Operator Manual
Z 560x / 967 669702-00
Please read the operator manual carefully and
make sure you understand the instructions
before using the machine.
Gasoline containing a maximum of 10% ethanol
(E10) is permitted for use in this machine. The
use of gasoline with more than 10% ethanol
115 92 55-26 Rev. A
(E10) will void the product warranty.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Z560 series and is the answer not in the manual?

Questions and answers

Dale
June 20, 2025

Type of oil for Jawasaki FX801V

1 comments:
Joel Chandler
July 30, 2025

@Dale , I need to load it on a trailer to get to repair shop. I don't need oil. Mower wont crank and I need to disengage hydraulics to load. what should I do?

Joel Chandler
July 30, 2025

how to disengage drive hydrolics so you can tow. Z560 - 5/16 hex head on this one

Summary of Contents for Husqvarna Z560 series

  • Page 1 English Operator Manual Z 560x / 967 669702-00 Please read the operator manual carefully and make sure you understand the instructions before using the machine. Gasoline containing a maximum of 10% ethanol (E10) is permitted for use in this machine. The use of gasoline with more than 10% ethanol 115 92 55-26 Rev.
  • Page 2 WARNING! Failure to follow cautious WARNING! Engine exhaust and certain operating practices can result in dangerous vehicle components contain or emit chemicals injury to the operator or other persons. The considered to cause cancer, birth defects, owner must understand these instructions, or other reproductive system damage.
  • Page 3: Table Of Contents

    CONTENTS INTRODUCTION..........4 OPERATION ........... 17 Driving and Transport on Public Roads ..4 Training ............17 Towing ............4 Steering ............. 17 Operating ............. 4 Operating on Hills ........18 Moving Machine By Hand ......19 SYMBOLS AND DECALS ......... 6 MAINTENANCE ..........
  • Page 4: Introduction

    Do not let children or others in or on the towed equipment. Make wide Thank you for purchasing a Husqvarna ride- turns to avoid jack-knifing. Travel slowly and leave on mower. This machine is built for superior more distance to stop.
  • Page 5: Good Service

    INTRODUCTION Good Service Husqvarna's products are sold throughout the world and only in specialized retail stores with complete service. This ensures that you as a customer receive only the best support and service. Before the product is delivered, the machine has, for example, been inspected and adjusted by your retailer.
  • Page 6: Symbols And Decals

    SYMBOLS AND DECALS IMPORTANT INFORMATION Xxxx xxxxxx xxxxx xxxx xxxxxxxxx xxxxxx xxxxxxxxx. These symbols are found on the machine and in the operator manual. Study them carefully until Used in this publication to tell the reader of a you know what they mean. risk of material damage, particularly if the reader neglects to obey the instructions in the manual.
  • Page 7: Safety

    General Operation SAFETY • Read, understand, Safety Instructions and obey all instructions on the These instructions are for your safety. Read them machine and in carefully. the manual before starting. WARNING! THIS CUTTING MACHINE CAN AMPUTATE HANDS AND FEET AND •...
  • Page 8: Personal Safety Equipment

    • Always wear approved protective glasses or a SAFETY full visor when assembling or driving. • Disengage blades when not mowing. Shut off • Always wear gloves when handling the blades. engine and wait for all parts to come to a full •...
  • Page 9: Safe Handling Of Gasoline

    General Maintenance SAFETY • Do not use the Safe Handling of Gasoline machine indoors or in spaces lacking To avoid personal injury or damage to property, correct ventilation. use care in handling gasoline. Gasoline is very The exhaust flammable and the vapors are explosive. fumes contain carbon monoxide, WARNING! The engine and the exhaust...
  • Page 10: Transport

    If a spark arrestor is used, it must be be used and directed down and out from the maintained in good working order by the operator. machine. A spark arrestor for the muffler is available through your authorized Husqvarna dealer.
  • Page 11: Rollover Protection System

    • Reduce speed when turning, crossing slopes SAFETY and on rough, slick or muddy surfaces. Stay off slopes too steep for safe operation. Rollover Protection System • Watch where you are going, especially at row The Rollover Protection System ROPS) ends, on roads and around trees.
  • Page 12: Controls

    CONTROLS belt-driven hydraulic pumps. Using the left and right steering controls, the flow is regulated and This operator manual describes the Husqvarna thereby the direction and speed. Zero Turn Rider. The rider is fitted with a four- stroke overhead valve engine.
  • Page 13: Steering Control Levers

    Park Brake CONTROLS Steering Control Levers The park brake is integrated with the steering control levers. Move the two levers out from the neutral position to engage the park brake. The machine’s speed and direction are continuously variable using the two steering To release the park brake, pull the two steering controls.
  • Page 14: Ignition Switch

    Service Meter CONTROLS Ignition Switch The service meter is located on the left hand control panel and shows the total operating time with the blades engaged. The ignition switch is used to start and stop the engine. On models equipped with headlights, turn After every 50 hours of operation, an oil can icon the key clockwise to ACCESSORY for headlight will appear and stay on for two hours, before...
  • Page 15: Fuel Shut Off Valve

    Cutting Height CONTROLS Fuel Shut Off Valve The cutting height pedals release the deck lift and set the desired deck height. Apply pressure to the lift pedal (lower) and rotate foot to also apply The fuel shut off valve is located at the right rear pressure to the release pedal (upper), unlocking of the seat.
  • Page 16: Tracking

    2. For preliminary tracking adjustment, move CONTROLS unit to an open, unobstructed area such as an empty parking lot or open field. Technical Data concerning ethanol fuel. Methanol fuel is not allowed. Do not use E85 alcohol based 3. Back the bolts out until flush with nut. fuel.
  • Page 17: Operation

    To turn to the left OPERATION While moving in a forward direction pull the left Read the Safety section and following pages, if lever back towards the neutral position while you are unfamiliar with the machine. maintaining the position of the right lever, this will slow the rotation of the left wheel and cause the Training machine to turn in that direction.
  • Page 18: Operating On Hills

    tries to leave the seat with the engine running, OPERATION without first engaging the park brake, the engine will shut off. 3. Disengage the mower blades by pressing the blade switch down. 2. Release deck height control by pushing the pedal forward to lower the deck to selected 4.
  • Page 19: Moving Machine By Hand

    • Hose the mower deck underside with water OPERATION after each use. When cleaning, the mower deck shall be raised into the transport position. Make • Try not to stop or change speed on hills. sure the mower is cooled and the engine is off. •...
  • Page 20: Maintenance

    carried out by an authorized service workshop MAINTENANCE is recommended to maintain your machine in the best possible condition and to ensure safe Maintenance Schedule operation. Following is a list of maintenance procedures Read General Maintenance in the Safety that must be performed on the machine. For section.
  • Page 21 MAINTENANCE MAINTENANCE INTERVAL LEAST DAILY IN HOURS ONCE EACH MAINTENANCE BEFORE AFTER YEAR CHECK ■ Throttle and choke cables for adjustment ● ● Mower deck for adjustment ● ● Condition of belts, belt pulleys ● ● Caster wheels (every 200 hours) ●...
  • Page 22: Battery

    Battery Removal MAINTENANCE Corrosion and dirt on the battery and terminals Battery can cause the battery to lose power. If the battery is too weak to start the engine, it 1. Lift and rotate the seat fully forward until must be recharged. supported by the seat rod.
  • Page 23: Deck Maintenance

    IMPORTANT INFORMATION Special blade have twists. bolt is heat treated. Replace with a Husqvarna 5. Adjust belt tension by turning the eyebolt nut bolt if required. Do not use lower grade until there is approximately 22.2 mm - 25.4...
  • Page 24: Adjusting The Mower Deck

    Four bolts control the height and pitch of the MAINTENANCE mower deck. Adjust the deck slightly higher in the rear. Pump Belt NOTE: To insure precision in the leveling The belts are not adjustable and need to be procedure, mower deck drive belt must be replaced if they begin to slip from wear.
  • Page 25: Deck Lift Spring

    Park Brake MAINTENANCE Deck Lift Spring WARNING! Faulty adjustment will result in reduced braking and can cause an accident. When mowing 5.1 cm or lower, it may be necessary to adjust the deck lift springs. Access Visually check that no damage is found on the the springs by tilting the seat forward.
  • Page 26: Safety System

    Anti-scalp Rollers MAINTENANCE Anti-scalp rollers keep the deck in the proper Safety System position to help prevent scalping in most terrain conditions. Do not adjust the rollers to support the The machine is equipped with a safety system deck. that prevents starting or driving under the following conditions.
  • Page 27: Lubrication

    LUBRICATION Lubrication Schedule Initial hydraulic oil and filter change at Lubricate with grease gun 12/12 Every year 100 hrs, every 400 hrs thereafter. 1/52 Every Week Filter change 1/365 Every day p Change engine oil every 50 hours. Oil change Level check General Remove the ignition key to prevent accidental...
  • Page 28: Engine Oil

    LUBRICATION Engine oil NOTE: Change the engine oil when the engine is warm. Refer to the engine owner’s manual for the correct replacement oil and filter change recommendations. WARNING! The engine drain plug is located close to the muffler. To prevent burns, the engine should be shut off and allowed to cool slightly so the engine is still warm but the Front Wheel Bearings...
  • Page 29 Transmission Purging LUBRICATION Due to the effects air has on efficiency in 4. After the oil has drained remove the filter from hydrostatic drive applications, it is critical to purge the housing. the system. 5. Install a new filter and gasket into the filter Perform the procedure first with the vehicle drive cover and install the assembly into the wheels off the ground, then repeated under...
  • Page 30: Troubleshooting

    TROUBLESHOOTING Problem / Cause Engine will not start Engine overheats Blade switch is engaged Clogged air intake or cooling fins Steering controls are not locked in the park Engine overloaded brake position Poor ventilation around engine Dead battery Defective engine speed regulator Contamination in the carburetor or fuel line Too little or no oil in the engine Fuel supply shutoff valve is closed or in the...
  • Page 31: Storage

    Handle the fuel with care. It is very purchase year, model, type, and serial number. flammable and can cause serious personal Always use genuine Husqvarna spare parts. injury and property damage. Drain the fuel An annual check-up at an authorized service...
  • Page 32: Schematic

    SCHEMATIC...
  • Page 33: Conformity

    CONFORMITY EC Declaration Of Conformity We, Husqvarna AB, SE 561 82 Huskvarna, SWEDEN, declare under our sole responsibility that the represented product: Description Combustion-engine-powered ride-on lawn mower with seated operator Brand Husqvarna Platform / Type / Model Z560X Batch Serial number dating 2017 and onwards...
  • Page 34: Technical Data

    2.5 cm - 12.7 cm Number of Blades Blade Length 53.34 cm Anti-scalp roller 4 adjustable Seat Husqvarna Commercial Suspension Hinged Arm Rests The power rating as declared Service Meter Digital by the engine manufacturer is the average gross power...
  • Page 35 TECHNICAL DATA DIMENSIONS Weight 594 kg Base Machine Length 210 cm Base Machine Height 127 cm Base Machine Width 138.4 cm Overall Width, Chute Up 162 cm Overall Width, Chute Down 188 cm Overall Height, ROPS up 183 cm VIBRATION AND SOUND Hand/Arm Vibration 1.27 m/s Whole Body Hand/Arm...
  • Page 36: Torque Specifications

    TECHNICAL DATA Torque Specifications Standard 1/4" fasteners 9 ft/lb Engine crankshaft bolt 50 ft/lb Standard 5/16" fasteners 18 ft/lb Deck pulley bolts 150 ft/lb Standard 3/8" fasteners 33 ft/lb Lug nuts 75 ft/lb Standard 7/16" fasteners 52 ft/lb Blade bolt 90 ft/lb Standard 1/2"...
  • Page 37: Service Journal

    SERVICE JOURNAL DELIVERY SERVICE Action Date, mtr reading, stamp, sign Charge and connect the battery Adjust the tire pressure of all wheels to 15 PSI (1 bar) Mount the steering controls in the normal position Connect the contact box to the cable for the seat’s safety switch Check that the right amount of oil is in the engine Adjust the position of the steering controls Fill with fuel and open the fuel shut off valve...
  • Page 38 SERVICE JOURNAL AFTER 10 HOURS Action Date, mtr reading, stamp, sign Change the engine oil Change the oil filter Inspect hydraulic hoses Inspect hydraulic belt Inspect hydraulic filter Check neutral position Check safety system Check seat belt Check ROPS Check fuel system for leaks Inspect safety guards and shields Check brake adjustment DAILY SERVICE...
  • Page 39 SERVICE JOURNAL 50-HOUR SERVICE Action Date, mtr reading, stamp, sign Clean debris from mower Check engine oil level Check the tire pressures Check underside of deck Inspect deck pulleys Check/clean the engine’s cooling air intake Check safety system Check seat belt Check ROPS Check fuel system for leaks Inspect safety guards and shields...
  • Page 40 SERVICE JOURNAL 250-HOUR SERVICE Action Date, mtr reading, stamp, sign Grease fittings (caster pivots and caster wheels) Inspect dampers Inspect frame Inspect throttle and choke cables Inspect hardware Check the tire pressures Change the engine oil and filter Change air filter Inspect spark plug Inspect fuel filter Check engine RPM...
  • Page 41 SERVICE JOURNAL 500-HOUR SERVICE Action Date, mtr reading, stamp, sign Grease fittings (caster pivots and caster wheels) Inspect dampers Inspect frame Inspect throttle and choke cables Inspect hardware Check the tire pressures Change the engine oil and filter Change air filter Inspect spark plug Inspect fuel filter Check engine RPM...
  • Page 42 SERVICE JOURNAL AT LEAST ONCE EACH YEAR Action Date, mtr reading, stamp, sign Clean the engine’s cooling air intake Replace the air cleaner’s foam pre-filter Replace the air filter’s paper cartridge Change the engine oil Replace the engine oil filter Check/adjust the cutting height Check/adjust the park brake Clean/Change the spark plugs...
  • Page 44 2017-12-15...
