Manual
Enter Serial No. here
MANUAL No.Y-DN-06E
In the event of an enquiry please quote this serial number.
Store this document safely and ensure it is available at all times.
Non-availability may affect the service / repair of your machine.
OPERATING AND MAINTENANCE MANUAL
ELECTRONIC DOUGHNUT JAMMER
ONLY FOR USE WITH SEEDLESS FILLINGS
FG053 -JAMMER 22-08-14 Rev A14
1
Advertisement
Table of Contents
Related Manuals for Mono FG053
Summary of Contents for Mono FG053
- Page 1 Store this document safely and ensure it is available at all times. Non-availability may affect the service / repair of your machine. OPERATING AND MAINTENANCE MANUAL ELECTRONIC DOUGHNUT JAMMER ONLY FOR USE WITH SEEDLESS FILLINGS FG053 -JAMMER 22-08-14 Rev A14...
- Page 2 FG053 -JAMMER 22-08-14 Rev A14...
- Page 3 Failure to adhere to the cleaning and maintenance instructions detailed in this booklet could affect the warranty of this machine ONLY FOR USE WITH SEEDLESS FILLINGS FG053 -JAMMER 22-08-14 Rev A14...
-
Page 4: Table Of Contents
INDEX INTRODUCTION DIMENSIONS SPECIFICATIONS SAFETY INSTALLATION ISOLATION CLEANING INSTRUCTIONS OPERATING CONDITIONS OPERATING INSTRUCTIONS 10.0 SETTING 11.0 MAINTENANCE 12.0 PROBLEM SOLVING 13.0 SPARES AND SERVICE 14.0 ELECTRICS FG053 -JAMMER 22-08-14 Rev A14... -
Page 5: Introduction
INTRODUCTION Mono’s electronic filler can fill doughnuts and pastries two at a time without mess or waste. Fillings are precisely dispensed through dual nozzles in variable, preset amounts. To change fillings halfway through a run – just lift the filler unit from the console and replace it with another unit containing the new filling. -
Page 6: Specifications
Only to be used with seedless jams and fillings ELECTRICAL REQUIREMENTS See serial plate for machine version. 240volt 1 phase 50Hz total power 60Watts 0.3amps 120volt 1 phase 50Hz total power 60Watts 1.5amps NOISE LEVEL Less than 85dB FG053 -JAMMER 22-08-14 Rev A14... -
Page 7: Safety
Cables should be checked regularly for damage (checks should be made with the cable disconnected from the mains). Damaged cables should be taken out of service straight away. Do not carry out makeshift repairs to cables Loose or damaged plugs must be replaced immediately. FG053 -JAMMER 22-08-14 Rev A14... -
Page 8: Installation
INSTALLATION The Mono electronic doughnut jammer should be plugged into a 13-amp wall socket. For best results the Electronic jammer should be used on a flat surface. ISOLATION TO STOP THE ELECTRONIC JAMMER IN AN EMERGENCY SWITCH OFF AT THE WALL SOCKET. -
Page 9: Cleaning Instructions
These screws should only be finger tight as the use of tools to over tighten could lead to the chamber cover fracturing. Wipe over all external surfaces with mild detergent/sanitiser and hot water. Never immerse the base console in water. FG053 -JAMMER 22-08-14 Rev A14... -
Page 10: Operating Conditions
“FAST FORWARD” on the membrane panel to advance the digital display to any number. Then touch the actuator tray to cycle the hopper drive which will allow the hopper to drop into place. The machine is now ready for use FG053 -JAMMER 22-08-14 Rev A14... -
Page 11: Setting
When finished the machine is turned off by pressing the red (4) panel. Be aware that if the actuator tray is operated, filling will be dispensed out of the nozzles FG053 -JAMMER 22-08-14 Rev A14... -
Page 12: Maintenance
11.0 MAINTENANCE By keeping the machine cleaned after every use it should operate smoothly, hygienically and economically. No other maintenance should be required. FG053 -JAMMER 22-08-14 Rev A14... -
Page 13: Problem Solving
Check that the pump plate seal (1) has not been left out after cleaning. Check that pump assembly is not damaged. Check that the thumbscrews (2) are tight but not over-tight (finger-tight only) If machine still has a problem please contact Mono Service Dept. (see last page). FG053 -JAMMER 22-08-14 Rev A14... -
Page 14: Spares And Service
13.0 SPARES AND SERVICE If a fault arises please contact MONO customer service dept. (see last page of manual) FG053 -JAMMER 22-08-14 Rev A14... -
Page 15: Electrics
14.0 ELECTRICAL INFORMATION FG053 -JAMMER 22-08-14 Rev A14... - Page 16 FG053 -JAMMER 22-08-14 Rev A14...
- Page 17 FG053 -JAMMER 22-08-14 Rev A14...
- Page 18 MONO Queensway Swansea West Industrial Estate Swansea. SA5 4EB email:spares@monoequip.com Spares Tel. +44(0)1792 564039 Web site:www.monoequip.com Tel. +44(0)1792 561234 Fax. 01792 561016 FG053 -JAMMER 22-08-14 Rev A14...
