- Page 1 3G/HD/SD-SDI Over Fiber Mini Transmitter and Receiver Extender User Manual L-1SDI-FE-3G-MN-TX/RX www.questtel.com sales@questtel.com...
-
Page 2: Table Of Contents
L-1SDI-FE-3G-MN-TX-RX HD/SD-SDI Over Fiber User Manual Contents 1INTRODUCTION .............................. 2 1.1O ..............................2 VERVIEW 1.2F ..............................2 EATURE 1.3A ..............................2 PPLICATION 2 PANEL DESCRIPTION ........................... 3 3TECHNICAL SPECIFICATION ........................3 4 DEVICE DIMENSION ............................5 www.questtel.com sales@questtel.com... -
Page 3: 1Introduction
1Introduction 1.1Overview The L-1SDI-FE-3G-MN-TX-RX is a thumb type 3G/HD/SD-SDI video optical transceiver, including a transmitter and a receiver, which achieves optical transmission of one HD/SD-SDI signal (audio signal embedded) and provides one reversed RS485 data channel, and can be widely used in high-definition video conference, high-definition video monitoring, intelligent transportation system and public security system. -
Page 4: Panel Description
L-1SDI-FE-3G-MN-TX-RX HD/SD-SDI Over Fiber User Manual 2 Panel Description +12V LINK Figure 2-1 Front panel Figure 2-2 Rear panel Table 2-1 Front panel Interface Description Optical interface, bi-directional, ST-PC connector Optical port status indicator, Green. LINK ON: Normal OFF: No optical signal. - Page 5 L-1SDI-FE-3G-MN-TX-RX HD/SD-SDI Over Fiber User Manual Transmission distance (Km) launched power (dBm) -9~-3 -6~-1 -7~-2 -5~0 -2~+3 Maximum receive sensitivity (dBm) Receiver optical interface Wavelength(nm) Tx1550FP Tx1550FP Tx1310FP Tx1310FP Tx1310FP /Rx1310 /Rx1310 /Rx1550 /Rx1550 /Rx1550 Transmission distance (Km) launched power (dBm)
-
Page 6: Device Dimension
L-1SDI-FE-3G-MN-TX-RX HD/SD-SDI Over Fiber User Manual 4 Device Dimension www.questtel.com sales@questtel.com... -
Page 7: Safety Instructions
This unit outputs continuous invisible light, which may be harmful to the eyes; use with caution. For additional safety, plug the attached WARNING! dust caps into the optical transceivers when the fiber optic cable is unplugged. Direct viewing into optical connectors should be avoided at all times! www.questtel.com sales@questtel.com...
