R-3119
INSTALLATION INSTRUCTIONS
OWNER'S MANUAL
Patent #5.664.555
AND
FAN TYPE
DIRECT VENT
WALL FURNACE
For Installation in
Manufactured (Mobile Home),
Modular or Residential Homes
MODEL
DV-55E-3
EFFECTIVE DATE
APRIL, 2001
WARNING: If not installed, operated
and maintained in accordance with the
manufacturer's instructions, this
product could expose you to substances
in fuel or from fuel combustion which
can cause death or serious illness.
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Empire Comfort Systems DV-55E-3
Summary of Contents for Empire Comfort Systems DV-55E-3
-
Page 1: Installation Instructions
Manufactured (Mobile Home), Modular or Residential Homes Patent #5.664.555 MODEL WARNING: If the information in DV-55E-3 this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. — Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. -
Page 2: Table Of Contents
TABLE OF CONTENTS Lighting Instructions ........................3 Gas Conversion Instructions ......................4 Liquefied Petroleum (Propane) Safety Information ............... 5 Specifications and Requirements....................6 Installation Location ........................... 6,7 Venting ..........................7,8 Gas Supply .......................... 8 Appliance Maintenance Information for Qualified Service Person ..........9 Maintenance Operation and Troubleshooting Guide.............. -
Page 3: Operating Instructions
FOR YOUR SAFETY READ BEFORE OPERATING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance does not have a pilot. It is equipped with •... -
Page 4: Gas Conversion Instructions
GAS CONVERSION INSTRUCTIONS Warning: Conversion must be done by a qualified service technician. Main burner orifice(s) and new gas conversion label are provided in conversion kit attached to manifold pipe. CONVERSION INSTRUCTIONS FROM (LP) PROPANE GAS TO NATURAL GAS 1. Make sure gas supply to furnace is off prior to conversion and disconnect electrical power to unit. 2. - Page 5 SAFETY INFORMATION FOR USERS OF LP-GAS Propane (LP-Gas) is a flammable gas which can cause fires by point with the members of your household. Someday when there may not be a minute to lose, everyone's safety will and explosions. In its natural state, propane is odorless and colorless.
- Page 6 Specifications Qualified Installing Agency Installation and replacement of gas piping, gas utilization equipment or Model DV-55E accessories and repair and servicing of equipment shall be performed only Input BTU/HR (KW/H) 55,000 (16.1) by a qualified agency. The term "qualified agency" means any individual, firm, corporation or company which either in person or through a Height 26"...
- Page 7 Installing Wall Bracket MAY BE 20" TO 13" MAY BE 20" TO 13" After finding a location for the furnace, gas supply and vent, the wall 20" (508mm) 20" (508mm) TO AVOID STUD TO AVOID STUD 12 5/16" 12 5/16" bracket must be positioned and installed.
-
Page 8: Location
shroud will not be able to be installed onto the side shrouds. The top shroud will appear to be 2 inches, too narrow. Vent Terminal EXHAUST AIR Place the 6 3/8" x 6 3/8" (162mm x 162mm) black foam, wall plate ORANGE SILICONE ORANGE SILICONE ELBOW CONNECTOR... -
Page 9: Appliance Maintenance Information For Qualified Service Person
(305m) above sea level, this may be accomplished by reducing A gas valve and ground joint union should be installed in the gas manifold pressure. The maximum allowable reduction in manifold line upstream of the gas control to aid in servicing. It is required pressure for Natural gas shall be from 3.5"... -
Page 10: Maintenance Operation And Troubleshooting Guide
MAINTENANCE OPERATION AND TROUBLESHOOTING GUIDE Maintenance and Service The inducer blower circuit is energized and the inducer blower Your new furnace should provide many years of trouble free comes on for 15 seconds pre-purging out any gas and closing performance, however, a yearly inspection of the burners , flue the pressure switch. -
Page 11: Control Board - Diagnostics
WIRING DIAGRAM WARNING: DISCONNECT THE ELECTRICAL POWER BEFORE SERVICING Wiring The appliance, when installed, must be electrically grounded in accor- for better room air sensing and control. dance with local codes or, in the absence of local codes, with the Replacement of Thermistor with 24 Volt Wall Thermostat National Electrical Code, ANSI/NFPA 70 or Canadian Electrical Code, 1. - Page 12 Do not order bolts, screws, washers or nuts. They are standard hardware items and can be purchased at any local hardware store. Shipments contingent upon strikes, fires and all causes beyond our control. Empire Comfort Systems, Inc. Nine Eighteen Freeburg Ave. Belleville, Illinois 62222-0529...
