TC5E 熱澆道溫度控制器
TC5E Hot-Runner Temperature Controller
保有權利於任何時間未經通知而修改或變更本手冊內容及型式，未經本公司同意，不得作任何形式的使用。
reserves the right to make any kind of design or functional modification at any moment without prior notice.
長 新 科 技 股 份 有 限 公 司
ARICO Technology Co., Ltd.
長新科技股份有限公司
USER'S MANUAL
ARICO Technology Co., Ltd.
R egister ed to
I SO 9001
操作手冊
Ver.:TC5E-1.0.3
VNA0000008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC5E and is the answer not in the manual?

Questions and answers

Related Manuals for Arico TC5E

Summary of Contents for Arico TC5E

  • Page 1 長 新 科 技 股 份 有 限 公 司 ARICO Technology Co., Ltd. R egister ed to I SO 9001 TC5E 熱澆道溫度控制器 TC5E Hot-Runner Temperature Controller 操作手冊 USER'S MANUAL Ver.:TC5E-1.0.3 VNA0000008 長新科技股份有限公司 ARICO Technology Co., Ltd. 保有權利於任何時間未經通知而修改或變更本手冊內容及型式，未經本公司同意，不得作任何形式的使用。 reserves the right to make any kind of design or functional modification at any moment without prior notice.

  • Page 2: Table Of Contents

    CONTENT Chapter 1 TC5E TEMPERATURE CONTROL MODULE 1-1 Features 1-2 Specification 1-3 Faceplate 1-4 Operating description Chapter 2 CABINET & ACCESSORIES...

  • Page 3: Chapter 1 Tc5E Temperature Control

    Chapter 1 TC5E TEMPERATURE CONTROL MODULE 1-1 Features ■ Dual SV temperature control ■ Dual lines LED display ■ Unit display ■ Auto/Manual function ■ PID auto temperature control ■ Selectable two thermocouple types (J or K) ■ Selectable two temperature scales (°C or °F) ■...

  • Page 4: Faceplate

    1-3 Faceplate 1-3-1 Faceplate description (1)PV: ○ Normal mode: Present value Parameter mode: Parameter ○ name (2)SV: ○ Normal mode: Setting value Parameter mode: Parameter ○ value Manual output mode: Manual ○ output % (3)UNIT: Temperature or parameter unit (4)Function key: Parameter level and parameter select key (5)Set key: Set enable and digital shift key (6)Decrement key: Setting number...
  • Page 5 1-3-2 Faceplate appearance and dimension Deviation: ±5mm...

  • Page 6: Operating Description

    1-4 Operating description 1-4-1 Parameter flow chart A R ICO T echnology Co., L td.

  • Page 7: Operating Modes

    1-4-2 Operating modes TC5E divide into Main mode and parameter mode. In main mode, press could entry parameter mode. Main mode: Controller display PV and SV, use for SV modification. Parameter mode: Controller display parameter name and its value, use for value modification.
  • Page 8 ＋ ＋1 sec: The alarm output function disable or enable select (when power re-setting, the default setting is enable) 1-4-5 Soft start (Heater dehumidify) function To avoid the humidity make the heater burn out. The soft start function could output a lower current to make dehumidify action when turn on the power. Soft start condition: The soft start percentage ( ) and time (...
  • Page 9 1-4-7 Process control 1-4-8 Error message 1-4-9 Wiring ：Input break ：Input reverse...

  • Page 10: Chapter 2 Cabinet & Accessories

    Chapter 2 CABINET 2-1 Dimension Unit: mm Cabinet 1 Zones 2 Zones 4 Zones 6 Zones 8 Zones 12 Zones A R ICO T echnology Co., L td.

  • Page 11: Specification

    2-2 Specification Type T5A01 T5A02 T5A04 T5A06 T5A08 T5A12 Zone Item Power Switch capacity(A) Output 4pin+E 16pins 16pins 24pins 16pins 24pins Connector (ground) 2.0mm 5.5mm 5.5mm 5.5mm 8.0mm 8.0mm Power Cable Weight(kg) 1.75 7.25 11.25 12.5 (non-module) 2-3 Connection description Connector Connector type Housing Hood...

  • Page 12: Type Of Power Wiring

    2-4 Type of power wiring A R ICO T echnology Co., L td. -11-...
  • Page 13 The following power wiring only for T5A01 Caution 1. Before operating, check connection ("y" or " △ ")and its voltage. 2. All instruments must be used in accordance with the specification to prevent fire or damage to instrument and equipment. 3.

  • Page 14: Connector Wiring

    2-5 Connector wiring Cabinet connector wiring are divided into A, B and C type as below: A type wiring ZONE CONN. CONNECTOR ASSIGNMENT 16*1 A16-2 16*1 A16-4 24*1 A24-6 16*2 A16-8 24*2 A24-12 A R ICO T echnology Co., L td. -13-...
  • Page 15 B type wiring ZONE CONN. CONNECTOR ASSIGNMENT 16*1 B16-2 16*1 B16-4 24*1 B24-6 16*2 B16-8 24*2 B24-12 -14-...
  • Page 16 C type wiring ZONE CONN. CONNECTOR ASSIGNMENT 16*2 C16-8 24*2 C24-12 A R ICO T echnology Co., L td. -15-...

  • Page 17: Cable

    Chapter 3 ORDER CODE 3-1 Cabinet: T5A a：Zone d ： Power Cable Length f ： Cable Wiring 01：1 zone 03 ： 3m (standard) 00 ： Without connection cable 02：2 zones e ： O/P Connector Wiring 03 ： 3m (standard) 04：4 zones A ：...

  • Page 18: Housing

    3-3 Housing: T5E Order code： Single hook Single button a: Pins--4, 16, 24 b: Type 1:Single hook 2:Dual hook 3:Single button Dual hook Dual button 4:Dual button 3-4 Hood: T5F Order code： Single hook Single button a: Pins--4, 16, 24 b: Type 1:Single hook 2:Dual hook...

  • Page 19: Trouble Shooting

    3-7 Trouble shooting Malfunction status Check item  TC5E is installed properly?  Power wiring is correct? 1.No action after power on.  Main power switch is malfunction?  TC5E module is malfunction?  Change the fuse accord with the brightly 2.F1 or F2 fuse break indicator bright.
  • Page 20 長新科技股份有限公司 ARICO Technology Co., Ltd. 總公司 (HEADQUARTERS) 23145 新北市新店區寶橋路 235 巷 1 弄 1 號 8 樓 8F., No.1, Alley. 1, Lane 235, Baociao Rd., Sindian District, New Taipei City, 23145, Taiwan TEL:+886-2-29101266 FAX:+886-2-29159434 www.arico.tw / www.arico.com.tw A R ICO T echnology Co., L td.
