view of the current video and network settings.
  • Page 8 Figure 2: Encoder Web UI Info Page Video The video section shows a scaled down preview of the video input to assist in verifying the video input signal. ​ Preview Update: W ith these buttons, you can select the frequency with which the picture will be updated. Spot ​...

  • Page 9: Network Page

    Network Encoder IP​ : IP address that the Encoder is using to send data from (source address) Decoder IP:​ IP address that the Encoder is using to send data to (destination address) Packet Size (MTU):​ IP Packet size (default = 1392) ​...
  • Page 10 Decoder when shuffle is enabled: buffer/jitter size in packets = FEC packets X shuffle size Protocol Streambox offers two types of Transport Protocol for streaming, UDP and LDMP. Both use the UDP network protocol. LDMP is a Streambox-proprietary protocol which uses 2-way UDP streaming. ●...

  • Page 11: Config Page

    HD, then the list will include possible resolutions for HD (vs SD, UHD, 4K, etc.). ​ Color Profile: T he video color profile specifies the detail level at which the Streambox Encoder captures color data. ​ Frame-rate: T he frame rate at which the ACT-L3 or ACT-L5 encodes video may be adjusted below full frame rate.
  • Page 12 ​ Advanced Profile (AP): T his feature allows improved quality for low delay application. Instead of sending single big iFrame, the encoder spreads keyframe in a left-to-right pattern, producing slightly lower delay and more graceful image recovery. This is more useful for lower bitrates, below 12 Mbps. ​...

  • Page 13: Accounts Page

    When streaming to Streambox Cloud, it’s recommended that the Reporter field be filled in. Note that DRM is the same as “Group” as seen in other Streambox products. This field is necessary for use with Streambox servers, such as Streambox Cloud Services. It is changed in the System tab.
  • Page 14 Check the box to enable encryption, and a field will appear in which to enter your Crypto-Key. This key is not given by Streambox, but rather is the shared-secret phrase that sender and receiver must use. We recommend that you use both letters and numbers in your crypto-key.
  • Page 15 D igital rights management (DRM) is the account designation assigned by Streambox. It is also called Group or Network 1 in other Streambox products. This metadata field is necessary for streaming to Streambox Cloud or Streambox Enterprise Server. When using the Sessions feature of Streambox Cloud, you enter the...
  • Page 16 Figure 11 Features Page The Features tab appears on the Navbar when opened from the System tab. It displays which features are enabled on the Chroma, and can also indicate expiration dates for features that have a time limit. System Info This section displays some hardware specifications of the Chroma, including Serial Number, CPU specs, memory, and info about the video card.
  • Page 17 Features This chart lists the available features for the hardware, and indicates which ones are activated. Consult the key in the Activation section of this same page. Not all Chroma hardware can support all listed features. 5.12 Log Page The log page is where the user can preview and download the Decoder application log. This tool is used to assist in troubleshooting possible issues.
  • Page 18 6 Decoder Web Administration The Streambox Decoder is also equipped with a web management feature. This allows easy control from any computer with network access to the unit. The web interface allows dynamic updates of the web interface so that information is updated without having to refresh the page. The web interface can be accessed by connecting to the IP address of the Streambox ACT-L3/L5 Decoder using a web browser.
  • Page 19 (or any descriptive text entered by the user) Connectivity:​ the type of connection used to transport the ACT-L3/L5 Stream Reporter:​ the name of the user operating the Streambox ACT-L3/L5 Encoder (or any descriptive text entered by the user)
  • Page 20 : the name of the producer (or any descriptive text entered by the user) Latitude:​ the latitude of the Streambox ACT-L3/L5 Encoder (supported by some mobile Streambox units) Longitude:​ the longitude of the Streambox ACT-L3/L5 Encoder (supported by some mobile Streambox...
  • Page 21 The Interface Info section shows statistics about the individual network adapters used by the Decoder including its IP address. 6.4 Network Page The network page allows access to the network settings on the Streambox ACT-L3/L5 Decoder. Network settings affect how the Decoder handles the network data stream.
  • Page 22 The use of IP Multicast can be useful where a stream needs to be shared within a closed network; e.g., multiroom lectures or sermons. The Multicast mode must be used within a single network. A Streambox Encoder must be setup for multicasting with matching settings;...
  • Page 23 Pull Stream This section allows users of Streambox Cloud and Streambox Enterprise Server to pull streams from those servers by matching the metadata of the stream being sent to the Server. This requires credentials for the server and knowledge of the metadata, or else a Session ID.
  • Page 24 ​ SDI Output: s elects the output configuration; depending on hardware, Chroma supports 3G, 6G, and 12G SDI connections. Depending on the video resolution, up to a single 12G connection, 2x 6G connections, or 4x 3G connections may be utilized to channel the output to the output monitor.
  • Page 25 ​ Force RGB Output: E nable this to force the output to RGB even if the incoming stream was sent with a different color gamut. Output HDR metadata over HDMI:​ Enables the HDR Metadata over HDMI Genlock Settings Genlock:​ Enable two modes of genlock, Reference or Input 1, or disable genlock with the Free Run setting. Dolby Settings ​...
  • Page 26 This page allows you to start the Activation process (if you’ve paid for an activation key) and, following activation, enter a Decryption Key. This key is not given by Streambox, but rather is the shared-secret phrase that sender and receiver must use. Use letters and numbers.
  • Page 27 If the stream is Encrypted, but the Decryption Key entered by the decoder user is not a match, the status line will report ​ B ad Decryption Key​ Figure 22 Decoder Web UI Encryption Failure ​ NOTE: I f the Encoder stream is not encrypted, there is no need to clear out the Decryption Key. 6.8 System Page The system page allows system functions to be performed on the unit and it displays the serial number, version and firmware.
  • Page 28 J ump to the end of the log stored in the browser buffer ​ AUTO UPDATE: E nable the Web UI to automatically refresh your view of the log The following should only be done if requested by Streambox Support: ​ DOWNLOAD LOG FILE: D ownload the most recent log file ​...

  • Page 29: Advanced Settings

    The Advanced Mode button can be found in the System tab of both the Encoder or Decoder web UI. Advanced Mode is a legacy user interface that contains a number of items that are useful to Chroma users. In general, it should only be accessed during system setup, such as to change the IP address, during troubleshooting, or when directed to by Support.
  • Page 30 Sometimes a few frames are dropped at the start of a video capture, but as long as the number is not increasing, there is nothing to be concerned about. Following dropped frames is the​ ​ D ecoder IP​ , which is the address at which the Streambox Decoder or Streambox Media Player is receiving the live stream.
  • Page 31 URL’s to the base IP address (see example above) By default, this remote connection (via SSH) allows the Chroma to use an available network connection to connect to the Streambox Remote Configuration Server. This enables both the online remote control page at http://avenir.streambox.com/remote​...
  • Page 32 URL’s to the base IP address (see example above) /avenir/settings_encautostart.php This setting allows the user to enable or disable the option to have Chroma start streaming automatically when booting up. Enable this if the unit is used in a permanent or unattended backhaul workflow. Disable this if the Chroma is streaming to the Cloud, or used only for discrete streams.
  • Page 33 7.10 Set Metadata Navigate to ​ M etadata ​ o r directly by appending the following URL’s to the base IP address (see example above) /avenir/settings_metadata.php Set the metadata, all in one place. It should not be necessary to use this page since all settings are accessible in the Encoder web 7.11 About Navigate to ​...

  • Page 34: Initial Connections

    8 Setting up Streambox Chroma for the First Time Initial Connections Connect to LAN (Internet) connection Chroma is equipped with 2 Gigabit Ethernet ports. Net1 (left port, when facing the back) is set to use DHCP; Net2 (right port) is pre-configured as a static IP: ​ 1 0.0.4.10/24​...
  • Page 35 5. Setting the IP address There are 2 ways to set the IP address on Chroma: Using the Front Control Panel (FCP) or using the Advanced Web Interface. The latter requires web access, either through the terminal or another computer.

  • Page 36: Find The Ip Address

    5. After saving the MSK value, press the Down arrow again to set the Default Gateway, which is the address the Streambox will use to reach outside the network. Edit and Save this value as above. 6. Press Down again, and you should see either SET STATIC or CHANGE STATIC, depending on whether there’s already a static value saved.
  • Page 37 Sending Live Streams (Point-to-Point) (1770/UDP) Streambox Encoders and Decoders can send live streams over private or public IP networks. The Decoder’s IP address is fed into the Encoder’s settings so it knows where to send the stream; the Decoder’s replies and acknowledgements are sent back to the Encoder (LDMP protocol).

  • Page 38: Network Ports

    52.66.83.26 Central Asia (India) Streambox Cloud is multi-tenant service; each Decoder setting for the Cloud can be configured for specific “destination” port number, with default port UDP 1770 . Streambox Cloud will use random source port number when routing stream to remote Decoder, so ​ t he firewall rule should not restrict traffic based on source port number, but can restrict traffic based on destination port number and Source IP.
  • Page 39 2. Name the file as “sb-4k-bmp.bmp” for 4K, “chroma2k.bmp” for 2K, or “sb-hd-bmp.bmp” for HD. All 3 of those resolutions, plus their fractional resolutions, will show a version of this splash screen. 3. Save the files and contact Streambox Support to assist you with uploading the files to their appropriate location.
