S U B - Z E R O W I N E S TO R AG E
L I G H T I N G I N F O R M AT I O N
C A B I N E T L I G H T I N G
Models ICB424 and ICB424FS: In these
models, rope-style LED lighting is mounted to
the top of the cabinet and cascades down the
entire front of the unit.
Models ICB427, ICB427R and ICB430: These
models have discreet lighting provided in two
places. Rope-style LED lighting is mounted to
the top of the cabinet and additional lighting is
mounted in the control panel to illuminate the
display shelf. Refer to the illustration below.
These lights have an extended life and it
should be some time before they need to be
replaced. If you have problems with the
cabinet lighting or need replacements, contact
your Sub-Zero dealer.
Shut off power to the unit before replacing
light bulbs. Wear protective gloves when
handling bulbs.
Cabinet Lighting
Cabinet lighting – Models ICB427,
ICB427R and ICB430
U S E & C A R E
D R AW E R L I G H T I N G – M O D E L I C B 4 2 7 R
Model ICB427R: Lighting is recessed into the
top area of each refrigerated drawer compart-
ment. Refer to the illustration below.
To replace a light bulb in the drawer compart-
ment, you must pull the drawer out to its
maximum extension. It is recommended that
you remove the drawer. Refer to page 13 for
the drawer removal procedure.
Remove the 25-watt bulb by unscrewing it
from its socket and complete the reinstallation
by following the reverse steps.
Drawer Compartment
Lighting
Drawer compartment lighting –
Model ICB427R
17
