  • Page 1 Concrete Moisture Meter Instruction Manual for Wagner Model C575 1-800-944-7078...

  • Page 2: Table Of Contents

    They deliver information to the user instantly. The C575 is designed to give an average moisture indication of everything within a specific area and depth penetration. Electronics inside the C575 converts the signal reading, which will appear on the analog dial.

  • Page 3: Features

    Press hand meter sensor firmly on surface, the reading should be 18 plus or minus 1. The C575 is a rugged instrument, which will give many years of service if used with care and properly maintained. Clean the meter case with a soft rag lightly moistened with water.

  • Page 4: Meter Storage

    • Designed for continuous use • One-Year Warranty Meter Storage: For a long service life, it is important to store your meter properly. Avoid excessively hot or cold locations, and keep the meter in the case provided. Do not store the meter in an area with excessive electro-magnetic interference, such as near an electric motor, or where it could be crushed, such as in front of a forklift.
  • Page 5 Taking a Reading: cont’d. 3. Place the sensor of the meter on the area of the concrete to be tested. Press down firmly, making sure the sensor rests flat against the concrete. 4. On a rough surface take a number of readings close to one another.
  • Page 6 Interpreting the Reading: Readings must be evaluated relative to the purpose for which they were taken. You must determine the readings, which work best for the products you install or apply. Always refer to the adhesive and/or floor covering recommendations for the acceptable moisture condition of the concrete.

  • Page 7: Concrete Baselines

    (kg. / 304.8 sq.m.) You can establish your own baseline or comfort range reading for use with the Wagner C575 meter. Once established, the baseline will become your “not-to- exceed” reading, indicating sub-floors that you cannot safely install your adhesives, paints or floor coverings over.

  • Page 8: Questions & Answers

    4. Add a volume of water that is equal to 1/4 the weight of the dry concrete sample. By definition this is 25% MC (moisture content). Measrue this sample with the C575 to see what the reading is at 25% MC For more details on this testing methods visit our website at http://www.moisturemeters.com.
  • Page 9 You should always wipe off as much excess water as possible. #3 Meter Ruggedness Q: How rugged is my C575 moisture meter? A: Your C575 meter is designed for compact convenience. It can be damaged by being dropped or slammed down on concrete or other hard surfaces, as can any meter.

  • Page 10: Meter Specifications

    C575 Meter Specifications: Size: Length: inches (11.59 cm) Width: inches (6.99 cm) Height: inches (3.97 cm) Scanning Area: Length: inches (6.35 cm) Width: inches (3.81 cm) Scanning Depth: inches (1.91 cm) Power: 9 volt Alkaline battery Auto Power Shutdown: 60 seconds Measurement Range: 0 –...

  • Page 11: Repair Service

    Repair Service: In the event of damage or failure, contact the Wagner Electronics Technical Services Department to arrange for repair and to acquire RMA Number with the appropriate repair form. When you send your meter, be sure it is insured. We cannot be responsible for items that do not reach us.
  • Page 12 (1) year from the date of purchase, subject to the following terms and conditions: Wagner’s liability under this warranty shall be limited, at Wagner’s option, to the repair or replacement of this product or any part thereof, which is demonstrated to be defective. To exercise...

  • Page 13: Warranty

    Wagner Electronic Products, Inc., recommends returning the unit to the factory for a diagnostic checkup and recalibration in the event the meter is dropped or otherwise damaged, or the meter accuracy is suspect.
  • Page 14 Inc. Accordingly, additional statements, whether oral or written, except written statements from an officer of Wagner Electronic Products, Inc. do not constitute warranties and should not be relied upon by the customer. Wagner Electronic Products, Inc. shall in no event...

  • Page 15: Fcc Compliance Statement

    FCC Compliance Statement This equipment has been tested and found to comply within the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in residential installations. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 16 Notes:...
  • Page 17 Notes:...
  • Page 18 Wagner Electronic Products, Inc. 326 Pine Grove Road, Rogue River, OR 97537 USA Phone: (541) 582-054 Fax: (541) 582-4138 E-mail: Sales@wwwagner.com Visit us on the Web at: http://www.moisturemeters.com © 2005 WEPI Wagner Part No: 500-57501-001 Rev. C...
