Sharp PJ-TA181 Service Manual

Electric fan.
Hide thumbs

Advertisement

SHARP SERVICE MANUAL
PARTS IDENTIFICATIONS AND SPECIFIC INFORMATION ...................................................
CAUTIONS FOR USE ....................................................................................................................
CLEANING AND MAINTENANCE ................................................................................................
WIRING DIAGRAM AND CIRCUIT DIAGRAM ...........................................................................
COMPONENT REPLACEMENT PROCEDURE .........................................................................
TROUBLESHOOTING ....................................................................................................................
SERVICE PARTS LIST ...................................................................................................................
In the interests of user-safety (Required by safety
regulations in some countries) the set should be restore
to its original condition and only parts identical to those
specified should be used.

TABLE OF CONTENTS

SHARP CORPORATION
ELECTRIC FAN
MODEL
PJ-TA181
PJ-SL181
Page
2 - 3
4
4
5
6-10
11

Advertisement

   Related Manuals for Sharp PJ-TA181

No related manuals

   Summary of Contents for Sharp PJ-TA181

  • Page 1: Table Of Contents

    SHARP SERVICE MANUAL ELECTRIC FAN MODEL PJ-TA181 PJ-SL181 In the interests of user-safety (Required by safety regulations in some countries) the set should be restore to its original condition and only parts identical to those specified should be used. TABLE OF CONTENTS Page PARTS IDENTIFICATIONS AND SPECIFIC INFORMATION ...........
  • Page 2: Parts Identifications And Specific Information

    Base Blade Spinner fan Knob switch Grille cover ass’y Fixing lock SPECIFIC INFORMATION Model PJ-TA181 Rated voltage (V) Rated frequency (Hz) Power consumption (W) Blade (mm.) Rated current (A) 0.36 Insulation class Product dimensions (W x H x D) (mm.)
  • Page 3 PARTS IDENTIFICATIONS Motor ass’y Rear grille Clutch knob Motor cover cap Grille lock nut Motor cover - B Front grille Motor cover - F Hinge Slide shaft Body cover Body Blade Spinner fan Base Grille cover ass’y Knob switch Fixing lock SPECIFIC INFORMATION PJ-SL181 Model...
  • Page 4: Cautions For Use

    SHARP. 2. In case the power cord is broken, it must be replaced by SHARP service center to avoid any damages. 3. Unplug every time before start to clean the parts or when you do not use the electric fan anymore.
  • Page 5: Wiring Diagram And Circuit Diagram

    WIRING DIAGRAM MOTOR L - WIRE YELLOW POWER CORD PLUG BLACK WHITE CLOSED TERMINAL REF. LINE BASE PIANO SWITCH CIRCUIT DIAGRAM...
  • Page 6: Component Replacement Procedure

    COMPONENT REPLACEMENT PROCEDURE REMOVE OF GRILLE ASS’Y 1. Unlock the fixing lock and pull the front grille. 2. Turn the spinner fan clockwise and remove the blade. 3. Turn the grille lock nut counterclockwise and remove the rear grille. Motor ass’y Blade Spinner fan Front grille...
  • Page 7 REMOVE OF POWER CORD 1. Remove the grille ass’y in accordance with “REMOVE OF GRILLE ASS’Y”. 2. Remove the hard board in accordance with “REMOVE OF HARD BOARD”. 3. Remove the closed terminal and cut the power cord lead wire from the piano switch ass’y. (See Fig. 3) 4.
  • Page 8 REMOVE OF MOTOR ASS’Y 1. Remove the grille ass’y in accordance with “REMOVE OF GRILLE ASS’Y”. 2. Remove the hard board in accordance with “REMOVE OF HARD BOARD”. 3. Remove the closed terminal and cut the red lead wise, yellow lead wise and white lead wise from the piano switch ass’y.
  • Page 9 REMOVE OF REEL SPRING ( For Model : PJ-SL181) 1. Remove the grille ass’y in accordance with “REMOVE OF GRILLE ASS’Y”. 2. Slide up the slide shaft by press the adjustable knob. 3. Remove 2 screws holding to the motor ass’y with the slide shaft. 4.
  • Page 10 1. Remove the motor ass’y in accordance with “REMOVE OF MOTOR ASS’Y”. 2. Remove 2 screws holding the hinge ass’y to the body (For PJ-TA181). 3. Remove 2 screws holding the hinge ass’y to the slide shaft ( For PJ-SL181).
  • Page 11: Troubleshooting

    TROUBLESHOOTING Possible Cause Corrective Action Problem Fan does not operate. 1. Motor does not operate. 1.1 Repair and replace the motor. 1.2 Replace current fuse. 2. Faulty connect the power connector 2. Repair. or switch. 3. Coil stator shock or lack of. 3.

This manual also for:

Pj-sl181
