Arico tc5f User Manual

Hot-runner temperature controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

TC5F 熱澆道溫度控制器
TC5F Hot-Runner Temperature Controller
保有權利於任何時間未經通知而修改或變更本手冊內容及型式，未經本公司同意，不得作任何形式的使用。
reserves the right to make any kind of design or functional modification at any moment without prior notice.
長 新 科 技 股 份 有 限 公 司
ARICO Technology Co., Ltd.
長新科技股份有限公司
USER'S MANUAL
ARICO Technology Co., Ltd.
Registered to
ISO 9001
操作手冊
VNA0000015
Ver.:TC5F-1.0.4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the tc5f and is the answer not in the manual?

Questions and answers

Related Manuals for Arico tc5f

Summary of Contents for Arico tc5f

  • Page 1 長 新 科 技 股 份 有 限 公 司 ARICO Technology Co., Ltd. Registered to ISO 9001 TC5F 熱澆道溫度控制器 TC5F Hot-Runner Temperature Controller 操作手冊 USER'S MANUAL VNA0000015 Ver.:TC5F-1.0.4 長新科技股份有限公司 ARICO Technology Co., Ltd. 保有權利於任何時間未經通知而修改或變更本手冊內容及型式，未經本公司同意，不得作任何形式的使用。 reserves the right to make any kind of design or functional modification at any moment without prior notice.

  • Page 2: Table Of Contents

    To avoid wrong operation, which may result in human injured or machine damage, please read this instruction carefully before use the instrument. CONTENT Chapter 1 TC5F TEMPERATURE CONTROL MODULE 1-1 Features 1-2 Specification 1-3 Faceplate 1-4 Operation description Chapter 2 CABINET&ACCESSORIES...

  • Page 3: Chapter 1 Tc5F Temperature Control Module

    ■ Power consumption: 7W ■ Input impedance: 10M Ω Every module) ■ Output wattage: 3600W(Max)、15A/240VAC ( ■ Storage temperature: -20~70℃ ■ Working temperature: 0~50℃ ■ Work Humidity: 10~80%RH (Non-condensing) ■ Control accuracy: ±0.25% ■ Measurement accuracy: ±0.25% ARICO Technology Co., Ltd.

  • Page 4: Faceplate

    1-3 Faceplate 1-3-1 Faceplate description (1) PV: 1.Normal mode: Present value 2.Parameter mode: Parameter name (2) SV: 1.Normal mode: Setting value 2.Parameter mode: Parameter name (10) 3.Manual output or parameter: Manual output% (11) (3) Aux. display: output percentage, electric current, frequency display.
  • Page 5 1-3-2 Faceplate appearance and dimension Deviation: ±5mm ARICO Technology Co., Ltd.

  • Page 6: Operation Description

    1-4 Operating description 1-4-1 Parameter flow chart...
  • Page 7 ARICO Technology Co., Ltd.

  • Page 8: Control Mode

    1-4-2 Soft start (Heater dehumidify) function To avoid the humidity burning the heater out, the soft start function could output a lower current to dehumidify the heater when the power turned on. Soft start condition: The soft start percentage (SSP) and time (SST). After power turned on, if SV >...
  • Page 9 0%. Regular: Actual current= 0 A Malfunction: When actual current is> 0 A, control will stop and alarm start, O1ST message will appear on first set of LED until the model starts power again. ARICO Technology Co., Ltd.
  • Page 10 1-4-7 Cooling control Start term: COOL= ON Action mode: The cycle time is CYT1. The output is P control way. 1-4-8 Alarm code ERRC 1 : Thermocouple break 2 : Thermocouple inverse 4 : Heat output short 8 : Heat output break 1-4-9 Error message ：Thermocouple break ：Heater break...
  • Page 11 (3)Set parameter TUN into YES PS: During PID auto tuning execution, the decimal point of PV will flash. After the instrument gets the optimal PID, the decimal point turns off and the instrument returns to auto temperature control. ARICO Technology Co., Ltd.

  • Page 12: Dimension

    Chapter 2 CABINET 2-1 Dimension Unit：mm Cabinet 1 Zone 2 Zones 4 Zones 6 Zones 8 Zones 12 Zones -10-...

  • Page 13: Specification

    12.5 (non-module) 2-3 Connection Description connector Connector type Housing Hood Hood Housing Name Type Socket Plug Socket Plug a: single hook b: single button c: dual hook d: dual button *Standard type **T5A01only for type1 -11- ARICO Technology Co., Ltd.

  • Page 14: Type Of Power Wiring

    2-4 Type of power wiring -12-...
  • Page 15 3. Make sure the ac power input is switched off before maintenance. Note: power type A and B differ with regard to “ ” connections. The FGND must be connected with earth ground. 2-4-4 Communication port Socket Plug -13- ARICO Technology Co., Ltd.

  • Page 16: Connector Wiring

    2-5 Connector wiring Single cabinet connector wiring ZONE CONN CONNECTOR ASSIGNMENT A4-1 Multi-cabinet connector wiring are divided into A, B, C and D type as below: A type wiring ZONE CONN CONNECTOR ASSIGNMENT 16*1 A16-2 16*1 A16-4 24*1 A24-6 16*2 A16-8 24*2 A24-12...
  • Page 17 B type wiring ZONE CONN CONNECTOR ASSIGNMENT 16*1 B16-2 16*1 B16-4 24*1 B24-6 16*2 B16-8 24*2 B24-12 -15- ARICO Technology Co., Ltd.
  • Page 18 C type wiring ZONE CONN CONNECTOR ASSIGNMENT 16*2 C16-8 24*2 C24-12 D type wiring ZONE CONN CONNECTOR ASSIGNMENT 16*1 D16-2 16*1 D16-4 24*1 D24-6 16*2 D16-8 24*2 D24-12 -16-...

  • Page 19: Cabinet

    B0: B type 3-phase 5-wire 380~415VAC A1: A type 3-phase 4-wire 200~242VAC* B1: B type 3-phase 5-wire 380~415VAC* *: for 1 zone T5A01 3-2 Cable: T5C Order code: T5C a: Wiring b: PIN c: Length（M） ◎Standard Length 3M -17- ARICO Technology Co., Ltd.

  • Page 20: Housing

    3-3 Housing: T5E Order code: T5E a: PIN--4、16、24 Single Single button b: Type 1. Single hook 2. Dual hook 3. Single button 4. Dual button Dual hook Dual button 3-4 Hood：T5F Order code：T5F a: PIN--4、16、24 Single hook Single button b: Type 1.

  • Page 21: Trouble Shooting

    6. In the normal operation, the temperature  Extension cable is loose or breaks? cannot rise up.  Heater is malfunction?  Module（TRIAC）is malfunction?  Refer 1-4-10, execute PID self – 7. Temperature control is unstable. tuning. -19- ARICO Technology Co., Ltd.
  • Page 22 長新科技股份有限公司 ARICO Technology Co., Ltd. 總公司 (HEADQUARTERS) 23145 新北市新店區寶橋路 235 巷 1 弄 1 號 8 樓 8F., No.1, Alley. 1, Lane 235, Baociao Rd., Sindian District, New Taipei City, 23145, Taiwan TEL:+886-2-29101266 FAX:+886-2-29159434 www.arico.tw / www.arico.com.tw -20-...
