INSTALLATION MANUAL FOR 230Vac OPERATORS MERCURIO SERIES
MT/404
MT/604
MT/804
Thank you for choosing a SERAI ELETTRONICA product, which we are confident will perform to your requirements. Please be
advised that you are about to install a device part of a "system for the motorization of gates and doors in commercial or
residential buildings, accessed by vehicles", which must be considered potentially hazardous. By law you, as the Installer, are
obliged to take all the actions necessary to guarantee the safety of the users of the installation.
Installation and maintenance of this system must therefore be carried out exclusively by qualified, skilled and trained personnel,
following state-of-the-art rules, according to the law requirements. The law prohibits both the implementation of this type of
installations and their maintenance to unqualified personnel.
Product category and intended use:
Reference Directives:
Low voltage (LVD):
Electromagnetic compatibility (EMC):
Restriction of hazardous substances (RoHS):
Generic reference standards:
Household and similar electrical appliances - safety - part 1:
generic standards:
Electromagnetic compatibility - immunity - part 2:
generic standard for industrial environments:
Electromagnetic compatibility - emission - part 3:
generic standard for commercial, residential and light industrial environments:
Product-specific reference standards:
Household and similar electrical appliances - safety - part 2:
particular requirements for the motorization of gates, doors and windows:
The installer is advised that the system he is going to install, whose operator MT/x04 is a component, will have to accomplish
also with the following directives and standards:
Machinery directive:
Industrial, commercial and garage doors and gates:
safety in use of power operated doors - requirements:
Industrial, commercial and garage doors and gates:
safety in use of power operated doors - test methods:
Industrial, commercial and garage doors and gates - product standard - part 1:
products without fire resistance or smoke control characteristics:
ATTENTION!
SERAI products are designed to allow the realisation of installations in accordance with the aforementioned
standards. Compliance with these legal prescriptions is extremely important, because you, as the Installer,
are responsible of the installation and of its safe functioning.
IMPORTANT:
This manual must be read in its entirety before proceeding with the installation of the various
components of the system.
MT/x04 V01 P08 20140612
2
A4VL 40g/m
- IS MT/x04-E
FOR THE AUTOMATION OF SLIDING GATES UP TO 400Kg
32.43
FOR THE AUTOMATION OF SLIDING GATES UP TO 600Kg
32.63
FOR THE AUTOMATION OF SLIDING GATES UP TO 800Kg
32.83
operator for the motorization of gates and doors up to 400-600-800Kg for vehicular
access, in commercial, residential and light industrial environments.
2006/95/CE
2004/108/CE
2011/65/UE
EN60335-1: 2013
EN61000-6-2: 2006
EN61000-6-3: 2007
EN60335-2-103: 2005
2006/42/CE
EN12453: 2002
EN12445: 2002
EN13241-1: 2011
Advertisement
Table of Contents
Related Manuals for Serai MT/604
Summary of Contents for Serai MT/604
- Page 1 32.83 Thank you for choosing a SERAI ELETTRONICA product, which we are confident will perform to your requirements. Please be advised that you are about to install a device part of a "system for the motorization of gates and doors in commercial or residential buildings, accessed by vehicles", which must be considered potentially hazardous.
- Page 2 OPERATOR TECHNICAL DATA MT/404 MT/604 MT/804 Operator characteristic irreversible Leaf max. weight up to 400Kg up to 600Kg up to 800Kg Operator supply voltage 230Vac ± 10% 50/60Hz Capacitor 10µF 14µF 14µF Max. absorbed current 2.1A 2.4A 2.8A Absorbed power...
-
Page 3: Before Starting
INSTALLATION OF THE OPERATOR BEFORE STARTING • Verify that the gate is equipped with a strong and solid support guide. • Verify that the rail is securely anchored to the ground. • Install 2 robust leaf mechanic stops and fix them strongly at the 2 ends of the rail. •... -
Page 4: Positioning The Operator
OPENING THE OPERATOR UNIT • Remove the fastening screws at both the sides of the unit. • Remove the operator plastic cover. • Remove the operator plastic band from the lower part of the unit. POSITIONING THE OPERATOR • Insert the 4 grub screws into their respective places and screw them with an hex key. - Page 5 INSTALLATION OF THE TOOTH RACK ATTENTION! Regulate the operator horizontal positioning so that the pinion matches the tooth rack for the entire width of the tooth. • Place the tooth rack so that, moving manually the leaf all along the rail, the distance between the pinion and the tooth rack is constantly at ~2mm.
- Page 6 INSTALLATION OF THE END STOP SLIDING PLATES A - POSITIONING ATTENTION! For safety reasons install leaf mechanic stops both opening closing movements. • Move manually the leaf along the rail up to 5cm from the closing position. • Position the closing sliding plate over the tooth rack starting from the opening side of the leaf, and make it slide towards the closing position until it operates the closing limit switch through the actuator spring: you'll hear a "click".
- Page 7 MT/404, MT/604, MT/804 CABLES DESCRIPTION CONNECTING OPERATOR AND OTHER DEVICES TO THE STANDARD CR/62 CONTROL UNIT...
-
Page 8: Troubleshooting Guide
To obtain the maximum radio coverage, disconnect the antenna inside the controls External antenna needed. flashing light and replace it with the optional external antenna OG/50 (SERAI reduced. code 25.50).
