Streambox AVENIRMicro Quick Start Manual page 4

Figure 2. Upside‐down View
Right‐side Up View
Top action item is associated with the top button
(green). Bottom action item is associated with bottom
button (blue).
Upside Down View
When a Micro or Drone is flipped upside‐down, the LCD
display is rotated so the text is always right‐side‐up. The
buttons will match the action times (compare green
and blue arrows in both orientations).
Figure 3. Custom Start Streaming
Custom Preset
Pressing the INFO button for 2 seconds on the
Home screen will initiate live streaming
(see Fig. 1)
using the values set by the Custom Preset option
(within the Web interface)
ABN Preset (Automatic Bandwidth Negotiations)
Pressing the START button for 2 seconds on the
Home screen will initiate live streaming
(see Fig. 1)
using an automated process to determine the best
bandwidth. Press ACCEPT when an acceptable
bandwidth has been reach or you can allow ABN
the full time to determine the best bandwidth
available (in this case there is 13 seconds left in the
process).
4
