Lipman NURIT 8210 Installation Manual

Handover payment terminal
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
®
NURIT 8210
Copyright
Copyright© Lipman Electronic Engineering Ltd.
All rights reserved.
The content of this publication is for informational purposes
Handover
only and is subject to change without notice. It does not
represent a commitment on the part of Lipman Electronic
Payment Terminal
Engineering Ltd.
No part of this publication may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated to any
language in any form by any means without the prior written
permission of Lipman.
Trademark Information
NURIT™, Lipman™, and Lipman Transaction Solutions™ are
trademarks of Lipman Electronic Engineering Ltd. and are used
Installation Manual
®
by Lipman subsidiaries under license. NURIT
is a registered
®
trademark in the US and Israel. Lipman Transaction Solutions
is a registered trademark in the US.
Catalog Number
DOC111EN01-C
Print Date
March, 2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NURIT 8210 and is the answer not in the manual?

Questions and answers

Related Manuals for Lipman NURIT 8210

Summary of Contents for Lipman NURIT 8210

  • Page 1 The content of this publication is for informational purposes Handover only and is subject to change without notice. It does not represent a commitment on the part of Lipman Electronic Payment Terminal Engineering Ltd. No part of this publication may be reproduced, transmitted,...

  • Page 2: Foreword

    (POS) terminals manufactured today. This manual provides basic installation instructions. To fully utilize the features of your NURIT 8210, and for general safety purposes, it is recommended that you familiarize yourself with this manual, the terminal and any peripheral equipment or accessories.

  • Page 3: Table Of Contents

    Foreword ......iii Cleaning the NURIT 8210 ..... . 43 Document Conventions .
  • Page 4 Using the Smart Card Reader ....50 Figure 6-1 NURIT 8210 - Front View ....14 Figure 6-2 NURIT 8210 - Bottom View .

  • Page 5: Product Regulatory Information

    The FCC has established rules permitting this device to be directly connected to the telephone network. Standardized jacks are used for these connections. This equipment should not Manufacturer: Lipman Electronic Engineering Ltd. be used on party or coin lines. Model: NURIT 8210 If this device is malfunctioning, it may be causing harm to the telephone network;...

  • Page 6: Eu Directives Compliance Statement

    B, déterminée par la Réglementation d’Interférence Radio du Ministère canadien des Communications. When using the NURIT 8210 or any associated device, the following basic safety precautions should always be observed to EU Directives Compliance Statement reduce the risk of fire, electric shock, or personal injury: •...

  • Page 7: Safety Precautions For Medical Devices

    If required, take the equipment to a qualified • Do not use your NURIT 8210 in an area of service representative. Opening or removing covers may potential explosive atmosphere, such as expose you to dangerous voltages or other risks.

  • Page 8: Specifications

    Output: 16 VDC at 1.5 A tampering and may affect the validity of the • The AC/DC Adapter must be approved by warranty for the device. Notify your Lipman the relevant authorities in the country distributor. where the equipment is sold.

  • Page 9: Contents Checklist

    Paper Roll Spindle Telephone Line Cable AC/DC Power Adapter • Place the NURIT 8210 on a flat table or countertop close AC Power Cable (boxed) (boxed) to the power supply, telephone connection, and any required peripheral devices. Ethernet Adapter Cable...

  • Page 10: Optional Accessories

    • Connects RJ-45 Ethernet cable (10/100/1000base-T) to the terminal Ethernet When the NURIT 8210 is used as a PIN entry device: Adapter Cable • Connects to the TEL connector on the • The customer should be able to obstruct terminal connections panel visual observation of the PIN entry with •...

  • Page 11: General Features

    NURIT 8210 NURIT 8210 6. General Features The NURIT 8210 includes the following features: Feature Description Base Unit • Base Unit with thermal printer and connectors • POS terminal with internal PIN pad Customer • Includes all customer interfaces: magnetic...

  • Page 12: Figure 6-2 Nurit 8210 - Bottom View

    NURIT 8210 NURIT 8210 4 5 6 Figure 6-3 NURIT 8210 - Connections Panel TEL External Telephone/ Figure 6-2 NURIT 8210 - Bottom View LINE Telephone Line RS-485 LAN/Ethernet LAN Connector Connector Model/Serial Number Compliance Label (model dependent) Barcode Label...

  • Page 13: Placing The Customer Interface Unit Onto The Base Unit

    Base Unit Connections Panel Cover The connections panel on the NURIT 8210 is located on the To place the Customer Interface Unit onto the Base Unit: bottom of the Base Unit, behind a plastic cover. This cover must •...

  • Page 14: Figure 8-2 Removing The Connections Panel Cover

    NURIT 8210 NURIT 8210 Figure 8-4 Closing the Connections Panel Cover Figure 8-2 Removing the Connections Panel Cover Connections panel cover locking tabs To replace the connections panel cover: Insert the hinge tabs on the edge of the cover into the hinge slots, located above the connectors.

  • Page 15: Connecting To An Ac Electrical Power Outlet

    Power Outlet It is recommended that you install a power surge arrestor at the power outlet to prevent To connect the NURIT 8210 to the AC power outlet: possible damage caused by electrical spikes or local lightning strikes. Remove the connections panel cover from the bottom of the Base Unit, as described in “Removing and Replacing the...

  • Page 16: Connecting To A Telephone Line

    Modular This is the most common type of telephone outlet used. To connect the NURIT 8210 to a telephone line: Plug the supplied telephone cord from the terminal into a Disconnect the AC/DC Power Adapter from the electrical standard modular telephone jack.

  • Page 17: Connecting An External Telephone

    12. Connecting to a LAN The NURIT 8210 can share a telephone line with a voice Some models of the NURIT 8210 can be connected to a Local telephone or fax machine. This type of connection requires Area Network (LAN) in addition to an analog telephone line.

  • Page 18: Connecting To An Rs-485 Lan

    NURIT 8210 Connecting to an RS-485 LAN 13. Connecting External Speakers or Headphones To connect the NURIT 8210 to an RS-485 LAN: Disconnect the AC/DC Power Adapter from the electrical The NURIT 8210 includes a speaker connector for external power outlet.

  • Page 19: Connecting Peripheral Devices

    NURIT 8210. Caution You can connect to up to two external peripheral devices to the NURIT 8210. Consult with your Lipman distributor for information about the peripheral devices that you can connect to your specific model.

  • Page 20: Loading Paper In The Printer

    Use of low-quality paper may damage the printer and/or cause it to malfunction. For further details regarding printer paper, contact your Lipman representative. To load a roll of thermal paper in the printer: Place the terminal on a flat, stable surface.

  • Page 21: Removing The Paper Roll From The Printer

    NURIT 8210 NURIT 8210 Removing the Paper Roll from the Printer 16. Installing Electronic Cards To remove an empty roll of thermal paper from the Depending on the particular model, up to two SAM cards and printer: an SD/MMC memory card can be installed in the Base Unit, and an additional two SAM cards in the Customer Interface Unit.

  • Page 22: Figure 16-2 Opening The Cards Compartment

    NURIT 8210 NURIT 8210 Figure 16-4 Inserting a SAM Card SAM Card Beveled Corner Figure 16-2 Opening the Cards Compartment Metal Contacts Triangular Protrusion SAM 2 Cardholder SAM 1 Cardholder Lower the SAM cardholder onto its base. Check that the corner of the SAM card is not obstructed...

  • Page 23: Installing Electronic Cards In The Base Unit

    NURIT 8210 Close the compartment cover and press down until the locking tab snaps into place. If the model of the NURIT 8210 includes a void label, apply the label over the recessed rectangle around the cover’s locking tab. Figure 16-8 Opening the Cards Compartment...

  • Page 24: Figure 16-9 Positioning The Sd/Mmc Card

    While holding down the tab with one finger, slide the If the model of the NURIT 8210 includes a void label, SD/MMC card out of its slot with another finger, over the apply the label over the compartment cover locking tab.

  • Page 25: General Care And Maintenance

    NURIT 8210 NURIT 8210 17. General Care and Maintenance The NURIT 8210 has been designed to give you long and trouble-free service with minimal operator care. Maintenance Recommendations To maintain the NURIT 8210 in proper working condition: • Keep the terminal dry and in the cleanest possible working and storage environment.

  • Page 26: Cleaning The Nurit 8210

    To ship the NURIT 8210: soft, damp, lint-free cloth. • A very mild dishwashing detergent can be used to dampen Carefully pack the NURIT 8210, preferably in the original the cloth. box. • Alcohol or alcohol-based cleansers may also be used for Attach a postage-paid letter to the outside of the package stains that are more difficult.

  • Page 27: Troubleshooting

    See Figure B-1 “Using the Smart electrician for a professional inspection. Card Reader” on page 50. 3. If possible, try to operate the NURIT 8210 with a different 2. If possible, try using a different Smart Card. Lipman supplied AC/DC Power Adapter.
  • Page 28 NURIT 8210 NURIT 8210 Operation with a peripheral device is not successful The printer continues to operate when out of paper 1. Verify that the peripheral device is properly connected to the 1. Remove the paper roll from its compartment, as described in terminal.

  • Page 29: Appendix A: Using The Magnetic Card Reader

    NURIT 8210 NURIT 8210 Appendix A: Using the Magnetic Card Appendix B: Using the Smart Card Reader Reader The EMV-compatible Smart Card reader is located at the top of To use the magnetic card reader: the Customer Interface Unit. Hold the card with the magnetic stripe facing left, and To use the Smart Card reader: positioned towards the bottom of the card.

  • Page 30: Installation Notes

    NURIT 8210 NURIT 8210 Installation Notes Contact Information Lipman Electronic Engineering Ltd. Lipman Corporate Headquarters Lipman USA Tel: +972 3 902 9730 Tel: +1 516 484 9898 Fax: +972 3 902 9731 Fax: +1 516 484 9057 info@lipman.co.il info@lipmanusa.com www.lipman.biz www.lipmanusa.com...
