Panasonic KX-NT553/556 Telephone
Quick Reference Guide
1. LCD SCREEN
2. MESSAGE LAMP: When you have a message it will light up the lamp red
3. FLEXIBLE CO BUTTONS: Used to access a line or perform a programmed function
4. HANDSET HOOK: Keeps the handset stable when the phone is mounted on the wall
5. HEADSET JACK: Jack to plug in a headset
6. PAUSE: Used to insert a pause when storing a number
7. CONF: Used to establish a multiple party conversation
8. MESSAGE: Used to leave a message waiting indication or call back the party who left the
message waiting indication
9. FLASH/RECALL: Used to disconnect the current call and make another call immediately
10. REDIAL: Used to redial the last dialed number
11. AUTO ANS / MUTE: Used to receive an incoming call in hands-free mode or mute
12. TRANSFER: Used to transfer a call to another party
13. AUTO DIAL/STORE: Used for System/Personal Speed Dialing or program changes
14. HOLD: Used to place a call on hold
15. INTERCOM: Used to make or receive intercom calls
16. SP-PHONE (Speakerphone): Used for performing hands-free operations
17. MICROPHONE: Used for hands-free conversations
18. NAVIGATOR KEY: Used to adjust the volume or display contrast or select desired items
19. ENTER: Used to assign the selected item
20. SOFT BUTTONS: S1-S4 are used to select the item displayed on the bottom line of the display
21. EHS (Electronic Hook Switch) JACK:
22. FWD/DND: Used to switch Call Forwarding or Do Not Disturb on your extension
23. CANCEL: Used to cancel the selected item
24. NEXT PAGE: Used to switch the page for the Self Labeling feature
25. SUB LCD: 12 lines
Answer a Call
 To answer a call, pick up the handset or press the speaker button
 Press the flexible CO button for the incoming call
 To turn on Auto Answer, press the AUTO ANS button and incoming calls will be answered
automatically in hands free mode
Make a Call
 To call an extension, pick up the handset or press the speaker button and dial the extension
 To make an outside call, pick up the handset, press LINE and dial 9 then the phone number
 To set a callback for a call not answered, press the MESSAGE button
 The dial tone for that extension will sound different to indicate that there is a call back
request.
 To call back the person who left the callback, press the MESSAGE button
Put a Call on Hold
 While on the call, press HOLD
 Press flashing line of the held call to retrieve it
Unity Connected Solutions – Panasonic KX-NT553/556 Telephone
Page 1

Advertisement

Table of Contents

   Related Manuals for Panasonic KX-NT553

   Summary of Contents for Panasonic KX-NT553

  • Page 1 24. NEXT PAGE: Used to switch the page for the Self Labeling feature Put a Call on Hold 25. SUB LCD: 12 lines  While on the call, press HOLD  Press flashing line of the held call to retrieve it Page 1 Unity Connected Solutions – Panasonic KX-NT553/556 Telephone...
  • Page 2  To save an outgoing call log entry to your Personal Directory, find the number and press STORE  Enter the name and press AUTO DIAL  Enter the speed dial number (01-09)  Press AUTO DIAL to complete and then press FLASH/RECALL to exit the menu Page 2 Unity Connected Solutions – Panasonic KX-NT553/556 Telephone...
  • Page 3  Enter the mailbox number and press 2 to accept  Press 1 to record a message and after recording press 1  Press 2 to accept and press 2 again to accept and delivery message Page 3 Unity Connected Solutions – Panasonic KX-NT553/556 Telephone...
