- Page 1 This document is hosted by Old Will Knott Scales www.oldwillknottscales.com Adam Equipment ADAM THERMAL PRINTER 3126611270 (P.N. Revision B, August 2011) © Adam Equipment Company 2011...
- Page 2 Model of the product linked to this printer: Software revision number of the product linked to the printer: Serial number of the product linked to the printer: Date of Purchase: Name of the supplier and place: © Adam Equipment Company 2011...
-
Page 3: Table Of Contents
TECHNICAL SPECIFICATIONS ................4 PRINTER INSTALLATION AND OPERATION.............6 Packing List ......................6 Printer connection ....................7 PAPER ROLL INSTALLATION ................8 FRONT PANEL DESCRIPTIONS .................8 SERIAL INTERFACE .....................9 BAUD RATE SETTING INSTRUCTIONS……………………………………………12 COMMAND FUNCTION LIST ................113 WARRANTY INFORMATION..................124 © Adam Equipment Company 2011... - Page 4 RS-232 interface found on the Adam balances but can easily be changed to work on other equipment as well. • The printer is easy to use with only an On/Off switch and a paper feed button. © Adam Equipment Company 2011...
- Page 5 Clean the print head regularly to avoid poor print quality, only attempt to clean when the printer is off and the head has had time to cool. Clean with a soft cloth using diluted alcohol. © Adam Equipment Company 2011...
-
Page 6: Technical Specifications
9600bps、19200bps、38400bps，57600, 115200, default is at 4800bps, data structure no parity, 8 digital word size,1 digital stop bit, supports RTS/CTS and XON/XOFF handshake protocol. Cash drawer： 6 wire RJ-11 socket， DC 12V/1A output signal to drive the cash drawer. © Adam Equipment Company 2011... - Page 7 Box of 20 – part number 3126011282 ● Printer power adaptor: Adaptor input voltage：AC 110V/220V，50～60Hz Adaptor output voltage：DC 8.5V/3A ● Printer weight：0.8kg ● Overall dimensions： 114（W）× 184（D）× 90（H）mm ● Working temperature: 0～45ºC Working relative humidity：10～80% © Adam Equipment Company 2011...
-
Page 8: Printer Installation And Operation
Power Adaptor Module 3124011269 Mains cable Country dependant RS 232 (25 pin to 9 pin) 3124011279 cable - female RS 232 (25 pin to 9 pin) 3124011273 cable - male Thermal paper 3126011263 Manual 3126611270 © Adam Equipment Company 2011... -
Page 9: Printer Connection
The RJ-11 jack is for use when connecting the printer to a cash drawer. Connect the Power adaptor to the printer and electricity supply (c) Turn the printer on using the ON/OFF switch located at the rear of the printer © Adam Equipment Company 2011... -
Page 10: Paper Roll Installation
POWER light： ： ： ： Power light to indicate POWER is supplied to the printer ERROR light：To indicate a paper jam or problem with printing PAPER light: To indicate the printer is out of paper © Adam Equipment Company 2011... -
Page 11: Serial Interface
—— Printer Same with RTS signal(pin 4) All Adam Equipment scales and balances use a 3 wire cable connection which includes TXD, RXD and GND. DTR and RTS are not required Printer serial interface DB-25 Host machine serial interface DB-9... -
Page 12: Baud Rate Setting Instructions
6. ATP BAUD RATE SETTING INSTRUCTIONS Please contact Adam Equipment to obtain the application tool required Connect the ATP to your PC using the cable provided Power ON the ATP Open the ATP baud rate setting application Select the COM port that your PC is using... -
Page 13: Command Function List
Set line feed amount 15 ESC ? n Delete download characters 16 ESC @ Initialize printer 17 ESC D Set horizontal tab position 18 ESC E n Specify/cancel emphasized characters 19 ESC J n Print and Paper Feed © Adam Equipment Company 2011... -
Page 14: Warranty Information
WARRANTY INFORMATION Adam Equipment offers Limited Warranty (Parts and Labour) for the components failed due to defects in materials or workmanship. Warranty starts from the date of delivery. During the warranty period, should any repairs be necessary, the purchaser must inform its supplier or Adam Equipment Company. - Page 15 Shielded interconnect cables must be employed with this equipment to insure compliance with the pertinent RF emission limits governing this device. Changes or modifications not expressly approved by Adam Equipment could void the user's authority to operate the equipment. WEEE COMPLIANCE...
- Page 16 All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior permission of Adam Equipment. Adam Equipment reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
