User Manual
ULTRAMATCH PRO SRC2496
Audiophile 24-Bit/96 kHz A/D-D/A & Sample Rate Converter

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ULTRAMATCH PRO SRC2496 and is the answer not in the manual?

Questions and answers

Related Manuals for Behringer ULTRAMATCH PRO SRC2496

Summary of Contents for Behringer ULTRAMATCH PRO SRC2496

  • Page 1 User Manual ULTRAMATCH PRO SRC2496 Audiophile 24-Bit/96 kHz A/D-D/A & Sample Rate Converter...

  • Page 2: Table Of Contents

    1.2 Before you begin ............... 4 2. Control Elements ............4 2.1 Front panel of the ULTRAMATCH PRO SRC2496 ........... 4 2.2 Rear panel of the ULTRAMATCH PRO ......6 3. Applications .............. 7 3.1 A/D and D/A conversion with the ULTRAMATCH PRO ..............

  • Page 3: Important Safety Instructions

    3. Heed all warnings. ARE SUBJECT TO CHANGE WITHOUT NOTICE AND 4. Follow all instructions. ACCURACY IS NOT GUARANTEED. BEHRINGER IS 5. Do not use this apparatus near water. PART OF THE MUSIC GROUP (MUSIC-GROUP.COM). ALL TRADEMARKS ARE THE PROPERTY OF THEIR 6.

  • Page 4: Introduction

    ◊ If the unit is damaged, please do NOT return it to BEHRINGER, but notify variety of signal processing possibilities available in the digital world, but also your dealer and the shipping company immediately, otherwise claims designed the ULTRAMATCH PRO SRC2496 to function as a universal inter-face for damage or replacement may not be granted.
  • Page 5 ULTRAMATCH PRO SRC2496 2.1.1 Monitor and input sections (12) The EMPH LED shows you whether or not the input signal includes an emphasis marker. “Emphasis” is a high-frequency boost function that (11) (13) (15) (16) (19) (21) (23) (25) is applied during the digital recording but is undone during playback.

  • Page 6: Rear Panel Of The Ultramatch Pro

    ULTRAMATCH PRO SRC2496 (18) The SAMPLE RATE switch selects the sampling rate to which the input Reducing the digital word length (e.g. from 24 bits to 20 bits) also means a signal is to be converted or made available at the outputs. For this purpose, reduction of the resolution.

  • Page 7: Applications

    ULTRAMATCH PRO SRC2496 (30) (31) (32) (33) (34) (35) (36) (37) (38) (30) (31) (32) (33) (34) (35) (36) (37) (38) Fig. 2.7: Wordclock connector Fig. 2.10: Analog outputs and inputs (30) The BNC connector WORDCLOCK is a high-impedance connector with no (37) ANALOG OUTPUTS.
  • Page 8 ULTRAMATCH PRO SRC2496 Digital Audio Workstation Tape Line outputs DAT-Recorder Analog inputs ULTRAMATCH PRO Digital input/Sound card Digital outputs Digital output Digital input ULTRAMATCH PRO Analog inputs/L+R Subgroup outputs Microphone BEHRINGER XM1800S Channel input Digital Audio Workstation Fig. 3.2: Example: A/D conversion of tape recordings...

  • Page 9: Sample Rate Conversion

    Conversion of older digital recordings from 44.056 kHz to 32, 44.1, 48, 88.2 cannot be synchronized. or 96 kHz By inserting the BEHRINGER ULTRAMATCH PRO SRC2496 between the equipment • Conversion of “foreign” material with 32 kHz to 44.1, 48, 88.2 or 96 kHz to be synchronized and the mixing console input, the SRC2496 can deliver •...

  • Page 10: Line Booster, Signal Refresher

    ULTRAMATCH PRO SRC2496 3.9 Format interface So much for the theory. In practice, a lit EMPHASIS LED does not necessarily show that the emphasis function has really been applied. In several situations the Many CD players have no coaxial but only an optical output. Some DAT recorders, emphasis bit was set during the mastering and editing process due to defective on the other hand, only have a coaxial input.

  • Page 11: Aes/Ebu And S/Pdif Standards

    S/PDIF-connections. between computation efforts and sound quality. Byte By processing data in real time, the processor used in the BEHRINGER ULTRAMATCH PRO can process incredible amounts of data. Audio Copy...

  • Page 12: Digital Inputs And Outputs

    It is The following figure shows how to correctly connect the unbalanced even possible to connect the XLR output (e.g. from the BEHRINGER ULTRA-CURVE wordclock input. The wiring scheme is the same as is used for networking in...

  • Page 13: Headphones Output

    ULTRAMATCH PRO SRC2496 6. Specifications Word clock output Word clock input device A ULTRAMATCH Synchronization signal ow terminating resistor Internal sampling rates 32, 44.1, 48, 88.2, 96 kHz Synchronization via digital input accepts all sampling rates and wordclock between 31 and 100 kHz, automatic synchronization by PLL Fig.
  • Page 14 7.48 lbs/3.4 kg S/N Ratio >108 dB BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, Jitter Suppression modifications may be made from time to time to existing products without prior notice. Specifications and appearance may differ from those listed or illustrated.
