Network - QoS (Quality of service)

Quality of Service (QoS) provides the means to guarantee a certain level of a specified
resource to selected traffic on a network. Quality can be defined as e.g. a maintained level
of bandwidth, low latency, no packet losses, etc. The main benefits of a QoS-aware
network can be summarized as:
• The ability to prioritize traffic and thus allow critical flows to be served before
flows with lesser priority.
• Greater reliability in the network, thanks to the control of the amount of band-
width an application may use, and thus control over bandwidth races between
applications.
The QoS in Axis network video products marks the data packets for various types of
network traffic originating from the product. This makes it possible for network routers
and switches to e.g. reserve a fixed amount of bandwidth for these types of traffic. The
following types of traffic are marked:
• live video
• live audio
• event/alarm traffic
• management network traffic.
QoS Settings
For each type of network traffic supported by your Axis network video product, enter a
DSCP (Differentiated Services Codepoint) value. This value is used to mark the traffic's IP
header. When the marked traffic reaches a network router or switch, the DSCP value in the
IP header tells the router or switch which type of treatment to apply to this type of traffic,
for example, how much bandwidth to reserve for it.
Note that DSCP values can be entered in decimal or hex form, but saved values are always
shown in decimal.
For more infomation on Quality of Service, please see the Axis support web at
www.axis.com/techsup

SMTP (email)

(Simple Mail Transfer Protocol) Enter the host names or addresses for your primary and
secondary mail servers in the fields provided to enable event and error email messages
from the AXIS 231D+/232D+ to predefined addresses, via SMTP.
