8.0 PRODUCT DETAILS

8.1 Technical data

Device type name
Batteries
Battery life
Max. current consumption
Receiver category
Radio frequency
Max. transmission power
Radio range in free-field conditions
42
Contact AA
2 × LR03/Micro/AAA
≥2 years
50 mA
SRD category 2
868.3 MHz / 869.525 MHz
10 mW
up to 100 m
Duty cycle
Protection class
Ambient temperature
Humidity
Software class
Dimensions of reed contact (W × H × D)
Dimensions of magnet unit (W × H × D)
Weight of reed contact (without batteries)
Weight of magnet unit
At 868.3 MHz < 1 % per h
At 869.525 MHz < 10 % per h
IP20
5 °C to 50 °C
5 % to 80 %
Class A
17 mm × 104 mm × 25 mm
12 mm × 48.7mm × 12/18 mm
21 g
16 g
43
