- Page 1 Installation / Warranty Citterio 39144XX1 Citterio 39148XX1...
-
Page 2: Technical Data
Axor Citterio Wall Mount Lav Mixer with Cross Handles 39144XX1 Axor Citterio Wall Mount Lav Mixer with Lever Handles 39148XX1 39144XX1 Technical Data Flow rate @ 45 psi Maximum water pressure Recommended water pressure: Recommended hot water temp.: *Some municipalities limit the maximum water temperature from the water heater to or below. - Page 3 · Remove the inserts from the hot and cold plaster shields. · Cut the plaster shields so that they extend 1/16” from the wall. Seal around the shields with a suitable, non-staining, waterproof bathroom sealant. · Lever handle version only: Remove the hot and cold cartridges using a 17 mm deep socket wrench.
- Page 4 · Install the outer sleeves to the hot and cold valves. Measure each outer sleeve to a point 3/8” from the surface of the finished wall. Mark the sleeve at this point. Cut the sleeves. Install the inner sleeve. · Measure the inner sleeve to a point 1⁄2”...
- Page 5 · Attach the spout and spout escutcheon to the wall plate with the screws provided. · Place the plate and spout assembly over the valve. Install the handle escutcheons and the handles. Turn the handle bases clockwise, so that they thread onto the outer sleeves.
- Page 6 Replacement parts lever handle cross handle hot escutcheon cold escutcheon spout escutcheon 96760XXX escutcheon aerator fixing set hot cartridge cold cartridge extension kit 39296XXX 39295XXX 96759XXX 96758XXX 96757XXX 13085000 96393000 96351000 96350000 96259000 (optional)
- Page 7 If you purchased the product for use primarily for any other purpose, including, without limitation, a commercial purpose, this warranty extends only (i) for 1 year, with respect to Interaktiv and Retroaktiv products, and (ii) for 5 years, with respect to AXOR, ShowerPower and Pharo products.
- Page 8 THIS WARRANTY DOES NOT COVER, AND HANSGROHE WILL NOT PAY FOR: Conditions, malfunctions or damage not resulting from defects in material or workmanship. Conditions, malfunctions or damage resulting from (1) improper installation, improper maintenance, misuse, abuse, negligence, accident or alteration, or (2) the use of abrasive or caustic cleaning agents or “no rinse” cleaning products, or the use of the product in any manner contrary to the product instructions.
