Sewell HD Link Plus HL17 User Manual

Hdmi over cat5e/6
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Quick Links

Download this manual
HDlink
HDMI over Cat5e/6
User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the HD Link Plus HL17 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sewell HD Link Plus HL17

Summary of Contents for Sewell HD Link Plus HL17

  • Page 1 HDlink HDMI over Cat5e/6 User Manual...
  • Page 2 Specs -Resolution: up to 1080p @ 60Hz -50m HDMI extension (for best results, use Cat6) -Power over cable -HDMI loop out w/ EDID management -Equalizer DIP switches...
  • Page 3 Box Contents (1) User Manual (1) HD Link+ Sender (Tx) (1) HD Link+ Receiver (Rx) (2) DC 5V Power Adapter (1) IR Transmitter (1) IR Receiver...
  • Page 4 Depending on Cat5e/6 cable length, please follow this table for EQ settings. *Black area is the switch.
  • Page 5 Transmitter (Tx) Front IR Out Cat5e/6 DC5V Back HDMI In EDID HDMI Out...
  • Page 6 Receiver (Rx) Front DC5V IR In Cat5e/6 Back HDMI Out...
  • Page 7 Setup HDMI HDMI IR Transmitter IR Transmitter IR Receiver IR Receiver Cat5e/6 Media Device Display HDlink HDlink Transmitter Receiver...
  • Page 8 EDID Management The EDID switch allows the user to select which EDID handshake to use. Either the display connected to the receiver or the display connected to the transmitter are selectable. This EDID handshake includes information such as supported resolution and audio capability. Whichever display you have selected will determine what resolution and audio type the input source will send to the displays.

  • Page 9: Need Help

    Need Help? Phone 800. 709. 1345 Email support@sewelldirect.com Chat sewelldirect.com/support Live support available Monday through Friday 9AM-8PM EST...
