F5 ARX-2500 Hardware Installation Manual

Hide thumbs Also See for ARX-2500:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual, Manual
®
ARX
–2500 Hardware Installation Guide
MAN-0417-00

Advertisement

Table of Contents
loading

Related Manuals for F5 ARX-2500

Summary of Contents for F5 ARX-2500

  • Page 1 ® –2500 Hardware Installation Guide MAN-0417-00...

  • Page 3: Legal Notices

    Clustered Multiprocessing, WA, WAN Optimization Manager, WANJet, WebAccelerator, WOM, and ZoneRunner, are trademarks or service marks of F5 Networks, Inc., in the U.S. and other countries, and may not be used without F5's express written consent. All other product and company names herein may be trademarks of their respective owners.
  • Page 4 Export Regulation Notice This product may include cryptographic software. Under the Export Administration Act, the United States government may consider it a criminal offense to export this product from the United States. RF Interference Warning This is a Class A product. In a domestic environment this product may cause radio interference, in which case the user may be required to take adequate measures.
  • Page 5 No association with any real company, organization, product, domain name, email address, logo, person, place, or event is intended or should be inferred. Revision History, MAN-0417-00 September 2012 — Rev. A. Hardware release. ARX-2500 Hardware Installation Guide...
  • Page 7 Table of Contents...

  • Page 9: Table Of Contents

    Installing a Redundant Peer or Cluster Peer ..............3-10 Replacing a Redundant Peer ..................... 3-11 Connecting the Out-of-Band Management Port ..............3-18 Maintenance POST Diagnostics ...........................4-3 Replacing Optical Transceivers or Chassis Before You Begin ...........................A-3 Replacing Optical Transceivers ....................A-3 Replacing the Chassis ........................A-4 Index ARX-2500 Hardware Installation Guide...
  • Page 10 Table of Contents...
  • Page 12 Table of Contents...

  • Page 13: Introduction

    Introduction • Audience for this Manual • Document Conventions • Related Documents • Safety and Regulatory Notices • Contacting Customer Service...

  • Page 15: Audience For This Manual

    Warnings are instructions for avoiding damage to the equipment. DANGER Danger notices help you to avoid personal injury. Related Documents In addition to this guide, the following F5 Data Solutions documentation is available: ® • ARX -2500 Quick Installation card ®...

  • Page 16: Safety And Regulatory Notices

    Chapter 1 Introduction Safety and Regulatory Notices Important The ambient room temperature range that the unit can operate in is 5 – 35° Important Do not block power supply vents or otherwise restrict airflow when installing unit in rack. WARNING Mechanical loading of rack should be considered so that the rack remains stable and unlikely to tip over.

  • Page 17: Class A Warning

    Only trained and qualified personnel should be allowed to install, replace, or service this equipment. ATTENTION Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. Battery Warning ARX-2500 Hardware Installation Guide 1 - 5...

  • Page 18: Environmental

    Chapter 1 Introduction Environmental High Temperature Warning WARNING To prevent the switch from overheating, do not operate it in an area that exceeds the maximum recommended ambient temperature of 35° C. To prevent airflow restriction, allow at least 3 inches (7.6 cm) of clearance around the ventilation openings.

  • Page 19: Power

    WARNING The power supply cords were designed to be connected and used for F5 devices, and the safety for this purpose has been confirmed. Please do not use them for other devices or usages. There may be danger of causing a fire or an electric shock.
  • Page 20 Chapter 1 Introduction Electric Shock Warning DANGER An ARX-2500 configured with two power supplies has two power cords. If you must remove AC power from the system, disconnect both power cords before servicing the system. DANGER Cette l'unité ARX-2500 peut être munie de deux cordons d'alimentation.

  • Page 21: Contacting Customer Service

    Contacting Customer Service Contacting Customer Service You can use the following methods to contact F5 Networks Customer Service: F5 Networks Online http://support.f5.com Knowledge Base Online repository of answers to frequently-asked questions. F5 Networks Services https://websupport.f5.com Support Online Online customer support...
  • Page 22 Chapter 1 Introduction 1 - 10...

  • Page 23: Unpacking And Installing The Switch

    Unpacking and Installing the Switch • Safety Instructions • Tools and Equipment • Unpacking and Verifying Shipment • Determining Which Rail Kit to Use • About the Rack-Mounting Ear Bracket Kit • About the Slide-Rail Mounting Kit • Inserting the Optical Transceivers (Optional) •...

  • Page 25: Safety Instructions

    • Laptop or PC to use as a serial console connected to the serial console interface • Customer-supplied standard 19-inch EIA rack Unpacking and Verifying Shipment The ARX-2500 is shipped in a single box with all components installed, except the (optional) optical transceivers. It weighs approximately 22.5 lb (10.2 kg)—not including packing materials. Note After installation, retain all packing materials.

  • Page 26: Determining Which Rail Kit To Use

    4 10-32 screws (5/8” to 7/8” long). Determining Which Rail Kit to Use The ARX-2500 platform comes with two types of rack mounting kits: a stationary rack-mounting type and a slide-rail-mounting type. An advantage of installing the slide-rail-mounting type is that you can then slide the component in and out of the rack as needed.

  • Page 27: General Recommendations For Rack Mounting

    This product is sensitive to electrostatic discharge (ESD). Proper ESD grounding procedures and equipment are recommended when you install or maintain the unit. Important Do not power on until the management serial console or the management network is connected to the unit. ARX-2500 Hardware Installation Guide 2 - 5...

  • Page 28: About The Rack-Mounting Ear Bracket Kit

    The rack-mounting ear bracket kit is located in the Accessory Kit. 1. Align the bracket’s keyhole slots with the PEM fasteners on the side of the component. The following figure shows the PEM fasteners on the side of the ARX-2500. 2 - 6...

  • Page 29: About The Slide-Rail Mounting Kit

    3. Slide the bracket toward the back of the component to lock the bracket into place. 4. Repeat steps 1 through 3 on the other side of the ARX-2500. 5. Lift the component into the rack. 6. Secure the ARX-2500 to the rack using customer-supplied hardware.

  • Page 30: Slide-Rail Mounting Hardware

    Chapter 2 Unpacking and Installing the Switch Slide-Rail Mounting Hardware The slide-rail mounting hardware includes the following: • Slide rails for the left side (1 pair) • Slide rails for the right side (1 pair) • Front-mounting bracket (1) • Rear-mounting bracket (1) •...
  • Page 31 Before tightening the wing nuts, ensure the end-to-end measurement of the slide rails of the mounting brackets matches the rail-to-rail measurement of the equipment rack. ARX-2500 Hardware Installation Guide 2 - 9...
  • Page 32 Chapter 2 Unpacking and Installing the Switch Ensure the three-hole side of the bracket is facing out (as shown in both of the following figures.) 7. Install the slide rails on the inside rail of the equipment rack. Insert the thumb screws provided in the top and bottom holes by screwing them through the cabinet rails and into the slide-bracket threaded inserts.

  • Page 33: Inserting The Optical Transceivers (Optional)

    If you ordered optical tranceivers, you can locate them in the Accessory Kit, packaged in thier own box. Insert them in the optical ports as identified in the following figure. Figure 2.3 ARX-2500 Optical Ports ARX-2500 Hardware Installation Guide 2 - 11...

  • Page 34: Attaching Cables And Powering On

    Chapter 2 Unpacking and Installing the Switch Attaching Cables and Powering On This section contains the procedure for attaching cables and powering on. Important Before powering on, make sure all AC outlets to the switch are properly grounded. Never assume that power is disconnected from a circuit; always check.

  • Page 35: Cabling The Client/Server Ports

    You can attach cables to the client/server ports before or after the switch is connected to the network. F5 Networks does not supply Ethernet cables. For cable specifications and requirements, consult the ARX Hardware Reference Guide. ARX-2500 Hardware Installation Guide...
  • Page 36 Chapter 2 Unpacking and Installing the Switch 2 - 14...

  • Page 37: Connecting The Switch To The Network

    Connecting the Switch to the Network • Identifying the Management Ports • Connecting the Console Port • Booting the Switch • Connecting the Out-of-Band Management Port...

  • Page 39: Identifying The Management Ports

    Identifying the Management Ports Identifying the Management Ports The ARX-2500 provides the following management ports: • Console. Serial console interface for connecting a console terminal. Labeled CONSOLE on the front of the switch. • Management. 10/100/1000 Ethernet port for connecting an out-of-band (OOB) management station.

  • Page 40: Booting The Switch

    DNS name server IP address (needed to access the license activation server). Note The alarm LEDs on the ARX-1500 and the ARX-2500 will remain red until the Switch Configuration process is complete. This is normal. For more information on the alarms and statuses for the ARX-1500 and ARX-2500, see the hardware installation guides for each platform (sections ARX-1500 Alarm and Status LEDs and ARX-2500 Alarm and Status LEDs).
  • Page 41 1. Enter the management port IP address    in the format nnn.nnn.nnn.nnn or 'none'. # 10.1.14.76 2. Enter the management port subnet mask    in the format nnn.nnn.nnn.nnn.(default=255.0.0.0) # 255.255.255.0 The switch's management port requires a gateway IP address. 3. Enter the gateway IP address for the management interface    in the format nnn.nnn.nnn.nnn or 'none'.(default=10.1.14.1) # 10.1.14.1 A name server address must be assigned so that the software license can be activated. 4. Enter the DNS name server IP address to access the license server    in the format nnn.nnn.nnn.nnn. # 192.168.90.54 A switch replacement requires additional configuration questions. 5. Are you doing a switch replacement?    in the format 'yes' or 'no'.(default=no) # no The base registration key is used to activate the software license for this system. 6. Enter the switch's base registration key    in the format xxxxxxx‐xxxxxx‐xxxxx‐xxxx‐xxxxxxx. (default=G061353‐397137‐82789‐5523‐0883750) #  <Enter> The crypto‐officer is the most privileged user in the system. 7. Enter the crypto‐officer username    in the format text (1‐28 characters). # admin 8. Enter the crypto‐officer password    in the format text (6‐28 characters). # mypassword          Confirm the crypto‐officer password # mypassword A system password is required for access to the master key. 9. Enter a system password    in the format text (12‐28 characters). # *************          Confirm the system password # ************* The master key is used to encrypt critical security parameters.                          10. Enter the master key    in the format base64‐encoded key or keyword 'generate'.(default=generate) # <Enter> The wrapping password is used to encrypt and decrypt the master key. ARX-2500 Hardware Installation Guide 3 - 5...

  • Page 42: Preparing For Switch Replacement

    Chapter 3 Connecting the Switch to the Network 14. Enter the wrapping password    in the format text (6‐28 characters). # *************          Confirm the wrapping password # ************* The system displays a configuration summary. See the following example. Configuration Summary      Management IP Address    10.1.14.76      Management IP Mask       255.255.0.0      Management Gateway       10.1.14.1      DNS IP Address           192.168.90.54     Chassis GUID             05d5a0fa‐f2fb‐11df‐8daf‐af50d57e388e      Chassis Base Reg Key     G061353‐397137‐82789‐5523‐0883750      Switch Password          #######      Switch Master Key        generate      Crypto‐officer Username  admin      Crypto‐officer Password  #######  Enter 'yes' to load the configuration or 'r' to redo the interview #  You have completed the switch startup configuration. The switch will now initialize the local database. The boot-up process continues to the Username prompt. Confirm that an administrator can log in by logging in with the Crypto-Officer username and password that you entered in the initial-boot script, as in the following example.
  • Page 43 ARX devices in the same RON and/or the switch’s redundant peer. All private subnets in the RON and/or pair are carried by the same VLAN. This private VLAN, and the separate metalog VLAN, must be reserved for ARX traffic only. ARX-2500 Hardware Installation Guide 3 - 7...
  • Page 44 UUID or it will reject all shares imported by its predecessor. Also, you must set the UUID if the switch is brought back to its factory defaults. A Manufacturing Installation by F5 personnel resets the switch and its UUID.
  • Page 45 Enter the UUID of the replaced switch when prompted by the initial-boot script. See the following example. If this is a replacement switch, the UUID MUST be entered and     it MUST match the UUID of the failed ARX.  The UUID can be found     using CLI command "show ron" on the peer switch. 8. Enter the switch's UUID    in the format  xxxxxxxx‐xxxx‐xxxx‐xxxx‐xxxxxxxxxxxx.(default=71305bb8‐cc3d‐11df‐825c ‐85aba8436d1c)  # 05d5a0fa‐f2fb‐11df‐8daf‐af50d57e388e Important No two running chassis should ever share the same UUID. Enter the UUID only in a switch-replacement scenario. ARX-2500 Hardware Installation Guide 3 - 9...

  • Page 46: Installing A Redundant Peer Or Cluster Peer

    Chapter 3 Connecting the Switch to the Network Installing a Redundant Peer or Cluster Peer If you are installing the second switch in a redundant pair (also called an ARX cluster) or if you are configuring a second ARX cluster in a Disaster Recovery (DR) configuration, you need to provide additional information to the initial-boot script because all members of the cluster share a common master key.

  • Page 47: Replacing A Redundant Peer

    If the replacement switch is running an outdated release of software, this example may not exactly match the text on your screen. F5 ARX Startup This F5 ARX switch does not currently have critical system information programmed.  The following wizard prompts you for this information.  You can connect to the switch through the out‐of‐band management interface when you finish. To restart the configuration program, enter 'r' at any prompt. The switch's management port requires an IP address and mask. 1. Enter the management port IP address    in the format nnn.nnn.nnn.nnn or 'none'. # 10.1.14.76 2. Enter the management port subnet mask    in the format nnn.nnn.nnn.nnn.(default=255.0.0.0) # 255.255.255.0 The switch's management port requires a gateway IP address. 3. Enter the gateway IP address for the management interface    in the format nnn.nnn.nnn.nnn or 'none'.(default=10.1.14.1) # <Enter> A name server address must be assigned so that the software license can be activated. ARX-2500 Hardware Installation Guide 3 - 11...
  • Page 48 Chapter 3 Connecting the Switch to the Network 4. Enter the DNS name server IP address to access the license server    in the format nnn.nnn.nnn.nnn. # 192.168.90.54 Note the questions regarding switch replacement in the following: A switch replacement requires additional configuration questions. 5. Are you doing a switch replacement?    in the format 'yes' or 'no'.(default=no) # yes The switch's internal subnet requires an IP address and mask. 6. Enter the switch's private IP address    in the format nnn.nnn.nnn.nnn.(default=169.254.52.0) # 169.254.94.0 7. Enter the switch's private subnet mask    in the format nnn.nnn.nnn.nnn.(default=255.255.255.0) # <Enter> 8. Enter the switch's UUID in the format  xxxxxxxx‐xxxx‐xxxx‐xxxx‐xxxxxxxxxxxx.(default=6df0854c‐6af4‐11d8‐954a‐f844c83bc5f3)  # 05d5a0fa‐f2fb‐11df‐8daf‐af50d57e388e The base registration key is used to activate the software license for this system. 9. Enter the switch's base registration key    in the format xxxxxxx‐xxxxxx‐xxxxx‐xxxx‐xxxxxxx.(default=G061353‐397137‐82789‐5523‐0883750)  # <Enter> The crypto‐officer is the most privileged user in the system. 10. Enter the crypto‐officer username    in the format text (1‐28 characters). # admin 11. Enter the crypto‐officer password    in the format text (6‐28 characters). # mypassword    Confirm the crypto‐officer password # mypassword A system password is required for access to the master key.
  • Page 49 For example, the following CLI session shows the running software on an ARX named stoweA. The version number is highlighted in bold. stoweA# show version   Copyright (c) 2002‐2012 by F5 Networks, Inc. All rights reserved. Running Release test3.rel :  Version 6.02.000.14353 (Apr  6 2012 20:12:43) [nbuilds] Armed Release test3.rel :  Version 6.02.000.14353 (Apr  6 2012 20:12:43) [nbuilds] Backup Release test2.rel :  Version 6.01.001.14115 (Apr  9 2012 17:52:54) [bmeifert] System Configuration:  Version 602000.33   Slot  Admin     ModuleType     ModuleState        FW Upgrade   ‐‐‐‐  ‐‐‐‐‐‐‐   ‐‐‐‐‐‐‐‐‐‐‐‐   ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐   ‐‐‐‐‐‐‐‐‐‐     1   Enabled   ACM            Online             Disabled ARX-2500 Hardware Installation Guide 3 - 13...
  • Page 50 Chapter 3 Connecting the Switch to the Network  Resource         State                             Forwarding  ‐‐‐‐‐‐‐‐         ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐   ‐‐‐‐‐‐‐‐‐‐   Switch           Up                               Disabled Check the version at the replacement ARX. In this example, the software version (6.02.00) is not outdated: SWITCH> show version   Copyright (c) 2002‐2009 by F5 Networks, Inc. All rights reserved. Running Release test1.rel :  Version 6.02.000.11927 (Nov 23 2009 21:57:26) [nbuilds] Armed Release test1.rel :  Version 6.02.000.11927 (Nov 23 2009 21:57:26) [nbuilds] Backup Release test3.rel :  Version 6.02.000.11927 (Nov 23 2009 21:57:26) [nbuilds] System Configuration:  Version 501000.36 Connecting to the Client/Server Network...
  • Page 51 Arm the system with the new release and then reload the ARX to activate. SWITCH# boot system test5.rel % INFO: The boot system command may take up to 5 minutes to complete. SWITCH# show releases   releases   R   test1.rel               Dec  8 00:14  800 MB       test2.rel               Dec  7 00:06  800 MB   A B test5.rel               Sep 10 00:09  1.0 GB SWITCH# reload Reload the entire chassis? [yes/no/diags] yes System is resetting. After the reboot, log in and confirm that you are running the new release. User Access Authentication Username: admin Password: mypassword stoweA# show version ARX-2500 Hardware Installation Guide 3 - 15...

  • Page 52: Activating The License

    ‐‐‐‐  ‐‐‐‐‐‐‐   ‐‐‐‐‐‐‐‐‐‐‐‐   ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐   ‐‐‐‐‐‐‐‐‐‐ 1   Enabled   ACM            Online             Disabled Activating the License To successfully join a redundant pair, activate the ARX license. To prepare for licensing, identify a DNS server that can resolve the name of the F5 license server (activate.f5.com). For example: SWITCH> enable SWITCH# config SWITCH(cfg)# ip name‐server 192.168.90.18 SWITCH(cfg)# end...
  • Page 53 SWITCH> enable SWITCH# copy ftp://juser:jpasswd@ftp.wwmed.com/a2kconfig scripts running SWITCH# show scripts   scripts       running  Apr 12 17:45  2.1k SWITCH# run scripts running The running‐config script set up all local parameters, such as the hostname and the network  settings: SWITCH#; ARX‐2000 SWITCH#; Version 6.02.000.14293 (Dec  2 2011 20:04:01) [nbuilds] SWITCH#; Database version: 602000.21 SWITCH#; Generated running‐config Thu Dec  8 03:10:49 2011 SWITCH#; System UUID 876616f6‐79ac‐11d8‐946f‐958fcb4e6e35 SWITCH#; ip private vlan internal 1008 metalog 1009 subnet 169.254.100.0 255.255.255.0 SWITCH#; SWITCH#terminal character‐set unicode‐utf‐8 SWITCH#;================================= vlan ================================== SWITCH#config SWITCH#  vlan 74 SWITCH#    description "personnel dept." SWITCH#    members 1/5 to 1/6 SWITCH#... SWITCH#;================================ system ================================= SWITCH#config SWITCH(cfg)#  clock timezone America New_York SWITCH(cfg)#  hostname stoweA stoweA(cfg)# ip domain‐list wwmed.com stoweA(cfg)# ... ARX-2500 Hardware Installation Guide 3 - 17...

  • Page 54: Connecting The Out-Of-Band Management Port

    Restoring to an ARX-2500 Pair There is a special consideration you must take into account when restoring a configuration to an ARX-2500 pair, if the configuration changes the setting of the resource-profile command. After you replay the running-config, you must reboot the switch in order for the resource-profile legacy setting to take effect.

  • Page 55: Maintenance

    Maintenance • POST Diagnostics...

  • Page 57: Post Diagnostics

    System Configuration:  Version 602000.33 See the following example output for the show chassis command. stoweA> show chassis  Identification:  Hostname                             UUID  ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐  stowe                                05d5a0fa‐f2fb‐11df‐8daf‐af50d57e388e  Chassis:  Chassis Type  Model Number                          Serial Number  ‐‐‐‐‐‐‐‐‐‐‐‐  ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐  ‐‐‐‐‐‐‐‐‐‐‐‐‐  ARX‐2500      ARX2500HE‐F5                          XX‐ABCD‐0495  Private Subnet:  Subnet             Subnet Mask  ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐   ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐  169.254.88.0       255.255.255.0  Chassis Environment:  Base MAC Address    Power            Fan(setting)    Temperature  ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐   ‐‐‐‐‐‐‐‐‐‐‐‐‐‐   ‐‐‐‐‐‐‐‐‐‐‐‐‐   ‐‐‐‐‐‐‐‐‐‐‐‐‐  00:0a:49:75:39:00   Online Partial   Online (high)   Normal 28 C  Power Details:  Supply   State  ‐‐‐‐‐‐   ‐‐‐‐‐    A      Online    B      Absent ARX-2500 Hardware Installation Guide 4 - 3...
  • Page 58 Chapter 4 Maintenance  Logical Disk Details:  Disk    Status                 Verification Mode  Verification Rate  ‐‐‐‐‐‐  ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐  ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐  ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐  1       Optimal                Automatic          10 %  Disk Details:  Disk       Size          State               Transfer Rate   Model  ‐‐‐‐‐‐‐‐   ‐‐‐‐‐‐‐‐‐‐‐   ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐   ‐‐‐‐‐‐‐‐‐‐‐‐‐   ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐   Bay 1     136.91G       Online              3.0Gb/sec       HUC103014CSS600   Bay 2     136.91G       Online              3.0Gb/sec       HUC103014CSS600  RAID Controller Details:  Rebuild Rate  Max Transfer Rate  Firmware       RAID Alarm  ‐‐‐‐‐‐‐‐‐‐‐‐  ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐  ‐‐‐‐‐‐‐‐‐‐‐‐‐  ‐‐‐‐‐‐‐‐‐‐‐‐  90 %          3.0Gb/sec          5.2‐0[17899]   Enabled  Module:  Slot Ports Procs Card      Xeon               ECC State  ‐‐‐‐ ‐‐‐‐‐ ‐‐‐‐‐ ‐‐‐‐‐‐‐‐  ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐  ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐   1   6     1     ACM       2.6 GHz 16128 MB   Good                                                      Slot MAC Address                   BIOS Version  ‐‐‐‐ ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐  ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐   1   000A49753900 to 000A497539FF  8.15:1.3:2.0  Port Media Details:  Slot/Port   Type                 Vendor            Status  ‐‐‐‐‐‐‐‐‐   ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐      ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐   ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐   2/1        N/A                  N/A               Unknown   2/2        N/A                  N/A               Unknown  Disk Usage:  Name                              Total MB    Used MB     Free MB     Used%  ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐  ‐‐‐‐‐‐‐‐‐‐  ‐‐‐‐‐‐‐‐‐‐  ‐‐‐‐‐‐‐‐‐‐  ‐‐‐‐‐  System                            3173        1691        1320        57%  Releases                          6345        3327        2695        56%  Logs                              52838       152         50001       1%  Cores; DiagInfo; Lists            21133       60          19999       1%  Scripts                           3172        48          2962        2%  Reports                           8458        33          7994        1%  Temperature Details:  Slot  Module   Sensor 1 (C)   Fan Status  ‐‐‐‐  ‐‐‐‐‐‐   ‐‐‐‐‐‐‐‐‐‐‐‐   ‐‐‐‐‐‐‐‐‐‐‐‐    1   ACM      28             Online (high)    2   ACM      28             Online (high)  Metalog Usage:...

  • Page 59: Replacing Optical Transceivers Or Chassis

    Replacing Optical Transceivers or Chassis • Before You Begin • Replacing Optical Transceivers • Replacing the Chassis...

  • Page 61: Before You Begin

    Note When returning chassis to F5 Networks, you must include the chassis serial number. In some cases, you also need to include the base MAC address. From the CLI, enter the show chassis command to obtain the serial number.

  • Page 62: Replacing The Chassis

    The ARX-2500 contains two optical ports (located on the front of the chassis). You are notified of the failure of an optical transceiver through an SNMP trap.
  • Page 63 17. Reboot the switch. 18. Replace the running configuration. 19. Unless the switch is running standalone, ensure that it pairs with the active peer. To confirm, issue the show redundancy command. ARX-2500 Hardware Installation Guide A - 5...
  • Page 64 Appendix A Replacing Optical Transceivers or Chassis A - 6...
