10
receiver as well as an additional battery placed at the back
of the docking station.
When two batteries are charged simultaneously, fast
charging (< 4 hours) is for the battery in the receiver and
slow charging (about 11 hours) for the spare battery
located at the back of the docking station.
Charging for the spare battery switches to fast charging
once the receiver battery is fully charged or the receiver is
removed from the docking station.
• As an interface with a computer for office work, using a
serial data line and Microsoft ActiveSync.
Top View
The top view of the docking station shows the slot [19] in
which to insert the receiver from above the docking station.
At the bottom of the slot is the 16-contact connector [20].
When resting on the docking station, the receiver is
automatically powered from the AC adapter (if connected)
and the charging status of its internal battery tested.
[19]
[20]
