TONNEAU COVER INSTALLATION
INSTRUCTIONS AND OWNER'S MANUAL
Thank you for purchasing a tonneau cover. ACI
pride using superior quality materials and workmanship. With proper care, your
cover will provide years of service and enjoyment.
NOTICE TO INSTALLER: It is recommended instructions are read before
installation, even if familiar with cover. Improvements may be made without
prior notice. Always handle cover and components with care. If you have any
problems or questions, have serial number ready and call customer service.
When done, this owner's manual must be given to the consumer.
NOTICE TO CONSUMER: Before using cover, read operating, maintenance,
and safety sections and save owner's manual for future reference.
DATE PURCHASED:
WHERE PURCHASED:
SERIAL NUMBER:
Call Us First!
HELP LINE
HELP LINE
STOP
FOR YOUR RECORDS
(Located on decal under rear bar by tailgate)
1-866-630-8726
manufactured this cover with
®
Problems? Questions? Missing or
Damaged Parts? Install Questions?
Customer Service Hours:
8:00am-5:00pm CST, Mon. - Fri.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACCESS series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for aci ACCESS series

Summary of Contents for aci ACCESS series

  • Page 1 TONNEAU COVER INSTALLATION INSTRUCTIONS AND OWNER’S MANUAL Thank you for purchasing a tonneau cover. ACI manufactured this cover with ® pride using superior quality materials and workmanship. With proper care, your cover will provide years of service and enjoyment. NOTICE TO INSTALLER: It is recommended instructions are read before installation, even if familiar with cover.

  • Page 2: Installation Instructions

    INSTALLATION INSTRUCTIONS: PREPARATION Unpack cover components. Clean truck box if dirty. COMPONENTS: 1 driver side rail 1 passenger side rail 6 clamps 1 left and 1 right tension adjuster with nuts & bolts 1 pre-rolled up cover assembly Note: Side rails and bows are silver finish. TOOLS NEEDED: 2 - 1/2”...
  • Page 3 1. INSTALLING COVER SIDE RAILS NOTE: Some installs require drilling/bolting. Those kits will contain special side rail instructions. Follow those instructions for rail attachment in conjunction with instructions in this owner’s manual. A. Position side rail with weather strip against inside lip of box. Push rail Nylon strike Align outside edge to rear...
  • Page 4 1. INSTALLING COVER SIDE RAILS (Continued) E. Install second clamp on rail at Third clamp midway point of box. Adjust rail flush Second last Clamp at top of box and repeat clamping procedure, always making sure teeth are engaged on rail grooves. F.
  • Page 5 3. MOUNTING COVER TO SIDE RAILS A. Set rolled up cover on rails at front of box (behind cab) with front bar facing up. Roll cover bar onto front of rails and fold/tuck vinyl flap under with storage strap tabs out. Now bar will face down.
  • Page 6 4. INITIAL OPERATION AND ADJUSTMENTS A. Unroll cover and place rear bar into strikes on side rails. Press down on bar to close (20-30 lbs pressure). The cover fabric may be tight. Over time under tension it will conform to its hardware and loosen slightly.
  • Page 7 OPERATING INSTRUCTIONS TO CLOSE Release storage straps at Position rear bar against Alongside of box, seal cover front and using both hands, strikes. Push down on bar edges with hook and loop roll cover to rear of box. until latch locks in place. sealing system the full length of cover on both sides.

  • Page 8: Troubleshooting

    TROUBLESHOOTING PROBLEM SOLUTION Turn both tension adjusters counter clockwise to Cover too loose move front bar forward. (Refer to Step 4C, see arrows next to adjuster) Turn both tension adjusters clockwise to move front Cover too tight bar back. (Refer to Step 4C, see arrows next to adjuster) Rails set too high (Refer to Step 4B) Gap between roll-up bar and...

  • Page 9: Inspection And Maintenance

    TIPS FOR A LONGER LASTING COVER • Keep cover closed when not in use and always seal cover edges the full length of box on both sides with hook and loop sealing sys- tem. • Keep the cover tight; cover vinyl should sound drum-like when tapped on.

  • Page 10: Safety Information

    SAFETY INFORMATION • Do not cover cargo that is higher than the cover. • Do not place object(s) on or against the cover or its framework at any time. • Always secure cargo so it cannot shift and damage the cover or its parts.

  • Page 12: Manufacturer's Limited Warranty

    PO Box 508 | 3000 Hwy 281 SE Jamestown, ND 58402 Phone: 866-630-8726 For ACI patent information, please visit: http://www.agricover.com/patents/ PHONE 866-630-8726 8:00 am - 5:00 pm CST Monday through Friday except Holidays Product subject to change without notice PN 80535_H ©...
