Mobeye CMVXI-R User Manual

Outdoor detector
Hide thumbs Also See for CMVXI-R:
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
®
Mobeye
Outdoor Detector
CMVXI-R
SW version 4.n

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CMVXI-R and is the answer not in the manual?

Questions and answers

Related Manuals for Mobeye CMVXI-R

Summary of Contents for Mobeye CMVXI-R

  • Page 1 USER MANUAL ® Mobeye Outdoor Detector CMVXI-R SW version 4.n...
  • Page 2 • Do not use in an environment where any inflammable gases, vapors or dust are present or could be present. ® • Repair of the device may only be carried out by people, trained for Mobeye repair. • If the device must be repaired, only original replacement components may be used. The ®...

  • Page 3: Table Of Contents

    Entry delay time Inactive time Automatic arming / disarming 4.10 Test message 4.11 System reset 5. Request list of the status, settings and signal strenght 6. Enrolment of new tags 7. Mobeye Internet Portal 8. Technical messages and status feedback...

  • Page 4: General Description

    - When a movement is detected, the Mobeye Outdoor Detector sends an alarm SMS text message and calls the phone numbers programmed in by the user. - When the batteries need to be replaced, the Mobeye Outdoor Detector sends a ‘low battery’ SMS text message to the first telephone number (administrator).

  • Page 5: Getting Started

    2. GETTING STARTED To get started with the Mobeye Outdoor Detector, at least the following steps need to be taken in the following order: 1. Open the Outdoor Detector 2. Insert a SIM card 3. Insert the batteries 4. Enter the program mode 5.

  • Page 6: Insert The Batteries

    The Mobeye Outdoor Detector returns to the program mode by holding the tag to the tag reader for 5 seconds (make sure the tag connects to the metal plate and the ring at the same time), until the LED starts flashing red/green.

  • Page 7: Switching On/Off

    4.1. 2.6 SWITCHING ON/OFF After the previous steps, the Mobeye Outdoor Detector is ready for use. In order to switch on (arm) the Mobeye Outdoor Detector: - Hold a tag briefly against the tag reader, after which the exit indication starts. The exit time takes 120 seconds;...

  • Page 8: Configuration

    GSM module. In this way the program mode is cancelled. 3.2 THE (SECURITY) CODE For configuration activities the (security) code of the Mobeye Outdoor Detector must be used. The initial (security) code is ‘1111’. You can change the (security) code to...

  • Page 9: Programming The Settings By Sms

    3.3 PROGRAMMING THE SETTINGS BY SMS To program the settings by SMS text message: 1. Make sure the Outdoor Detector is in program mode (please refer to 3.1). 2. Send an SMS text message with the (security) code and the command. 3.

  • Page 10: List Of Sms Commands For Configuration

    0000···9999 1111 Set telephone number for TEL1: Empty alarm messages TEL5: Delete telephone number DEL1 DEL5 Identification text NAME: 20 characters Mobeye Call on/off CALL: ON, OFF SMS on/off SMS: ON, OFF Exit delay DELAYEXIT: 0···999 (sec) Entry delay DELAYENTRY: 0···999 (sec)
  • Page 11 Examples: Set phone number 1: 1111 TEL1:0712345678 Delete phone number 1: 1111 del1 Be aware of the space between “1111” and the command.

  • Page 12: Possible Settings

    4. POSSIBLE SETTINGS 4.1 PHONE NUMBERS The Mobeye Outdoor Detector is able to send alarm messages to up to 5 phone numbers. The first telephone number (TEL1) belongs to the administrator. Only this number receives all system messages. The other phone numbers (including the administrator) only get the alarm messages.

  • Page 13: Alarm Texts

    4.3 ALARM TEXTS A unique alarm text can be programmed into the Mobeye Outdoor Detector. The user defined text has a maximum length of 20 characters. The default text for the alarm text is Alarm. SMS command text alarm: TEXT1:...

  • Page 14: Entry Delay Time

    1111 INACTIVEIN1:45 4.9 AUTOMATIC ARMING / DISARMING The Mobeye Outdoor Detector only works if the unit is armed by the tag. It is also possible to automatically arm and disarm the unit, based on time schemes. Two schemes can be entered, which can be assigned to the days in the week (e.g. to have a different weekend scheme).
  • Page 15 To set the actual date: SMS command actual date: DATE: To set the actual time: SMS command actual time: TIME: To set a daily arming scheme: SMS command arming scheme 1: TIMEARM1: To set a daily disarming scheme: SMS command disarming scheme 1: TIMEDISARM1: To set a second daily arming scheme: SMS command arming scheme 2:...

  • Page 16: Test Message

    4.10 TEST MESSAGE The Mobeye Outdoor Detector can send regular test SMS messages (keep alive) to the administrator (first phone number), to ensure the proper functioning of the unit. The test message function is only active if the unit is armed.

  • Page 17: Request List Of The Status, Settings And Signal Strenght

    5. REQUEST LIST OF THE STATUS, SETTINGS AND SIGNAL STRENGHT Several lists and status reports can be retrieved by sending an SMS text message to the Mobeye Outdoor Detector, from any telephone. Before sending the request, make sure the unit is in the program mode (please refer to 3.1).

  • Page 18: Enrolment Of New Tags

    The detector leaves the enrolment mode if no tag was hold against the tag reader for 15 seconds. In total 25 tags can be enrolled to the CMVXI-R. The same tags will function in combination with other CMVXI-R Outdoor Alarm systems, which makes it possible to...

  • Page 19: Mobeye Internet Portal

    7. MOBEYE INTERNET PORTAL The Mobeye Outdoor Detector sends GSM messages to the preset contact persons. It is also possible to connect the system to the Mobeye Internet Portal. In this secured internet environment the Mobeye Outdoor Detector system(s) can be administered.

  • Page 20: Technical Messages And Status Feedback

    8. TECHNICAL MESSAGES AND STATUS FEEDBACK Technical messages In the event of technical issues the administrator receives an SMS message. Possible technical messages are: Message Reason Low batteries, external power Power is available, batteries need to be replaced. supply OK No external power supply, No external power supply, batteries are able to batteries OK...
  • Page 21 Status feedback LED pattern Status Required action Blinking green, 1 second Module not configured Configure at least one on / 1 second off telephone number. 1 green flash every 3 Module is switched on, No action required. seconds powered by batteries Green LED stays on Module is switched on, No action required.
  • Page 22 Publisher. Reprinting, even in summary, is prohibited. This user manual meets the technical requirements at the moment of printing. Changes in technology and equipment are reserved. © Copyright 2017 by Mobeye, version CM-VXI-EN171101...
