Z-Extender
ZXT-300
(
Z-Wave-to-IR Extender)
Operating Instructions
Introduction
ZXT-300 works with any Z-Wave compliant controller or gateway
translating Z-Wave's Simple AV command to IR control code. User is
able to set the IR code and using the larger code library of ZXT-300. It
is capable to use the learning function of ZXT-300 through the simple
UI on gateway or Z-Wave remote controller. It is allow to download
the preset/learnt commands from gateway or Z-Wave remote controller
to ZXT-300. User can enjoy the fully wireless control in anywhere at
home.
Figure 1 ZXT-300
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Remotec Z-Extender ZXT-300
Summary of Contents for Remotec Z-Extender ZXT-300
- Page 1 Z-Extender ZXT-300 Z-Wave-to-IR Extender) Operating Instructions Introduction ZXT-300 works with any Z-Wave compliant controller or gateway translating Z-Wave’s Simple AV command to IR control code. User is able to set the IR code and using the larger code library of ZXT-300. It is capable to use the learning function of ZXT-300 through the simple UI on gateway or Z-Wave remote controller.
- Page 2 ZXT-300 Operations Before using the ZXT-300, please read the [INSTALLATION] if it is need to mount the ZXT-300 to a wall. Power up the ZXT-300 by the supplied AC/DC adaptor. CAUTION − Be sure to always use the supplied AC/DC adaptor. −...
- Page 3 Change Z-Wave-to-IR Channel (EP) on ZXT-300 LED Indication Status Step Setup Key on ZXT-300 • LED flashes 1 = EP1 Press and hold PROG button on the ZXT-300 for 3seconds to • LED flashes 2 = EP2 switch the EP (1->2->3->4- •...
-
Page 4: Installation
Do not mount the ZXT-300 so that it sticks out from the wall edge. It could get hit by people’s bodies or objects and cause an injury. • Remotec will not be liable for any accidents or injuries that occur due to improper mounting or handling. •... - Page 5 Note 2: No screws are provided for mounting to a wall. Note 3: Before mounting to a wall, be sure to fully read the precautions. Obtain two screws suitable for the wall strength and material. The screw size is shown in the figure below. The positional relationship between the ZXT-300 key holes and the screw mounting positions are shown in the figure below.
-
Page 6: Wireless Information
WIRELESS INFORMATION Wireless range: This device has an open air line of sight transmission distance of 100 feet which complies with the Z-Wave standards. Performance can vary depending on the amount of objects in between Z-Wave devices such as walls and furniture. Every Z-Wave device set up in your house will act as a signal repeater allowing devices to talk to each other and find alternate routes in the case of a reception dead spot. -
Page 7: Checking The Accessories
COMMAND_CLASS_MANUFACTURER_SPECIFIC COMMAND_CLASS_SIMPLE_AV_CONTROL, Multi Channel Command Class, version 2 Z-Wave protocol stack revision: Ver. 5.02 patch 3 CHECKING THE ACCESSORIES After opening the cover of the packing box, check that the following accessories are included. • ZXT-300: Z-Wave-to-IR Extender • Power adaptor: 100~240Vac input, 5Vdc 1000mA (for ZXT-300) •... - Page 8 - RISK OF FIRE - RISK OF ELECTRICAL SHOCK - RISK OF BURNS - The socket-outlet shall be installed near the equipment and shall be easily accessible. - Use only power supplies listed in the user instructions. www.remotec.com.hk Printed in China F820-8370-000...
