Specifications - Lexicon DD-8+ Owner's Manual

APPENDIX

Specifications

Output Power:
Frequency Response:
Total Harmonic Distortion (THD):
Signal-to-Noise Ratio:
Crosstalk:
Input Sensitivity:
Gain:
Input Impedance (analog):
Trigger Input:
Dimensions (H x W x D):
Weight:
Power Requirements:
Mode
Standby Mode
Idle
Typical
Maximum
* Typical usage is considered to be 1/8th power (pink noise) on all channels into the rated load (8 ohms).
Part No. 070-90057 Rev. 2.0
30
125W RMS per channel into 8 ohms from 20Hz – 20kHz
20Hz - 20kHz +0.2dB/–1.5dB
<0.02%, 1kHz (at full rated power)
<0.1%, 20Hz-20kHz (at full rated power)
< –105dB below rated full power A-weighted
< –70dB @ 1kHz
1.12 volts for 125W out into 8 ohms
29dB
100K ohms typical
5V minimum – 15V maximum DC
2.1" (w/ feet) / 1.7" (w/out feet) x 17.3" x 14.9"
5.4 cm (w/ feet) / 4.5cm (w/out feet) x 43.8 cm x 37.8 cm
9.2 lbs (4.2 kg)
100 - 240VAC
50/60Hz
Power Consumption (W)
<0.5
<35
<200
1000
DD-8+ Power
Heat Output (BTU/hr)
<2
<120
<260
680
Owner's Manual
