- Page 1 Dual USB 2.0 Video to USB 3.0 Converter User Guide v1.1 Thank you! You have just acquired the finest and easiest to use tool for simultaneous capture of two streams of uncompressed video with audio for your computer. Easy, No Drivers, No Setup ! Versatile ! Compatible with all Apps !
- Page 2 Professional grade full-metal enclosure OVERVIEW The INOGENI SHARE2U Converter is the most easy and reliable tool for simultaneous capture of two webcam and HDMI feeds into one single USB stream with audio for your PC for recording, videoconferencing, lecture capture and streaming applications. No driver installation is necessary and it will work on all motherboards and USB 3.0 chipsets.
-
Page 3: Device Connectors
DEVICE CONNECTORS CONNECTION DIAGRAM INOGENI SHARE2U User Guide – V1.1 – January 31, 2018... -
Page 4: Specifications
2 x USB 3.0 ports for expansion purposes. The devices connected will appear to the expansion host. Audio Audio input 2-channel LPCM 48kHz audio from Line input or embedded in HDMI Audio output 2-channel LPCM 48kHz audio Line level INOGENI SHARE2U User Guide – V1.1 – January 31, 2018... - Page 5 Runs with all software compatible to DirectShow, V4L2, QuickTime and Compatibility AVFoundation. Dimensions 18.5 x 11 x 3 [W x L x H, cm] Weight Power 12V, 700mA (adapter included) UPC Code 040232355523 Origin Canada Harmonized 8517.62.000.900 Code INOGENI SHARE2U User Guide – V1.1 – January 31, 2018...
-
Page 6: Serial Communication Protocol
Picture in Picture at top left corner where Input 1 is the background <PPTL2> Picture in Picture at top left corner where Input 2 is the background <PPBR1> Picture in Picture at bottom right corner where Input 1 is the background INOGENI SHARE2U User Guide – V1.1 – January 31, 2018... - Page 7 SHARE2U device. Make sure to set the DIP SW6 in order to apply power to the remote before going further. See “DIP SWITCHES” section of this document for more details. INOGENI SHARE2U User Guide – V1.1 – January 31, 2018...
-
Page 8: Lan Interface
Picture in Picture at bottom left corner where Input 2 is the background $SAVE$ Save the current configuration onboard for future use $RSTR$ Erase the current configuration onboard and return to default values $BLK$ Black video $SHW$ Show video INOGENI SHARE2U User Guide – V1.1 – January 31, 2018... -
Page 9: Dip Switches
Frame buffer frequency is set to 50Hz. Reserved Reserved Disable 5V on terminal block. (default) Enable 5V on terminal block. This switch must be set in order to power up the connected remote. INOGENI SHARE2U User Guide – V1.1 – January 31, 2018... - Page 10 2- Connect any type of video source 3- Run your App or Download INOGENI Software Suite You can use our INOGENI Software Suite in order to preview and record your video sources. 1. You can open the INOGENI Simple Capture application.
- Page 11 4. The application will then record your video sources. The length of the recording will also be available in the application. You can also use our INOGENI Simple Viewer which only offers a single preview of a video and audio sources.
- Page 12 CRESTON MODULES You can use the Crestron modules in order to control the INOGENI SHARE2U device using the serial or the IP connections. These modules are available on our website under the section Software Update. Refer to the Help file on how to use the modules.
- Page 13 © Copyright 2018 by INOGENI INC. All Rights Reserved. INOGENI name and logo are trademarks or registered trademark of INOGENI. Use of this product is subject to the terms and conditions of the license and limited warranty in effect at the time of purchase. Product specifications can change without notice.
