Page 1 COMPONENTS IDENTIFIED BY MARK ON THE SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE THESE COMPONENTS WITH ONKYO PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL. MAKE LEAKAGE-CURRENT OR RESISTANCE...
Page 2: Service Procedure
TX-NR5007 SERVICE PROCEDURE-1 1. Replacing the fuses This symbol located near the fuse indicates that the fuse used is show operating type, For continued protection against fire hazard, replace with same type fuse, For fuse rating, refer to the marking adjacent to the symbol.
Page 3 V id e o: 1 . 1 3/ 09Y0 2AR [TX-NR1007] [TX-NR5007, NR3007, PR-SC5507, DTR-70.1, DTR-80.1, DHC-80.1] V S P ( R e o n ) : 1 .0 3 /0 9 Z 1 1 A E O Version of VSP(Video Signal Processor) FW...
Page 4 TX-NR5007 SERVICE PROCEDURE-3 6. Replacing Power Amplifier Parts When a power amplifier of certain channel is broken and goes into Protect mode, the following parts in the channel must be replaced at the sametime, because these parts get damage in most cases.
Page 5 TX-NR5007 EXPLODED VIEWS-1 A557 U007 x 3 pcs. A553 A279 U0046 MDC type : x 12 pcs. MMP, MMR type : x 11 pcs. A215 A251 A551 L=10mm A183 A287 x 24 pcs. A289 F2005 P4104 F2001 A291 U0040 A193...
Page 6 TX-NR5007 A247 EXPLODED VIEWS-2 A297 A031 A115 A009 x 2 pcs. x 4 pcs. x 2 pcs. x 10 pcs. A109 L=15mm Q6062 A296 A105 Q6066 x 2 pcs. A033 A295 Q6064 x 2 pcs. Q6068 A103 U0014 A111 x 2 pcs.
Page 7 TX-NR5007 EXPLODED VIEWS-3 A215 L=110mm P8641 P3101 P7501 U0058 U0050 U0101 A321 U0054 A319 x 16 pcs. A319 A363 x 2 pcs. x 3 pcs. U0057 A301 A215 U0053 L=30mm A315 A365 x 2 pcs. A309 A343 U0051 x 2 pcs.
Page 8 TX-NR1007/3007/5007/NA1007/5007,DTR-70.1/80.1, DHC-80.1, PR-SC5507 BLOCK DIAGRAMS-1 / PART-1 AUDIO SECTION PHONES AUDIO MUTING XM-RADIO For only DD,DC TUNER DHC-** only PACK 9CH POWER AMPLIFIER NJU7312A XM/DT IC except SA*** 3-3-2 x2 CS3318 for US MAIN L SPEAKER TERMINALS EXCEPT DHC-80.1/PR-SC5507 DAC FL SIRIUS MIX L AMUTE...
Page 9: Part
TX-NR3007/5007/NA5007,DTR-70.1/80.1, DHC-80.1, PR-SC5507 BLOCK DIAGRAMS-3 / PART-3 VIDEO SECTION Scanning Line TX-NA1007/5007 ONLY Progressive/Interlace TC4052BF Aspect Ratio Scanning Line Progressive/Interlace ANALOG Q8801 Q8001 VIDEO TC74ALVCH162841 ADV7342 ADV7800 BUS FUFFER VIDEO ENCODER (PY/PB/PR, CV, SY/SC) VIDEO DECODER ANALOG VIDEO MAIN MPU Scanning Line TC4052BF MAIN MPU...
Page 10: Part
TX-NR1007/3007/5007/NA1007/5007, DTR-70.1/80.1, DHC-80.1/PR-SC5507 BLOCK DIAGRAMS-4 / PART-4 USB FS RJ-45 Reserved USB HS HOST DSP/ETHER/USB/NET SECTION Reserved HiSideSw SDR SDRAM(x16bit) EtherMAC HiSideSw from HDMI block EMIFB x32DataBus NAND Controles NANDFlash EMFB_A[1:2] EMIFA EMFA_D[0:7] Reserved 256Mbit Level Convert DSDSLRSEL UART2 RS-232C for Linux SerialConsole UART2 24.576MHz...
Page 11 TX-NR1007/3007/5007/NA1007/5007, DTR-70.1/80.1, DHC-80.1, PR-SC5507 BLOCK DIAGRAMS-5 / PART-5 DIGITAL AUDIO CLOCK SECTION 12.288MHz 11.2896MHz AXR0[10]/AXR1[3] DSP3(***) AXR0[11]/AXR1[2] PCMF2 PCMF3 PCM_SL/SBL4 // PCMF4 AXR0[10]/AXR1[3] AXR0[0] AXR0[11]/AXR1[2] AXR0[0] AXR0[11]/AXR1[2] AXR0[0] PCMSUR2 PCMSUR3 PCM_FL/LHLW4 AXR0[11]/AXR1[2] AXR0[1] AXR0[12]/AXR1[1] AXR0[1] AXR0[12]/AXR1[1] AXR0[1] PCMCSW2 PCMCSW3 PCM_C4 AXR0[12]/AXR1[1] AXR0[2] AXR0[13]/AXR1[0]...
Page 12 TX-NR1007/3007/5007/NA1007/5007, DTR-70.1/80.1, DHC-80.1, PR-SC5507 SCHEMATIC DIAGRAMS-1 / PART-6 AMP1 (VOLTAGE AMP) SECTION BACLA-0226 IDLING CURRENT ADJUSTMENT 1. Wait for 4 - 6 minutes after power on. (Heat running) U008 AMPLIFIER PC BOARD 2. Re-adjust the trimming resistors according to the following values. Adjustment point Measured value Re-adjustment value...
Page 13 TX-NR1007/3007/5007/NA1007/5007, DTR-70.1/80.1, DHC-80.1, PR-SC5507 SCHEMATIC DIAGRAMS-2 / PART-7 AMP2 (FINAL STAGE) SECTION BAAMP-0191 BAAMP-0192 U0020 AMPLIFIER PC BOARD U0021 AMPLIFIER PC BOARD TO BAAMP-0192 PART-7 : I2 P6350A TO BAAMP-0192 PART-7 : J2 P6340A +60V +60V +B1R +B1L L6001 L6000 R6081 IPRO R6080...
Page 14 TX-NR1007/3007/5007/NA1007/5007, DTR-70.1/80.1 SCHEMATIC DIAGRAMS-3 / PART-8 AMP3 (POWER SUPPLY, PROTECT ,ETC.) SECTION BAAF-0180 U0010 POWER SUPPLY PC BOARD inputC GND_inputC GND_NFC 2SC1740S-S Q6002 P5022B P5032B U0014 THERMAL SENS PC BOARD inputSR GND_inputSR BCETC-0184 GND_NFSR Q6380 LM61CIZ 2SC1740S-S Q6004 P5024B P5034B inputRH GND_inputRH GND_NFRH...
Page 15 TX-NR1007/3007/5007/NA1007/5007, DTR-70.1/80.1, DHC-80.1, PR-SC5507 SCHEMATIC DIAGRAMS-4 / PART-9 TO BAAF-0242 TO BAVD-0203 DHC*** ANALOG AUDIO SECTION 1 PART-40 : E2 PART-12 : H1 JL4001A JL2104A BAASP-0202(1/3) -13VSEL BAAF-0211 U0043 PHONO AMP. PC BOARD R4303 U0030 ANALOG AUDIO PC BOARD Subwoofer R4304 80Hz -12dB/oct R4037...
Page 16 TX-NR1007/3007/5007/NA1007/5007,DTR-70.1/80.1/PR-SC5507.DHC-80.1 SCHEMATIC DIAGRAMS-5 / PART-10 ANALOG AUDIO SECTION 2 TO BAAF-0204 TO BACPU-0209 TO BACPU-0209 TO BARF-0204 PART-14 : A4 PART-18 : G4 PART-18 : I4 PART-14 : A4 NSCT-11P2191 P107B P7009A P7010A P104B BAASP-0202(2/3) U0030 ANALOG AUDIO PC BOARD FR_OUT SBR_OUT RH_OUT...
Page 17 TX-NR1007/3007/5007/NA1007/5007, DTR-70.1/80.1, DHC-80.1, PR-SC5507 SCHEMATIC DIAGRAMS-6 / PART-11 ANALOG AUDIO SECTION 3 BAACC-0212-1 U0044 BUFFER AMPLIFIER PC BOARD R4522 22(1/2W) C4500 NE5532 47/50 47/50 Q4500A C4502 47/50 Q4500B C4503 47/50 NE5532 C4501 R4523 22(1/2W) C4504 NE5532 47/50 47/50 Q4501A C4506 47/50 Q4501B C4507...
Page 18 TX-NR1007/3007/5007/NA1007/5007, DTR-70.1/80.1, DHC-80.1, PR-SC5507 SCHEMATIC DIAGRAMS-7 / PART-12 ANALOG VIDEO SECTION TO HDMI TO D Terminal PWB TO MICON PWB TO ASP PWB TO TRM PWB TO RF PWB TO Primary PS PWB TO BAVD-0205 TO BAHDM-0132 / 0157 TO BAHDM-0132 / 0157 TO BATRM-0214 TO BAPS-0217 PART-13 : A2...
Page 19 TX-NR1007/3007/5007/1007/5007,DTR-70.1/80.1/PR-SC5507,DHC-80.1 SCHEMATIC DIAGRAMS-9 / PART-14 SIRIUS, ANALOG TUNER SECTION BADG-0208(3/9) BARF-0204 U0045 SIRIUS, ANALOG TUNER PC BOARD 3PLLVSWSCL 3PLLVSWSCL 3PLLVSELSDA 3PLLVSELSDA FRONT SIDE STEREO STEREO MAX=110mA +9VTU +9VTU -15V- PREF TU_L_OUT 10/50(UTSP) PLYPSVSW TUNER_GND 10/50(UTSP) PRESW TU_L TU_R_OUT PRESR TUNER_GND PREC DET_OUT PRESB...
Page 20 TX-NR1007/3007/5007/1007/5007, DTR-70.1/80.1, DHC-80.1, PR-SC5507 SCHEMATIC DIAGRAMS-11 / PART-16 DG AUDIO IN SECTION BADG-0208(8/9) TO BAHDM-0132/0157 PART-29 : A1 JL3889A NSCT-5P896 2.5mm pich BAETC-0246 U0046 DG AUDIO IN PC BOARD SEL_SPDIF GNDDAC +5VDG L3884 P3886 R3914 C3886 COAX1 LBC2518T2R2M LBC2518T470M 232RXD 104K C3888 100/16...
Page 21 TX-NR1007/3007/5007/NA1007/5007, DTR-70.1/80.1, DHC-80.1 , PR-SC5507 SCHEMATIC DIAGRAMS-12 / PART-17 CODEC, DAC AND VLSC SECTION BADG-0208-1 U0040 CODEC, DAC AND VLSC PC BOARD VLSC on VLSC off VLSC on VLSC off R1220-29,R1450-51 C1230-39 331J 221J +OP6 +OP3 R1240-49,R1430-31 C1440-41 R1390 R1393 R1280-89,R1500-01 C1240-49 331J...
Page 22 TX-NR1007/3007/5007/NA1007/5007, DTR-70.1/80.1, DHC-80.1, PR-SC5507 SCHEMATIC DIAGRAMS-13 / PART-18 MAIN MICROPROCESSOR SECTION TO BAETC-0246 TO_BAHDM-0132/0157 TO DEBUGER TO FLASH WRITER PART-29 : E1 PART-16 : H2 P3885A BADG-0208(2/9) NSCT-9P2472 IMSA-9618S-09A P7002 P7003B IMSA-9142S-18A P3608B NPLG-11P0966 BACPU-0209 U0041 MAIN CPU PC BOARD 2.2K R7001 105Z...
Page 23 TX-NR1007/3007/5007/NA1007/5007, PR-SC5507 SCHEMATIC DIAGRAMS-14 / PART-19 DISPLAY SECTION BADIS-0135(1/3) BADIS-0135 U0050 DISPLAY PC BOARD FLAC1 TO BCPS0140 PART-20 : C2 NSCT-5P876 FLAC2 JL9303A J9303 Q7500 HNA-16SL04T Q7500A FL HOLDER +3.3VMPU U0052 PHONE JACK PC BOARD GNDVD AUX2CV_IN BAETC-0137 JL4103 P7580 -15VA TX:5J550606H(P2.5X5 L=55) 807,1007,3007:MSJ-064-05A SR...
Page 24 TX-NR1007/3007/5007/NA1007/5007, PR-SC5507 SCHEMATIC DIAGRAMS-15 / PART-20 DG POWER SUPPLY SECTION BADIS-0135(2/3) BAPS-0140 U0055 DG POWER SUPPLY PC BOARD NSCT-7P99 F9301 JL9501B D9303 3.15A 125A D10XB60H GNDDAC GNDDAC +5.9V +5.9V GNDDG GNDDG +9VDG C9302 (EH) P9301A 10000/16(VR) NPLG-6P120 DSP_AC1 D9350 R9310 DSP_AC2 27(1W) -VP_AC1...
Page 25 TX-NR1007/3007/5007/NA1007/5007, DTR-70.1/80.1 SCHEMATIC DIAGRAMS-18 / PART-23 POWER SUPPLY AND SPEAKER TERMINAL SECTION BATRM-0214(1/2) U0065 BAETC-0219 NPLG-3P117 P9422B (EH) ANALOG AUDIO POWER SUPPLY PC BOARD BATRM-0214 U0060 Q9427 2SB1565-E R9429 POWER SUPPLY AND SPEAKER TERMINAL PC BOARD BLUE Q9429 BLUE R9430 (or 2SA1488-Y) 2SB1565-E BLUE...
Page 26 THIS SYMBOL LOCATED NEAR THE FUSE INDICATES THAT THE FUSE USED IS SLOW OPERATING TYPE FOR CONTINUED PROTECTION AGAINST FIRE FUSE TX-NR3007 Transformer TX-NR5007/NA5007,DTR-80.1 Transformer TX-NR1007/NA1007,DTR-70.1 Transformer HAZARD,REPLACE WITH SAME TYPE FUSE. FOR FUSE RATING REFER TO THE MAKING ADJACENT TO THE SYMBOL.
Page 27 TX-NR1007/3007/5007/1007/5007, DTR-70.1/80.1, DHC-80.1, PR-SC5507 SCHEMATIC DIAGRAMS-21 / PART-26 NET / USB / ZONE2 SECTION BAHDM-0132/0157 (1/8) SPI0 & control signals U007 to 2nd DSP HDMI PC BOARD from HDMI Block from DIR Block VDD_MPU3.3V C3202 105Z VDD_CSW3.3 TC74VHC157FT Q3202 DIG/NETUSB R3233 +3.3V SELECT...
Page 28 TX-NR1007/3007/5007/1007/5007, DTR-70.1/80.1, DHC-80.1, PR-SC5507 SCHEMATIC DIAGRAMS-22 / PART-27 NET / USB / POWER SECTION BAHDM-0132/0157 (2/8) for Debugging Boot Opt. NAND UART1 SPI0 R3115 or R3116 BOOT2 BOOT7 +5VHD BOOT1 U007 R3111 or R3112 BOOT5 TPD2E001DRLR BOOT0 R3109 or R3110 BOOT6 BOOT3 HDMI PC BOARD...
Page 29 TX-NR1007/3007/5007/1007/5007, DTR-70.1/80.1, DHC-80.1, PR-SC5507 SCHEMATIC DIAGRAMS-23 / PART-28 DSP MEMORY SECTION BAHDM-0132/0157 (3/8) U007 HDMI PC BOARD GND_ARM VDD_MPU3.3V GND_ARM PA_12 MB_A12 +3.3V C3001 105Z R3009 L3001 PBA_0 MB_BA0 BLM18PG121SN1D PA_0 MB_A0 GND_ARM PA_1 MB_A1 C3002 105Z VDD_NAND3.3V C3003 106K/6.3 33x4 R3010 MB_A0...
Page 30 TX-NR1007/3007/5007/NA1007/5007,DTR-70.1/80.1, DHC-80.1, PR-SC5507 SCHEMATIC DIAGRAMS-24 / PART-29 DSP CONNECTOR SECTION BAHDM-0132/0157 (4/8) U007 HDMI PC BOARD TO_BAETC-0246 TO_BADG-0208 TO_BADG-0208 TO_BADG-0208 TO_BACPU-0209 PART-16 : E2 PART-17 : A6 PART-17 : A7 PART-17 : A8 PART-18 : D1 NSCT-5P97 IMSA-9142B-18A IMSA-9142B-8A IMSA-9142B-16A JL3889B IMSA-9142B-18A P3608A...
Page 31 TX-NR1007/3007/5007/NA1007/5007, DTR-70.1/80.1, DHC-80.1, PR-SC5507 SCHEMATIC DIAGRAMS-25 / PART-30 2ND DSP SECTION BAHDM-0132/0157 (5/8) U007 HDMI PC BOARD SPI0 & control signals GND_ARM High from1stDSP R3411 2.2K R3410 EM2_A14 EM2_A15 to 2nd DSP R3416 +3.3V EM2_A13 BYTE EM2_A12 EM2_A11 EM2_D15 Q15/A-1 +1.2V EM2_A10 EM2_D7...
Page 32 TX-NR1007/3007/5007/NA1007/5007, DTR-70.1/80.1, DHC-80.1, PR-SC5507 SCHEMATIC DIAGRAMS-26 / PART-31 3RD DSP SECTION BAHDM-0132/0157 (6/8) U007 HDMI PC BOARD SPI0 & control signals GND_ARM High from 2nd DSP R3511 2.2K R3510 EM3_A14 EM3_A15 from 3rd DSP R3516 +3.3V EM3_A13 BYTE EM3_A12 EM3_A11 EM3_D15 Q15/A-1 +1.2V...
Page 33 TX-NR1007/3007/5007/NA1007/5007, DTR-70.1/80.1, DHC-80.1, PR-SC5507 SCHEMATIC DIAGRAMS-27 / PART-32 HDMI IN/OUT SECTION BAHDM-0132/0157 (7/8) U007 HDMI PC BOARD TX_SCL TX_SDA TX_INT TX_RST TX2_INT GNDHD 3.3V TX2_RST +3.3VHD1 INPSEL Q205 HPLG_DET TC74VHC157FT SN74CB3Q3305PWR HPLG2_DET L251 INPSEL R268 +3.3VHD1 SELECT C8632 RX_CLK PCMLRCK_DR0_A BLM18PG181SN1 R269 0ohm...
Page 34: Part
TRINO or VX-50 PART GNDVD R8751 0 OC_FLMDO VSP_RXD +12V VDLOCK PART-36 GNDVD VSP_RST +12V GNDVD TO DSP PART POWER SUPPLY TX-NR5007 Only R8951 FOR REON CHASSIS_GND C8302 +3.3V 0ohm HPD_IN7 HP DET R8313 +5V_IN7 THRM DSDA_IN7 DDC DATA L8955...
Page 35: Vhd2
TX-NR3007/5007/NA5007, DTR-70.1/80.1, DHC-80.1, PR-SC5507 SCHEMATIC DIAGRAMS-31 / PART-36 REON (VX-50) SECTION BAHDM-0157 U007 HDMI PC BOARD REON VIDEO SIGNAL I/O REON FLASH MEMORY I/O REON POWER SUPPLY NO CONNECTION TO PART25 SYNC SIGAL OUTPUT TO PART22 PCI_AD[31:0] TO PART25 SYNC SIGNAL INPUT VSS1 VSS64 VICLK1...
Page 36 TX-NR3007/5007/NA5007, DTR-70.1/80.1, DHC-80.1, PR-SC5507 SCHEMATIC DIAGRAMS-32 / PART-37 REON (VX-50) MEMORY SECTION BAHDM-0157 U007 HDMI PC BOARD MAD[13:0] DQS0 MCLK MDQS0 MCLK DQS1 /CLK /MCLK 47x4 MDQS1 MCLK DQS2 CLKE R8123 MCLKE RN8063 MDQS2 MCLKE DQS3 MAD3 RN8037 33X4 MDQS3 MDQ0 DQS4 /RAS...
Page 37 TX-NR3007/5007/NA5007, DTR-70.1/80.1, DHC-80.1, PR-SC5507 SCHEMATIC DIAGRAMS-33 / PART-38 VIDEO DECODER / SW SECTION BAHDM-0157 U007 HDMI PC BOARD C8104 C8102 L8006 105K 823K LBC2518T2R2M X8001 P8003C cn11 L8005 NC_NSCT-9P2472 28.6363MHz LBC2518T2R2M R8102 ADINCV C8050 103K A_HS C8049 ANALOG VIDEO 104Z ADINSY VGASDA AGND...
Page 38 TX-NR3007/5007/NA5007, DTR-70.1/80.1, DHC-80.1, PR-SC5507 SCHEMATIC DIAGRAMS-36 / PART-41 FRONT HDMI / USB SECTION BAHDM-0291 U0101 FRONT HDMI / USB PC BOARD R8870 HP DET R8869 C8876 102K DSDA_FTI DDC DATA DSCL_FTI DDC CLK C8875 105Z CERemote XCN_FTI CK Shield C8880 XCP_FTI 106K/6.3 L8861...
Page 39 TX-NR1007/3007/5007/NA1007/5007, DTR-70.1/80.1, DHC-80.1, PR-SC5507 SCHEMATIC DIAGRAM-37 (PART-42) WAVEFORM SECTION Video Waveform Part Digital Audio Waveform Part Video source color and pattern Composite waveform S-Video Y waveform S-Video C waveform WF21 SD-7:B7 WF22 SD-7:B7 WF23 SD-7:B7 NOTE: LR CLOCK (SAI_LRCK, CX_LRCK) WF01 is short for Waveform01 .
Page 40 TX-NR1007/3007/5007/NA1007/5007,DTR-70.1/80.1 PRINTED CIRCUIT BOARD VIEWS-01 / U001 U0010 POWER SUPPLY PC BOARD (BAAF-0180) Component side view from soldering side P5001A P5034B P5000A P5037B P5033B P5038B P5035B P5030B P5036B P6140D P5032B P6140F P6240D P5031B P6140E P6140B P6240B P6240A P6140A P6240G P6140G P5002A P6240F P6240C...
Page 41 TX-NR1007/3007/5007/NA1007/5007,DTR-70.1/80.1 PRINTED CIRCUIT BOARD VIEWS-02 / U001 U0010 POWER SUPPLY PC BOARD (BAAF-0180) Soldering side view from component side P5001A P5033B P5037B P5000A P5034B P5035B P5038B P5030B P6240D P6140D P5036B P6140E P5031B P6140F P5032B P6140B P6140A P6240B P6240A P6140G P6240G P5002A P6140C P6240C...
Page 42 TX-NR1007/3007/5007/NA1007/5007,DTR-70.1/80.1 PRINTED CIRCUIT BOARD VIEWS-03 / U002 U0020 U0021 AMPLIFIER PC BOARD (C,SR,RH,SBR,R) (BAAMP-0191) AMPLIFIER PC BOARD (L,SBL,LH,SL) (BAAMP-0192) Component side view from soldering side Component side view from soldering side P6072 J6052 P6073 P6071 P6078 P6074 P6076 P6075 P6077 P6070 BCAMP-0191 J6045...
Page 43 TX-NR1007/3007/5007/NA1007/5007,DTR-70.1/80.1, DHC-80.1, PR-SC5507 PRINTED CIRCUIT BOARD VIEWS-04 / U003 U0030 ANALOG AUDIO PC BOARD (BAASP-0202) Component side view from soldering side P4100 P5001B P5000B JL4014B BCASP-0202 R4351 JL4103A C4343 R4341 R4343 R4349 R4325 25140202C R4356 R4353 R4350 R4326 R4347 C4305 R4352 C4341 R4323...
Page 44 TX-NR1007/3007/5007/NA1007/5007,DTR-70.1/80.1, DHC-80.1, PR-SC5507 PRINTED CIRCUIT BOARD VIEWS-05 / U003 U0030 ANALOG AUDIO PC BOARD (BAASP-0202) Soldering side view from component side R4563 R4383 C4381 GND_TU TUNE_L R4404 R4406 GND_TU MIX-L TUNE_R GND_TU R4408 SIRIUS_R D4403 1.SIRIUS_L MIX-R LPF-OUT R4387 R4386 R4407 Z2SW Z3SW...
Page 45 TX-NR1007/3007/5007/NA1007/5007,DTR-70.1/80.1, DHC-80.1, PR-SC5507 PRINTED CIRCUIT BOARD VIEWS-06 / U003 U0031 ANALOG VIDEO PC BOARD (BAVD-0203) Component side view from soldering side JL2601B TO HDMI BCVD-0203 TO HDMI TRGB POFF2_HDM TO TRM 25140203 GNDVD TRGC +12VDG P2901 C2006 L2000 MM_SDA POFF MM_SCL +SUB E2000...
Page 46 TX-NR1007/3007/5007/NA1007/5007,DTR-70.1/80.1, DHC-80.1, PR-SC5507 PRINTED CIRCUIT BOARD VIEWS-07 / U003 U0030 ANALOG VIDEO PC BOARD (BAVD-0203) Soldering side view from component side TRGB POFF2_HDM GNDVD +12VTRG +12VDG TRGC POFF GNDTU MM_SDA +SUB MM_SCL GNDVD MM_RST VIN_AUX2 UART_RX +9VTU +3.3VST UART_TX IRIN œ...
Page 47 TX-NR1007/3007/5007/NA1007/5007,DTR-70.1/80.1, DHC-80.1, PR-SC5507 PRINTED CIRCUIT BOARD VIEWS-08 / U004 U0040 CODEC, DAC PC BOARD (BADG-0208) Component side view from soldering side Soldering side view from component side GND TCKTDOTDI TMS L3710 R3771 BCDG-0208 R3725 L3712 R3724 R3891 R3774 R3723 P1010 R3770 R3721 25140208D...
Page 48 TX-NR1007/3007/5007/NA1007/5007,DTR-70.1/80.1, DHC-80.1, PR-SC5507 PRINTED CIRCUIT BOARD VIEWS-09 / U004 U0041 U0042 MAIN CPU PC BOARD (BACPU-0209) ZONE-2 & ZONE-3 CIRCUIT PC BOARD (BAAR-0210) Component side view from soldering side Soldering side view from component side Component side view from soldering side INT3 INT2 INT1...
Page 49 TX-NR1007/3007/5007/NA1007/5007,DTR-70.1/80.1, DHC-80.1, PR-SC5507 PRINTED CIRCUIT BOARD VIEWS-10 / U004 U0045 SIRIUS PC BOARD (BARF-0204) U0043 PHONO AMP. PC BOARD (BAAF-0211) Component side view from soldering side Soldering side view from component side Component side view from soldering side PHONO EQ R4008 Q4004 R4007...
Page 50 TX-NR1007/3007/5007/NA1007/5007,DTR-70.1/80.1 PRINTED CIRCUIT BOARD VIEWS-11 / U005 U0050 DISPLAY PC BOARD P7591A P7501B C7506 JL9303A BCDIS-0135 (BADIS-0135) 25140135C J7642 Component side view LEDSTBY GNDDG LEDZ2 LEDZ3 from soldering side LEDZ4 LEDPURE KEY0 REMIN REMO_IN LED_REMO FLD1CS FLD2CS Q7500 FLDRST GNDDG DIGCLK DIGSDO GNDDG...
Page 51 TX-NR1007/3007/5007/NA1007/5007,DTR-70.1/80.1 PRINTED CIRCUIT BOARD VIEWS-12 / U005 U0050 DISPLAY PC BOARD (BADIS-0135) FLAC1 œ C7507 C7508 FLAC2 C7509 +3.3VMPU LEDSTBY Soldering side view C7510 GNDDG from component side LEDZ3 LEDZ2 LEDZ4 LEDPURE KEY0 REMIN REMO_IN LREMO FLD1CS FLD2CS GNDDG FLDRST DIGSDO DIGCLK GNDDG...
Page 52 TX-NR1007/3007/5007/NA1007/5007,DTR-70.1/80.1 PRINTED CIRCUIT BOARD VIEWS-13 / U005 U0055 FUSE PC BOARD (BAPS-0140) Component side view from soldering side BCPS-0140 25140140 œ FLAC1 C9305 FLAC2 C9304 +3.3VMPU L9350 FLAC2 N.C. Q9301 FLAC1 -VP_AC1 -VP_AC1 F9301 DSP_AC2 œ œ 3.15A/125V DSP_AC1 +9VDG GNDDG GNDDG J7645...
Page 53 TX-NR1007/3007/5007/NA1007/5007,DTR-70.1/80.1 PRINTED CIRCUIT BOARD VIEWS-14 / U006 U0060 POWER SUPPLY & SPEAKER TERMINAL PC BOARD (BATRM-0214) Component side view from soldering side F9401A F9402A J6887 Q9423 GNDTU P9422B SPRLC 25140214C SPRLF SPRLSPB BCTRM-0214 SPRLSR R9427 J6890 SPRLSB R9428 R6822 C6872 J6886 SPRLFW P9422C...
Page 54 TX-NR1007/3007/5007/NA1007/5007,DTR-70.1/80.1 PRINTED CIRCUIT BOARD VIEWS-15 / U006 U0060 POWER SUPPLY & SPEAKER TERMINAL PC BOARD (BATRM-0214) Soldering side view from component side J6887 F9402A F9401A Q9423 GNDTU P9422B SPRLC SPRLF 25140214C SPRLSPB SPRLSR BCTRM-0214 R9427 J6890 SPRLSB C6872 R6822 R9428 SPRLFW J6886 P9422C...
Page 55 TX-NR1007/3007/5007/NA1007/5007,DTR-70.1/80.1 PRINTED CIRCUIT BOARD VIEWS-16 / U006 U0061 SPEAKER TERMINAL (SR/RH) PC BOARD (BATRM-0215) Component side view from soldering side Soldering side view from component side P6808 P6808 JL6901A JL6901A D6848 D6848 C6838 C6838 J6915 J6915 C6901 C6901 C6900 C6900 J6924 J6924 C6903...
Page 56 TX-NR3007/5007//5007,DTR-70.1/80.1, DHC-80.1, PR-SC5507 PRINTED CIRCUIT BOARD VIEWS-17 / U007, U010 U007 HDMI PC BOARD (BAHDM-0157) Component side view from soldering side RN8062 RN8072 DAC OUT AD IN C8840 C8839 C8838 R3603 RN8067 RN8063 P8008 C8057 C8111 C8103 R3116 RN8015 RN8019 R3510 RN8066 C8215...
Page 57 TX-NR3007/5007//5007,DTR-70.1/80.1, DHC-80.1, PR-SC5507 PRINTED CIRCUIT BOARD VIEWS-18 / U007, U010 U007 HDMI PC BOARD (BAHDM-0157) Soldering side view from component side C8084 C8083 C3507 C3509 R8099 R8097 C8086 R8095 C3523 C3506 C3556 C8085 R8126 C8081 C3508 R8264 C8082 RN8068 R8100 R8098 R8096 C3462...
Page 58 TX-NR1007/3007/5007/NA1007/5007,DTR-70.1/80.1 PRINTED CIRCUIT BOARD VIEWS-19 / U008 U0080~U0088 AMPLIFIER PC BOARD (BACLA-0226~0234) Component side view from soldering side BIAS BIAS BIAS BIAS R6040 R6047 R6043 R6045 R6283 R6287 R6280 R6113 R6285 R6110 R6117 R6115 Q6043 Q6040 C6007 C6003 Q6045 C6005 C6000 R5243 R5245...
Page 59 TX-NR1007/3007/5007/NA1007/5007,DTR-70.1/80.1 PRINTED CIRCUIT BOARD VIEWS-20 / U008 U0080~U0088 AMPLIFIER PC BOARD (BACLA-0226~0234) Soldering side view from component side BIAS BIAS BIAS BIAS R6040 R6045 R6043 R6047 R6283 R6280 R6285 R6287 R6110 R6115 R6113 R6117 Q6040 C6003 Q6043 C6000 C6005 Q6045 C6007 R5240 R5245...
Page 60 TX-NR5007 PACKING PROCEDURE-1 MDC type Procedure of door section 1. Open the Door. A808 A833 A840 A882 2. Cushion (A616) on Front panel and fixed with the Fixlon tape (A615). A837 A852 A847 A891 A616 A615 A892 A838 A820 A853...
Page 61 TX-NR5007 PACKING PROCEDURE-2 MMP, MMR type Procedure of door section A808 1. Open the Door. A830 A837 2. Cushion (A616) on Front panel and fixed with A882 the Fixlon tape (A615). A852 A831 A839 A892 A815 A616 A841 A832 A615...
Page 62: Exploded View Parts List
1/221 PAGE TX-NR5007 <Note> Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. NOTE : THE COMPONENTS IDENTIFIED BY THE MARK ! ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE ONLY WITH PART NUMBER SPECIFIED.
Page 63 2/221 PAGE Q6061A ISO SHEET ISO SHEET(NR5007_5CH) 223051 EXPLODED Q6062 TTA0002(Q)TO3PL 2204140 EXPLODED Q6063 TTA0002(Q)TO3PL 2204140 EXPLODED Q6064 TTA0002(Q)TO3PL 2204140 EXPLODED Q6065 TTA0002(Q)TO3PL 2204140 EXPLODED Q6066 TTA0002(Q)TO3PL 2204140 EXPLODED Q6067 TTA0002(Q)TO3PL 2204140 EXPLODED Q6068 TTA0002(Q)TO3PL 2204140 EXPLODED Q9427 2SB1565-E 2202715 EXPLODED Q9427or TR 2SA1488-Y...
Page 64 3/221 PAGE F6604 FUSE 20A-UL-250V 252304GR EXPLODED F9100 FUSE 6.3A-SE-EAK FUSE 252079GR !, <MMP, MMR> EXPLODED F9100or FUSE 6.3A-SE-TL250V ( 1) 252279GR !, <MMP, MMR> EXPLODED F9100 FUSE 12A-UL-ST6 252340GR !, <MDC> EXPLODED F9301 FUSE 3.15A-UL/T-233 252323GR EXPLODED F9301or FUSE 3.15A-T/UL-ST2 ( 1) 252256GR EXPLODED...
Page 65 4/221 PAGE A025 HOLDER UA-0 27190432 EXPLODED A027 HOLDER WS-4NS 27191207 EXPLODED A029 RETAINER (HS-R)B 27142163 EXPLODED A031 SCREW 3TTB+8B(3CM)SR 801637 EXPLODED A033 HOLDER UA-0 27190432 EXPLODED A037 SCREW 3TTB+8B(3CM)SR 801637 EXPLODED A039 SCREW 3TTB+8B(3CM)SR 801637 EXPLODED A041 HEAT SINK(S) 27160608 EXPLODED A043...
Page 66 5/221 PAGE W15 x 3t TAPE A109 IB CUSHION (1) 28141585 EXPLODED A111 SCREW 4TTC+8C(3BC) 830440089GR EXPLODED A113 SCREW 4TTC+8C(3BC) 830440089GR EXPLODED A115 SCREW 3TTB+8B(3CM)SR 801637 EXPLODED A119 SCREW 4TTC+8C(3BC) 830440089GR EXPLODED d = 9mm t=0.5 A121 SPACER 27270489 EXPLODED A125 SCREW 3TTB+8B(3CM)SR...
Page 67 6/221 PAGE A183 HOLDER KGLS-18S 27190470 EXPLODED A185 HOLDER KGLS-22RT 27190772 EXPLODED A187 SCREW 3TTB+8B(3CM)SR 801637 EXPLODED A189 SCREW 3TTB+8B(3CM)SR 801637 EXPLODED A191 SCREW 3TTB+8B(3CM)SR 801637 EXPLODED A193 SCREW 3TTB+8B(3CM)SR 801637 EXPLODED A195 SCREW 3TTB+8B(3BC) 838430088GR EXPLODED A197 SCREW 3TTB+8B(3BC) 838430088GR EXPLODED A199...
Page 68 7/221 PAGE A299 SCREW 3TTB+8B(3CM)SR 801637 EXPLODED P6800 P RIVET JB-407A-C 880052 <MMP, MMR> EXPLODED [CABINET] EXPLODED A301 F BRACKET AS(5007 BLACK) 27111564D EXPLODED A301 F BRACKET AS(5007 SILVER) 27111565D EXPLODED A303 B PLATE 28133428 EXPLODED A303 B PLATE 28133429 EXPLODED A307 FACET...
Page 69 29364123 EXPLODED A555 ST SCREW 4TTB+8C(NI) 838240089 EXPLODED A555 SCREW 4TTB+8C(3BC) 838440089GR EXPLODED A557 SCREW 3TTB+8B(3CM)SR 801637 EXPLODED A557 SCREW 3TTB+8B(3BC) 838430088GR EXPLODED A561 LABEL HOOKUP-ONKYO 29363194 (B) <MDC> EXPLODED A694 CUSHION 28141828 (FNP) t25 x 15 x 10 EXPLODED...
Page 70 9/221 PAGE [TUNER UNIT] EXPLODED U001 U0010 + U0011 + U0012 + U0013 + U0014 BAAF-0180-1C * 1B234580-1C EXPLODED U0010 POWER SUPPLY PC board ass'y BAAF-0180-1C 1B2345180-1C EXPLODED U0011 DIODE PC board ass'y BAPS-0181-1C INCLUDED IN REF.NO. U0010 EXPLODED U0012 RELAY PC board ass'y BAPS-0182-1C 1B2345182-1C...
Page 71 10/221 PAGE U0045 SIRIUS PC board ass'y BARF-0204-1H 1B2345204-1H N <MMR> EXPLODED U0046 DG AUDIO IN PC board ass'y BAETC-0246-1G N <MDC>, NSP EXPLODED U0046 DG AUDIO IN PC board ass'y BAETC-0246-1H N <MMP>, NSP EXPLODED U0046 DG AUDIO IN PC board ass'y BAETC-0246-1H N <MMR>, NSP EXPLODED...
Page 72 11/221 PAGE U0058 HOLDER PC board BAETC-0128-1E N <MDC>, NSP EXPLODED U0058 HOLDER PC board BAETC-0128-1F N <MMP>, NSP EXPLODED U0058 HOLDER PC board BAETC-0128-1F N <MMR>, NSP EXPLODED U0059 HOLDER PC board BAETC-0144-1F N <MMP>, NSP EXPLODED U0059 HOLDER PC board BAETC-0144-1F N <MMR>, NSP EXPLODED...
Page 73 U011 TUNER UNIT FAEH06-E01EX 240165 <MMP> EXPLODED U011 TUNER UNIT FAEH06-E01EX 240165 <MMR> EXPLODED TX-NR5007 PC BOARD PARTS LIST U0010 POWER SUPPLY PC BOARD (BAAF-0180-1C) PCB-U001 U0011 DIODE PC BOARD (BAPS-0181-1C) PCB-U001 U0012 RELAY PC BOARD (BAPS-0182-1C) PCB-U001 U0013 THERMAL SENSOR FUSE PC BOARD (BAETC-0183-1C)
Page 74 13/221 PAGE Q6000 2SC1740S-S 2213285T PCB-U001 Q6001 2SC1740S-S 2213285T PCB-U001 Q6002 2SC1740S-S 2213285T PCB-U001 Q6003 2SC1740S-S 2213285T PCB-U001 Q6004 2SC1740S-S 2213285T PCB-U001 Q6005 2SC1740S-S 2213285T PCB-U001 Q6006 2SC1740S-S 2213285T PCB-U001 Q6007 2SC1740S-S 2213285T PCB-U001 Q6008 2SC1740S-S 2213285T PCB-U001 Q6226 2SB1240-R 2213794T PCB-U001 Q6380...
Page 75 14/221 PAGE Q6713 or TR KTA1268-BL ( 1) 2215886T PCB-U001 [CAPACITOR] PCB-U001 C6222 UTSP C CE04W25V-220M(UTSP) 397552217T PCB-U001 C6601 MKT C B32529C0102J289 376491024T PCB-U001 C6601 or TF C ECQ-B50V-102J ( 1) 374721024T PCB-U001 C6602 PLA C ECQE250V-334J 3700083S PCB-U001 C6611 MKT C B32529C0102J289 376491024T...
Page 76 15/221 PAGE R6603 METAL O R RS1/2WBJ-22 443522204T PCB-U001 R6611 CARBON R R16J-1K 417341024T PCB-U001 R6612 CARBON R R16J-4.7K 417344724T PCB-U001 R6613 METAL O R RS1/2WBJ-22 443522204T PCB-U001 R6701 CARBON R R16J-22K 417342234T PCB-U001 R6702 CARBON R R16J-10K 417341034T PCB-U001 R6704 CARBON R R16J-33K...
Page 77 16/221 PAGE P003 BCPS-0182 { 1} 25140182 PCB-U001 P004 BCETC-0183 { 1} 25140183 PCB-U001 P005 BCETC-0184 { 1} 25140184 PCB-U001 P5000A SOCKET AS NSAS-20P1811 2009991171UL PCB-U001 P5001A SOCKET AS NSAS-16P1810 2009991170UL PCB-U001 P5002A CRIMP AS CRIMP SR805_1 20799169UL PCB-U001 P5010B PLUG NPLG-3P0958 25056008...
Page 78 17/221 PAGE P6140 SOCKET AS NSAS-9P1790 2009991156UL PCB-U001 P6240 SOCKET AS NSAS-9P1812 2009991172AUL PCB-U001 P6340 SOCKET AS NSAS-8P1660 2009991064AUL PCB-U001 P6500 PLUG NPLG-7P163 25055179 PCB-U001 P6550 PLUG NPLG-2P83 25055099 PCB-U001 P6560 PLUG NPLG-2P568 25055600 PCB-U001 P6601 SOCKET AS NSAS7P-1815 2009991174UL PCB-U001 P6601A PLUG NPLG-7P163...
Page 79 18/221 PAGE D6006 DIODE 1SS133 223163T PCB-U002 D6007 DIODE 1SS133 223163T PCB-U002 D6008 DIODE 1SS133 223163T PCB-U002 Q6070 2SC2631-R 2214984T PCB-U002 Q6070 or TR 2SC2631-S ( 1) 2214985T PCB-U002 Q6071 2SC2631-R 2214984T PCB-U002 Q6071 or TR 2SC2631-S ( 1) 2214985T PCB-U002 Q6072 2SC2631-R...
Page 80 19/221 PAGE L6012 FR CORE 5597-45502 PCB-U002 L6013 FR CORE 5597-45502 PCB-U002 L6014 FR CORE 5597-45502 PCB-U002 L6015 FR CORE 5597-45502 PCB-U002 L6016 FR CORE 5597-45502 PCB-U002 L6017 FR CORE 5597-45502 PCB-U002 L6018 FR CORE 5597-45502 PCB-U002 [CAPACITOR] PCB-U002 C6040 TF C ECQ-V50V-223J 374722234T...
Page 81 20/221 PAGE R6096 METAL O R RS1/2WBJ-10 443521004T PCB-U002 R6097 METAL O R RS1/2WBJ-10 443521004T PCB-U002 R6098 METAL O R RS1/2WBJ-10 443521004T PCB-U002 R6170 CARBON R R16J-33K 417343334T PCB-U002 R6171 CARBON R R16J-33K 417343334T PCB-U002 R6172 CARBON R R16J-33K 417343334T PCB-U002 R6173 CARBON R...
Page 82 21/221 PAGE R6213 CARBON R R16J-47K 417344734T PCB-U002 R6214 CARBON R R16J-47K 417344734T PCB-U002 R6215 CARBON R R16J-47K 417344734T PCB-U002 R6216 CARBON R R16J-47K 417344734T PCB-U002 R6217 CARBON R R16J-47K 417344734T PCB-U002 R6218 CARBON R R16J-47K 417344734T PCB-U002 R6230 CARBON R R16J-47K 417344734T PCB-U002...
Page 83 22/221 PAGE [SW TRM] PCB-U002 JL6041B WIRE TRAP NPLG-3P586 25055624 PCB-U002 JL6042A WIRE HOL NSCT-3P874 25051087 PCB-U002 JL6042B WIRE TRAP NPLG-3P586 25055624 PCB-U002 P001 BCAMP-0191 25140191B PCB-U002 P002 BCAMP-0192 { 1} 25140192 PCB-U002 P6030A PLUG IMSA-9115B-05 25056335 PCB-U002 P6031A PLUG IMSA-9115B-05 25056335 PCB-U002...
Page 84 23/221 PAGE P6070 PLUG NPLG-2P645 25055689 PCB-U002 P6071 PLUG NPLG-2P645 25055689 PCB-U002 P6072 PLUG NPLG-2P645 25055689 PCB-U002 P6073 PLUG NPLG-2P645 25055689 PCB-U002 P6074 PLUG NPLG-2P645 25055689 PCB-U002 P6075 PLUG NPLG-2P645 25055689 PCB-U002 P6076 PLUG NPLG-2P645 25055689 PCB-U002 P6077 PLUG NPLG-2P645 25055689 PCB-U002 P6078...
Page 85 24/221 PAGE D2003 DIODE RB070M-30 22380361R2 PCB-U003 D2004 ZENER D UDZS3.9B 224550390R2 PCB-U003 D2005 DIODE RL1N4003 22380260T PCB-U003 D2006 DIODE RL1N4003 22380260T PCB-U003 D2007 DIODE RL1N4003 22380260T PCB-U003 D2008 DIODE RL1N4003 22380260T PCB-U003 D2009 ZENER D UDZS3.9B 224550390R2 PCB-U003 D2010 C-DIODE 1SS352 223234R2...
Page 86 25/221 PAGE D2704 or C-DIODE MA2J111 ( 1) 223279R2 PCB-U003 D2704 or C-DIODE KDS4148U ( 1) 223283R2 PCB-U003 D2705 C-DIODE 1SS352 223234R2 PCB-U003 D2705 or C-DIODE 1SS355 ( 1) 223269R2 PCB-U003 D2705 or C-DIODE MA2J111 ( 1) 223279R2 PCB-U003 D2705 or C-DIODE KDS4148U ( 1) 223283R2 PCB-U003...
Page 87 26/221 PAGE D4431 or C-DIODE 1SS355 ( 1) 223269R2 PCB-U003 D4431 or C-DIODE MA2J111 ( 1) 223279R2 PCB-U003 D4431 or C-DIODE KDS4148U ( 1) 223283R2 PCB-U003 D4432 C-DIODE 1SS352 223234R2 PCB-U003 D4432 or C-DIODE 1SS355 ( 1) 223269R2 PCB-U003 D4432 or C-DIODE MA2J111 ( 1) 223279R2 PCB-U003...
Page 88 27/221 PAGE D4443 or C-DIODE MA2J111 ( 1) 223279R2 PCB-U003 D4443 or C-DIODE KDS4148U ( 1) 223283R2 PCB-U003 D4444 C-DIODE 1SS352 223234R2 PCB-U003 D4444 or C-DIODE 1SS355 ( 1) 223269R2 PCB-U003 D4444 or C-DIODE MA2J111 ( 1) 223279R2 PCB-U003 D4444 or C-DIODE KDS4148U ( 1) 223283R2 PCB-U003...
Page 89 28/221 PAGE Q2701 or TR RN1402 ( 1) 2214470R2 PCB-U003 Q2702 2SA1162-GR 2214375R2 PCB-U003 Q2703 KRC102S 2216190R2 PCB-U003 Q2703 or TR RN1402 ( 1) 2214470R2 PCB-U003 Q4008 NE5532APSR 22242283R2 PCB-U003 Q4009 NE5532APSR 22242283R2 PCB-U003 Q4010 NE5532APSR 22242283R2 PCB-U003 Q4011 NE5532APSR 22242283R2 PCB-U003 Q4041...
Page 90 29/221 PAGE Q4301 NE5532APSR 22242283R2 PCB-U003 Q4341 NE5532APSR 22242283R2 PCB-U003 Q4342 NE5532APSR 22242283R2 PCB-U003 Q4371 NE5532APSR 22242283R2 PCB-U003 Q4401 2SC2712-GR 2213145R2 PCB-U003 Q4402 2SA950-Y 2211504T PCB-U003 Q4403 2SA1162-GR 2214375R2 PCB-U003 Q4404 2SC2120-Y 2211164T PCB-U003 Q4420 RN1402 2214470R2 PCB-U003 Q4421 RN1402 2214470R2 PCB-U003 Q4422...
Page 91 30/221 PAGE Q4648 RN1441 2215410R2 PCB-U003 Q4741 RN1441 2215410R2 PCB-U003 Q4742 RN1441 2215410R2 PCB-U003 Q4801 RN1441 2215410R2 PCB-U003 Q4802 RN1441 2215410R2 PCB-U003 Q4803 RN1441 2215410R2 PCB-U003 Q4804 RN1441 2215410R2 PCB-U003 [TRANS COIL] PCB-U003 L2000 CHOKE COIL NCH-2541 231363K470A PCB-U003 L2000 or COIL 0182-7310-470K-RB ( 1) 231389 PCB-U003...
Page 92 31/221 PAGE L2523 EMIFIL BK1608LM182-T 230958R1 PCB-U003 L2702 EMIFIL BK1608LM182-T 230958R1 PCB-U003 L2703 EMIFIL BK1608LM182-T 230958R1 PCB-U003 [CAPACITOR] PCB-U003 C2000 ELECT C CE04W18V-10000M(VZ) 3945H1037S PCB-U003 C2002 VR C CE04W16V-220M(VR) 394642217T PCB-U003 C2003 UTSP C CE04W50V-10M(UTSP) 397581007T PCB-U003 C2004 VR C CE04W16V-100M(VR) 394641017T PCB-U003...
Page 93 32/221 PAGE C2146 VR C CE04W35V-47M(VR) 394664707T PCB-U003 C2148 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U003 C2149 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U003 C2150 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U003 C2152 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U003 C2153 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U003 C2154 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U003...
Page 94 33/221 PAGE C2194 VR C CE04W35V-47M(VR) 394664707T PCB-U003 C2195 VR C CE04W35V-47M(VR) 394664707T PCB-U003 C2196 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U003 C2197 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U003 C2198 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U003 C2199 VR C CE04W35V-47M(VR) 394664707T PCB-U003 C2200 C-CERA C CC725CH1H-151J1 342101514R1 PCB-U003...
Page 95 34/221 PAGE C2239 C-CERA C CK725B0J-225K 332092255R1 PCB-U003 C2240 C-CERA C CK725B0J-225K 332092255R1 PCB-U003 C2241 C-CERA C CK725B0J-225K 332092255R1 PCB-U003 C2242 C-CERA C CK725B0J-225K 332092255R1 PCB-U003 C2243 C-CERA C CK725B0J-225K 332092255R1 PCB-U003 C2244 C-CERA C CK725B0J-225K 332092255R1 PCB-U003 C2245 C-CERA C CK725B0J-225K 332092255R1 PCB-U003...
Page 96 35/221 PAGE C2526 C-CERA C CK725B1H-102K1 332101025R1 PCB-U003 C2527 C-CERA C CC725CH1H-470J1 342104704R1 PCB-U003 C2528 VR C CE04W16V-100M(VR) 394641017T PCB-U003 C2529 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U003 C2530 C-CERA C CK725B1H-102K1 332101025R1 PCB-U003 C2531 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U003 C2532 C-CERA C CC725CH1H-470J1 342104704R1 PCB-U003...
Page 97 36/221 PAGE C4042 UPZ C 2AUPZTF221JE 376332214T PCB-U003 C4043 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U003 C4044 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U003 C4045 UTSP C CE04W50V-100M(UTSP) 397581017T PCB-U003 C4046 UTSP C CE04W50V-100M(UTSP) 397581017T PCB-U003 C4060 MKT C B32529C0102J289 376491024T PCB-U003 C4061 C-CERA C CC725CH1H-221J1...
Page 98 37/221 PAGE C4123 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U003 C4124 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U003 C4131 UPZ C 2AUPZTF221JE 376332214T PCB-U003 C4132 UPZ C 2AUPZTF221JE 376332214T PCB-U003 C4133 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U003 C4134 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U003 C4135...
Page 99 38/221 PAGE C4226 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U003 C4243 MKT C B32529C0102J289 376491024T PCB-U003 C4244 C-CERA C CC725CH1H-102J1 342101024R1 PCB-U003 C4303 UTSP C CE04W50V-1M(UTSP) 397580107T PCB-U003 C4304 C-CERA C CK725F1C-224Z1 332172240R1 PCB-U003 C4305 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U003 C4345 UTSP C CE04W50V 47M(UTSP) 397584707T...
Page 100 39/221 PAGE C4432 TF C ECQ-V50V-104J 374721044T PCB-U003 C4433 TF C ECQ-V50V-104J 374721044T PCB-U003 C4434 TF C ECQ-V50V-104J 374721044T PCB-U003 C4435 TF C ECQ-V50V-104J 374721044T PCB-U003 C4436 TF C ECQ-V50V-104J 374721044T PCB-U003 C4441 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U003 C4442 UTSP C CE04W50V 47M(UTSP) 397584707T...
Page 101 40/221 PAGE C4615 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U003 C4616 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U003 C4617 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U003 C4620 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U003 C4621 MKT C B32529C0102J289 376491024T PCB-U003 C4633 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U003 C4634...
Page 102 41/221 PAGE C4802 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U003 C4803 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U003 C4804 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U003 C4811 C-CERA C CC725CH1H-221J1 342102214R1 PCB-U003 C4812 C-CERA C CC725CH1H-221J1 342102214R1 PCB-U003 C4813 C-CERA C CC725CH1H-221J1 342102214R1 PCB-U003 C4814 C-CERA C...
Page 103 42/221 PAGE R2100 C-CARBON R RN72K1J-750JE 435037504R1 PCB-U003 R2101 C-CARBON R RN72K1J-750JE 435037504R1 PCB-U003 R2102 C-CARBON R RN72K1J-750JE 435037504R1 PCB-U003 R2104 C-CARBON R RN72K1J-750JE 435037504R1 PCB-U003 R2105 C-CARBON R RN72K1J-750JE 435037504R1 PCB-U003 R2106 C-CARBON R RN72K1J-750JE 435037504R1 PCB-U003 R2107 C-CARBON R RN72K1J-750JE 435037504R1 PCB-U003...
Page 104 43/221 PAGE R2179 C-CARBON R RN72K1J-750JE 435037504R1 PCB-U003 R2180 C-CARBON R RN72K1J-750JE 435037504R1 PCB-U003 R2181 C-CARBON R RN72K1J-750JE 435037504R1 PCB-U003 R2186 C-CARBON R RN72K1J-750JE 435037504R1 PCB-U003 R2189 C-CARBON R RN72K1J-750JE 435037504R1 PCB-U003 R2190 METAL R RNU1/2WCJ-0.1 453531094T PCB-U003 R2191 METAL R RNU1/2WCJ-0.1 453531094T PCB-U003...
Page 105 44/221 PAGE R2505 C-CARBON R RN72K1J-223JE 435032234R1 PCB-U003 R2506 C-CARBON R RN72K1J-223JE 435032234R1 PCB-U003 R2507 C-CARBON R RN72K1J-223JE 435032234R1 PCB-U003 R2508 C-CARBON R RN72K1J-223JE 435032234R1 PCB-U003 R2510 C-CARBON R RN72K1J-223JE 435032234R1 PCB-U003 R2512 C-CARBON R RN72K1J-223JE 435032234R1 PCB-U003 R2513 C-CARBON R RN72K1J-220JE 435032204R1 PCB-U003...
Page 106 45/221 PAGE R2707 C-CARBON R RN72K1J-224JE 435032244R1 PCB-U003 R2708 C-CARBON R RN72K1J-102JE 435031024R1 PCB-U003 R2710 C-CARBON R RN72K1J-101JE 435031014R1 PCB-U003 R2714 C-CARBON R RN72K1J-000JE 435030004R1 PCB-U003 R2715 C-CARBON R RN72K1J-000JE 435030004R1 PCB-U003 R2716 C-CARBON R RN72K1J-000JE 435030004R1 PCB-U003 R2718 C-CARBON R RN72K1J-000JE 435030004R1 PCB-U003...
Page 107 46/221 PAGE R4075 C-CARBON R RN72K1J-224JE 435032244R1 PCB-U003 R4076 C-CARBON R RN72K1J-224JE 435032244R1 PCB-U003 R4077 METAL O R RS1/2WBJ-22 443522204T PCB-U003 R4078 METAL O R RS1/2WBJ-22 443522204T PCB-U003 R4081 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U003 R4082 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U003 R4083 C-CARBON R RN72K1J-563JE...
Page 108 47/221 PAGE R4122 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U003 R4123 C-CARBON R RN72K1J-563JE 435035634R1 PCB-U003 R4124 C-CARBON R RN72K1J-563JE 435035634R1 PCB-U003 R4125 C-CARBON R RN72K1J-224JE 435032244R1 PCB-U003 R4126 C-CARBON R RN72K1J-224JE 435032244R1 PCB-U003 R4131 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U003 R4132 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U003...
Page 109 48/221 PAGE R4214 METAL O R RS1/2WBJ-15 443521504T PCB-U003 R4215 METAL O R RS1/2WBJ-15 443521504T PCB-U003 R4216 C-CARBON R RN72K1J-681JE 435036814R1 PCB-U003 R4217 C-CARBON R RN72K1J-681JE 435036814R1 PCB-U003 R4218 METAL O R RS1/2WBJ-10 443521004T PCB-U003 R4219 METAL O R RS1/2WBJ-10 443521004T PCB-U003 R4221...
Page 110 49/221 PAGE R4348 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U003 R4349 C-CARBON R RN72K1J-152JE 435031524R1 PCB-U003 R4350 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U003 R4351 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U003 R4352 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U003 R4353 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U003 R4354 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U003...
Page 111 50/221 PAGE R4400 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U003 R4401 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U003 R4402 METAL O R RS1/2WBJ-22 443522204T PCB-U003 R4403 METAL O R RS1/2WBJ-22 443522204T PCB-U003 R4404 C-CARBON R RN72K1J-222JE 435032224R1 PCB-U003 R4405 C-CARBON R RN72K1J-222JE 435032224R1 PCB-U003 R4406 C-CARBON R RN72K1J-331JE...
Page 112 51/221 PAGE R4456 C-CARBON R RN72K2E-220JE 435222204R1 PCB-U003 R4463 C-CARBON R RN72K1J-473JE 435034734R1 PCB-U003 R4464 C-CARBON R RN72K1J-473JE 435034734R1 PCB-U003 R4465 C-CARBON R RN72K1J-223JE 435032234R1 PCB-U003 R4466 C-CARBON R RN72K1J-223JE 435032234R1 PCB-U003 R4467 C-CARBON R RN72K1J-333JE 435033334R1 PCB-U003 R4468 C-CARBON R RN72K1J-333JE 435033334R1 PCB-U003...
Page 113 52/221 PAGE R4603 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U003 R4604 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U003 R4605 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U003 R4606 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U003 R4607 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U003 R4610 C-CARBON R RN72K1J-563JE 435035634R1 PCB-U003 R4611 C-CARBON R RN72K1J-563JE 435035634R1 PCB-U003...
Page 114 53/221 PAGE R4646 C-CARBON R RN72K1J-224JE 435032244R1 PCB-U003 R4647 C-CARBON R RN72K1J-223JE 435032234R1 PCB-U003 R4648 C-CARBON R RN72K1J-223JE 435032234R1 PCB-U003 R4650 C-CARBON R RN72K1J-221JE 435032214R1 PCB-U003 R4651 C-CARBON R RN72K1J-221JE 435032214R1 PCB-U003 R4652 C-CARBON R RN72K1J-221JE 435032214R1 PCB-U003 R4653 C-CARBON R RN72K1J-221JE 435032214R1 PCB-U003...
Page 115 54/221 PAGE R4683 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U003 R4684 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U003 R4685 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U003 R4686 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U003 R4687 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U003 R4688 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U003 R4741 C-CARBON R RN72K1J-224JE 435032244R1 PCB-U003...
Page 116 55/221 PAGE R4842 C-CARBON R RN72K1J-224JE 435032244R1 PCB-U003 [SW TRM] PCB-U003 NTM-1P232(M1700) 25060301 PCB-U003 E2000 TRM-423(SCREW) NEJITANSI ST3 25060495 PCB-U003 F2001A FUSE HOL NSCT-1P2031 25052133T PCB-U003 F2001B FUSE HOL NSCT-1P2031 25052133T PCB-U003 F2004A FUSE HOL NSCT-1P2031 25052133T PCB-U003 F2004B FUSE HOL NSCT-1P2031 25052133T PCB-U003...
Page 117 56/221 PAGE P2112 PIN JACK NPJ-10PDSY628 25045849 PCB-U003 P2112 or PIN JACK NPJ-10PDBY481 ( 1) 25045684 PCB-U003 P2113 PIN JACK NPJ-1PDY655 25045882 PCB-U003 P2500 SOCKET NNA1-01-006 25053357 PCB-U003 P2700 ST JACK HSJ1002-01-6020 25045647 PCB-U003 P2702 ST JACK HSJ1002-01-6020 25045647 PCB-U003 P2901 RETAINER (PC-HOLD)
Page 118 57/221 PAGE RL4008 RELAY NRL-2P2A-DC12-178 25065664 PCB-U003 RL4009 RELAY NRL-2P2A-DC12-178 25065664 PCB-U003 [CHASSIS SCREW] PCB-U003 Q2000A HEAT-SINK HEAT-SINK(RAD-67) 27160209 PCB-U003 Q2000B SCREW 3P+6FN(3BC) 82143006GR PCB-U003 U0040 DAC PC BOARD (BADG-0208-1G/ 1H) PCB-U004 U0041 MAIN CPU PC BOARD (BACPU-0209-1G/ 1H) PCB-U004 U0042 ZONE-2 &...
Page 119 58/221 PAGE D7003 or C-DIODE 1SS355 ( 1) 223269R2 PCB-U004 D7003 or C-DIODE MA2J111 ( 1) 223279R2 PCB-U004 D7003 or C-DIODE KDS4148U ( 1) 223283R2 PCB-U004 D7006 C-DIODE 1SS352 223234R2 PCB-U004 D7006 or C-DIODE 1SS355 ( 1) 223269R2 PCB-U004 D7006 or C-DIODE MA2J111 ( 1) 223279R2 PCB-U004...
Page 120 59/221 PAGE Q1003 PCM1795DBR 22242612R2 N <MMP, MMR> PCB-U004 Q1004 PCM1795DBR 22242612R2 N <MDC> PCB-U004 Q1004 PCM1795DBR 22242612R2 N <MMP, MMR> PCB-U004 Q1005 PCM1795DBR 22242612R2 N <MDC> PCB-U004 Q1005 PCM1795DBR 22242612R2 N <MMP, MMR> PCB-U004 Q1006 PCM1795DBR 22242612R2 N <MDC> PCB-U004 Q1006 PCM1795DBR...
Page 121 60/221 PAGE Q1224 NE5532APSR 22242283R2 <MMP, MMR> PCB-U004 Q1225 NE5532APSR 22242283R2 <MDC> PCB-U004 Q1225 NE5532APSR 22242283R2 <MMP, MMR> PCB-U004 Q1226 NE5532APSR 22242283R2 <MDC> PCB-U004 Q1226 NE5532APSR 22242283R2 <MMP, MMR> PCB-U004 Q1227 NE5532APSR 22242283R2 <MDC> PCB-U004 Q1227 NE5532APSR 22242283R2 <MMP, MMR> PCB-U004 Q1228 NE5532APSR...
Page 122 61/221 PAGE Q1242 NE5532APSR 22242283R2 <MDC> PCB-U004 Q1242 NE5532APSR 22242283R2 <MMP, MMR> PCB-U004 Q1243 NE5532APSR 22242283R2 <MDC> PCB-U004 Q1243 NE5532APSR 22242283R2 <MMP, MMR> PCB-U004 Q1244 NE5532APSR 22242283R2 <MDC> PCB-U004 Q1244 NE5532APSR 22242283R2 <MMP, MMR> PCB-U004 Q1245 NE5532APSR 22242283R2 <MDC> PCB-U004 Q1245 NE5532APSR 22242283R2...
Page 123 62/221 PAGE Q4005 2SC2712-GR 2213145R2 PCB-U004 Q4006 2SC2240-BL(TPE2_F) 2211406T PCB-U004 Q4007 2SC2240-BL(TPE2_F) 2211406T PCB-U004 Q4037 NE5532APSR 22242283R2 <MDC> PCB-U004 Q4037 NE5532APSR 22242283R2 <MMP, MMR> PCB-U004 Q4038 NE5532APSR 22242283R2 <MDC> PCB-U004 Q4038 NE5532APSR 22242283R2 <MMP, MMR> PCB-U004 Q4046 M61540FP 22242497R2 PCB-U004 Q4047 M61540FP 22242497R2...
Page 124 63/221 PAGE Q7009 or TR RN1404 ( 1) 2214490R2 PCB-U004 Q7010 KRA102S 2216220R2 PCB-U004 Q7010 or TR RN2402 ( 1) 2214530R2 PCB-U004 Q7011 KRC102S 2216190R2 PCB-U004 Q7011 or TR RN1402 ( 1) 2214470R2 PCB-U004 Q7012 KRC104S 2216210R2 PCB-U004 Q7012 or TR RN1404 ( 1) 2214490R2 PCB-U004...
Page 125 64/221 PAGE Q7037 S3F80K9 22242602R3 <MDC> PCB-U004 Q7037 S3F80K9 22242602R3 <MMP, MMR> PCB-U004 Q7038 2SC2712-GR 2213145R2 <MDC> PCB-U004 Q7038 2SC2712-GR 2213145R2 <MMP, MMR> PCB-U004 NE5532APSR 22242283R2 <MDC> PCB-U004 NE5532APSR 22242283R2 <MMP, MMR> PCB-U004 [TRANS COIL] PCB-U004 L1001 CHOKE COIL LBC2518T4R7M 231364M047R2 PCB-U004 L1002...
Page 126 65/221 PAGE L3701 CHOKE COIL LBC2518T470M 231364M470R2 PCB-U004 L3702 CHOKE COIL LBC2518T4R7M 231364M047R2 PCB-U004 L3703 EMIFIL BK1608LM182-T 230958R1 PCB-U004 L3704 EMIFIL BK1608LM182-T 230958R1 PCB-U004 L3705 CHOKE COIL LBC2518T4R7M 231364M047R2 PCB-U004 L3706 CHOKE COIL LBC2518T4R7M 231364M047R2 PCB-U004 L3707 CHOKE COIL LBC2518T470M 231364M470R2 PCB-U004 L3708...
Page 127 66/221 PAGE C1005 C-FILM C ECHU16V-104J 373041044R2 PCB-U004 C1006 UTSP C CE04W10V-220M(UTSP) 397532217T PCB-U004 C1007 UTSP C CE04W10V-220M(UTSP) 397532217T PCB-U004 C1008 UTSP C CE04W10V-220M(UTSP) 397532217T PCB-U004 C1009 UTSP C CE04W10V-220M(UTSP) 397532217T PCB-U004 C101 C-CERA C CC725CH1H-331J1 342103314R1 <MMP, MMR> PCB-U004 C1010 UTSP C CE04W10V-220M(UTSP)
Page 128 67/221 PAGE C1035 C-FILM C ECHU16V-104J 373041044R2 PCB-U004 C1036 UTSP C CE04W10V-220M(UTSP) 397532217T PCB-U004 C1037 C-FILM C ECHU16V-104J 373041044R2 PCB-U004 C1038 UTSP C CE04W10V-220M(UTSP) 397532217T PCB-U004 C1039 UTSP C CE04W10V-220M(UTSP) 397532217T PCB-U004 C104 C-CERA C CK725B1H-103K1 332101035R1 <MMP, MMR> PCB-U004 C1040 UTSP C CE04W10V-220M(UTSP)
Page 129 68/221 PAGE C1213 C-FILM C ECHU50V-152J 373021524R2 PCB-U004 C1214 C-FILM C ECHU50V-152J 373021524R2 PCB-U004 C1215 MKT C B32529C0152J289 376491524T PCB-U004 C1216 MKT C B32529C0152J289 376491524T PCB-U004 C1217 C-FILM C ECHU50V-152J 373021524R2 PCB-U004 C1218 MKT C B32529C0152J289 376491524T PCB-U004 C1219 MKT C B32529C0152J289 376491524T PCB-U004...
Page 130 69/221 PAGE C1238 UPZ C 2AUPZTF331JE 376333314T <MDC> PCB-U004 C1238 UPZ C 2AUPZTF331JE 376333314T <MMP, MMR> PCB-U004 C1239 UPZ C 2AUPZTF331JE 376333314T <MDC> PCB-U004 C1239 UPZ C 2AUPZTF331JE 376333314T <MMP, MMR> PCB-U004 C1240 UPZ C 2AUPZTF331JE 376333314T <MDC> PCB-U004 C1240 UPZ C 2AUPZTF331JE 376333314T...
Page 131 70/221 PAGE C1254 MKT C B32529C0682J289 376496824T <MMP, MMR> PCB-U004 C1255 MKT C B32529C0682J289 376496824T <MDC> PCB-U004 C1255 MKT C B32529C0682J289 376496824T <MMP, MMR> PCB-U004 C1256 MKT C B32529C0682J289 376496824T <MDC> PCB-U004 C1256 MKT C B32529C0682J289 376496824T <MMP, MMR> PCB-U004 C1257 MKT C B32529C0682J289...
Page 132 71/221 PAGE C1271 UPZ C 2AUPZTF101JE 376331014T <MDC> PCB-U004 C1271 UPZ C 2AUPZTF101JE 376331014T <MMP, MMR> PCB-U004 C1272 UPZ C 2AUPZTF101JE 376331014T <MDC> PCB-U004 C1272 UPZ C 2AUPZTF101JE 376331014T <MMP, MMR> PCB-U004 C1273 UPZ C 2AUPZTF101JE 376331014T <MDC> PCB-U004 C1273 UPZ C 2AUPZTF101JE 376331014T...
Page 133 72/221 PAGE C1287 C-FILM C ECHU50V-222J 373022224R2 <MMP, MMR> PCB-U004 C1288 C-FILM C ECHU50V-222J 373022224R2 <MDC> PCB-U004 C1288 C-FILM C ECHU50V-222J 373022224R2 <MMP, MMR> PCB-U004 C1289 C-FILM C ECHU50V-222J 373022224R2 <MDC> PCB-U004 C1289 C-FILM C ECHU50V-222J 373022224R2 <MMP, MMR> PCB-U004 C1290 UTSP C CE04W25V-220M(UTSP)
Page 134 73/221 PAGE C1470 UPZ C 2AUPZTF221JE 376332214T <MDC> PCB-U004 C1470 UPZ C 2AUPZTF221JE 376332214T <MMP, MMR> PCB-U004 C1471 UPZ C 2AUPZTF221JE 376332214T <MDC> PCB-U004 C1471 UPZ C 2AUPZTF221JE 376332214T <MMP, MMR> PCB-U004 C1480 UPZ C 2AUPZTF101JE 376331014T <MDC> PCB-U004 C1480 UPZ C 2AUPZTF101JE 376331014T...
Page 135 74/221 PAGE C3713 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U004 C3714 UTSJ C CE04W25V-47M(UTSJ) 398054707T PCB-U004 C3715 VR C CE04W16V-100M(VR) 394641017T PCB-U004 C3716 UTSP C CE04W10V-470M(UTSP) 397534717T PCB-U004 C3717 C-FILM C ECHU50V-222J 373022224R2 PCB-U004 C3718 C-FILM C ECHU50V-222J 373022224R2 PCB-U004 C3719 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U004...
Page 136 75/221 PAGE C3749 UTSP C CE04W25V-47M(UTSP) 397554707T PCB-U004 C3750 UTSP C CE04W25V-47M(UTSP) 397554707T PCB-U004 C3886 C-CERA C CK725B1C-104K1 332121045R1 PCB-U004 C3887 C-CERA C CC725CH1H-101J1 342101014R1 PCB-U004 C3888 VR C CE04W16V-100M(VR) 394641017T PCB-U004 C3889 C-CERA C CC725CH1H-101J1 342101014R1 PCB-U004 C3890 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U004...
Page 137 76/221 PAGE C4004 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U004 C4005 C-CERA C CC725CH1H-221J1 342102214R1 PCB-U004 C4006 C-CERA C CC725CH1H-221J1 342102214R1 PCB-U004 C4007 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U004 C4008 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U004 C4009 C-CERA C CC725CH1H-152J1 342101524R1 PCB-U004 C4010 C-CERA C...
Page 138 77/221 PAGE C4514 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U004 C4515 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U004 C4516 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U004 C4517 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U004 C4518 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U004 C4519 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U004...
Page 139 78/221 PAGE C4917 CHIP ELECT C CEWX4V-22M 3981G2207R2 <MDC> PCB-U004 C4917 CHIP ELECT C CEWX4V-22M 3981G2207R2 <MMP, MMR> PCB-U004 C4918 CHIP ELECT C CEWX4V-22M 3981G2207R2 <MDC> PCB-U004 C4918 CHIP ELECT C CEWX4V-22M 3981G2207R2 <MMP, MMR> PCB-U004 C4919 TF C ECQ-V50V-333J 374723334T <MDC>...
Page 140 79/221 PAGE C4963 UTSP C CE04W25V-47M(UTSP) 397554707T <MMP, MMR> PCB-U004 C4964 UTSP C CE04W25V-47M(UTSP) 397554707T <MDC> PCB-U004 C4964 UTSP C CE04W25V-47M(UTSP) 397554707T <MMP, MMR> PCB-U004 UTSP C CE04W50V-10M(UTSP) 397581007T <MDC> PCB-U004 UTSP C CE04W50V-10M(UTSP) 397581007T <MMP, MMR> PCB-U004 UTSP C CE04W50V-10M(UTSP) 397581007T <MDC>...
Page 141 80/221 PAGE C7021 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U004 C7022 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U004 C7023 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U004 C7024 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U004 C7025 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U004 C7026 C-CERA C CK725B1H-102K1 332101025R1 PCB-U004 C7027 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U004...
Page 142 81/221 PAGE C7060 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U004 C7061 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U004 C7302 VR C CE04W6.3V-470M(VR) 394624717T <MDC> PCB-U004 C7302 VR C CE04W6.3V-470M(VR) 394624717T <MMP, MMR> PCB-U004 C7303 C-CERA C CK725F1E-104Z1 332161040R1 <MDC> PCB-U004 C7303 C-CERA C CK725F1E-104Z1 332161040R1 <MMP, MMR>...
Page 143 82/221 PAGE R1018 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U004 R1019 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R1020 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R1021 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U004 R1022 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U004 R1023 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004 R1024 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004...
Page 144 83/221 PAGE R1051 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U004 R1052 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U004 R1053 C-CARBON R RN72K1J-750JE 435037504R1 PCB-U004 R1054 C-CARBON R RN72K1J-750JE 435037504R1 PCB-U004 R1055 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004 R1056 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004 R1057 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U004...
Page 145 84/221 PAGE R1215 C-CARBON R RN72K1J-821JE 435038214R1 PCB-U004 R1216 C-CARBON R RN72K1J-821JE 435038214R1 PCB-U004 R1217 C-CARBON R RN72K1J-821JE 435038214R1 PCB-U004 R1218 C-CARBON R RN72K1J-821JE 435038214R1 PCB-U004 R1219 C-CARBON R RN72K1J-821JE 435038214R1 PCB-U004 R1220 C-CARBON R RN72K1J-271JE 435032714R1 <MDC> PCB-U004 R1220 C-CARBON R RN72K1J-271JE 435032714R1...
Page 146 85/221 PAGE R1238 C-CARBON R RN72K1J-272JE 435032724R1 PCB-U004 R1239 C-CARBON R RN72K1J-272JE 435032724R1 PCB-U004 R1240 C-CARBON R RN72K1J-271JE 435032714R1 <MDC> PCB-U004 R1240 C-CARBON R RN72K1J-271JE 435032714R1 <MMP, MMR> PCB-U004 R1241 C-CARBON R RN72K1J-271JE 435032714R1 <MDC> PCB-U004 R1241 C-CARBON R RN72K1J-271JE 435032714R1 <MMP, MMR>...
Page 147 86/221 PAGE R1261 C-CARBON R RN72K1J-472JE 435034724R1 PCB-U004 R1262 C-CARBON R RN72K1J-472JE 435034724R1 PCB-U004 R1263 C-CARBON R RN72K1J-472JE 435034724R1 PCB-U004 R1264 C-CARBON R RN72K1J-472JE 435034724R1 PCB-U004 R1265 C-CARBON R RN72K1J-472JE 435034724R1 PCB-U004 R1266 C-CARBON R RN72K1J-472JE 435034724R1 PCB-U004 R1267 C-CARBON R RN72K1J-472JE 435034724R1 PCB-U004...
Page 148 87/221 PAGE R1287 C-CARBON R RN72K1J-820JE 435038204R1 <MDC> PCB-U004 R1287 C-CARBON R RN72K1J-820JE 435038204R1 <MMP, MMR> PCB-U004 R1288 C-CARBON R RN72K1J-820JE 435038204R1 <MDC> PCB-U004 R1288 C-CARBON R RN72K1J-820JE 435038204R1 <MMP, MMR> PCB-U004 R1289 C-CARBON R RN72K1J-820JE 435038204R1 <MDC> PCB-U004 R1289 C-CARBON R RN72K1J-820JE 435038204R1...
Page 149 88/221 PAGE R1303 C-CARBON R RN72K1J-472JE 435034724R1 <MMP, MMR> PCB-U004 R1304 C-CARBON R RN72K1J-472JE 435034724R1 <MDC> PCB-U004 R1304 C-CARBON R RN72K1J-472JE 435034724R1 <MMP, MMR> PCB-U004 R1305 C-CARBON R RN72K1J-472JE 435034724R1 <MDC> PCB-U004 R1305 C-CARBON R RN72K1J-472JE 435034724R1 <MMP, MMR> PCB-U004 R1306 C-CARBON R RN72K1J-472JE...
Page 150 89/221 PAGE R1320 C-CARBON R RN72K1J-472JE 435034724R1 <MDC> PCB-U004 R1320 C-CARBON R RN72K1J-472JE 435034724R1 <MMP, MMR> PCB-U004 R1321 C-CARBON R RN72K1J-472JE 435034724R1 <MDC> PCB-U004 R1321 C-CARBON R RN72K1J-472JE 435034724R1 <MMP, MMR> PCB-U004 R1322 C-CARBON R RN72K1J-472JE 435034724R1 <MDC> PCB-U004 R1322 C-CARBON R RN72K1J-472JE 435034724R1...
Page 151 90/221 PAGE R1336 C-CARBON R RN72K1J-472JE 435034724R1 <MMP, MMR> PCB-U004 R1337 C-CARBON R RN72K1J-472JE 435034724R1 <MDC> PCB-U004 R1337 C-CARBON R RN72K1J-472JE 435034724R1 <MMP, MMR> PCB-U004 R1338 C-CARBON R RN72K1J-472JE 435034724R1 <MDC> PCB-U004 R1338 C-CARBON R RN72K1J-472JE 435034724R1 <MMP, MMR> PCB-U004 R1339 C-CARBON R RN72K1J-472JE...
Page 152 91/221 PAGE R1353 C-CARBON R RN72K1J-561JE 435035614R1 <MDC> PCB-U004 R1353 C-CARBON R RN72K1J-561JE 435035614R1 <MMP, MMR> PCB-U004 R1354 C-CARBON R RN72K1J-561JE 435035614R1 <MDC> PCB-U004 R1354 C-CARBON R RN72K1J-561JE 435035614R1 <MMP, MMR> PCB-U004 R1355 C-CARBON R RN72K1J-561JE 435035614R1 <MDC> PCB-U004 R1355 C-CARBON R RN72K1J-561JE 435035614R1...
Page 153 92/221 PAGE R1369 C-CARBON R RN72K1J-102JE 435031024R1 <MMP, MMR> PCB-U004 R1370 C-CARBON R RN72K1J-152JE 435031524R1 <MDC> PCB-U004 R1370 C-CARBON R RN72K1J-152JE 435031524R1 <MMP, MMR> PCB-U004 R1371 C-CARBON R RN72K1J-152JE 435031524R1 <MDC> PCB-U004 R1371 C-CARBON R RN72K1J-152JE 435031524R1 <MMP, MMR> PCB-U004 R1372 C-CARBON R RN72K1J-272JE...
Page 154 93/221 PAGE R1386 C-CARBON R RN72K1J-272JE 435032724R1 <MDC> PCB-U004 R1386 C-CARBON R RN72K1J-272JE 435032724R1 <MMP, MMR> PCB-U004 R1387 C-CARBON R RN72K1J-272JE 435032724R1 <MDC> PCB-U004 R1387 C-CARBON R RN72K1J-272JE 435032724R1 <MMP, MMR> PCB-U004 R1388 C-CARBON R RN72K1J-272JE 435032724R1 <MDC> PCB-U004 R1388 C-CARBON R RN72K1J-272JE 435032724R1...
Page 155 94/221 PAGE R1461 C-CARBON R RN72K1J-272JE 435032724R1 PCB-U004 R1470 C-CARBON R RN72K1J-472JE 435034724R1 PCB-U004 R1471 C-CARBON R RN72K1J-472JE 435034724R1 PCB-U004 R1480 C-CARBON R RN72K1J-472JE 435034724R1 PCB-U004 R1481 C-CARBON R RN72K1J-472JE 435034724R1 PCB-U004 R1490 C-CARBON R RN72K1J-820JE 435038204R1 <MDC> PCB-U004 R1490 C-CARBON R RN72K1J-820JE 435038204R1...
Page 156 95/221 PAGE R1620 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004 R1621 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004 R1622 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004 R1623 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004 R1624 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004 R1625 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004 R1626 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004...
Page 157 96/221 PAGE R1671 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004 R1680 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004 R1681 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004 R1682 C-CARBON R RN72K1J-273JE 435032734R1 PCB-U004 R1683 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004 R1684 C-CARBON R RN72K1J-273JE 435032734R1 PCB-U004 R1685 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004...
Page 158 97/221 PAGE R3730 C-CARBON R RN72K1J-392JE 435033924R1 PCB-U004 R3731 C-CARBON R RN72K1J-220JE 435032204R1 PCB-U004 R3732 C-CARBON R RN72K1J-220JE 435032204R1 PCB-U004 R3733 C-CARBON R RN72K1J-151JE 435031514R1 PCB-U004 R3734 C-CARBON R RN72K1J-220JE 435032204R1 PCB-U004 R3735 C-CARBON R RN72K1J-151JE 435031514R1 PCB-U004 R3736 C-CARBON R RN72K1J-221JE 435032214R1 PCB-U004...
Page 159 98/221 PAGE R3765 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004 R3766 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U004 R3767 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U004 R3768 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U004 R3769 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R3770 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R3771 C-CARBON R RN72K1J-221JE 435032214R1 PCB-U004...
Page 160 99/221 PAGE R3884 C-CARBON R RN72K1J-221JE 435032214R1 PCB-U004 R3885 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004 R3886 C-CARBON R RN72K1J-221JE 435032214R1 PCB-U004 R3887 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R3888 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R3889 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R3890 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004...
Page 161 100/221 PAGE R3916 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R3917 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R3918 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U004 R3919 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U004 R3920 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U004 R3921 C-CARBON R RN72K1J-750JE 435037504R1 PCB-U004 R3922 C-CARBON R RN72K1J-224JE 435032244R1 PCB-U004...
Page 162 101/221 PAGE R4030 C-CARBON R RN72K1J-393JE 435033934R1 PCB-U004 R4031 C-CARBON R RN72K1J-122JE 435031224R1 PCB-U004 R4032 C-CARBON R RN72K1J-122JE 435031224R1 PCB-U004 R4033 C-CARBON R RN72K1J-821JE 435038214R1 PCB-U004 R4034 C-CARBON R RN72K1J-821JE 435038214R1 PCB-U004 R4035 C-CARBON R RN72K1J-224JE 435032244R1 PCB-U004 R4036 C-CARBON R RN72K1J-224JE 435032244R1 PCB-U004...
Page 163 102/221 PAGE R4522 METAL O R RS1/2WBJ-22 443522204T PCB-U004 R4523 METAL O R RS1/2WBJ-22 443522204T PCB-U004 C-CARBON R RN72K1J-223JE 435032234R1 <MDC> PCB-U004 C-CARBON R RN72K1J-223JE 435032234R1 <MMP, MMR> PCB-U004 R4900 C-CARBON R RN72K1J-224JE 435032244R1 PCB-U004 R4901 C-CARBON R RN72K1J-224JE 435032244R1 PCB-U004 R4902 C-CARBON R...
Page 164 103/221 PAGE R4952 C-CARBON R RN72K1J-224JE 435032244R1 <MMP, MMR> PCB-U004 R4953 C-CARBON R RN72K1J-224JE 435032244R1 <MDC> PCB-U004 R4953 C-CARBON R RN72K1J-224JE 435032244R1 <MMP, MMR> PCB-U004 R4954 C-CARBON R RN72K1J-224JE 435032244R1 <MDC> PCB-U004 R4954 C-CARBON R RN72K1J-224JE 435032244R1 <MMP, MMR> PCB-U004 R4967 METAL O R RS1/2WBJ-22...
Page 165 104/221 PAGE C-CARBON R RN72K1J-103JE 435031034R1 <MDC> PCB-U004 R7001 C-CARBON R RN72K1J-222JE 435032224R1 PCB-U004 R7002 C-CARBON R RN72K1J-000JE 435030004R1 PCB-U004 R7003 C-CARBON R RN72K1J-000JE 435030004R1 PCB-U004 R7004 C-CARBON R RN72K1J-102JE 435031024R1 PCB-U004 R7005 C-CARBON R RN72K1J-222JE 435032224R1 PCB-U004 R7006 C-CARBON R RN72K1J-101JE 435031014R1 PCB-U004...
Page 166 105/221 PAGE R7033 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R7034 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R7035 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R7036 C-CARBON R RN72K1J-221JE 435032214R1 PCB-U004 R7037 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R7044 C-CARBON R RN72K1J-221JE 435032214R1 PCB-U004 R7045 C-CARBON R RN72K1J-221JE 435032214R1 PCB-U004...
Page 167 106/221 PAGE R7080 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004 R7081 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004 R7082 C-CARBON R RN72K1J-272JE 435032724R1 PCB-U004 R7083 C-CARBON R RN72K1J-272JE 435032724R1 PCB-U004 R7084 C-CARBON R RN72K1J-272JE 435032724R1 PCB-U004 R7088 C-CARBON R RN72K1J-221JE 435032214R1 PCB-U004 R7089 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004...
Page 168 107/221 PAGE R7122 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004 R7123 C-CARBON R RN72K1J-473JE 435034734R1 PCB-U004 R7124 C-CARBON R RN72K1J-102JE 435031024R1 PCB-U004 R7125 C-CARBON R RN72K1J-000JE 435030004R1 PCB-U004 R7126 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R7127 C-CARBON R RN72K1J-000JE 435030004R1 PCB-U004 R7128 C-CARBON R RN72K1J-221JE 435032214R1 PCB-U004...
Page 169 108/221 PAGE R7156 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R7157 C-CARBON R RN72K1J-103JE 435031034R1 <MDC> PCB-U004 R7157 C-CARBON R RN72K1J-103JE 435031034R1 <MMP, MMR> PCB-U004 R7158 C-CARBON R RN72K1J-473JE 435034734R1 PCB-U004 R7159 C-CARBON R RN72K1J-333JE 435033334R1 <MDC> PCB-U004 R7159 C-CARBON R RN72K1J-333JE 435033334R1 <MMP, MMR>...
Page 170 109/221 PAGE R7186 C-CARBON R RN72K1J-221JE 435032214R1 PCB-U004 R7187 C-CARBON R RN72K1J-221JE 435032214R1 PCB-U004 R7188 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R7189 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R7190 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R7191 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R7192 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004...
Page 171 110/221 PAGE R7233 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R7234 C-CARBON R RN72K1J-103JE 435031034R1 <MDC> PCB-U004 R7235 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004 R7237 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U004 R7238 C-CARBON R RN72K1J-562JE 435035624R1 <MDC> PCB-U004 R7238 C-CARBON R RN72K1J-562JE 435035624R1 <MMP, MMR> PCB-U004 R7239 C-CARBON R...
Page 172 111/221 PAGE R7275 C-CARBON R RN72K1J-102JE 435031024R1 PCB-U004 R7276 C-CARBON R RN72K1J-222JE 435032224R1 PCB-U004 R7285 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R7286 C-CARBON R RN72K1J-221JE 435032214R1 PCB-U004 R7289 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R7290 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004 R7291 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U004...
Page 173 112/221 PAGE R7318 C-CARBON R RN72K1J-102JE 435031024R1 PCB-U004 [SW TRM] PCB-U004 NTM-1P233(M1969) 25060302 PCB-U004 TRM-423(SCREW) NEJITANSI ST3 25060495 PCB-U004 JL3889A WIRE HOL NSCT-5P896 25051109 PCB-U004 JL9501A WIRE HOL NSCT-7P898 25051111 PCB-U004 P004 BCDG-0208 25140208E PCB-U004 P005 BCCPU-0209 { 1} 25140209 PCB-U004 P006 BCAR-0210...
Page 174 113/221 PAGE P3886 PIN JACK NPJ-3PDO431 25045624 <MMP, MMR> PCB-U004 P3886 or PIN JACK NPJ-3PDO657 ( 1) 25045885 <MMP, MMR> PCB-U004 P3887 SOCKET MDS-09P-V-01(DSUB9P) 25053363 PCB-U004 P3888 ST JACK MSJ-035-22 25045887 PCB-U004 P3888 or JACK YKB21-5130 ( 1) 25045387 PCB-U004 P4002B SOCKET NSCT-9P1024...
Page 175 114/221 PAGE U00510 POWER SWITCH PC BOARD (BASW-0143-1F) <Note> MMP, MMR type only PCB-U005 PCB-U005 CIRCUIT. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS PCB-U005 [TUNER UNIT] PCB-U005 U7520 PHT CP JSR1321-001 24120138 PCB-U005 U7560 REMO SENS TSOP34338RF1F 24130017 PCB-U005 [SEMI CONDUCTOR] PCB-U005 D7500...
Page 176 115/221 PAGE D7560 C-DIODE 1SS355 223269R2 PCB-U005 D7560 or C-DIODE 1SS352 ( 1) 223234R2 PCB-U005 D7560 or C-DIODE MA2J111 ( 1) 223279R2 PCB-U005 D7560 or C-DIODE KDS4148U ( 1) 223283R2 PCB-U005 D7561 C-DIODE 1SS355 223269R2 PCB-U005 D7561 or C-DIODE 1SS352 ( 1) 223234R2 PCB-U005 D7561 or C-DIODE...
Page 177 116/221 PAGE D9306 ZENER D UDZS30B 224553000R2 PCB-U005 D9310 ZENER D UDZS16B 224551600R2 PCB-U005 D9312 DIODE RL1N4003 22380260T PCB-U005 D9313 DIODE RL1N4003 22380260T PCB-U005 D9314 DIODE RL1N4003 22380260T PCB-U005 D9315 DIODE RL1N4003 22380260T PCB-U005 D9316 DIODE RL1N4003 22380260T PCB-U005 D9350 C-DIODE 1SS355 223269R2...
Page 178 117/221 PAGE L7520 CHOKE COIL LBC2518T2R2M 231364M022R2 PCB-U005 L7530 CHOKE COIL LBC2518T2R2M 231364M022R2 PCB-U005 L7580 CHOKE COIL LBC2518T2R2M 231364M022R2 PCB-U005 L7581 CHOKE COIL LBC2518T2R2M 231364M022R2 PCB-U005 L7582 CHOKE COIL LBC2518T2R2M 231364M022R2 PCB-U005 L9350 CHOKE COIL NCH-2541 231363K470A <MDC> PCB-U005 L9350 CHOKE COIL NCH-2541 231363K470A...
Page 179 118/221 PAGE C7537 C-CERA C CC725CH1H-330J1 342103304R1 PCB-U005 C7538 ELECT C CE04W35V-10M(S) 353761009T PCB-U005 C7539 ELECT C CE04W35V-10M(S) 353761009T PCB-U005 C7540 ELECT C CE04W35V-10M(S) 353761009T PCB-U005 C7543 C-CERA C CK725B1H-102K1 332101025R1 PCB-U005 C7560 ELECT C CE04W6.3V-220M 355722219T PCB-U005 C7561 C-CERA C CK725B1H-102K1 332101025R1 PCB-U005...
Page 180 119/221 PAGE R7505 C-CARBON R RN72K1J-222JE 435032224R1 PCB-U005 R7506 C-CARBON R RN72K1J-222JE 435032224R1 PCB-U005 R7507 C-CARBON R RN72K1J-222JE 435032224R1 PCB-U005 R7508 C-CARBON R RN72K1J-222JE 435032224R1 PCB-U005 R7509 C-CARBON R RN72K1J-222JE 435032224R1 PCB-U005 R7510 C-CARBON R RN72K1J-222JE 435032224R1 PCB-U005 R7520 C-CARBON R RN72K1J-221JE 435032214R1 PCB-U005...
Page 181 120/221 PAGE R7592 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U005 R7593 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U005 R7594 C-CARBON R RN72K1J-121JE 435031214R1 PCB-U005 R7595 C-CARBON R RN72K1J-121JE 435031214R1 <MDC> PCB-U005 R7595 C-CARBON R RN72K1J-121JE 435031214R1 <MMP, MMR> PCB-U005 R7596 C-CARBON R RN72K1J-181JE 435031814R1 PCB-U005 R7597 C-CARBON R...
Page 182 121/221 PAGE R7638 C-CARBON R RN72K1J-392JE 435033924R1 PCB-U005 R7639 C-CARBON R RN72K1J-123JE 435031234R1 PCB-U005 R7641 C-CARBON R RN72K1J-271JE 435032714R1 PCB-U005 R7642 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U005 R7643 C-CARBON R RN72K1J-471JE 435034714R1 PCB-U005 R7644 C-CARBON R RN72K1J-561JE 435035614R1 PCB-U005 R7645 C-CARBON R RN72K1J-821JE 435038214R1 PCB-U005...
Page 183 122/221 PAGE F9301A FUSE HOL NSCT-1P2031 25052133T !, <MDC> PCB-U005 F9301A FUSE HOL NSCT-1P2031 25052133T !, <MMP, MMR> PCB-U005 F9301B FUSE HOL NSCT-1P2031 25052133T !, <MDC> PCB-U005 F9301B FUSE HOL NSCT-1P2031 25052133T !, <MMP, MMR> PCB-U005 JL4103B SOCKET NSCT-5P97 25050269 PCB-U005 JL7560A WIRE HOL NSCT-3P874...
Page 184 123/221 PAGE S7590 R ENCODE EC12E2425WITH WASHER 25065655W PCB-U005 S7611 PUSH SW NPS-111-S681 25035718T PCB-U005 S7612 PUSH SW NPS-111-S681 25035718T PCB-U005 S7613 PUSH SW NPS-111-S681 25035718T PCB-U005 S7614 PUSH SW NPS-111-S681 25035718T PCB-U005 S7615 PUSH SW NPS-111-S681 25035718T <MDC> PCB-U005 S7615 PUSH SW NPS-111-S681...
Page 185 124/221 PAGE S7644 PUSH SW NPS-111-S681 25035718T PCB-U005 S7645 PUSH SW NPS-111-S681 25035718T PCB-U005 S7646 PUSH SW NPS-111-S681 25035718T PCB-U005 S7647 PUSH SW NPS-111-S681 25035718T PCB-U005 S7648 PUSH SW NPS-111-S681 25035718T PCB-U005 S7649 PUSH SW NPS-111-S681 25035718T PCB-U005 S7650 PUSH SW NPS-111-S681 25035718T PCB-U005...
Page 186 125/221 PAGE D6811 DIODE 1SS133 223163T PCB-U006 D6812 DIODE 1SS133 223163T PCB-U006 D9000 DIODE 1SS133 223163T PCB-U006 D9001 DIODE 1SS133 223163T PCB-U006 D9002 DIODE 1SS133 223163T PCB-U006 D9003 DIODE 1SS133 223163T PCB-U006 D9004 DIODE 1SS133 223163T PCB-U006 D9005 DIODE 1SS133 223163T PCB-U006 D9006...
Page 187 126/221 PAGE Q9200 2SC1815-GR 2211255T <MDC> PCB-U006 Q9200 2SC1815-GR 2211255T <MMP, MMR> PCB-U006 Q9410 NJM2388F09 22242383 <MDC> PCB-U006 Q9410 NJM2388F09 22242383 <MMP, MMR> PCB-U006 Q9423 2SC1815-GR 2211255T PCB-U006 Q9424 2SA1015-GR 2211455T PCB-U006 Q9425 2SK365-GR 2212445T PCB-U006 Q9426 2SK365-GR 2212445T PCB-U006 [TRANS COIL] PCB-U006 L6800...
Page 188 127/221 PAGE C5575 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U006 C5576 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U006 C5579 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U006 C6800 TF C ECQ-V50V-103J 374721034T PCB-U006 C6801 TF C ECQ-V50V-103J 374721034T PCB-U006 C6802 TF C ECQ-V50V-103J 374721034T PCB-U006 C6803 TF C...
Page 189 128/221 PAGE C6838 or TF C ECQ-B50V-102J ( 1) 374721024T PCB-U006 C6839 MKT C B32529C0102J289 376491024T PCB-U006 C6839 or TF C ECQ-B50V-102J ( 1) 374721024T PCB-U006 C6840 MKT C B32529C0102J289 376491024T PCB-U006 C6840 or TF C ECQ-B50V-102J ( 1) 374721024T PCB-U006 C6850 TF C...
Page 190 129/221 PAGE C9008 VR C CE04W16V-470M(VR) 394644717T <MDC> PCB-U006 C9008 VR C CE04W16V-470M(VR) 394644717T <MMP, MMR> PCB-U006 C9108 PLA C MKP R46 104M 3800041S <MDC> PCB-U006 C9108 PLA C MKP R46 104M 3800041S <MMP, MMR> PCB-U006 C9115 TF C ECQ-V50V-103J 374721034T <MDC>...
Page 191 130/221 PAGE R6803 CARBON R R16J-22 417342204T <MMP, MMR> PCB-U006 R6804 CARBON R R16J-22 417342204T <MDC> PCB-U006 R6804 CARBON R R16J-22 417342204T <MMP, MMR> PCB-U006 R6805 CARBON R R16J-22 417342204T <MDC> PCB-U006 R6805 CARBON R R16J-22 417342204T <MMP, MMR> PCB-U006 R6806 CARBON R R16J-22...
Page 192 131/221 PAGE R6824 METAL R RNU1WCJ-8.2 453630824T PCB-U006 R6825 METAL R RNU1WCJ-8.2 453630824T PCB-U006 R6826 METAL R RNU1WCJ-8.2 453630824T PCB-U006 R6827 METAL R RNU1WCJ-8.2 453630824T PCB-U006 R6828 METAL R RNU1WCJ-8.2 453630824T PCB-U006 R6900 METAL O R RS1/2WBJ-330 443523314T PCB-U006 R6901 METAL O R RS1/2WBJ-330 443523314T...
Page 193 132/221 PAGE R9402 METAL PR MPR2W+2WK 0R47 4000253 PCB-U006 R9410 METAL R RNU1/2WCJ-0.22 453532294T PCB-U006 R9421 METAL R RNU1WCJ-0.22 453632294T PCB-U006 R9422 METAL R RNU1WCJ-0.22 453632294T PCB-U006 R9427 CARBON R R16J-330 417343314T PCB-U006 R9428 CARBON R R16J-330 417343314T PCB-U006 R9429 CARBON R R16J-10 417341004T...
Page 194 133/221 PAGE P001 BCTRM-0214 25140214C PCB-U006 P002 BCTRM-0215 { 1} 25140215 PCB-U006 P003 BCTRM-0216 { 1} 25140216 PCB-U006 P004 BCPS-0217 { 1} 25140217 PCB-U006 P005 BCPS-0218 { 1} 25140218 PCB-U006 P006 BCETC-0219 { 1} 25140219 PCB-U006 P3101B SOCKET IMSA-9142S-26A 25053235 PCB-U006 P6140H PLUG NPLG-9P165...
Page 195 134/221 PAGE P6853B PLUG NPLG-9P0964 25056014 PCB-U006 P6902B PLUG NPLG-9P356 25055373 PCB-U006 P9000 AC INLET NPLG-2P913 25055960 !, <MDC> PCB-U006 P9000 AC INLET NPLG-2P913 25055960 !, <MMP, MMR> PCB-U006 P9006 CRIMP AS CRIMP AS 206CC45159UL PCB-U006 P9007 CRIMP AS CRIMP AS 206CC45150UL PCB-U006 P9008A PLUG...
Page 196 135/221 PAGE RL6808 orRELAY NRL-2P5A-DC12-155 ( 1) 25065607 PCB-U006 RL6809 RELAY NRL-2P5A-DC12-192 25065702 PCB-U006 RL6809 orRELAY NRL-2P5A-DC12-155 ( 1) 25065607 PCB-U006 RL6810 RELAY NRL-2P5A-DC12-192 25065702 PCB-U006 RL6810 orRELAY NRL-2P5A-DC12-155 ( 1) 25065607 PCB-U006 RL6811 RELAY NRL-2P5A-DC12-192 25065702 PCB-U006 RL6811 orRELAY NRL-2P5A-DC12-155 ( 1) 25065607 PCB-U006...
Page 197 136/221 PAGE D8302 or C-DIODE MA2J111 ( 1) 223279R2 PCB-U007 D8302 or C-DIODE KDS4148U ( 1) 223283R2 PCB-U007 D8351 C-DIODE 1SS226(TE85L_F) 223266R2 PCB-U007 D8352 C-DIODE 1SS352 223234R2 PCB-U007 D8352 or C-DIODE MA2J111 ( 1) 223279R2 PCB-U007 D8352 or C-DIODE KDS4148U ( 1) 223283R2 PCB-U007 D8652...
Page 198 137/221 PAGE Q3103 BH18LB1WG-TR 22242562R2 PCB-U007 Q3104 TPD2E001DRLR 22242589R2 PCB-U007 Q3106 BH33FB1WG-TR 22242585R2 PCB-U007 Q3107 TA48033BF(TE16L_NQ) 22278033DBR2TO PCB-U007 Q3108 KSZ8041NL 22242591R2 PCB-U007 Q3109 BD7820 22242300R2 PCB-U007 Q3110 MIC2005-0.5YM6 22242590R2 PCB-U007 Q3202 TC74VHC157FT 22274157ER2TO PCB-U007 Q3204 TC7SZU04FU 22242512R2TO PCB-U007 Q3205 TC7SZU04FU 22242512R2TO PCB-U007 Q3206...
Page 199 138/221 PAGE Q3604 PCM1754DBQR 22242598R2 PCB-U007 Q8001 ADV7800BSTZ-150 22242606R3 PCB-U007 Q8002 TA48018BF(TE16L_NQ) 22278018DBR2TO PCB-U007 Q8003 K4S641632K-UC60 22242462R2 PCB-U007 Q8003 or IC K4S641632N-LC60 ( 1) 22242603R2 PCB-U007 Q8161 TA48018BF(TE16L_NQ) 22278018DBR2TO PCB-U007 Q8162 SII9185ACTU 22242471R3 PCB-U007 Q8305 S-812C50BUC-C5ET2G 22242407R2 PCB-U007 Q8306 NC7SZ08P5X_F042 22242482R2 PCB-U007 Q8306 or IC...
Page 200 139/221 PAGE Q8810 TC74VCX162827 22242395R2 PCB-U007 Q8811 TC74VCX162827 22242395R2 PCB-U007 Q8812 TC74VCX162827 22242395R2 PCB-U007 Q8813 TC74VCX162827 22242395R2 PCB-U007 Q8814 TC74VCX162827 22242395R2 PCB-U007 Q8815 TC74VCX162827 22242395R2 PCB-U007 Q8817 TC74VCX162827 22242395R2 PCB-U007 Q8818 TC74VCX162827 22242395R2 PCB-U007 Q8951 MP1593DN 22242601R2 PCB-U007 Q8952 MP1593DN 22242601R2 PCB-U007 Q8953...
Page 201 140/221 PAGE L251 CORE BLM18PG181SN1D 2350005R1 PCB-U007 L261 EMIFIL BK1608LM182-T 230958R1 PCB-U007 L3001 CORE BLM18PG121SN1D 2350006R1 PCB-U007 L3002 CORE BLM18PG121SN1D 2350006R1 PCB-U007 L3003 CORE BLM18PG121SN1D 2350006R1 PCB-U007 L3004 CORE BLM18PG121SN1D 2350006R1 PCB-U007 L3005 CORE BLM18PG121SN1D 2350006R1 PCB-U007 L3102 CORE BLM18PG181SN1D 2350005R1 PCB-U007 L3103...
Page 202 141/221 PAGE L3410 CORE MMZ1608Y601BT 2350004R1 PCB-U007 L3411 CORE MMZ1608Y601BT 2350004R1 PCB-U007 L3501 C-CARBON R RN72K1J-000JE 435030004R1 PCB-U007 L3502 CORE BLM18PG121SN1D 2350006R1 PCB-U007 L3503 CORE MMZ1608Y601BT 2350004R1 PCB-U007 L3505 CORE BLM18PG121SN1D 2350006R1 PCB-U007 L3506 CORE BLM18PG121SN1D 2350006R1 PCB-U007 L3507 CORE BLM18PG121SN1D 2350006R1 PCB-U007...
Page 203 142/221 PAGE L8405 CORE BLM18PG181SN1D 2350005R1 PCB-U007 L8406 C-R NET MNR12E0APJ000 43464900002R2 PCB-U007 L8407 C-R NET MNR12E0APJ000 43464900002R2 PCB-U007 L8408 CORE BLM18PG181SN1D 2350005R1 PCB-U007 L8409 C-R NET MNR12E0APJ000 43464900002R2 PCB-U007 L8410 C-R NET MNR12E0APJ000 43464900002R2 PCB-U007 L8450 C-R NET MNR12E0APJ000 43464900002R2 PCB-U007 L8451...
Page 204 143/221 PAGE L8854 C-CARBON R RN72K2B-000JE 433220004R1 PCB-U007 L8855 C-CARBON R RN72K2B-000JE 433220004R1 PCB-U007 L8856 C-CARBON R RN72K2B-000JE 433220004R1 PCB-U007 L8951 CHOKE COIL 0182-7E08Q-100M-RA 231396M100R2 PCB-U007 L8952 CHOKE COIL 0182-7E08Q-6R8N-RA 231395P068R2 PCB-U007 L8953 CHOKE COIL 0182-7E08Q-6R8N-RA 231395P068R2 PCB-U007 L8954 CHOKE COIL 0182-7E08Q-100M-RA 231396M100R2 PCB-U007...
Page 205 144/221 PAGE C3003 C-CERA C CK725B0J-106K 332091065R2 PCB-U007 C3004 C-CERA C CK725B0J-106K 332091065R2 PCB-U007 C3005 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3006 C-CERA C CC725CH1H-102J1 342101024R1 PCB-U007 C3007 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3008 C-CERA C CC725CH1H-102J1 342101024R1 PCB-U007 C3009 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007...
Page 206 145/221 PAGE C3036 C-CERA C CC725CH1H-120J1 342101204R1 PCB-U007 C3037 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3038 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3039 C-CERA C CK725B1H-103K1 332101035R1 PCB-U007 C3040 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3041 C-CERA C CK725B0J-106K 332091065R2 PCB-U007 C3042 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007...
Page 207 146/221 PAGE C3127 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3128 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3129 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3130 C-CERA C CK725B0J-106K 332091065R2 PCB-U007 C3131 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3132 C-CERA C CC725CH1H-101J1 342101014R1 PCB-U007 C3133 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007...
Page 208 147/221 PAGE C3166 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3202 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3204 C-CERA C CK725B0J-106K 332091065R2 PCB-U007 C3205 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3206 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3207 C-CERA C CK725B0J-106K 332091065R2 PCB-U007 C3208 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007...
Page 209 148/221 PAGE C3409 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3410 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3412 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3413 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3414 C-CERA C CC725CH1H-102J1 342101024R1 PCB-U007 C3415 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3416 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007...
Page 210 149/221 PAGE C3443 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3444 C-CERA C CC725CH1H-102J1 342101024R1 PCB-U007 C3445 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3446 C-CERA C CK725B0J-106K 332091065R2 PCB-U007 C3447 C-CERA C CK725B0J-106K 332091065R2 PCB-U007 C3448 C-CERA C CK725B0J-106K 332091065R2 PCB-U007 C3449 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007...
Page 211 150/221 PAGE C3515 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3516 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3517 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3518 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3519 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3520 C-CERA C CK725B0J-106K 332091065R2 PCB-U007 C3521 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007...
Page 212 151/221 PAGE C3548 C-CERA C CK725B0J-106K 332091065R2 PCB-U007 C3549 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3550 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3551 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C3552 CHIP ELECT C CEWX4V-22M 3981G2207R2 PCB-U007 C3553 C-CERA C CK725B1H-103K1 332101035R1 PCB-U007 C3554 C-CERA C CK725F1A-105Z1 332181050R1...
Page 213 152/221 PAGE C8024 CHIP ELECT C CEWX16V-10M 398141007R2 PCB-U007 C8025 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8026 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8027 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8028 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8029 C-CERA C CK725B1H-103K1 332101035R1 PCB-U007 C8030 C-CERA C CK725F1E-104Z1 332161040R1...
Page 214 153/221 PAGE C8057 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8058 C-CERA C CK725B1H-103K1 332101035R1 PCB-U007 C8060 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8061 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8062 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8063 CHIP TANTAL F93-6.3V-100M 395521017R2 PCB-U007 C8063 or CHIP TANTAL TCSCS0J107MBAR ( 1) 396521017R2 PCB-U007...
Page 215 154/221 PAGE C8091 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8092 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8093 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8094 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8095 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8096 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8097 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007...
Page 216 155/221 PAGE C8147 CHIP TANTAL F93-16V-10M 395541007R2 PCB-U007 C8147 or CHIP TANTAL TCSCS1C106MAAR ( 1) 396541007R2 PCB-U007 C8148 CHIP ELECT C CEWX4V-100M 3981G1017R2 PCB-U007 C8161 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8162 CHIP ELECT C CEWX4V-100M 3981G1017R2 PCB-U007 C8163 C-CERA C CK725B1H-102K1 332101025R1 PCB-U007...
Page 217 156/221 PAGE C8208 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8209 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8210 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8211 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8212 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8213 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8214 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007...
Page 218 157/221 PAGE C8238 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8239 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8240 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8241 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8242 CHIP TANTAL F93-16V-10M 395541007R2 PCB-U007 C8242 or CHIP TANTAL TCSCS1C106MAAR ( 1) 396541007R2 PCB-U007 C8243 C-CERA C...
Page 219 158/221 PAGE C8268 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8269 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8270 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8271 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8272 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8273 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8274 CHIP TANTAL F93-16V-10M 395541007R2 PCB-U007...
Page 220 159/221 PAGE C8322 C-CARBON R RN72K1J-000JE 435030004R1 PCB-U007 C8326 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8327 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8328 CHIP ELECT C CEWX16V-22M 398142207R2 PCB-U007 C8329 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8330 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8332 C-CERA C CK725F1E-104Z1 332161040R1...
Page 221 160/221 PAGE C8380 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8381 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8390 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8398 C-CARBON R RN72K1J-000JE 435030004R1 PCB-U007 C8399 C-CARBON R RN72K1J-000JE 435030004R1 PCB-U007 C8401 CHIP ELECT C CEWX4V-22M 3981G2207R2 PCB-U007 C8402 CHIP ELECT C CEWX4V-22M 3981G2207R2...
Page 222 161/221 PAGE C8430 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8431 C-CERA C CK725B1H-102K1 332101025R1 PCB-U007 C8432 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8433 C-CERA C CK725B1H-102K1 332101025R1 PCB-U007 C8434 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8435 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8436 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007...
Page 223 162/221 PAGE C8474 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8475 C-CERA C CK725B1H-102K1 332101025R1 PCB-U007 C8476 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8477 C-CERA C CK725B1H-102K1 332101025R1 PCB-U007 C8478 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8479 C-CERA C CK725B1H-102K1 332101025R1 PCB-U007 C8480 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007...
Page 224 163/221 PAGE C8517 C-CERA C CK725B1H-102K1 332101025R1 PCB-U007 C8518 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8519 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8521 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8522 C-CERA C CK725B0J-106K 332091065R2 PCB-U007 C8525 C-CERA C CK725B0J-106K 332091065R2 PCB-U007 C8527 C-CERA C CK725B1H-102K1 332101025R1 PCB-U007...
Page 225 164/221 PAGE C8564 C-CERA C CK725B0J-106K 332091065R2 PCB-U007 C8565 C-CERA C CK725B0J-106K 332091065R2 PCB-U007 C8566 C-CERA C CK725B1H-102K1 332101025R1 PCB-U007 C8567 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8573 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8584 C-CERA C CK725B0J-106K 332091065R2 PCB-U007 C8585 C-CERA C CK725B0J-106K 332091065R2 PCB-U007...
Page 226 165/221 PAGE C8805 CHIP ELECT C CEWX4V-220M 3981G2217R2 PCB-U007 C8810 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8811 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8812 C-CERA C CK725B1A-154K1 332131545R1 PCB-U007 C8813 C-CERA C CK725B1H-153K1 332101535R1 PCB-U007 C8814 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8815 C-CERA C CK725B1A-154K1 332131545R1...
Page 227 166/221 PAGE C8868 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8869 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8870 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8871 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8872 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8873 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8874 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007...
Page 228 167/221 PAGE C8926 CHIP TANTAL F93-10V-47M 395534707R2 PCB-U007 C8926 or CHIP TANTAL TCSCS1A476MBAR ( 1) 396534707R2 PCB-U007 C8927 C-CERA C CK725F1E-104Z1 332161040R1 PCB-U007 C8928 C-CERA C CC725CH1H-101J1 342101014R1 PCB-U007 C8951 C-CERA C CK725B1C-104K1 332121045R1 PCB-U007 C8952 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8953 CD C...
Page 229 168/221 PAGE C8985 C-CERA C CK725B1H-222K1 332102225R1 PCB-U007 C8986 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 C8987 CD C UCD1A471MNL1GS 396634717R2 PCB-U007 C8988 C-CERA C CK725F1A-105Z1 332181050R1 PCB-U007 [RESISTOR] PCB-U007 R268 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U007 R269 C-CARBON R RN72K1J-331JE 435033314R1 PCB-U007 R270 C-CARBON R RN72K1J-331JE...
Page 230 169/221 PAGE R3024 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007 R3025 C-CARBON R RN72K1J-102JE 435031024R1 PCB-U007 R3026 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007 R3028 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007 R3029 C-CARBON R RN72K1J-102JE 435031024R1 PCB-U007 R3032 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U007 R3033 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007...
Page 231 170/221 PAGE R3064 C-CARBON R RN72K1J-680JE 435036804R1 PCB-U007 R3065 C-CARBON R RN72K1J-680JE 435036804R1 PCB-U007 R3066 C-CARBON R RN72K1J-102JE 435031024R1 PCB-U007 R3101 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U007 R3102 C-CARBON R RN72K1J-153JE 435031534R1 PCB-U007 R3108 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U007 R3113 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U007...
Page 232 171/221 PAGE R3148 C-CARBON R RN72K1J-390JE 435033904R1 PCB-U007 R3149 C-CARBON R RN72K1J-102JE 435031024R1 PCB-U007 R3150 C-CARBON R RN72K1J-151JE 435031514R1 PCB-U007 R3151 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U007 R3152 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U007 R3154 C-CARBON R RN72K1J-390JE 435033904R1 PCB-U007 R3155 C-CARBON R RN72K1J-390JE 435033904R1 PCB-U007...
Page 233 172/221 PAGE R3187 C-CARBON R RN72K1J-223FE 435032232R1 PCB-U007 R3188 C-CARBON R RN72K1J-224FE 435032242R1 PCB-U007 R3189 C-CARBON R RN72K1J-103FE 435031032R1 PCB-U007 R3190 C-CARBON R RN72K1J-393FE 435033932R1 PCB-U007 R3191 C-CARBON R RN72K1J-105FE 435031052R1 PCB-U007 R3192 C-CARBON R RN72K1J-472JE 435034724R1 PCB-U007 R3193 C-CARBON R RN72K1J-472JE 435034724R1 PCB-U007...
Page 234 173/221 PAGE R3237 C-CARBON R RN72K1J-221JE 435032214R1 PCB-U007 R3238 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007 R3239 C-CARBON R RN72K1J-221JE 435032214R1 PCB-U007 R3240 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U007 R3241 C-CARBON R RN72K1J-221JE 435032214R1 PCB-U007 R3242 C-CARBON R RN72K1J-221JE 435032214R1 PCB-U007 R3243 C-CARBON R RN72K1J-220JE 435032204R1 PCB-U007...
Page 235 174/221 PAGE R3274 C-CARBON R RN72K1J-390JE 435033904R1 PCB-U007 R3275 C-CARBON R RN72K1J-220JE 435032204R1 PCB-U007 R3276 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007 R3277 C-CARBON R RN72K1J-220JE 435032204R1 PCB-U007 R3278 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007 R3279 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007 R3280 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007...
Page 236 175/221 PAGE R3307 C-CARBON R RN72K1J-104JE 435031044R1 PCB-U007 R3308 C-CARBON R RN72K1J-223JE 435032234R1 PCB-U007 R3309 C-CARBON R RN72K1J-332JE 435033324R1 PCB-U007 R3310 C-CARBON R RN72K1J-182JE 435031824R1 PCB-U007 R3311 C-CARBON R RN72K1J-471JE 435034714R1 PCB-U007 R3312 C-CARBON R RN72K1J-223JE 435032234R1 PCB-U007 R3313 C-CARBON R RN72K1J-152JE 435031524R1 PCB-U007...
Page 237 176/221 PAGE R3426 C-R NET RM7LJ330X04 43484733004R2 PCB-U007 R3427 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007 R3428 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007 R3429 C-R NET RM7LJ330X04 43484733004R2 PCB-U007 R3430 C-R NET RM7LJ330X04 43484733004R2 PCB-U007 R3431 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U007 R3432 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U007...
Page 238 177/221 PAGE R3460 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007 R3461 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007 R3462 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007 R3464 C-CARBON R RN72K1J-102JE 435031024R1 PCB-U007 R3465 C-CARBON R RN72K1J-223FE 435032232R1 PCB-U007 R3466 C-CARBON R RN72K1J-392FE 435033922R1 PCB-U007 R3467 C-CARBON R RN72K1J-224FE 435032242R1 PCB-U007...
Page 239 178/221 PAGE R3522 C-CARBON R RN72K1J-330JE 435033304R1 PCB-U007 R3523 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007 R3524 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007 R3525 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007 R3526 C-R NET RM7LJ330X04 43484733004R2 PCB-U007 R3527 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007 R3528 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007...
Page 240 179/221 PAGE R3555 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U007 R3556 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007 R3557 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007 R3558 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007 R3559 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007 R3560 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007 R3561 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007...
Page 241 180/221 PAGE R8055 C-CARBON R RN72K1J-272JE 435032724R1 PCB-U007 R8056 C-CARBON R RN72K1J-101JE 435031014R1 PCB-U007 R8057 C-CARBON R RN72K1J-101JE 435031014R1 PCB-U007 R8058 C-CARBON R RN72K1J-562JE 435035624R1 PCB-U007 R8059 C-CARBON R RN72K1J-101JE 435031014R1 PCB-U007 R8060 C-CARBON R RN72K1J-101JE 435031014R1 PCB-U007 R8061 C-CARBON R RN72K1J-101JE 435031014R1 PCB-U007...
Page 242 181/221 PAGE R8097 C-R NET RM7LJ220X04 43484722004R2 PCB-U007 R8098 C-R NET RM7LJ220X04 43484722004R2 PCB-U007 R8099 C-R NET RM7LJ220X04 43484722004R2 PCB-U007 R8100 C-R NET RM7LJ220X04 43484722004R2 PCB-U007 R8101 C-R NET RM7LJ220X04 43484722004R2 PCB-U007 R8102 C-CARBON R RN72K1J-105JE 435031054R1 PCB-U007 R8103 C-CARBON R RN72K1J-561JE 435035614R1 PCB-U007...
Page 243 182/221 PAGE R8206 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U007 R8207 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U007 R8210 C-CARBON R RN72K1J-470JE 435034704R1 PCB-U007 R8211 C-CARBON R RN72K1J-101JE 435031014R1 PCB-U007 R8212 C-CARBON R RN72K1J-101JE 435031014R1 PCB-U007 R8213 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U007 R8214 C-CARBON R RN72K1J-101JE 435031014R1 PCB-U007...
Page 244 183/221 PAGE R8330 C-CARBON R RN72K1J-473JE 435034734R1 PCB-U007 R8333 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U007 R8334 C-CARBON R RN72K1J-222JE 435032224R1 PCB-U007 R8335 C-CARBON R RN72K1J-222JE 435032224R1 PCB-U007 R8336 C-CARBON R RN72K1J-472JE 435034724R1 PCB-U007 R8337 C-CARBON R RN72K1J-473JE 435034734R1 PCB-U007 R8338 C-CARBON R RN72K1J-473JE 435034734R1 PCB-U007...
Page 245 184/221 PAGE R8418 C-R NET RM7LJ220X04 43484722004R2 PCB-U007 R8419 C-R NET RM7LJ220X04 43484722004R2 PCB-U007 R8420 C-R NET RM7LJ220X04 43484722004R2 PCB-U007 R8421 C-R NET RM7LJ220X04 43484722004R2 PCB-U007 R8422 C-R NET RM7LJ220X04 43484722004R2 PCB-U007 R8423 C-R NET RM7LJ220X04 43484722004R2 PCB-U007 R8424 C-R NET RM7LJ220X04 43484722004R2 PCB-U007...
Page 246 185/221 PAGE R8482 C-CARBON R RN72K1J-220JE 435032204R1 PCB-U007 R8492 C-CARBON R RN72K1J-102JE 435031024R1 PCB-U007 R8501 C-CARBON R RN72K1J-330JE 435033304R1 PCB-U007 R8502 C-CARBON R RN72K1J-120JE 435031204R1 PCB-U007 R8503 C-R NET RM7LJ330X04 43484733004R2 PCB-U007 R8504 C-R NET RM7LJ330X04 43484733004R2 PCB-U007 R8505 C-R NET RM7LJ330X04 43484733004R2 PCB-U007...
Page 247 186/221 PAGE R8607 C-CARBON R RN72K1J-473JE 435034734R1 PCB-U007 R8608 C-CARBON R RN72K1J-473JE 435034734R1 PCB-U007 R8609 C-CARBON R RN72K1J-000JE 435030004R1 PCB-U007 R8617 C-CARBON R RN72K1J-473JE 435034734R1 PCB-U007 R8618 C-CARBON R RN72K1J-473JE 435034734R1 PCB-U007 R8619 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U007 R8627 C-CARBON R RN72K1J-473JE 435034734R1 PCB-U007...
Page 248 187/221 PAGE R8715 C-R NET RM7LJ103X04 43484710304R2 PCB-U007 R8716 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U007 R8717 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U007 R8718 C-CARBON R RN72K1J-220JE 435032204R1 PCB-U007 R8719 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U007 R8720 C-CARBON R RN72K1J-220JE 435032204R1 PCB-U007 R8721 C-CARBON R RN72K1J-220JE 435032204R1 PCB-U007...
Page 249 188/221 PAGE R8817 C-CARBON R RN72K1J-332JE 435033324R1 PCB-U007 R8818 C-CARBON R RN72K1J-332JE 435033324R1 PCB-U007 R8819 C-CARBON R RN72K1J-821JE 435038214R1 PCB-U007 R8820 C-CARBON R RN72K1J-332JE 435033324R1 PCB-U007 R8821 C-CARBON R RN72K1J-821JE 435038214R1 PCB-U007 R8822 C-CARBON R RN72K1J-473JE 435034734R1 PCB-U007 R8823 C-CARBON R RN72K1J-000JE 435030004R1 PCB-U007...
Page 250 189/221 PAGE R8921 C-CARBON R RN72K1J-122JE 435031224R1 PCB-U007 R8922 C-CARBON R RN72K1J-122JE 435031224R1 PCB-U007 R8923 C-CARBON R RN72K1J-122JE 435031224R1 PCB-U007 R8924 C-CARBON R RN72K1J-122JE 435031224R1 PCB-U007 R8940 C-CARBON R RN72K1J-104JE 435031044R1 PCB-U007 R8941 C-CARBON R RN72K1J-104JE 435031044R1 PCB-U007 R8942 C-CARBON R RN72K1J-103JE 435031034R1 PCB-U007...
Page 251 190/221 PAGE RN8014 C-R NET RM7LJ330X04 43484733004R2 PCB-U007 RN8015 C-R NET RM7LJ330X04 43484733004R2 PCB-U007 RN8016 C-R NET RM7LJ330X04 43484733004R2 PCB-U007 RN8017 C-R NET RM7LJ330X04 43484733004R2 PCB-U007 RN8018 C-R NET RM7LJ330X04 43484733004R2 PCB-U007 RN8019 C-R NET RM7LJ330X04 43484733004R2 PCB-U007 RN8020 C-R NET RM7LJ330X04 43484733004R2 PCB-U007...
Page 252 191/221 PAGE RN8058 C-R NET RM7LJ330X04 43484733004R2 PCB-U007 RN8059 C-R NET RM7LJ330X04 43484733004R2 PCB-U007 RN8060 C-R NET RM7LJ330X04 43484733004R2 PCB-U007 RN8061 C-R NET RM7LJ330X04 43484733004R2 PCB-U007 RN8062 C-R NET RM7LJ680X04 43484768004R2 PCB-U007 RN8063 C-R NET RM7LJ470X04 43484747004R2 PCB-U007 RN8064 C-R NET RM7LJ680X04 43484768004R2 PCB-U007...
Page 253 192/221 PAGE JL3201 WIRE TRAP NPLG-5P588 25055626 PCB-U007 JL3889B SOCKET NSCT-5P97 25050269 PCB-U007 JL8002B SOCKET NSCT-5P97 25050269 PCB-U007 P3001 SOCKET(B to B) IMSA-9850S-20Y900 25052813R2 PCB-U007 P3101A PLUG NPLG-5P918 25055965R2 PCB-U007 P3102A SOCKET NSCT-9P2472 25052575R2 PCB-U007 P3103A SOCKET YKF45-0029N 25053242 PCB-U007 P3104 SOCKET SI-60073-F...
Page 254 193/221 PAGE U0083 AMPLIFIER PC BOARD (L/SL/SBL/LH) (BACLA-0229-1A) PCB-U008 U0084 AMPLIFIER PC BOARD (R/SR/SBR/RH/C) (BACLA-0230-1A) PCB-U008 U0085 AMPLIFIER PC BOARD (L/SL/SBL/LH) (BACLA-0231-1A) PCB-U008 U0086 AMPLIFIER PC BOARD (R/SR/SBR/RH/C) (BACLA-0232-1A) PCB-U008 U0087 AMPLIFIER PC BOARD (L/SL/SBL/LH) (BACLA-0233-1A) PCB-U008 U0088 AMPLIFIER PC BOARD (R/SR/SBR/RH/C) (BACLA-0234-1A) PCB-U008 PCB-U008 CIRCUIT.
Page 255 194/221 PAGE Q5016 2SC2240-BL(TPE2_F) 2211406T PCB-U008 Q5017 2SC2240-BL(TPE2_F) 2211406T PCB-U008 Q5018 2SC2240-BL(TPE2_F) 2211406T PCB-U008 Q5020 2SC2240-BL(TPE2_F) 2211406T PCB-U008 Q5021 2SC2240-BL(TPE2_F) 2211406T PCB-U008 Q5022 2SC2240-BL(TPE2_F) 2211406T PCB-U008 Q5023 2SC2240-BL(TPE2_F) 2211406T PCB-U008 Q5024 2SC2240-BL(TPE2_F) 2211406T PCB-U008 Q5025 2SC2240-BL(TPE2_F) 2211406T PCB-U008 Q5026 2SC2240-BL(TPE2_F) 2211406T PCB-U008 Q5027...
Page 256 195/221 PAGE Q5041 or TR 2SA949-Y(TPE6_F) ( 1) 2211354T PCB-U008 Q5042 2SA949-O(TPE6_F) 2211353T PCB-U008 Q5042 or TR 2SA949-Y(TPE6_F) ( 1) 2211354T PCB-U008 Q5043 2SA949-O(TPE6_F) 2211353T PCB-U008 Q5043 or TR 2SA949-Y(TPE6_F) ( 1) 2211354T PCB-U008 Q5044 2SA949-O(TPE6_F) 2211353T PCB-U008 Q5044 or TR 2SA949-Y(TPE6_F) ( 1) 2211354T PCB-U008...
Page 257 196/221 PAGE Q5060 2SC2240-BL(TPE2_F) 2211406T PCB-U008 Q5061 2SC2240-BL(TPE2_F) 2211406T PCB-U008 Q5062 2SC2240-BL(TPE2_F) 2211406T PCB-U008 Q5063 2SC2240-BL(TPE2_F) 2211406T PCB-U008 Q5064 2SC2240-BL(TPE2_F) 2211406T PCB-U008 Q5065 2SC2240-BL(TPE2_F) 2211406T PCB-U008 Q5066 2SC2240-BL(TPE2_F) 2211406T PCB-U008 Q5067 2SC2240-BL(TPE2_F) 2211406T PCB-U008 Q5068 2SC2240-BL(TPE2_F) 2211406T PCB-U008 Q5070 2SC2240-BL(TPE2_F) 2211406T PCB-U008 Q5071...
Page 258 197/221 PAGE Q5083B SCREW 3TTB+8B(3BC) 838430088GR PCB-U008 Q5084 2SC3423-Y 2202104 PCB-U008 Q5084 or TR 2SC3423-O ( 1) 2202103 PCB-U008 Q5084A HEAT SINK (CLA)B 27160642 PCB-U008 Q5084B SCREW 3TTB+8B(3BC) 838430088GR PCB-U008 Q5085 2SC3423-Y 2202104 PCB-U008 Q5085 or TR 2SC3423-O ( 1) 2202103 PCB-U008 Q5085A HEAT SINK (CLA)B...
Page 259 198/221 PAGE Q6020 or TR KTA1267-GR ( 1) 2215995T PCB-U008 Q6021 2SA933S-R 2213354T PCB-U008 Q6021 or TR 2SA1048-GR ( 1) 2212125T PCB-U008 Q6021 or TR 2SA933S-S ( 1) 2213355T PCB-U008 Q6021 or TR KTA1267-GR ( 1) 2215995T PCB-U008 Q6022 2SA933S-R 2213354T PCB-U008 Q6022 or TR...
Page 260 199/221 PAGE Q6030 2SC2229-O(TPE6_F) 2211633T PCB-U008 Q6030 or TR 2SC2229-Y(TPE6_F) ( 1) 2211634T PCB-U008 Q6031 2SC2229-O(TPE6_F) 2211633T PCB-U008 Q6031 or TR 2SC2229-Y(TPE6_F) ( 1) 2211634T PCB-U008 Q6032 2SC2229-O(TPE6_F) 2211633T PCB-U008 Q6032 or TR 2SC2229-Y(TPE6_F) ( 1) 2211634T PCB-U008 Q6033 2SC2229-O(TPE6_F) 2211633T PCB-U008 Q6033 or TR...
Page 261 200/221 PAGE Q6047 or TR 2SA949-Y(TPE6_F) ( 1) 2211354T PCB-U008 Q6048 2SA949-O(TPE6_F) 2211353T PCB-U008 Q6048 or TR 2SA949-Y(TPE6_F) ( 1) 2211354T PCB-U008 Q6100 TTA-004(Q)TO126 2217442 PCB-U008 Q6101 TTA-004(Q)TO126 2217442 PCB-U008 Q6102 TTA-004(Q)TO126 2217442 PCB-U008 Q6103 TTA-004(Q)TO126 2217442 PCB-U008 Q6104 TTA-004(Q)TO126 2217442 PCB-U008 Q6105...
Page 262 201/221 PAGE C5012 UTSJ C CE04W50V-47M(UTSJ) 398084707T PCB-U008 C5013 UTSJ C CE04W50V-47M(UTSJ) 398084707T PCB-U008 C5014 UTSJ C CE04W50V-47M(UTSJ) 398084707T PCB-U008 C5015 UTSJ C CE04W50V-47M(UTSJ) 398084707T PCB-U008 C5016 UTSJ C CE04W50V-47M(UTSJ) 398084707T PCB-U008 C5017 UTSJ C CE04W50V-47M(UTSJ) 398084707T PCB-U008 C5018 UTSJ C CE04W50V-47M(UTSJ) 398084707T PCB-U008...
Page 263 202/221 PAGE C5078 VX C CE04W100V-10M(VX_BLK) 397391007T PCB-U008 C5080 VX C CE04W63V-22M(VX_BLK) 397372207T PCB-U008 C5081 VX C CE04W63V-22M(VX_BLK) 397372207T PCB-U008 C5082 VX C CE04W63V-22M(VX_BLK) 397372207T PCB-U008 C5083 VX C CE04W63V-22M(VX_BLK) 397372207T PCB-U008 C5084 VX C CE04W63V-22M(VX_BLK) 397372207T PCB-U008 C5085 VX C CE04W63V-22M(VX_BLK) 397372207T PCB-U008...
Page 264 203/221 PAGE C5125 SPC C CE04W100V-100M(RJ5) 396791017T PCB-U008 C5126 SPC C CE04W100V-100M(RJ5) 396791017T PCB-U008 C5127 SPC C CE04W100V-100M(RJ5) 396791017T PCB-U008 C5128 SPC C CE04W100V-100M(RJ5) 396791017T PCB-U008 C5130 SPC C CE04W100V-100M(RJ5) 396791017T PCB-U008 C5131 SPC C CE04W100V-100M(RJ5) 396791017T PCB-U008 C5132 SPC C CE04W100V-100M(RJ5) 396791017T PCB-U008...
Page 265 204/221 PAGE C6022 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U008 C6023 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U008 C6024 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U008 C6025 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U008 C6026 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U008 C6027 UTSP C CE04W50V 47M(UTSP) 397584707T PCB-U008...
Page 266 205/221 PAGE R5027 CARBON R R16J-330 417343314T PCB-U008 R5028 CARBON R R16J-330 417343314T PCB-U008 R5030 CARBON R R16J-330 417343314T PCB-U008 R5031 CARBON R R16J-330 417343314T PCB-U008 R5032 CARBON R R16J-330 417343314T PCB-U008 R5033 CARBON R R16J-330 417343314T PCB-U008 R5034 CARBON R R16J-330 417343314T PCB-U008...
Page 267 206/221 PAGE R5064 CARBON R R16J-2.7K 417342724T PCB-U008 R5065 CARBON R R16J-2.7K 417342724T PCB-U008 R5066 CARBON R R16J-2.7K 417342724T PCB-U008 R5067 CARBON R R16J-2.7K 417342724T PCB-U008 R5068 CARBON R R16J-2.7K 417342724T PCB-U008 R5070 CARBON R R16J-100K 417341044T PCB-U008 R5071 CARBON R R16J-100K 417341044T PCB-U008...
Page 268 207/221 PAGE R5121 CARBON R R16J-2.2K 417342224T PCB-U008 R5122 CARBON R R16J-2.2K 417342224T PCB-U008 R5123 CARBON R R16J-2.2K 417342224T PCB-U008 R5124 CARBON R R16J-2.2K 417342224T PCB-U008 R5125 CARBON R R16J-2.2K 417342224T PCB-U008 R5126 CARBON R R16J-2.2K 417342224T PCB-U008 R5127 CARBON R R16J-2.2K 417342224T PCB-U008...
Page 269 208/221 PAGE R5157 METAL O R RS1/2WBJ-10K 443521034T PCB-U008 R5158 METAL O R RS1/2WBJ-10K 443521034T PCB-U008 R5160 NF CARBON R R25J-1.0K 415471024T PCB-U008 R5161 NF CARBON R R25J-1.0K 415471024T PCB-U008 R5162 NF CARBON R R25J-1.0K 415471024T PCB-U008 R5163 NF CARBON R R25J-1.0K 415471024T PCB-U008...
Page 270 209/221 PAGE R5214 CARBON R R16J-18K 417341834T PCB-U008 R5215 CARBON R R16J-18K 417341834T PCB-U008 R5216 CARBON R R16J-18K 417341834T PCB-U008 R5217 CARBON R R16J-18K 417341834T PCB-U008 R5218 CARBON R R16J-18K 417341834T PCB-U008 R5220 CARBON R R16J-18K 417341834T PCB-U008 R5221 CARBON R R16J-18K 417341834T PCB-U008...
Page 271 210/221 PAGE R5251 CARBON R R16J-68K 417346834T PCB-U008 R5252 CARBON R R16J-68K 417346834T PCB-U008 R5253 CARBON R R16J-68K 417346834T PCB-U008 R5254 CARBON R R16J-68K 417346834T PCB-U008 R5255 CARBON R R16J-68K 417346834T PCB-U008 R5256 CARBON R R16J-68K 417346834T PCB-U008 R5257 CARBON R R16J-68K 417346834T PCB-U008...
Page 272 211/221 PAGE R5297 CARBON R R16J-100K 417341044T PCB-U008 R5298 CARBON R R16J-100K 417341044T PCB-U008 R5300 NF CARBON R R25J-82 415478204T PCB-U008 R5301 NF CARBON R R25J-82 415478204T PCB-U008 R5302 NF CARBON R R25J-82 415478204T PCB-U008 R5303 NF CARBON R R25J-82 415478204T PCB-U008 R5304...
Page 273 212/221 PAGE R5374 CARBON R R16J-560K 417345644T PCB-U008 R5375 CARBON R R16J-560K 417345644T PCB-U008 R5376 CARBON R R16J-560K 417345644T PCB-U008 R5377 CARBON R R16J-560K 417345644T PCB-U008 R5378 CARBON R R16J-560K 417345644T PCB-U008 R6010 CARBON R R16J-4.7K 417344724T PCB-U008 R6011 CARBON R R16J-4.7K 417344724T PCB-U008...
Page 274 213/221 PAGE R6041 TRIM R N06HR1KBB 5211401T PCB-U008 R6042 TRIM R N06HR1KBB 5211401T PCB-U008 R6043 TRIM R N06HR1KBB 5211401T PCB-U008 R6044 TRIM R N06HR1KBB 5211401T PCB-U008 R6045 TRIM R N06HR1KBB 5211401T PCB-U008 R6046 TRIM R N06HR1KBB 5211401T PCB-U008 R6047 TRIM R N06HR1KBB 5211401T PCB-U008...
Page 275 214/221 PAGE R6077 NF CARBON R R25J-82 415478204T PCB-U008 R6078 NF CARBON R R25J-82 415478204T PCB-U008 R6110 CARBON R R16J-10K 417341034T PCB-U008 R6111 CARBON R R16J-10K 417341034T PCB-U008 R6112 CARBON R R16J-10K 417341034T PCB-U008 R6113 CARBON R R16J-10K 417341034T PCB-U008 R6114 CARBON R R16J-10K...
Page 276 215/221 PAGE R6274 NF CARBON R R25J-18 415471804T PCB-U008 R6275 NF CARBON R R25J-18 415471804T PCB-U008 R6276 NF CARBON R R25J-18 415471804T PCB-U008 R6277 NF CARBON R R25J-18 415471804T PCB-U008 R6278 NF CARBON R R25J-18 415471804T PCB-U008 R6280 NF CARBON R R25J-18 415471804T PCB-U008...
Page 277 216/221 PAGE R6311 NF CARBON R R25J-10 415471004T PCB-U008 R6312 NF CARBON R R25J-10 415471004T PCB-U008 R6313 NF CARBON R R25J-10 415471004T PCB-U008 R6314 NF CARBON R R25J-10 415471004T PCB-U008 R6315 NF CARBON R R25J-10 415471004T PCB-U008 R6316 NF CARBON R R25J-10 415471004T PCB-U008...
Page 278 217/221 PAGE P5026A TRM NTM-1P233(M1969) 25060302 PCB-U008 P5027A TRM NTM-1P233(M1969) 25060302 PCB-U008 P5028A TRM NTM-1P233(M1969) 25060302 PCB-U008 P6010A SOCKET NSCT-3P2183 25052286 PCB-U008 P6011A SOCKET NSCT-3P2183 25052286 PCB-U008 P6012A SOCKET NSCT-3P2183 25052286 PCB-U008 P6013A SOCKET NSCT-3P2183 25052286 PCB-U008 P6014A SOCKET NSCT-3P2183 25052286 PCB-U008 P6015A SOCKET...
Page 279 218/221 PAGE D8862 or C-DIODE 1SS352 ( 1) 223234R2 PCB-U010 Q3300 TPD2E001DRLR 22242589R2 PCB-U010 Q8861 TMDS141RHARG4 22242586R2 PCB-U010 [TRANS COIL] PCB-U010 L8861 CORE BLM18PG181SN1D 2350005R1 PCB-U010 [CAPACITOR] PCB-U010 C3302 C-FILM C ECHU16V-104J 373041044R2 PCB-U010 C3303 C-FILM C ECHU16V-104J 373041044R2 PCB-U010 C3304 C-CERA C CK725F1A-105Z1...
Page 280 SOCKET YKF45-0029N 25053242 PCB-U010 P8641D SOCKET FX16-31S-0.5SV 25053354R2 PCB-U010 P8861 SOCKET YKF45-7037V 25053253R3 PCB-U010 TX-NR5007 PACKING PROCEDURE PARTS LIST REF. NOPART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS [PACKING] PACKING A615 TAPE FIXLON #817 W12 29110207 PACKING A615 or TAPE...
Page 281 PACKING A811 INS MANUAL U2NlSv (TX-NR3007/5007) 29400062 <MMP> PACKING A812 INS MANUAL Ru (TX-NR3007/5007) 29400063 <MMP> PACKING A815 INS MANUAL Cs (TX-NR5007) 29400066 <MMR> PACKING A820 INS MANUAL En (QSS_TX-NR3007/5007) 29400071 PACKING A821 INS MANUAL Cs (QSS_TX-NR5007) 29400072A <MMR> PACKING...
Page 282 221/221 PAGE A891 BATTERY R6/AA (UM-3) 3010194 <MDC, MMP> PACKING A891 or BATTERY R6/AA (UM-3) ( 2) 3010054 <MDC, MMP> PACKING A892 ANT COIL NMA-3057 232140 PACKING A893 FM ANT AS Type W 292191 PACKING A894 MIC-7000 245044 PACKING P901 AC CORD AS-CEE-3 253298VOL...
Page 283 Tel: 072-831-8023 Fax: 072-831-8163 ONKYO U.S.A. CORPORATION 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 http://www.us.onkyo.com/ ONKYO EUROPE ELECTRONICS GmbH (DUISBURG OFFICE) Hafennr.7602, Logport Office-Center, Bliersheimerstr.80B, 47229 Duisburg, Germany Tel: +49-2065-90198-00 Fax: +49-2065-90198-40 http://www.eu.onkyo.com/ ONKYO EUROPE UK Office...

This manual is also suitable for:

Tx-nr5007b Tx-nr5007s

Onkyo TX-NR5007 Service Manual

Quick Links

Related Manuals for Onkyo TX-NR5007

Summary of Contents for Onkyo TX-NR5007

Page 2: Service Procedure

Page 9: Part

Page 10: Part

Page 34: Part

Page 35: Vhd2

Page 62: Exploded View Parts List

This manual is also suitable for:
