King Technology 01-01-7820 Instruction Manual

Mineral pool-care infuzer for pools up to 25,000 gallons
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FROG Leap
®
Instruction Manual
®
Mineral Pool-Care Infuzer
for Pools up to 25,000 Gallons
Cleaner
because it kills bacteria two ways
Clearer
because it helps keep pH in range
Softer
because it reduces chlorine use up to 50%*
Easier
with pre-fi lled pacs for no mess,
no guess and no stress
FROG Leap Infuzer comes with the
®
FROG Leap Anti-Bac Mineral Pac
Patented Mineral Disinfectant
Customer Service 800-222-0169
frogproducts.com
WARNING
To minimize the risk of serious injury, death or
damage, before installing or first using this
equipment, read Instruction Manual and all safety
labels and follow all safety instructions and
precautions. Save manual for future reference.
Ver la versión en español de este manual en frogproducts.com/product/frog-leap
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 01-01-7820 and is the answer not in the manual?

Questions and answers

Related Manuals for King Technology 01-01-7820

Summary of Contents for King Technology 01-01-7820

  • Page 1 FROG Leap ® Instruction Manual ® Mineral Pool-Care Infuzer for Pools up to 25,000 Gallons Cleaner because it kills bacteria two ways Clearer because it helps keep pH in range Softer because it reduces chlorine use up to 50%* Easier with pre-fi lled pacs for no mess, no guess and no stress FROG Leap Infuzer comes with the...

  • Page 2: Table Of Contents

    Using FROG Leap ALL-OUT ® Using FROG Leap Torpedo Pac Winterizing Troubleshooting Parts List Maintenance - Replacing Control Dial O-Rings Maintenance - Replacing Cap O-Rings and Knobs Warranty For information on King Technology’s entire product line, visit our website at frogproducts.com...

  • Page 3: Frog Leap Introduction

    FROG Leap Infuzer. System. Product #01-12-7822 THE FROG LEAP ANTI-BAC For Pools Up to 25,000 MINERAL PAC MUST BE gallons. Product #01-01-7820 REPLACED EVERY SIX MONTHS OR AFTER ONE POOL SEASON, WHICHEVER IS SHORTER. Part 3 Part 4...

  • Page 4: Notes And Safety Information

    • Keep the instructions nearby and available for reference covered suffi ciently in this manual, contact King Technology at throughout the service life of this system. 800-222-0169.

  • Page 5: Safety Labels On Infuzer

    Safety Labels on Infuzer Review this label before installing or operating this Infuzer. Contact King Technology at 800-222-0169 if this label is missing from your FROG Leap Infuzer. Fire, explosion and high pressure hazards To minimize the risk of serious injury, death or property damage while using the FROG Leap Infuzer: a Read, understand and follow all instructions and safety precautions in the manual, and on this Infuzer and on any label for chemicals used with this Infuzer including FROG Leap Torpedo Pacs, FROG Leap Anti-Bac Mineral Pacs and FROG Leap Wake Up!/Hibernation.

  • Page 6: Installation Tips To Ensure Proper Performance

    Change the eyeball fi ttings in IN-FLOOR CLEANER the return jets to a smaller size to increase Line 2 VALVE back pressure. Contact King Technology at FILTER PUMP 800-222-0169 for a specially designed Infuzer pressure gauge to determine back pressure at pool start-up.

  • Page 7: Filter Flex-Hose Installation

    To avoid over or under chlorination, replace eyeball fi ttings in the return jets to a smaller or larger size to adjust back pressure. For best results use King Technology’s pressure gauge, order part number 01-22-4000. To prevent damage to heaters...

  • Page 8: Base Flex-Hose Installation

    FLEX HOSE or fi lters, see your dealer about size to adjust back pressure. For installing a corrosion resistant best results use King Technology’s pressure gauge, order part number check valve which will reduce the 01-22-4000. back fl ow of chlorine gas when the...

  • Page 9: Hard-Plumbed Installation

    Hard-Plumbed Installation TOOLS NEEDED Pipe Wrench Hacksaw The FROG Leap Infuzer should always be installed between Do NOT install in copper pipe if using the fi lter and pool (or between heater and pool if applicable). FROG Leap Torpedo Pac as chemical Tape Never install FROG Leap Infuzer before the heater or corrosion may lead to pipe failure.

  • Page 10: Step 1: Preparing The Pool

    Step 1: Preparing the Pool Make sure the pool has adequate Check for metals in the pool such circulation. The total volume of pool as iron or copper. Before attempting water must completely circulate Metal water balance these should be through the pump and fi lter at least removed.

  • Page 11: Step 1: Preparing The Pool

    Continue... Step 1: Preparing the Pool For best results in achieving water balance, follow steps 5a Initially shock the pool with a chlorine shock only to through 5e in order. rid the water of contaminants and establish a chlorine residual. Always follow the manufacturer’s directions carefully.

  • Page 12: Step 2: Putting The System To Work

    Step 2: Putting the System to Work Create a chlorine residual with nstall a FROG Leap Anti-Bac FROG Leap Reveille. (See page Mineral Pac into the FROG 16 for FROG Leap Reveille Leap Infuzer. (See page 15 for directions.) directions.) IMPORTANT: Replace the FROG Leap Anti- Bac Mineral Pac every 6 months...

  • Page 13: Step 3: Setting The Control Dial

    Step 3: Setting the Control Dial This system is designed to work effectively with a variety of pool equipment as long as the following procedures are followed. Set the control dial by matching up the parameters of your pool on the chart below. THIS IS A STARTING POINT ONLY and may need to be adjusted to fi t your individual pool needs.

  • Page 14: Step 4: Routine Pool Care

    Step 4: Routine Pool Care Run fi ltration enough hours to Shock the pool every other week circulate all water 1 to 2 times per or as needed. We recommend a day. More than that could result in non-chlorine shock as reducing over chlorination.

  • Page 15: Replacing Frog Leap Anti-Bac Mineral Pac

    Replacing a FROG Leap Anti-Bac Mineral Pac Must be replaced every 6 months or after one pool season. For Pools up to 25,000 Gallons Open FROG Leap Infuzer cap. Check the top of the box and back label of product to make sure you have the correct FROG Leap Anti-Bac Mineral Pac to fi t your FROG Leap Infuzer.

  • Page 16: Using Frog Leap Wake Up

    Using FROG Leap Wake Up! FROG Leap Depth Charge is a one time start-up product used to rid the water of all contaminants. FROG Leap Reveille - also used at start up, sets the chlorine residual 90-DAY to help fi nd the proper dial setting for maintaining up to 50%* less chlorine.

  • Page 17: Using Frog Leap All-Out

    Using FROG Leap ALL-OUT for an Algae-Protection Guarantee For a preventive dose add: If you are not using FROG Leap ALL-OUT refer to page 18 for Using the FROG Leap Torpedo Pac. See FROG Leap ALL-OUT product labeling for •One FROG Leap ALL-OUT for pools up to 15,000 gallons. •Two FROG Leap ALL-OUT for pools between 15,000 &...

  • Page 18: Using Frog Leap Torpedo Pac

    Using the FROG Leap Torpedo Pac Line up small leg of the FROG FROG Leap Torpedo Pac is required to Leap Torpedo Pac with small assure up to 50% reduction in chlorine opening in FROG Leap Anti-Bac use*. FROG Leap Torpedo Pac sold Mineral Pac, and large leg with separately.

  • Page 19: Winterizing

    Winterizing If FROG Leap Torpedo Pac still contains chlorine, wrap in Before closing your plastic bag and store in shed or pool, refer to page 14 cool, dry, well-ventilated location and follow directions away from children, pets, cars, for using FROG Leap motorcycles or anything metal 90-DAY Hibernation.

  • Page 20: Troubleshooting

    Troubleshooting For more in-depth troubleshooting, go to frogproducts.com or call King Technology at 800-222-0169. Problem Remedy What do I do 1. Make sure your fi ltration time if not. 5. Make sure pool has a if the water looks system is working properly (i.e.

  • Page 21: Parts List

    Parts List Model 7800 SILICONE LUB RICANT Included with FROG Leap Infuzer 7800 Replacement parts for FROG Leap Infuzer 7800 REF. # DESCRIPTION QTY. INCLUDED REF. # PART NO. DESCRIPTION 1 & 2 Cap w/O-Ring 1 & 2 01-22-1416 Cap w/O-Ring Body 01-22-1920 Cap O-Ring...

  • Page 22: Maintenance - Replacing Control Dial O-Rings

    FROG Leap Infuzer Maintenance Replacing the Control Dial O-Rings Replacing the Cap O-Ring Remove old o-ring. Center of locking pin Top half of In the back of the FROG Leap groove. Infuzer, depress center of Place new o-ring in bottom locking pin with a fi nger and pull half of groove.

  • Page 23: Warranty

    5. Misuse or failure to use the proper FROG Leap Anti-Bac Mineral your unit and return it to King Technology within 30 days of purchase Pac and FROG Leap Torpedo Pac may cause damage to equipment and installation.
  • Page 24 MANUFACTURED BY © King Technology, Inc. The following are trademarks of King Technology, Inc. FROG ® Flippin’ FROG ® FILTER FROG ® FROG Jump Start ® ® ® ® ® FROG Leap Flippin’ FROG XL INSTANT FROG Fresh Mineral Water ®...
