- Page 1 Grand Rapids, Michigan, U.S.A. 49504-5298 USER’S OPERATING AND INSTRUCTION MANUAL MODEL 1308-C & 1308-N HEAT SEALER 1308S20000CV1...
- Page 2 Cleaning Cutter Blade------------------------------------------------------------------------------------ 7-2 Replacing and Checking Gaskets---------------------------------------------------------------------- 7-3 Disposal Procedure---------------------------------------------------------------------------------------- 7-3 TROUBLE SHOOTING---------------------------------------------1308S20020---------------------------8-1 WIRING DIAGRAM--------------------------------------------------1308S20021---------------------------9-1 1308-C HEAT SEALER---------------------------------------------1308S20022--------------------------10-1 1308 Heat Sealer Parts Lists----------------------------------------------------------------------------10-2 1308 Heat Sealer Parts Lists Con’t--------------------------------------------------------------------10-3 1308 Tray Carrier-------------------------------------------------------------------------------------------10-4 1308 Tray Carrier Parts List------- ----------------------------------------------------------------------10-4 WARRANTY ------------------------------------------------------- GEN 050816...
-
Page 3: Description/Specifications
DESCRIPTION/SPECIFICATIONS Description The Oliver Model 1308 Heat Sealer is designed and manufactured to ensure a user friendly operation of producing film lidded trays with a cost effective approach. The manually operated machine operates with either a 120 or 230 V.A.C. outlet. The machine was designed to be compact to limit the amount of table space needed to operate. -
Page 4: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS WARNING IT IS ESSENTIAL THAT ALL OPERATORS AND MAINTENANCE PERSONNEL OBSERVE THE FOLLOWING SAFETY PRECAUTIONS. IMPROPER INSTALLATION, MAINTENANCE, OR OPERATION OF THIS EQUIPMENT MAY CAUSE SERIOUS INJURY. 1. Read this manual before attempting to operate your heat sealer. Never allow an untrained person to operate or service this unit. -
Page 5: Part Description
BAKERY 35804 AR Venray, PRODUCTS The Netherlands MODEL NO. SERIAL NO. VOLTAGE CYCLE PHASE AMPS MFG’D MASS “OLIVER” 6401-5076 “STAY CLEAR” 6401-9043 “CONSULT OPERATORS…..” 6400-3039 “ELECTRICAL SHOCK” 6400-5009 “UNPLUG BEFORE OPENING” 6402-1028 “HOT SURFACE” 6400-8021 **SEE SHEET 3-2 FOR NAMEPLATE LOCATIONS BY ITEM NUMBER... - Page 6 NAMEPLATE/PICTOGRAM LOCATIONS BY ITEM NUMBER 1308S20015...
-
Page 11: Operating Procedures
OPERATING PROCEDURES 1. Plug the power cord into a properly grounded outlet. Avoid the use of extension cords. 2. Pusher rocker switch to “On” position (red light indicates on). NOTE: It should take approximately 15 minutes for the machine to warm up to operating temperature. - Page 12 ADJUSTMENT AND QUALITY Your OLIVER Model 1308 was tested at the factory using Oliver trays and film. NOTE • THE TEMPERATURE CANNOT BE ADJUSTED BY THE OPERTATOR The heater platen temperature is factory set at approximately 300°F (Approx. 150°C). Contact the Oliver Service Department if you suspect the heated platen temperature is not correct.
- Page 13 BASIC MACHINE COMPONENTS AND SET UP Before proceeding further, take a moment to familiarize yourself with the identification of the machine components as shown in the illustration below. SET UP 1. Carefully remove the Model 1308 from the box. Check to make sure the order is complete, and it has not been damaged during shipment.
- Page 14 SET UP CONTIUED NOTE: FILM SUPPLIED BY OLIVER PRODUCTS COMPANY IS WOUND WITH THE ADHEASIVE SIDE IN. FEED FILM FROM THE TOP OF THE ROLL AS SHOWN. 1308S20016...
-
Page 15: Cleaning And Maintenance
It is important that the surface of the heater platen is kept clean and smooth. Regularly clean the OLIVER Model 1308 with a mild cleaner and a damp cloth. If food product comes in contact with the surface of the platen, it tends to burn on and become hard. -
Page 16: Cleaning Procedures
CLEANING AND MAINTENANCE CONTINUED CLEANING PROCEDURES 1. Unplug the unit and allow one hour for cooling. 2. Remove tray carrier. 3. Place tray carrier in the dishwasher or wipe down with a standard cleaning solution. 4. Lift operating handle to expose the bottom side of the heater, and then wipe off the heater platen. -
Page 17: Disposal Procedure
CLEANING AND MAINTENANCE CONTINUED REPLACING AND CHECKING GASKETS • If there are any gouges, cuts or gaps in the gasket, the gasket will have to be replaced. • Be sure to replace all the gaskets not just the piece that is damaged. •... -
Page 18: Wiring Diagram
WIRING DIAGRAM 1-60-120V REF. W/D 1308C12002 1-60-230V REF. W/D 1308C12000 1308S20021... - Page 19 MODEL 1308 HEAT SEALER Rev 8-15-09 1308S20022 10-1...
-
Page 20: Part Description
MODEL 1308 HEAT SEALER PARTS LISTS ITEM NO PART DESCRIPTION PART NUMBER______QTY Base 1308-0015-301 Bumper-Rubber 5902-0035 PIN-DOWEL 1/4X3/4" STST 5835-6475 Tube-Aluminum 7/8” O.D. 4639-1414-1116 Bearing-Roll End 5252-3002 Guide-Roller Film 1908-0041 O-ring 6909-3211 Rod-Film Dispensing 1308-0018 SCREW-SOCSET CUPPT 5842-6120 Tube-Film Shaft 1308-0016 WASHER-FLAT 5851-9306... - Page 21 PARTS LIST CONTINUED ITEM NO PART DESCRIPTION PART NUMBER______QTY Shaft-Mid Pivot 1308-0002-001 PLUG-HOLE DOME WHITE 3/16" 5769-3000 Weight-Counter 1308-0042-1 Counter Weight 1308-0065 COVER-CLAMP 1908-0262 Assembly-Handle 1308-0500-1 Shaft-Handle Pivot 1308-0007-001 BEARING SINT BRZ SLV 5254-0306 Platen-120V Heater 1308-0062 Platen-230V Heater 1308-0061-002 Spring-Compression 7015-2200 Blade-Cutting...
- Page 22 PARTS LIST CONTINUED ITEM NO PART DESCRIPTION PART NUMBER______QTY Bar-Pusher 1308-0057 Bolt-Carriage ½-13 x 4-1/2” 5804-1722 NUT-ACORN STD 1/2"-13 5831-8100 NUT-HEX FULL 1/2-13 5832-0524 WASHER-1/2" SPRING LOCK 5851-9011 WASHER-7/16" FLAT 5851-9307 Box-Relief 1308-0059 Bushing-Strain Relief 5765-1110 Nut-Hex Head Lock (PG-11) 5766-7786 SCREW-ROUND HD 6-32 5843-5210...
- Page 23 ** Cushions differ from tray carrier to tray carrier. The cushion that is used is determined by the engineer during the design process. FOR SERVICE PARTS CALL OLIVER PRODUCTS @ 800-253-3893 Rev 8-15-09 1308S20022...
