- Page 1 Adam Equipment ADAM STATISTICS PRINTER ADAM EQUIPMENT CO. LTD. p.n. 3778, Rev. F1, January 2004 © Adam Equipment Company 2004...
- Page 2 © Adam Equipment Company 2004...
-
Page 3: Table Of Contents
CONTENTS ADAM PRINTER WITH STATISTICS..............2 SPECIFICATIONS ...................2 PAPER LOADING ...................3 CONFIGURATION...................4 INTERFACE ....................5 STATISTICS OPERATION................6 NORMAL PRINTING ..................8 SETTING DATE AND TIME ................8 © Adam Equipment Company 2004... -
Page 4: Adam Printer With Statistics
20 meter roll maximum diameter 48mm. Size 60 x 180 x 150mm 0.6kg Interface RS-232 or RS-242 (TTL) 5 pin DIN Connector 1200, 2400, 4800 or 9600 baud 8 bit or 7 bit With or without parity © Adam Equipment Company 2004... -
Page 5: Paper Loading
If the paper does not feed easily check whether you are using the paper entry slot and there are no obstructions in the paper path. Configuration Dip-Sw itch Paper Loading Note direction of paper roll © Adam Equipment Company 2004... -
Page 6: Configuration
Date/time enabled* Parity Odd Date/Time not printed 80 column Print all statistics* 40 column Print only number of readings and total High Quality Print (slow) High Quality Print (slow) Normal Print (fast) Normal Print (fast)* © Adam Equipment Company 2004... -
Page 7: Interface
Pin 1 Not used by Adam balances Pin 3 GND ----------- Pin 5 Signal ground Pin 4 nu Pin 5 TXD ----------- Pin 2 Data to scale Pin 7 Connected to Pin 8 Pin 4 Connected to Pin 6 © Adam Equipment Company 2004... -
Page 8: Statistics Operation
Press [Print] to get a Statistics Report PRINT + PF Start a new Series by holding [Print] then pressing the [Paper Feed] switch PF + PRINT Continue by holding [Paper Feed] then pressing the [Print] switch © Adam Equipment Company 2004... - Page 9 * Data Error * will be printed. If the message does not get cleared when the balance data is sent to the printer, it may be necessary to turn the printer off and then on, before starting the data collection again. © Adam Equipment Company 2004...
-
Page 10: Normal Printing
The baud rate and parity should be as set above regardless of how the printer is configured using the dip-switches. • A program to set the date and time is available from Adam Equipment. This program will run under Windows. Contact your supplier for details. - Page 11 Shielded interconnect cables must be employed with this equipment to insure compliance with the pertinent RF emission limits governing this device. Changes or modifications not expressly approved by Adam Equipment could void the user's authority to operate the equipment. © Adam Equipment Company 2004...
- Page 12 Copyright by Adam Equipment Co. Ltd. All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior permission of Adam Equipment. Adam Equipment reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
