- Page 1 2100 Digital Indicator Operator Manual For use with Software Versions 2.0 and above 2100-602-240...
- Page 2 Rinstrum Pty Ltd. Disclaimer Rinstrum Pty Ltd reserves the right to make changes to the products contained in this manual in order to improve design, performance or reliability. The information in this manual is believed to be accurate in all respects at the time of publication, but is subject to change without notice.
-
Page 3: Table Of Contents
Rinstrum - 2100 Digital Indicator Operator Manual Rev 2.4 Table of Contents 1. INTRODUCTION ............4 1.1. Approvals ............4 1.2. Features.............. 4 1.3. rin-SMART Software Options......4 1.4. Manuals .............. 4 2. SAFETY................ 5 2.1. Operating Environment ........5 2.2. -
Page 4: Introduction
Rinstrum - 2100 Digital Indicator Operator Manual Rev 2.4 1. Introduction The 2100 is a precision digital indicator using the latest Sigma-Delta A/D technology to ensure fast and accurate weight readings. 1.1. Approvals • NSC S403 approval (6000 divisions at 1µV/division). -
Page 5: Safety
Rinstrum - 2100 Digital Indicator Operator Manual Rev 2.4 2. Safety 2.1. Operating Environment • Operating Temperature: –10 to 50°C • Humidity: <90% non-condensing • Operating Voltage: Shown on rear label 2.2. Electrical Safety • For your protection all mains electrical hardware must be rated to the environmental conditions of use. -
Page 6: Basic Operation
Rinstrum - 2100 Digital Indicator Operator Manual Rev 2.4 3. Basic Operation 3.1. User Interface Display and Controls 3.2. Keypad Buttons Description POWER: The Power key is used to turn the instrument ON and OFF. • To Turn Instrument OFF: Press and hold the <POWER>... -
Page 7: Annunciators
Rinstrum - 2100 Digital Indicator Operator Manual Rev 2.4 Description ZERO: The Zero key sets the display weight to gross zero, providing the weight is within the zero range of the instrument (Tare weight is cleared). TARE: The Tare key temporarily sets the weight on the instrument to be displayed as zero. -
Page 8: Basic Weighing
Rinstrum - 2100 Digital Indicator Operator Manual Rev 2.4 Basic Weighing 4.1. Normal Weighing • Ensure instrument is On and zero annunciator is lit. • Place your item on the weigh platform. • Read the weight display. 4.2. Using Tare •... -
Page 9: Special Functions
Rinstrum - 2100 Digital Indicator Operator Manual Rev 2.4 Special Functions 5.1. Units Switching (kg / lb) • Press the <UNITS> key to switch the display between kilograms and pounds. Note: Printing and serial communications will use the units displayed (either kg or lb), but calibration weights and targets, etc., must be entered in the primary display units... -
Page 10: Hold
Rinstrum - 2100 Digital Indicator Operator Manual Rev 2.4 5.3. Hold • Press the <HOLD> key to hold the displayed weight at its current weight. • Units will flash to indicate that the displayed reading is held. • Press the <HOLD> key again to release the weight reading and return the display to normal weighing. -
Page 11: Live Weight
• ‘- - - - - -‘ is displayed until a reliable weight reading has been acquired. • Once a weight has been determined the 2100 beeps to indicate how reliable the reading is. -A single beep indicates that the sample is too unreliable and has been discarded. -
Page 12: Showing Totals
• While a batch is running (or paused) all keyboard keys other that the batch key are blocked (ie. Zero, Tare, Gross/Net, Print/M+). • If the 2100 has printing enabled there will be a standard batch print ticket automatically generated for each batch. Page 12... -
Page 13: Setting Target Weights
Rinstrum - 2100 Digital Indicator Operator Manual Rev 2.4 5.8. Setting Target Weights • Press and hold the <TARE> key for two seconds to enter the material target weights. • The 2100 displays TARG A. • Press the <TARE> key to step through the available targets, flight and hysteresis options. -
Page 14: Error Messages
Rinstrum - 2100 Digital Indicator Operator Manual Rev 2.4 Error Messages Error Description The weight reading is below the (U - - - - - -) normal weighing range. The weight reading is above the (O - - - - - -) maximum capacity of the equipment. -
Page 15: Diagnostic Errors
Rinstrum - 2100 Digital Indicator Operator Manual Rev 2.4 Diagnostic Errors Error Description Action E0001 Power supply voltage too low. Check supply E0002 Power supply voltage too high. Check scale / cables E0004 Load cell excitation voltage too low. Check scale...
