User’s Manual
Version 1.0
July 2002
www.behringer.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ultramatch PRO SRC2496 and is the answer not in the manual?

Questions and answers

Related Manuals for Behringer Ultramatch PRO SRC2496

Summary of Contents for Behringer Ultramatch PRO SRC2496

  • Page 1 User’s Manual Version 1.0 July 2002 www.behringer.com...

  • Page 2: Safety Instructions

    ULTRAMATCH PRO SRC2496 SAFETY INSTRUCTIONS All the safety and operation instructions should be read before the device is operated. The safety and operating instructions should be retained for future reference. All warnings on the device and in the operating instructions should be adhered to.
  • Page 3 ULTRAMATCH PRO SRC2496 ULTRAMATCH PRO Ultra high-resolution 24-bit/96 kHz A/D-D/A, sample rate and format converter s High-end 24-bit/96 kHz A/D and D/A converters for ultimate signal purity s Converts any sample rate between 31 and 100 kHz into 32, 44.1, 48, 88.2 or 96 kHz sample rates...

  • Page 4: Table Of Contents

    ULTRAMATCH PRO SRC2496 FOREWORD TABLE OF CONTENTS Dear Customer, welcome to the team of BEHRINGER users and thank you 1. INTRODUCTION ............5 very much for expressing your confidence in us by purchasing the 1.1 The design concept ............5 SRC2496.

  • Page 5: Introduction

    ULTRAMATCH PRO SRC2496 to function as a universal inter- face between the various digital formats and sampling rates. Thus, incompatibilities between different devices and equipment...

  • Page 6: Monitor And Input Sections

    ULTRAMATCH PRO SRC2496 Similarly to the input section, the display provides you with The EMPH LED shows you whether or not the input signal all the information on the output signal. includes an emphasis marker. “Emphasis” is a high-frequency boost function that is applied during the digital recording but is undone during playback.

  • Page 7: Rear Panel Of The Ultramatch Pro

    ULTRAMATCH PRO SRC2496 in the output section should read the same status as the The LEDs 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz and 96 kHz EMPH LED in the input section. In the rare case of a signal...

  • Page 8: Applications

    ULTRAMATCH PRO SRC2496 Fig. 2.8: Wordclock connector The BNC connector WORDCLOCK is a high-impedance Fig. 2.11: Analog outputs and inputs connector with no internal terminating impedance (75 ohms). Use it to connect devices for the external synchronization of ANALOG OUTPUTS. These balanced analog XLR outputs your ULTRAMATCH PRO.

  • Page 9: Converting Digital To Analog

    ULTRAMATCH PRO SRC2496 Fig. 3.2: Example: A/D conversion of tape recordings Fig. 3.1: Example: A/D conversion of a microphone signal Fig. 3.1 shows a typical setup for recording a signal source on a digital recording device (here: hard-disk recording system). If your HD recording system is equipped with a digital interface, you can use the ULTRAMATCH PRO to “circumvent”...

  • Page 10: Sample Rate Conversion

    Conversion of older digital recordings from 44.056 kHz to By inserting the BEHRINGER ULTRAMATCH PRO SRC2496 32, 44.1, 48, 88.2 or 96 kHz. between the device to be synchronized and the mixing console input, Conversion of “foreign”...

  • Page 11: Line Booster, Signal Refresher

    ULTRAMATCH PRO SRC2496 boost step involved prior to recording. This treble boost is undone the SRC2496 this problem is now history. The input of your during playback. A specific bit (emphasis bit) in the digital data ULTRAMATCH PRO readily accepts any standard used today.

  • Page 12: Aes/Ebu And S/Pdif Standards

    Audio ref. Reserved Reserved By processing data in real time, the processor used in the BEHRINGER ULTRAMATCH PRO can process incredible Tab. 4.2: Markers in professional format (AES/EBU) amounts of data. Table 4.3 presents the corresponding consumer-format data, The noise and interference floor is thus below -117 dBFS, and as normally used with S/PDIF-connections.

  • Page 13: Analog Inputs And Outputs

    S/PDIF format. They accept and deliver data streams in both the professional and the consumer format. It is even possible to connect the XLR output (e.g. from the BEHRINGER ULTRA-CURVE PRO DSP8024 or another device) to the RCA input on the ULTRAMATCH PRO by using an adapter. Whether or not the reverse will work, namely connecting the ULTRAMATCH PRO’s...

  • Page 14: Wordclock

    ULTRAMATCH PRO SRC2496 The following figure illustrates how to correctly connect the optical input and output connections. Fig. 5.7: Unbalanced connection (loop through) of the wordclock input Fig. 5.5: Connecting the ULTRAMATCH PRO optically via Toslink 5.3.5 Connecting with an adapter In certain cases it makes sense to connect the SRC2496’s inputs...

  • Page 15: Specifications

    >40 ns Internal jitter at input <2 ns BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made from time to time to existing products Internal jitter with external without prior notice. Specifications and appearance may differ from those listed or Synchronization <20 ns, 10 ns typ.

  • Page 16: Warranty

    5. Any repair or opening of the unit carried out by unauthorized this warranty as described under § 3 and 4, BEHRINGER shall, at personnel (user included) will void the warranty.
