Lipman Nurit 3010 User Manual

Pos/edc terminal
Hide thumbs Also See for Nurit 3010:
Table of Contents

Advertisement

Quick Links

Download this manual
Exhibit 9
Nurit 3010 ARDIS
DataTAC
Point of Sale Device
Lipman USA
FCC ID: O2SNURIT3010A
User's Manual
August 2000
APREL Project No.: LPMB-NURIT 3010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Nurit 3010 and is the answer not in the manual?

Questions and answers

Related Manuals for Lipman Nurit 3010

Summary of Contents for Lipman Nurit 3010

  • Page 1 Exhibit 9 Nurit 3010 ARDIS DataTAC Point of Sale Device Lipman USA FCC ID: O2SNURIT3010A User’s Manual August 2000 APREL Project No.: LPMB-NURIT 3010...
  • Page 2 082-32-001 NURIT 3010 POS/EDC TERMINAL USER MANUAL NURIT /3010  User Manual...
  • Page 3 The information contained in this publication is for informational purposes only and subject to change without notice. It does not represent a commitment on the part of Lipman USA Inc. or Lipman Electronic Engineering Ltd. No part of this publication may be reproduced,...
  • Page 4 082-32-001 WARNING Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC compliance statement This equipment has been tested to be found to comply with the limits for class A digital device, pursuant to Part 15 of the FCC Rules.
  • Page 5 If this device (equipment) is used in a residential area, it may cause unacceptable interference to radio and TV reception requiring the operator to take whatever steps necessary to correct the interference. • Repair work on this device (equipment) must by done by Lipman USA, Inc, or an authorized repair station.
  • Page 6 LIPMAN USA - NURIT /3010 Limited Warranty Lipman USA Inc. will repair this product with new or rebuilt parts, free of charge, in the U.S.A. for one (1) year from the date of original purchase in the event of a defect in materials or workmanship.
  • Page 7 If you ship the product Carefully pack and send the package prepaid, adequately insured and preferably in the original carton. Attach a postage-paid letter to the outside of the package detailing the complaint. PLEASE NOTE: SHIPMENT MUST BE SENT TO AN AUTHORIZED DEALER OR SERVICE CENTER ONLY.
  • Page 8 082-32-001 USER SAFETY INSTRUCTIONS When using this NURIT, basic safety precautions as below should always be followed to reduce the risk of fire, electric shock, or personal injury. The following safety instructions are based on those provided by Underwriters Laboratories Inc. U.S.A. 1.
  • Page 9 082-32-001 but take it to a qualified serviceperson when some service or repair work is required. Opening or removing covers may expose you to dangerous voltages or other risks. Incorrect re-assembly can cause electric shock. 12. Unplug this unit from the wall outlet and refer servicing to qualified service personnel under the following conditions: •...
  • Page 10 082-32-001 FOREWORD Thank you for purchasing a NURIT POS/EDC terminal. You now own one of the most advanced electronic point-of-sale (POS) devices manufactured today. This manual explains how to use the NURIT terminal. To fully utilize the features of your terminal, take some time to familiarize yourself with this manual and the terminal itself.
  • Page 11 082-32-001 NOTE This publication could include technical or typo- graphical errors. Changes periodically made to our publications; these changes will be incorporated in future editions. NURIT /3010  User Manual...

  • Page 12: Table Of Contents

    082-32-001 CONTENTS CHAPTER 1 OPERATION1 Report Setup OPERATIONAL MERCHANT PARAMS..20 OVERVIEW ......1 Authorizations (Transaction Setting Time and Date.....1 Types)........20 Performing a Sale .....1 Authorizations (Card Types)22 Credit Return ......2 Security Levels .......23 Verify .........2 Edit Header/Trailer....29 Forced Transaction....3 Set Cash EDC......30 Voids..........3 Surcharge Rate .......31 Void a Credit Sale ....3...
  • Page 13 082-32-001 Working Mode (Restaurant power ........67 Application)......55 “NO LINE” appears on the Test Mode .......59 display ........67 Pre-dial Call......56 Printer does not function PIN Pad Function properly ........68 PIN Pad Config Card reader not working..68 DOWNLOAD Possible PIN pad error..68 PARAMETERS......61 Receipt prints “CANCELED”68 COMMUNICATION ....62...

  • Page 14: Overview

    082-32-001 C H A P T E R OPERATION OPERATIONAL OVERVIEW This chapter explains the various instructions required in operating the NURIT /3010 POS/EDC Terminal. The terminal keyboard allows for selecting specific transaction types, entering of data, and performing various functions. In this manual, transactions, operations, and specific functions available with the NURIT /3010 is explained.

  • Page 15: Credit Return

    082-32-001 Credit Return A refund to a customer’s credit card account can be done if the original sale is from a different batch (if the sale and refund are in the same batch refer to page 3 - Voids ), otherwise, a refund is done as follows: 1.

  • Page 16: Forced Transaction

    082-32-001 Forced Transaction When voice authorization has been obtained on a customer’s credit card, a Forced Sale should be done to process the transaction. CREDIT..SALE, ACCOUNT ? , press <FORCED>. The terminal will display: CREDIT..FORCED, ACCOUNT ? Swipe the card, or key in the account number and expiration date manually.

  • Page 17: Void A Return

    082-32-001 Void a Return A Void Refund is done, if the original return is from the same batch. If the refund is from a different batch, you will not be able to perform a void return, (check with your processing bank for instructions on handling the transaction), otherwise, a void refund is done as follows: 1.

  • Page 18: Debit Transactions

    082-32-001 Follow the steps in Chapter 2, on page 43 to void by transaction number. DEBIT TRANSACTIONS A debit transaction can only be done using a bank issued debit card, and there must be a PIN pad connected to the terminal. Debit Sale Follow these steps to process a debit card: 1.

  • Page 19: Debit Return

    082-32-001 Debit Return Please keep in mind, that this transaction is host specific. Therefore, this transaction may not be available. CREDIT..SALE, ACCOUNT ? , press <ENTER>, until your terminal displays: DEBIT...SALE, ACCOUNT ? Press <RETURN>. Terminal will display: DEBIT….RETURN, ACCOUNT. Swipe the debit card (debit account numbers can NOT be keyed in manually).

  • Page 20: Check Verify

    082-32-001 CHECK TRANSACTIONS To perform a check transaction, follow these steps: 1. At , press <ENTER> until the CREDIT..SALE, ACCOUNT ? terminal displays: CHECK... VERIFY, AMOUNT ? 2. Enter the amount of the check, and press <ENTER>. 3. Enter the MICR number (this number is usually the account number on the bottom of the check), or feed check through a check reader.

  • Page 21: Cash Transactions

    082-32-001 not want to receive cash back, press <ENTER> to bypass this option. The terminal will display: PLEASE ENTER PIN ON PIN and PIN pad will beep to prompt the customer to enter PAD, the PIN number on the pad. The terminal will dial, process, and print out a receipt.

  • Page 22: Phone Card Activation

    082-32-001 Phone Card Activation To Activate a Phone Card: press <ENTER> until CREDIT..SALE, ACCOUNT ?, your terminal displays: PHONE CARD, SWIPE CARD? Swipe Phone Card to be activated. Key in amount of activation and press <ENTER>. Key in Clerk Number and press <ENTER>. Confirm correct amount for activation and press <ENTER>.

  • Page 23: Auto Close

    082-32-001 4. Press the correct numbered key. Terminal will dial out to the host processor. If batch was approved, a batch response will print, and a current report will be generated. Auto Close If a terminal is programmed for auto batch, the host will close the batch automatically each night, at a specific time, and print a batch report.

  • Page 24: Chapter 2 Menu

    082-32-001 C H A P T E R MENU The NURIT /3010 has a menu with several options that control some of the terminal’s basic operational functions, and can be manually changed (refer to Appendix B). The menu is divided into main menus and sub-menus that can be accessed by pressing the <MENU/ESC>...

  • Page 25: Current Report

    082-32-001 You will notice that the first menu is already highlighted. The <FORCED> and <RETURN> keys can be used to scroll up and down the menu. To enter the Report menu, press <ENTER> to make selection. Terminal will display: REPORTS: Default Report Current Report History Report...
  • Page 26 082-32-001 The terminal will display four options; use the <FORCED> key to scroll through the options, or press the corresponding number: - will print transaction number, Condensed Report card type, transaction type, last four digits of the account number, and amount of sale. Short Report - will print type of transaction, and amount of sale.

  • Page 27: History Report

    082-32-001 Terminal will display: CHOOSE TRAN. TYPE: SALE FORCED Use the <FORCED> key to highlight the selection and press <ENTER>. There will be eight different transaction types. 10. Terminal will display: Set Cur. Defaults, ENTER=Yes, ESC=No . This will customize the Default Report. History Report This report will allow you to print previous batch totals from the last 30 days.
  • Page 28 082-32-001 Type in the desired date, and terminal will display: HISTORY REPORTS: Total Per Batch Use the <FORCED> key to highlight desired selection, and press <ENTER>. Terminal will display: CHOOSE EDC TYPE: CREDIT DEBIT Use the <FORCED> key to highlight desired selection, and press <ENTER>.

  • Page 29: Display Transaction

    082-32-001 Display Transaction This option will allow you to view daily transactions on the terminal display. You can view these transactions several ways. To do so, follow these steps: MENU SCREEN: Reports Merch. Params Merch. Options Highlight Reports, and press <ENTER>. Terminal will display: REPORTS: Default Report...

  • Page 30: Last Receipt

    082-32-001 Terminal will display the following: #001 1.00 549974444444444400 Terminal displays the transaction number, transaction type, transaction amount, and card number. Use the <FORCED> key to scroll through transactions. Last Receipt This option will print a copy of the last transaction. If a report was the last printed item, this option cannot be used to print a copy of last transaction.
  • Page 31 082-32-001 Terminal will display: REPORTS: Default Report Current Report History Report Display Transaction Using the <FORCED> key, scroll down to number PERFORMANCE and press <ENTER>. Terminal will display: CHOOSE EDC TYPE: CREDIT DEBIT Highlight a selection by using the <FORCED> key and press <ENTER>.

  • Page 32: Report Setup

    082-32-001 Report Setup This menu give the option of having Visa and MasterCard print together (Default) or separately. MENU SCREEN: Reports Merch. Params Merch. Options Host Params Highlight 1. Reports and press <ENTER> Terminal will display: REPORTS: Default Report Current Report History Report Display Transaction Using the <FORCED>...

  • Page 33: Merchant Params

    082-32-001 MERCHANT PARAMS This menu contains nine different functions that can be changed manually, if necessary. The first function available is Authorizations, which allows specific card types, and transaction types to be enabled and disabled. Authorizations (Transaction Types) This allows transaction types, such as Sales, Returns, Voids, etc. to be turned off, or on.
  • Page 34 082-32-001 Once password is entered, terminal will display: CHOOSE EDC TYPE: CREDIT DEBIT Use the <FORCED> to highlight selection and press <ENTER>. Terminal will display: CREDIT FORCED (EN), (DIS), or (MGR) VERIFY (EN), (DIS), or (MGR) RETURN (EN), (DIS), or (MGR) Use the <FORCED>...

  • Page 35: Authorizations (Card Types)22

    082-32-001 Authorizations (Card Types) This allows card types, such as Visa, MasterCard, and Discover card to be disabled: CREDIT..SALE, ACCOUNT ?, press <MENU/ESC>. Terminal will display: MENU SCREEN: Reports Merch. Params Merch. Options Press <2>. Terminal will display: MERCHANT PARAMS: Authorizations Security Level Edit Header...

  • Page 36: Security Levels

    082-32-001 Press <ENTER> to make selection, and terminal will display: VISA+ Disabled (+) - credit card type is always enabled (-) – credit card type is disabled, and Always Enabled can not be processed Use the <FORCED> key to scroll to the option needed, and press <ENTER>...
  • Page 37 082-32-001 Press <2>. Terminal will display: MERCHANT PARAMS: Authorizations Security Level Edit Header Use the <FORCED> key to highlight number 2. SECURITY LEVEL and press <ENTER>. Press <ENTER>. Terminal will display: SECURITY SWITCH: Menu- disables or enables access to the Menu disables or enables access to process a batch.
  • Page 38 082-32-001 To set a security level for BATCHING: CREDIT..SALE, ACCOUNT ?, press <MENU/ESC>. Terminal will display: MENU SCREEN: Reports Merch. Params Merch. Options Press <2>. Terminal will display: MERCHANT PARAMS: Authorizations Security Level Edit Header Use the <FORCED> key to highlight number 2.
  • Page 39 082-32-001 To set a security level for SECURE CARD: press <MENU/ESC>. CREDIT..SALE, ACCOUNT ?, Terminal will display: MENU SCREEN: Reports Merch. Params Merch. Options Press <2>. Terminal will display: MERCHANT PARAMS: Authorizations Security Level Edit Header Use the <FORCED> key to highlight number 2.
  • Page 40 082-32-001 Press <MENU/ESC> three times return CREDIT…SALE ACCOUNT ? To set a security level for the CARD MAN. ENTRY: CREDIT..SALE, ACCOUNT ?, press <MENU/ESC>. Terminal will display: MENU SCREEN: Reports Merch. Params Merch. Options Press <2>. Terminal will display: MERCHANT PARAMS: Authorizations Security Level Edit Header...
  • Page 41 082-32-001 Use the <FORCED> key to highlight an option and press <ENTER> to make selection. will allow Always Enabled manual entries, and will prompt for a Manager Only manager card, or a password. Press <MENU/ESC> three times return CREDIT…SALE ACCOUNT ? To set a security level for the PRINT ACCOUNT: CREDIT..SALE, ACCOUNT ?, press <MENU/ESC>.

  • Page 42: Edit Header/Trailer

    082-32-001 Terminal will display: PRINT ACCOUNT: Always full Full on report Always short Use the <FORCED> key to highlight an option and press <ENTER> to make selection. Always Full will print full account number on receipt and report, Full on Report will print last 4 digits on receipt and full account number on report, and Always Short will print last 4 digits on both receipt and reports.

  • Page 43: Set Cash Edc

    082-32-001 Terminal will display, HEADER (TRAILER) TEXT 1N , and the first line of your current receipt header will appear. The N stands for Normal print. If BOLD print is desired, press the <BATCH> key, and N will switch to a B. Please keep in mind that bold print allows 12 characters to a line, and normal print allows 23 characters.

  • Page 44: Surcharge Rate

    082-32-001 Terminal will display: Manager Card, or ESC for Password. Press <MENU/ESC>. Terminal will display: ENTER PASSWORD. If password is unknown, call customer service. Once password is entered, terminal will display: CASH EDC SET: WITH CASH WITHOUT CASH Highlight an options and press <ENTER> to make your selection.

  • Page 45: Set Batch Time

    082-32-001 Press <MENU/ESC >. Terminal will display: ENTER . Type in password, and press <ENTER>. PASSWORD Terminal will display: SURCHARGE: $ 0.00 NEW RATE: 0.00 Enter amount of surcharge rate and press <ENTER>. Terminal will display: On CashBack Only ENTER=Yes, ESC=No Make the proper selection and then press <MENU/ESC>...

  • Page 46: Server Id/Invoice

    082-32-001 Press <MENU/ESC>. Terminal will display:ENTER PASSWORD. If password is unknown, call customer service. Once password is entered, terminal will display: BATCH TIME: HH:MM. Enter the desired time (military time), and press <ENTER>, and then press <MENU/ESC> twice to exit menu. Server ID/Invoice This will allow the terminal to prompt for a server or invoice number, or both.

  • Page 47: Site Id

    082-32-001 Terminal will then display: INVOICE MODE: AUTO Use the <FORCED> key to scroll to highlight an option and press <ENTER> to make selection. (In the Restaurant application, there are two more options after Invoice; Table #’s and Guest #’s. In the Bar application, there is Tab open.

  • Page 48: No Paper Mode

    082-32-001 Terminal will display MENU SCREEN: Reports Merch. Params Merch. Options Press <3>. Terminal will display: MERCH. OPTIONS: Paper Type No-Paper Mode Buzzer Set Press <ENTER>. Terminal will display: PAPER TYPE: Single Ply Double Ply Customized Scroll through options, using the <FORCED> key, and press <ENTER>...

  • Page 49: Buzzer Set

    082-32-001 Press <3>. Terminal will display: MERCH. OPTIONS : Paper Type No-Paper Mode Buzzer Set Operation Mode Use the <FORCED> key to scroll to 2. No-Paper Mode press <ENTER>. Terminal will display: Manager Card, or ESC for Password. Press <MENU/ESC>. Terminal will display: ENTER PASSWORD If password is unknown, call customer...

  • Page 50: Operation Mode

    082-32-001 Press <3>. Terminal will display: MERCH. OPTIONS : Paper Type No-Paper Mode Buzzer Set Use the <FORCED> key to scroll to 3. BUZZER SET press <ENTER>. Terminal will display: BUZZER SET: Use the <FORCED> key to highlight option and press <ENTER>...
  • Page 51 082-32-001 Use the <FORCED> key to scroll to 4. OPERATION MODE and press <ENTER>. Terminal will display: OPERATION MODE Demo Mode Normal Mode Use the <FORCED> key to highlight an option and press <ENTER>. Terminal will display: Sure? Enter=Yes, ESC=No Press <ENTER>, and then <MENU/ESC>...

  • Page 52: Prints Disclaimer

    082-32-001 Terminal will display: PRT DSCLMR MODE OFF- battery saver off Radio Only – will shut off only the radio after a specific amount of time is set in terminal Radio+Auto off – will shut off radio and terminal after a specific amount of time set in terminal Auto Off Only –...

  • Page 53: Menu Type

    082-32-001 Terminal will display: PRT DSCLMR MODE Use the <FORCED> key to highlight an option, and press <ENTER>. Then press <MENU/ESC> twice to exit menu. Menu Type The menu in the terminal can be set to scroll automatically, or manually. Follow these steps: , press <MENU/ESC>.

  • Page 54: Set Halo

    082-32-001 Set Halo This option sets a limit that the cashier should not exceed for sales, refunds, and cash back. CREDIT..SALE, ACCOUNT ? , press <MENU/ESC>. Terminal will display: MENU SCREEN: Reports Merch. Params Merch. Options Press <3>. Terminal will display: MERCH.

  • Page 55: Print Setup

    082-32-001 Terminal will display: HALO FOR RETURN: Use the <FORCED> key to select an option and press <ENTER>. Follow the same steps above for Return Halo and Cash Back Halo. Print Setup This option will print a setup report. It will show all the options that have been turned on for the terminal.

  • Page 56: Host Parameters

    082-32-001 HOST PARAMETERS This menu allows you to change host parameters, such as merchant numbers, terminal IDs, and authorization numbers. Each host has different individual parameters, and should only be changed, if advised by the processing bank, or NURIT technical support. There are three sub-menus in Host Parameters.

  • Page 57: Host Phones

    082-32-001 Terminal will display: HOST NAME: (Please keep in mind, this display will 1. MERCHANT ID differ according to each host). Use the <FORCED> key to scroll through the options, and press <ENTER> to enter new information. When changes are completed, press <ENTER> and then <MENU/ESC>.
  • Page 58 082-32-001 Terminal will display, ENTER PASSWORD Type in password (if password is not known, call customer service), and press <ENTER>. Terminal will display: PHONE MENU: Host Name CR Host Name DB Host Name CHK Use the <FORCED> key to highlight an option. Press <ENTER>...

  • Page 59: Print Edc Setup

    082-32-001 Print EDC Setup This report prints host information such as merchant numbers, phone numbers, baud rates, and capture type. To print this report: CREDIT..SALE, ACCOUNT press <MENU/ESC>. Terminal will display: MENU SCREEN: Reports Merch. Params Merch. Options Press <4>. Terminal will display: HOST PARAMS: Hosts Params Hosts Phone...

  • Page 60: System Options

    082-32-001 Press <4>. Terminal will display: HOST PARAMS: Hosts Params Hosts Phone Prnt EDC Setup Use the <FORCED> key to scroll to 4. Protocol Version and press <ENTER> to view. Press <ENTER> and then <MENU/ESC> three times to exit menu. SYSTEM OPTIONS This menu consists of ten different functions that can be changed manually, however, only a customer service representative should...

  • Page 61: Edit Pin Key

    082-32-001 Press <ENTER>. Terminal will display: Setting Date: MM/DD/YY Type in the month, date, and year. Terminal will automatically display: Setting Time: HH:MM:00 Enter the correct time (military time). Terminal will display the date and time entered. Press <MENU/ESC> three times to exit menu. Edit PIN key This option allows the changing or viewing of the working key for the PIN pad (access to this menu is not available without a PIN pad).

  • Page 62: Select Master Key

    082-32-001 Press <MENU/ESC>. Terminal will display: ENTER . Type in password, and press <ENTER>. PASSWORD Terminal will dipslay: EDIT WORKING KEY 0000000000000000000 Type in the correct working key, and press <ENTER>. Then press <MENU/ESC> twice to exit menu. Select Master Key This changes the Master key location (access to this menu is not available without a PIN pad).

  • Page 63: Set Batch Number

    082-32-001 Terminal will display: MASTER KEY LOCATION Type in correct master key location (0-9), and press <ENTER>. Then press <MENU/ESC> twice to exit menu. Set Batch Number This allows the batch number to be changed, if needed. This is also a field that should only be changed when instructed by customer service.

  • Page 64: Edit Database

    082-32-001 Once password is entered, terminal will display: CHOOSE HOST: Host Name CR Host Name DB Host Name CHK Use the <FORCED> key to the host needed and press <ENTER> to make selection. Terminal will display: New Batch No: Enter new batch number and press <ENTER>. Then press <MENU/ESC>...
  • Page 65 082-32-001 Terminal will display: EDIT DATABASE: Void Transact. Clear Database Once password is entered, terminal will display: CHOOSE EDC TYPE CREDIT DEBIT Press <ENTER>. Terminal will display: Manager Card or ESC for Password. Press <MENU/ESC>. Terminal will display: ENTER PASSWORD .
  • Page 66 082-32-001 To Clear Database: , press <MENU/ESC>. CREDIT..SALE, ACCOUNT ? Terminal will display: MENU SCREEN: Reports Merch. Params Merch. Options Press <5>. Terminal will display: SYSTEM OPTIONS : Set Time/Date Edit PIN Key Sel. Mstr Key Use the <FORCED> key to scroll to 5.

  • Page 67: Working Mode (Retail Application)

    082-32-001 Press <ENTER> and terminal will print message that database has been cleared. Working Mode (Retail Application) This option places terminal in AVS mode. AVS (Address Verification) will prompt for a zip code, and street address. There are three options for AVS: •...

  • Page 68: Working Mode (Restaurant Application)

    082-32-001 Press <MENU/ESC> three times to exit menu. Working Mode (Restaurant Application) This option offers different tip options. There are as follows: • IN TIP MENU – terminal will print a tip line on the receipt • IN TRANSACTION - terminal will prompt for tip amount during the transaction.

  • Page 69: Pre-Dial Call

    082-32-001 If option 3. Print Percent is selected, terminal will display, Enter percentage amount, and press Percentage of Sum <ENTER>. Press <MENU/ESC> three times to exit menu. Pre-dial Call Terminal can be programmed to start dialing once the credit card is swiped.

  • Page 70: Pin Pad Function

    082-32-001 Once password is entered, terminal will display: PREDIAL CALL: Use the <FORCED> key to highlight an option and press <ENTER> to make selection, and then press <MENU/ESC> twice to exit menu. PIN Pad Function (Only for NURITs with internal PIN Pad) This menu gives option to encrypt terminal manually for the internal PIN Pad.

  • Page 71: Pin Pad Config

    082-32-001 PIN Pad Configuration (Only for NURITs with internal PIN Pad) Terminal can be programmed for internal PIN Pad, or an external PIN Pad. To change from internal to external: CREDIT..SALE, ACCOUNT ? , press <MENU/ESC>. Terminal will display: MENU SCREEN: Reports Merch.

  • Page 72: Test Mode

    082-32-001 Test Mode Only NURIT programmers use this menu for testing purposes. RADIO TEST (Relevant to NURIT 2070, 2090, and ) This menu is applicable to the NURIT 2070 and 2090 (radio terminal). It allows viewing of the radio information. The sub-menus are as follows: Radio RSSI This shows the radio strength signal (coverage area).
  • Page 73 082-32-001 Radio Address This displays the radio’s MAN number. This is needed when the radio signal provider (Bell South Wireless 1-800-662-4839) needs to contact the radio, or look up the account. An RSSI test must first be performed before displaying the MAN# (or else MAN# = 0). To view the MAN#: At “CREDIT..SALE, ACCOUNT ?”, press <MENU/ESC>.

  • Page 74: Download Parameters

    082-32-001 Battery Test Displays battery the power. To check battery strength: At “CREDIT..SALE, ACCOUNT ?”, press <MENU/ESC>. Terminal will display: MENU SCREEN: Reports Merch. Params Merch. Options Use the <FORCED> key to scroll to and press 6. RADIO TEST <ENTER>. Terminal will display: RADIO TESTS: Radio RSSI...

  • Page 75: Communication

    082-32-001 COMMUNICATION This Main Menu has four sub-menus pertaining to communication. The sub-menus are as follows: Minimum Retries The amount of times the terminal dials for authorization or batching can be programmed through the terminal. To program the amount of retries: CREDIT..SALE, ACCOUNT ? , press <MENU/ESC>.

  • Page 76: Dial: Tone/Pulse

    082-32-001 Dial: Tone/Pulse The terminal can be set to dial at a pulse or touch tone. To change to either option: CREDIT..SALE, ACCOUNT ? , press <MENU/ESC>. Terminal will display: MENU SCREEN: Reports Merch. Params Merch. Options Use the <FORCED> to scroll to and press 8.

  • Page 77: Exchange Prefix

    082-32-001 Exchange Prefix The terminal can be programmed to dial an exchange prefix before a phone number, if needed. To add an exchange prefix: CREDIT..SALE, ACCOUNT ? , press <MENU/ESC>. Terminal will display: MENU SCREEN: Reports Merch. Params Merch. Options Use the <FORCED>...

  • Page 78: Gateway

    082-32-001 Gateway This menu is used for technical purposes only. Suffix This field is used when a suffix is needed at the end of a phone number. To enter a suffix: , press <MENU/ESC>. CREDIT..SALE, ACCOUNT ? Terminal will display: MENU SCREEN: Reports Merch.

  • Page 79: Via Line/Radio

    082-32-001 Via Line/Radio (This option is for the NURIT ) CREDIT..SALE, ACCOUNT ? , press <MENU/ESC>. Terminal will display: MENU SCREEN: Reports Merch. Params Merch. Options Use the <FORCED> to scroll to 6. VIA LINE/RADIO and press <ENTER> . Terminal will display: LINE / RADIO: Both: Line Only...

  • Page 80: Chapter 3 Basic Troubleshooting

    • If using the NURIT 3010*, try pressing <ON/STANDBY> on the keypad . • If using the NURIT 3010, allow the battery to charge 10 to 12 hours with the terminal on and AC adapter plugged into the wall (in standby mode).

  • Page 81: Printer Does Not Function Properly

    082-32-001 Printer does not function properly • Check that the paper has been fed to the printer properly (underhand). See the figure and instructions in Appendix C. The NURIT /3010 uses thermal paper only. • Check there is paper in the printer compartment. Replace if required. •...

  • Page 82: Phone Card

    082-32-001 APPENDIX A PHONE CARD The NURIT /3010 has phone card capabilities. A merchant can supply phone cards that can be reused as long as the card is valid. The phone cards work in the following manner: a customer purchases a phone card for any amount desired;...

  • Page 83: Reports For Phone Card

    082-32-001 CREDIT SALE….ACCOUNT, swipe the phone card: Press <ENTER MODE>. Terminal will display: ENTER AMOUNT ($) 0 Enter the amount that customer purchased for the phone card, anywhere from $1 to $99. It must be a rounded number, no cents will be accepted.
  • Page 84 082-32-001 Press <ENTER>. Terminal will display: REPORTS: Default Report Current Report History Report Press <2>. Terminal will display: CURRENT REPORT TYPE: Condensed Rport Short Report Journal Report Press <ENTER>. Terminal will display: CHOOSE EDC TYPE: CREDIT DEBIT Use the <FORCED> to scroll to 7.
  • Page 85 082-32-001 T h i s P a g e L e f t B l a n k I n t e n t i o n a l l y NURIT /3010  User Manual...

  • Page 86: Appendix B

    082-32-001 APPENDIX B NURIT /3010 QUICK REFERENCE MENU TABLE Press <MENU/ESC> to access the menu below. Use the <RETURN> and the <FORCED> keys to scroll through menu, and <ENTER> to select. MAIN MENU SUB-MENU FUNCTION or ACTION 1. Reports 1. Default Report Prints programmed Default Report 2.
  • Page 87 082-32-001 MAIN MENU SUB-MENU FUNCTION or ACTION 6. Print Disclaimer Prints Credit Disclaimer on Receipt 7. Menu type Sets menu to auto scroll or manual scroll 8. Set Halo Maximum limit for a transaction (for sales, refunds, and cash back) 9.
  • Page 88 7. Chk Line: ON Telephone Line Test 9. Remote 1. Start Diags Remote Diagnostic controlled by the Help Diagnostic Desk PC 2. Set Comm Prm Phone, Exchange Prefix, Via, Baud, Dial. * For Wireless POS/EDC Terminal NURIT 3010 NURIT /3010  User Manual...
  • Page 89 082-32-001 NURIT /3010  User Manual...

  • Page 90: Nurit /3010/3010 Quick Reference Menu Table73

    082-32-001 APPENDIX C INSTALLING/REMOVING PAPER ROLL Note: See illustration on the opposite page. Removing an Empty Paper Roll: Remove the paper compartment cover by grasping it on both sides and lifting it towards you and upwards. Remove the paper roll core and spindle. Discard the core but save the spindle to be used with a new paper roll.
  • Page 91 082-32-001 Lift up the paper roll and tighten up any excessive paper slack. Make sure that the paper unrolls from the bottom. Slide the spindle into the paper roll and lower the paper roll into the spindle slots on each side of the paper compartment. Replace the paper cover by first inserting the tabs on each side of the cover into their designated slots on each side of the paper cover.
  • Page 92 082-32-001 T h i s P a g e L e f t B l a n k I n t e n t i o n a l l y NURIT /3010  User Manual...
  • Page 94 INTERNATIONAL HEADQUARTERS 11 Haamal Street, Park Afek, Rosh Haayin, ISRAEL 48092 Tel: (972) 3-9029730; Fax: (972) 3-9029731 E-mail: mail@lipman.co.il USA HEADQUARTERS 50 Gordon Drive, Sysset, NY USA 11791 Tel: (1) 516-484-9898; Fax: (1) 516-484-9057 E-mail: nuritsys@lipmanusa.com 7 Ostozenka Street, 119034 Moscow, RUSSIA Tel: (7) 095-2905852;...
